Condition: ready for operation (used), chuck outer diameter: 1,200 mm, controller model: E.C.S CNC 1400, Carnaghi - Ø1400 mm CNC Max turningdia -- passage: 1400 mm Max hight of workpiece Z-axis: 1000 mm TOOLING: yes Turret: yes Qty Tools: 7 Fgsdjxl Hx Ispfx Afpsh Coolant pump: yes

Condition: ready for operation (used), chuck outer diameter: 1,600 mm, controller model: E.C.S CNC 2600, Carnaghi Ø 1700 mm CNC Max turningdia -- passage: 1700 mm Max hight of workpiece Z-axis: 1000 mm Turret: yes Qty Tools: 7 Coolant pump: yes Fsdoxl Hxzepfx Afpogh

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, Vertical Turning Lathe – WEBSTER & BENNETT R48R 2PB C-axis, driven tools Condition: Used Year of manufacture: 2006 CNC: Siemens 840D Powerline Technical Specifications Faceplate diameter: 1,200 mm Turning diameter: 1,200 mm Number of slides (ram): 1 Ram stroke: 1,200 mm Ram cross-section: 200 × 200 mm Max. workpiece height under crossbeam: 1,200 mm X-axis travel: 1,200 mm C-axis: available (C-Axis) Drives / Speeds Fgedpfjxl E R Nox Afpeh Main spindle motor: 37 kW Main spindle speed: 0.2 – 430 rpm Milling spindle motor: 17 kW Milling spindle speed: 20 – 3,000 rpm Tool changer Turning: 50 positions, Capto C6, robot handling Milling: 10 positions, ISO 50, robot handling Other features Magazine and stations for turret/tool holders Machine weight: approx. 18 t Scope of delivery as described above only. Further options/accessories only as per written agreement.

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, machine/vehicle number: YVX160TCO4876A, workpiece weight (max.): 8,000 kg, spindle motor power: 45,000 W, total length: 5,500 mm, total height: 5,400 mm, total width: 5,500 mm, type of input current: AC, input voltage: 380 V, workpiece diameter (max.): 2,000 mm, overall weight: 25,000 kg, workpiece height (max.): 1,200 mm, nominal power (apparent): 65 kVA, number of spindles: 2, rotary table diameter: 1,600 mm, number of slots in tool magazine: 16, Equipment: chip conveyor, documentation/manual, The YV-1600-ATC+C vertical turning centre is a large, high precision and heavy duty machine. The rigid vertical column and base are meehanite castings, heavily ribbed for reduced thermal distortion and vibration damping. It is built for heavy duty turning of large size workpieces. The machine has live spindle and 16 tools ATC. Fgedpfxsxl Avcj Afpsh Machine can be dismounted and loaded on truck by use of overhead crane.

Condition: excellent (used), Year of construction: 2009, operating hours: 67,343 h, functionality: fully functional, All data will be provided upon request regarding this listing. The machine is dirty. Up until July, the machine delivered top tolerances at MAGNA POWERTRAIN and is otherwise in fully functional condition. Fedpfx Afsxl Ah Sspegh

Condition: ready for operation (used), Year of construction: 2016, operating hours: 18,071 h, General Data Machine weight 6000 kg Main Drive Number of axis 3 Fgodpfx Ajxlvc Nefpjh Media Main electronic connection 40 kVA Additional Equipment shopturn option This 3-axis DMG MORI Gildemeister CTV 250 2nd was manufactured in 2016. Ideal for precision vertical turning, this machine maintains robust construction and reliability. If you are looking to get high-quality turning capabilities, consider the DMG MORI Gildemeister CTV 250 2nd machine we have for sale. Contact us for more information. Application Types Turning

Condition: ready for operation (used), Year of construction: 2005, General Data Machine weight 18000 kg Control Unit Brand FANUC Model FANUC 18I TB Main Drive Spindle speed range 2000 RPM Spindle motor power 30 kW Tool taper ASA A2-11 Number of axis 2 Movement X-Axis Movement 380 mm X-Axis Rapid Traverse 20 m/min Z-Axis Movement 760 mm Z-Axis Rapid Traverse 20 m/min Turret Number of turrets 1 Additional Equipment Holders for External Turning: HO10-25RL (4 pcs) Holders for Face Turning: HF10-25RL (2 pcs) Fedpfxexirkqo Afpjgh Holders for Internal Turning: HB10-50N (4 pcs), HB10-40N (2 pcs) Reduction Sleeves: BS 40-10, -12, -16, -20, -25 (2 sets) This DOOSAN V740T vertical turning machine was manufactured in 2005. It features a maximum swing diameter of 800 mm, turning diameter of 740 mm, and a turning length of 760 mm. The main spindle supports a rotational speed up to 2000 RPM with a motor power of 30 kW. It includes a 12-position turret and rapid traverse rates of 20 m/min for both X and Z axes. If you are looking to get high quality turning capabilities consider the DOOSAN V740T machine we have for sale. Contact us for further details regarding this machine. Application Types Turning

Condition: good (used), Year of construction: 2004, Table diameter: 1220 mm Max. turning diameter: 1500 mm Table speed range: 4.5 to 100 rpm Feed range: 0.127 mm to 6.35 mm per revolution Maximum height under crossrail: 900/1200 mm Slide travel (X-axis): 1000 mm Main drive motor: 41 kW Tool changer: 30 positions Accessories: - 8 clamping jaws - 30 tool holders with full enclosure Fedpfx Afoxg Nmkjpegh - Oil mist extraction

Condition: ready for operation (used), chuck outer diameter: 2,000 mm, empty load weight: 35,000 kg, Rafamet KCF 200 verticale draaibank De Rafamet is een robuuste draaibank met de volgende capaciteiten: * max. afmetingen werkstuk: - Hoogte: 1.690 mm - Ø werkstuk: 2.400 mm Dit type machine is ideaal voor ombouw naar CNC! Max turningdia -- passage: 2.400 mm Power on the spindle: 55 kW Fgjdpfx Afjxgv R Aspsh Max hight of workpiece Z-axis: 1.690 mm (Z= 1.000 mm) Digital screen: Yes

Condition: ready for operation (used), total height: 3,600 mm, empty load weight: 22,000 kg, Schiess Ø 2070 x H 1330 mm Chuck dia.: Ø 1700 mm Fgedpsxgv R Nofx Afpjh Max turningdia -- passage: Ø 2070 mm - H 1330 mm Power on the spindle: 30 kW Max hight of workpiece Z-axis: 1330 mm (Z: 1000mm) Number of speeds: 1.7 -> 53 rpm

Condition: ready for operation (used), chuck outer diameter: 1,620 mm, total height: 4,650 mm, empty load weight: 20,000 kg, + zijsteun Elektrisch vernieuwd in 2007!!! Max turningdia -- passage: 1700 mm Power on the spindle: 37 kW Max hight of workpiece Z-axis: 1290 mm Digital screen: Heidenhain 2 axes Number of speeds: 3,5 - 150 rpm Long: 4550 mm Fgjdexgv Rcspfx Afpeh Wide: 2670 mm

Condition: used, Hyundai Wia LV-1100RM C Axis Vertical Lathe – 2020 Model Fgsdpfxoxgczbs Afpoh Operating Hours: 995 hours CNC Controller: Fanuc 32i-B Chuck: 32 inch Maximum Turning Diameter: 1160 mm Maximum Turning Length: 1000 mm Spindle Bore Diameter: 110 mm Spindle Speed: 800 rpm (Gearbox) Spindle Power: 65 kW Torque: 7,671 Nm Number of Tools: 12 C Axis Milling (Live Tool) Speed: 3,000 rpm X/Z Axis Travel: 620 / 1000 mm X/Z Axis Rapid Traverse: 24 / 24 m/min Machine Weight: 22,000 kg *All machine accessories and standard tooling, including 2 live tools (vertical and horizontal), will be supplied.

Condition: like new (used), Year of construction: 2009, operating hours: 26,000 h, travel distance X-axis: 725 mm, travel distance Y-axis: 50 mm, travel distance Z-axis: 300 mm, spindle motor power: 11 W, spindle speed (min.): 5,000 rpm, total length: 3,171 mm, total height: 2,648 mm, total width: 4,254 mm, overall weight: 6,000 kg, CNC controller: SIEMENS SINUMERIK 840D-ERGOLINE Capacity X-axis travel mm: 725 Y-axis travel mm: ± 50 Fgedexf Hlbjpfx Afpeh Z-axis travel mm: 300 Turning length mm: 160 Max. turning diameter mm: ø: 250 Swing over bed mm: ø: 320 Tool magazine Magazine places: 16 Tool holder: VDI-30 Tool length max. mm: 390 Tool diameter max. mm: 140 Lower turret Number of tool slots St .: 12 Speed driven tools RPM: 4.000 Drive power driven tools kW: 11,7 Milling function: Yes Main spindle Speed spindle rpm: 5.000 Drive power spindle kW: 11,7 (40% ED) Maximun torque Nm: 280 / 360 (100% / 40% ED) Coolant system Tank capacity liter: 980 L High-pressure bar: 8 / 20 Equipment Chip conveyor CE conformity Coolant gun Air blast / coolant switch-over Internal coolant supply Paper band filter Automatic workpiece magazine loader - 16 positions x ø 220 Working time hours Under power: 38.000 Cutting Time: 26.000 Basic machine dimensions / weight Length mm: 3.171 Width mm: 4.254 Height mm: 2.648 Weight kg: 6.000

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, travel distance X-axis: 300 mm, travel distance Z-axis: 700 mm, turning diameter: 140 mm, turning height: 380 mm, turning diameter over bed slide: 250 mm, TECHNICAL DETAILS Turning diameter: 140 mm Swing diameter: 250 mm Turning height: 380 mm Travel paths Travel - X axis: 300 mm Travel - Z axis: 700 mm Spindle Spindle speeds: 1 - 6,000 rpm Drive power 40% duty cycle: 38.00 kW Spindle nose: DIN 55026 - size 6 Spindle bore diameter at front bearing: 110 mm Feed & Rapid Traverse X-axis feed rate: 1 - 30,000 mm/min X-axis rapid traverse: 30.00 m/min X-axis feed force: 9,000 N Z-axis feed rate: 1 - 40,000 mm/min Z-axis rapid traverse: 40.00 m/min Z-axis feed force: 10,000 N Fodpfxexf A Npe Afpsgh Tools Number of tools in turret 1: 11 Number of tools in turret 2: 11 Toolholder: VDI 40 MACHINE DETAILS Control: SINUMERIK 840D Total power requirement: 70.00 kW Machine weight: approx. 22.00 t Space requirements: approx. 5.80 x 8.60 x H3.80 m EQUIPMENT Chip conveyor Extraction unit Infeed and outfeed Reversing gripper

Condition: ready for operation (used), Year of construction: 2015, operating hours: 15,050 h, functionality: fully functional, travel distance X-axis: 660 mm, travel distance Y-axis: 300 mm, travel distance Z-axis: 200 mm, spindle speed (max.): 7,500 rpm, turning diameter: 220 mm, turning height: 175 mm, TECHNICAL DETAILS Turning diameter: 220 mm Swing diameter: 270 mm Turning height: 175 mm Control & axis travel Control: SIEMENS 840 D SL X-axis: 660 mm Y-axis: 300 mm Z-axis: 200 mm Spindle & tool change Max. speed: 7,500 rpm Tool changer: 12-station Fgjdpfx Afoxf Apvjpsh MACHINE DETAILS Total power requirement: 24 kW Machine weight: approx. 5.2 t Space requirement: approx. 2.5 x 1.6 x 2.3 m

Condition: good (used), Year of construction: 2008, functionality: fully functional, machine/vehicle number: 101331, travel distance X-axis: 300 mm, travel distance Z-axis: 700 mm, spindle speed (max.): 5,000 rpm, turning diameter: 140 mm, turning length: 630 mm, TECHNICAL DETAILS Max. turning diameter: 140 mm Chuck swing diameter: Ø 250 mm Turning height: 630 mm Control: SIN840 PL Spindle Spindle speeds: continuously variable 1 - 5,000 rpm Drive power (40% duty cycle): 38.00 kW Spindle head: according to DIN 55026 - size 6 Spindle diameter in the front bearing: 110 mm Axes X-axis travel: 300 mm X-axis feed: 1 - 30,000 mm/min X-axis rapid traverse: 30.00 m/min X-axis feed force: 9,000 N Z-axis travel: 700 mm Z-axis feed: 1 - 40,000 mm/min Z-axis rapid traverse: 40.00 m/min Feed force Z-axis: 10,000 N Tool turret Number of tools in turret 1: 12 Number of tools in turret 2: 12 Tool holder: VDI 40 DIN 69880 MACHINE DETAILS Total power requirement: 70 kW Machine weight: approx. 25 t Space requirement (L x W x H): approx. 6.8 m x 4.7 m x 4.3 m Fjdpfxexf An Sj Afpogh EQUIPMENT - Chip conveyor - HYFRA spindle air conditioning unit - Knoll coolant system

Condition: used, Year of construction: 2002, turning diameter 1000 mm swing diameter 1250 mm turning height 1000 mm Control Siemens 840D total power requirement 110 kW Fodpsxfwgpofx Afpogh weight of the machine ca. 25 t

Condition: used, Year of construction: 2014, Control Siemens 840DSL max. swing diameter 420 mm max. turning height 300 mm max. turning speeds 3400 min/-1 drive capacity - main spindle 45 / 35 kW max. torque 775 / 600 Nm chucking diameter 315 / 400 mm Fsdpfx Afoxfwffjpjgh number of tool places 12 Pos. Shank diameter 40 mm x-axis 850 mm z-axis 315 mm rapid traverse (x/z) 45 / 30 m/min weight of the machine ca. 10,0 t dimensions of the machine ca. 4,2 x 1,5 x 3,5 m In our opinion, the machine is in very good used condition and can be inspected under power by appointment. Technical features: - driven tools - c-axis - Capacity for pieces diameter 30 to 160 mm : 32 [pos] - Capacity for pieces diameter 120 to 220 mm : 24 [pos] - Capacity for pieces diameter 120 to 340 mm : 16 [pos] The scope of delivery of the machine does not include a clamping device. Accessories, tools and clamping devices shown are only part of the scope of delivery if this is noted in the additional information. Changes and errors in the technical data and information as well as Subject to prior sale!

Condition: ready for operation (used), Year of construction: 2007, operating hours: 29,152 h, Control Unit Brand OKUMA Model OSP-P200L Media Chip conveyor Yes Additional Equipment Chuck blow-out with compressed air Electronic spindle orientation Chuck opening/closing with the spindle running Fgsdpfx Aexfmm Ejfpoh Automatic shut-off at the end of a batch size Programmable tool life Chip conveyor Coolant pump (8 bar) Pre-filter Connection nozzle for extraction This Okuma LVT 300-M was manufactured in 2007. A vertical turning machine featuring a 3-jaw chuck Forrkardt QLC 200-54-K6, chip conveyor, and coolant pump at 8 bar. It includes a tool measuring device and electronic spindle orientation, enhancing operational precision and efficiency. Contact us for further details regarding this machine. Application Types Turning

Condition: ready for operation (used), Year of construction: 2003, operating hours: 18,951 h, Control Unit Brand OKUMA Model OSP-U100L Tools Number of station 12 Media Chip conveyor Yes Additional Equipment Fgodpfx Afsxfcqajpeh Coolant Pump: Reinforced coolant pump for pressures starting at 8 bar Coolant Tank: 400 liters Workholding: Full clamping cylinder Chucking: Chuck blow-out with compressed air Other: Automatic shut-off at the end of a batch This Okuma LVT 300-M 2003 was manufactured in 2003. It features a travel range of 280mm, 12 tool stations, and a reinforced coolant pump supporting pressures from 8 bar. The machine includes a 400-liter coolant tank and a full clamping cylinder for effective workholding. Consider the opportunity to buy this Okuma 2003 vertical turning machine. Contact us for more information about this machine. Application Types Turning

Condition: refurbished (used), Year of construction: 2007, functionality: fully functional, travel distance X-axis: 800 mm, travel distance Z-axis: 880 mm, rapid traverse X-axis: 20,000 m/min, rapid traverse Z-axis: 20,000 m/min, turning diameter: 900 mm, Machine Specifications: Brand and Model: YOU-JI YV-800A Category: CNC Vertical Lathes Year of Manufacture: 2007 CNC Control: FANUC SERIES 18i-TB Machine Weight: 16,000 kg Machine Dimensions: Length: 4,400 mm Width: 2,650 mm Height: 3,350 mm Total Installed Power: 60 kVA Capacity: Max Swing Diameter: Ø 1,000 mm Max Turning Diameter: Ø 900 mm Max Turning Height: 800 mm Max Admissible Chuck Load: 3,000 kg Spindle: Spindle Nose: ASA A2-11 Chuck Diameter: Ø 630 mm Spindle Speed Range: 10 – 800 rpm Number of Speed Ranges: 2 ranges (High/Low) Spindle Motor Power (30 min rating): 18.5/22 kW Travel: X-Axis: +810 mm / -50 mm Z-Axis: 880 mm Rapid Traverse: X-Axis Rapid: 20,000 mm/min Z-Axis Rapid: 20,000 mm/min Turret: Number of Stations: 6 Tool Slot Size: 32 x 32 mm / Ø50 mm Fedpjxfbfiefx Afpogh Accessories: Chip Conveyor: With coolant collection and washdown pump Manuals, Electrical Schematics and CE Declaration: Included

Condition: used, Morando Twin Head Vertical Turning Centre with Siemens 840D CNC Control, 1450 3 Jaw Chuck, (1) x Fixed Tool Head, (1) x 4 Position Tool Turret Head, Swarf Conveyor, Coolant Clarifier System - CE Mark Please Note: Dismantling and Loading will be carried out by our own supplier Fedpexdbydjfx Afpjgh Please Note: These lots are located in Ferrara, Italy. All/Any tooling is being offered as specifically described.

Condition: used, Year of construction: 2006, Technical details: turning diameter: 250 mm swing diameter: 260 mm Available from October 10, 2025 The system consists of two individual systems that are linked together. No driven tools! Fsdsxc Idgjpfx Afpjgh *

Condition: ready for operation (used), Year of construction: 2011, operating hours: 50,457 h, functionality: fully functional, spindle speed (max.): 4,000 rpm, rapid traverse X-axis: 50 m/min, rapid traverse Y-axis: 30 m/min, turning diameter: 200 mm, total length: 8,500 mm, total height: 3,800 mm, total width: 4,300 mm, type of input current: three-phase, workpiece diameter (max.): 250 mm, overall weight: 15,000 kg, controller model: Siemens 840 D sl, For sale is a MAG DVT250, year of manufacture 2011. Equipped with a Siemens 840 D sl control system. Equipment: - Infeed and outfeed conveyor - Chip conveyor (discharge to the right) - Coolant system - 2x tool turrets 12x VDI30 The machine is under power and can be inspected. *The marking unit (Richter [picture 1 right]) is defective and not part of the listing. Fsdpfx Afsxc Enijpjgh

Condition: ready for operation (used), Year of construction: 2014, functionality: fully functional, machine/vehicle number: 105958, travel distance X-axis: 700 mm, travel distance Y-axis: 375 mm, spindle speed (max.): 6,000 rpm, workpiece diameter (max.): 100 mm, workpiece length (max.): 150 mm, The automation is included in the scope of delivery! TECHNICAL DETAILS Travels X-axis: 700 mm Z-axis: 375 mm Workpiece Chuck diameter: 160 mm Max. workpiece diameter: 100 mm Max. workpiece length: 150 mm Main spindle Fgjdpfx Asxb Tu Iofpoh Power 40% / 100%: 19.5 / 12.5 kW Torque 40% / 100%: 75 / 48 Nm Max. speed: 6,000 rpm Turret Tool stations: 12 Rapid traverse speed X / Y / Z: 60 / 30 / 30 m/min Driven tools Speed: 6,000 rpm Torque 30% / 100%: 27 / 15 Nm MACHINE DETAILS Frequency: 50 Hz Operating voltage: 400 V Connected load: 30 kW Total weight: 6,000 kg
