Condition: good (used), Year of construction: 2017, functionality: unexamined, We offer this well-maintained Förster Welding Systems 4225 railing welding fixture, year 2017. Manufacturer: Förster Welding Systems Model: 4225 Year of manufacture: 2017 Condition: good Bdsdpfjy N A U Ajx Ambsd Category ID: 96 Type ID: 2257 Machine type: railing welding fixture If you have any questions or need more information, feel free to send us a message or call us.

Condition: ready for operation (used), Year of construction: 2021, A barely used allround PCB handling station RG Elektro-Technologie for loading purposes is available. Application possibility: before AOI/after AOI/combined, PCB transport height range: 930mm-970mm, min. PCB dimensions X/Y: 80mm/50mm, max. magazine dimensions X/Y/Z: 360mm/360mm/570mm, machine dimensions X/Y/Z: approx. 1200mm/1700mm/1800mm, weight: approx. 250kg, control: Siemens S7-1200. Documentation available. An on-site inspection is possible. The image is an example. Bdjdpoy Ndf Nofx Ambod

Condition: used, Year of construction: 2006, machine/vehicle number: OTW, Schmalz vacuum lifter with a load capacity of 125 kg Dimensions: 180x80 cm, suction pads are fully adjustable. These are porous and should be replaced. 4 suction pads, each with a diameter of 140 mm Connection: 400V 16A Good condition, see pictures Item location: 75053 Gondelsheim Bsdpfx Amoy Hf Itjbedd Shipment via freight carrier or collection by appointment only

Condition: used, Year of construction: 2020, functionality: fully functional, machine/vehicle number: WT 1104, total height: 3,421 mm, total width: 4,704 mm, total length: 9,550 mm, load capacity: 200 kg, construction height: 3,421 mm, Vacuum Turning Portal for Panels The turning unit offers two different "automatic" operating modes: I. Component is conveyed without rotation The component is only shifted laterally, aligned to the reference edge (zero line) of the machining center, and then fed further to the CNC machining center (BAZ). II. Component is conveyed with rotation The component is shifted laterally and rotated along its longitudinal axis before being fed further to the CNC machining center. Each function can also be manually controlled in "manual" mode. SPECIFICATIONS: Max. panel dimensions: LWH: 8000mm x 2500mm x 100mm Max. weight: 200kg Min. panel dimensions: LWH: 1500mm x 1500mm x 12mm The turning portal is equipped with a total of 24 vacuum suction cups, ensuring gentle handling of the panels. The panels are always lifted via suction, then either moved horizontally to the zero line of the machining center or additionally rotated 180° en route before being delivered to the reference edge. The rotational movement is monitored via absolute encoders; the lateral positioning is controlled by adjustable photoelectric sensors. Vacuum is generated by a blower. The roller table, measuring 8500 mm x 4300 mm with roller diameter 108 mm, is fitted with material-friendly rubber rings and is driven by a SEW gear motor. Control of the roller table is via frequency inverter, adjustable speed up to 45 m/min. GENERAL INFORMATION: The entire area is enclosed by fencing; the longitudinal side of the system is secured by two sliding doors, which are safety-monitored. An operator touchpanel (12") is integrated into the fence area. The installed PLC (Siemens S7-1500) is programmed with three modes: • Automatic operation • Manual operation • Maintenance operation Input signals, loading side: – Start roller table – Rotate yes/no – EMERGENCY STOP complete system Input signals, unloading side: – Start roller table – EMERGENCY STOP complete system Bdodpfx Ajyta R Usmbsd System output signals: – EMERGENCY STOP complete system – Panel infeed confirmed

Condition: like new (used), arm lifting capacity 120 kg, length 370 + 240 cm Bedpjynhz Defx Ambjdd air suction cup lifting capacity 120 kg MANUT Siemens pump motor power 3 kW base length 365 cm

Condition: like new (used), Arm lifting capacity 120 kg, length 600 cm Vacuum suction cup, lifting capacity 120 kg MANUT, year 2006 Siemens pump motor power 3 kW Base length 365 cm Bjdpfeynhvnsx Ambsdd

Condition: used, machine/vehicle number: Nr. 84064. Nr. 86016 Nr. 82013, 3 winding machines, 4-fold flyer Winding diameter: 40 mm, laying width: 150 mm Max. wire diameter: 1.0 mm Bdodpfxeylzurs Ambod HKW 2/7 no. 82013, 4-fold reversing bar Tool EI 84/20/5

Condition: used, machine/vehicle number: 85252. und 85122, Coil winding machine Aumann WG 85253 Winding diameter 160 mm, laying width 550 mm Wire guide DF 50 No. 85099 defective Coil winding machine Aumann PW 85122 Bjdsylztujpfx Ambedd Winding diameter 100 mm, laying width 200 mm Wire guide DF 70 No. 85115

Condition: used, machine/vehicle number: 423. 1245102, 4-strand flyer with reversing beam Wire diameter: 0.05 to 1.0 mm 2-strand flyer with reversing beam Winding diameter: 90 mm, traverse width: 120 mm Max. wire diameter: 1.0 mm Bdsdpfx Amjylzlkobjd

Condition: used, We offer for sale manipulators (new) as well as used single axes, accessories, and wiring. Delivery term: EXW Trstena Bdjdpeyc Rv Tofx Ambed Minimum order value: €5,000

Condition: used, Year of construction: 2017, Manufacturer: Manut LM Model : MAN Year: 2017 Bdjdpfx Aox R A Nvombed Body type : Vacuum Tube Manipulator Application : Handling of bags and boxes Maximum load : 30 kg Classification: ATEX Vacuum pump : Becker SV 8 400/2 Dimensions : see photo drawing.

Condition: excellent (used), Year of construction: 2024, functionality: fully functional, machine/vehicle number: 332113-01-01, overall weight: 172 kg, maximum load weight: 70 kg, Equipment: CE marking, Manipulator for furniture racks. Device facilitating the lifting of finished cabinet furniture components. Bdsdpfxsxz Dw To Ambed

Condition: used, Year of construction: 2000, Vacuum lifter from Schmalz Year of manufacture: 2000 Lifting capacity: 500 kgm The lifting device has been stored in working condition but is no longer needed. Bedpsxxv Eqofx Ambedd Only the vacuum lifter is offered, without the other items shown in the pictures (e.g., tires, pallets, roll containers, metal buckets, etc.). Collection in Bremen. _____ Our general terms and conditions apply. The seller is not liable for typographical or data transmission errors. The appearance of the offered items corresponds to their age and the images shown. The technology and wear of the offered items are consistent with their age. Used machines are sold exclusively to businesses and without any warranty.

Condition: like new (used), Year of construction: 2017, operating hours: 20 h, functionality: fully functional, machine/vehicle number: 1750851, load capacity: 100 kg, Dalmec manipulator with vacuum generator and column. Removed from an unused production line, in perfect condition. Tested, fully functional, practically new. Bjdpfx Aexxbczombjdd Working range: 2,530 mm Vertical lift: approx. 1,700 mm Load capacity: max. 100 kg Manipulator weight: 450 kg + column Our company can arrange professional transport and commissioning if required. Please feel free to call us for more details. (English is preferred). The indicated price is for 1 unit. (2 units available).

Condition: new, Year of construction: 2025, This handling device is suitable for safely and stably handling large-area materials with just one operator. The device can be provided as an independent unit to any machine. The price-performance ratio is impressive, as the payback period is less than one year. Comprises the following main components (also available individually): Bdsdpfx Amsw Nh Dzobed • Column stand • Pivot arm • Lifting traverse with controls Technical data VT 1000: Lifting capacity: 1000 kg Max. lifting height: 1295 mm Lifting speed: 4 and 8 m/min Max. rotation radius: 3900 mm Power supply: 400 V / 50 Hz Max. product dimensions: 4000 x 2000 mm² (weight dependent) Overall height: 2990 mm Total weight: 1350 kg Alternatively, we also offer this handling device with a lifting capacity of 500 kg.

Condition: excellent (used), Year of construction: 2022, operating hours: 1,619 h, functionality: fully functional, machine/vehicle number: PEC 50 2158273, total height: 3,000 mm, total width: 1,000 mm, total length: 1,000 mm, type of input current: three-phase, input voltage: 400 V, Arm-mounted manipulator with a gripper for cylindrical parts. Bdedpfx Amsw Hwq Tebed

Condition: good (used), overall weight: 280 kg, FANUC positioner. manufactured in 2012. tested and serviced. collection only Bdodpfx Ajwzk Syjmbsd

Condition: ready for operation (used), Year of construction: 2019, A conveyor belt is available for buffering and transferring PCBs between processing systems. Transport height: 870mm-970mm, max. transport width: 460mm, min. PCB dimensions X/Y: 70mm/50mm, max. PCB dimensions X/Y: 460mm/460mm, PCB thickness: 0.5mm-4.5mm, max. PCB weight: 3kg. Machine dimensions X/Y/Z: approx. 1590mm/800mm/925mm, weight: approx. 170kg. Documentation available. On-site inspection is possible. Bsdpfxewwvvvs Ambedd

Condition: excellent (used), Year of construction: 2005, Year of manufacture: 2005 Mounting: Ceiling Ceiling guide length: approx. 15 meters Availability: 2 units Load capacity: Manipulator 1 – 30 kg Manipulator 2 – 35 kg Number of axes: 4 Bodpfxjwvi Upe Ambjdd Gripper: Pneumatic parts gripper (per manipulator) For suspension on the rail

Condition: ready for operation (used), A DMG Automation robot automation cell is available. Interior dimensions X/Y: approx. 700mm/1050mm, max. workpiece weight: 10kg, max. workpiece dimensions X/Y: 150mm/120mm, positioning accuracy: +/-0.1mm, robot axes: 6, robot controller: Kuka KR C 2. Documentation available. On-site inspection is possible. Bsdpfx Amjwixzxjbedd

Condition: ready for operation (used), Year of construction: 2018, A Nutek PCB turning station with pneumatic lifting and turning mechanism for the semiconductor industry is available. Transfer height: 950mm, transfer height adjustment: +/-25mm, belt speed range: 2m-14m/min, PCB edge support: 3mm, component clearance (bypass mode) top/bottom: 30mm/30mm, PCB length range: 80mm-460mm, PCB width range: 75mm-460mm, machine dimensions X/Y/Z: approx. 1000mm/900mm/1100mm, weight: approx. 150kg. Documentation available. On-site inspection is possible. Bedpfx Aowhfnpsmbodd

Condition: ready for operation (used), Year of construction: 2007, A PCB destacker (PCB feeder) for the semiconductor industry is available. Transfer height: 950mm, transfer height adjustment: +/-25mm, belt speed: 12m/min, PCB edge support: 3mm, component clearance (bypass mode) top/bottom: 30mm/30mm, PCB thickness range: 0.6mm-4mm, PCB length range: 80mm-460mm, PCB width range: 75mm-460mm, max. PCB stacking height: 220mm, machine dimensions X/Y/Z: approx. 700mm/1000mm/1300mm, weight: approx. 200kg. Documentation available. On-site inspection is possible. Bodswhfnijpfx Ambedd

Condition: like new (used), Year of construction: 2022, operating hours: 5 h, functionality: fully functional, machine/vehicle number: 2260081, load capacity: 400 kg, Hello, I have this fully pneumatic DELMEC remote arm, which can lift and move up to 400 kg with one hand. The machine has been used very little; it's a showroom model. The machine is complete and in perfect working order. It can be sold as is, delivered, and even installed (to be determined together). Bedpfswcpl Usx Ambedd

Condition: new, Year of construction: 2025, functionality: fully functional, machine/vehicle number: KAP1, air demand: 16,000 m³/h, power: 36 kW (48.95 HP), suction capacity: 16,000 m³/h, Equipment: cabin, Dielectric automatic powder booth KAP1 Price: PLN 492,693.30 + VAT Electrical and energy data • Voltage: 400 V (3P + N + PE) • Power connection: 36.34 kW • Pneumatic connection: 1" • Air pressure: min. 6 bar • Air quality: oil < 0.1 mg/m³, water vapor < 1.3 g/m³ • Air consumption: 1710 Nl/min (operation) • Compressor: SC-30 • Air tank: 1800 L Painting parameters • Painting speed: 1933 mm/min • Part dimensions: 800 x 1800 mm • Hanger height: 500 mm Bsdpfx Aev Rpx Sombjdd • Coating thickness: 100 µM • Gun array: vertical Technical data and configuration • Design: dielectric plastic • Passage dimensions: 1000 x 2400 mm • Air flow: 12348–16000 m³/h • Powder center: ProfiCenter CP02 • Manipulators: 2 pcs. • Guns: 8 automatic, 2 manual (ProfiSpray) • Part detection: yes (height, width) • Systems: cyclone separator, ProfiControl, beam pulling • ATEX: zone 22, II 3D Platforms and cabin body • Platforms: entry, exit, stainless steel floor, anti-slip stairs • Housing: dielectric plastic, LED lighting, slots for manipulators Air knives and suction channel • Automatic floor cleaning • Suction channel with pneumatic flap Gun blow-off and control • Automatic blow-off guns • 10" touch panel, 50 programs, manipulator control, dust extractor, drive speed X-axis and part pulling system • Automatic gun setting • Part pulling: speed 570–2830 mm/min, 2 pullers The machine also includes: • ProfiSpray A applicator • PSS-1 controller • PM-1 guns • ProfiCenter CP-02 powder center • CK-D1400L cyclone dust extractor • MA1-180 manipulator and MX1-10 X-axis • OZ-12H dust extractor • ProfiControl 10" control • BP-H2000 W900 part measuring system

Condition: good (used), Year of construction: 2009, Stäubli t TX90 L with Controller CS8C. (2009) Number of axis: 6 Bdodpfxev Hdk Ij Ambjd Payload: 5 kg
