Condition: excellent (used), Adcock & Shipley 2E Universal Milling Machine Horizontal Milling attachements fitted Universal Swivel Table Table size 40 x 10” Speeds 30 – 1200rpm Power Feed to Table & Rapids Coolant Gaurds 3 Phase Electrics For sale with Jet Machinery Ltd Jet Machinery Stock No: #78947 Machine Serial Number: 1586K2AGU0665 Cost: £2,950.00 + VAT Nodpfx Aexxbhwsh Doli Whilst every effort has been made to ensure that the above information is accurate it is not guaranteed. We advise prospective purchasers to check any vital details. Health and Safety At Work Act 1974: It is not reasonably practical for ourselves as suppliers to ensure that for your application the goods comply with requirements of the Act with respect to guarding etc. Prospective purchasers should ensure that a guarding specialist inspect the goods prior to use.

Condition: good (used), Year of construction: 2003, INTOS Žebrák FN 20 Universal milling machine + accessories Manufacturer: INTOS Žebrák Type: FN 20 Condition: used Year of construction: 2003 Weight of the machine: 910 kg Dimension: - Length mm: 1690 - Width mm: 1270 - Height mm: 1175 Clamping surface of the vertical table: 216 x 680 Clamping surface of the angled table: 240 x 600 Width and distance of the T-slots mm: 12H8 x 45 0.1 Spindle diameter in the front bearing mm: 45 Spindle taper: ISO 40 Spindle speed: 18 RPM range: 50 - 2000 Feed rates : 18 Range mm: 8 - 400 Rapid feed mm/min: 1340 Movement of the headstock: - manually: 200 Nedpfx Ahexwl R He Djli - independently: 190 Achieved by adjusting the holder Design mm: 42 Longitudinal table movement: - manually mm: 300 - independently mm: 290 Vertical movement of the table: - manually mm: 350 - independently mm: 340 Scope of delivery: - INTOS Žebrák FN 20 universal milling machine - accessories - operating instructions

Condition: used, Year of construction: 1986, longitudinal travel 1200 mm vertical movement 600 mm cross travel 450 mm table-size 1500 x 600 mm max. table load 2 t spindle taper ISO 50 spindle drive 15 kW speeds 6 - 4000 U/min feeds 2 - 2500 mm/min rapid traverse 10 m/min voltage 400 V Nsdpfx Ajxukppjh Doli Bed milling machine with swivable spindle to horizontal or vertical. Control: Heidenhain TNC 155. Machine has an additional horizontal 4th axe.

Condition: ready for operation (used), Year of construction: 1999, General Data Measurements height 2860 mm Machine weight 3800 kg Control Unit Brand MITSUBISHI Main Drive Spindle speed range 12000 rpm Spindle motor power 7.5/5.5 kW Tool taper 7/24, No. 40 Movement X-Axis Movement 510 mm Y-Axis Movement 510 mm Z-Axis Movement 510 mm Table Number of tslots 5 Table load 350 kg Tools Number of index 25 Max weight 6 kg Max tool diameter 100 mm Max tool length 250 mm Media Power consumption 22.5 kVA Nodexpytaepfx Ah Doli Additional Equipment APC (Automatic Pallet Changer) - Only for CV-500A (APC): Number of Pallets: 2 Pallet Change Method: Front rotation This 3-axis MORI SEIKI CV-500 was manufactured in 1999. Ideal for precision CNC milling, this machine maintains robust construction and reliable performance. If you are looking to get high-quality milling capabilities, consider the MORI SEIKI CV-500 machine we have for sale. Contact us for more information. Application Types Milling

Condition: ready for operation (used), 1 used bed type milling machine Manufacturer: Knuth Model: KB 1400 Year: 2006 Technical Specifications: Working Area Distance spindle axis to table surface: 150 mm – 650 mm Number of T-slots: 3 Table clamping surface: 1400 mm x 400 mm T-slot width: 18 mm T-slot spacing: 100 mm Height adjustment speed (max.): 1670 mm/min Travel X-axis travel: 950 mm Y-axis travel: 400 mm Z-axis travel: 500 mm Vertical Milling Head Spindle taper: SK 50 DIN 2080 Overhang: 510 mm Spindle speed (vertical): 30 rpm – 1800 rpm Quill stroke: 105 mm Head swivel range: ±30° Nedpfxoxnp Epe Ah Djli Rapid Traverse Rapid traverse X-axis: 1670 mm/min Rapid traverse Y-axis: 1670 mm/min Rapid traverse Z-axis: 1670 mm/min Feed Feed speed X-axis: 18 mm/min – 627 mm/min Feed speed Y-axis: 18 mm/min – 627 mm/min Feed speed Z-axis: 18 mm/min – 627 mm/min Drive Capacity Main drive motor power: 7.5 kW Feed motor power: 0.75 kW Z-axis motor power: 0.75 kW Coolant pump motor power: 0.04 kW Dimensions and Weight Coolant pump flow rate: 12 l/min Dimensions (L x W x H): 2.29 m x 1.77 m x 2.12 m Weight: 3660 kg

Condition: used, Year of construction: 1995, operating hours: 24,142 h, functionality: fully functional, travel distance X-axis: 1,100 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 600 mm, rapid traverse X-axis: 10,000 m/min, rapid traverse Y-axis: 10,000 m/min, rapid traverse Z-axis: 10,000 m/min, feed rate X-axis: 3,000 m/min, feed rate Y-axis: 3,000 m/min, feed rate Z-axis: 3,000 m/min, spindle speed (max.): 3,000 rpm, spindle speed (min.): 50 rpm, type of input current: three-phase, workpiece weight (max.): 1,500 kg, spindle motor power: 7,500 W, controller manufacturer: Heidenhain, controller model: TNC 360, For sale is a Lagun CNC milling machine, year of manufacture 1995, with 24,150 operating hours. Technical data: - Control: Heidenhain TNC360 - X-axis: 1100 mm - Y-axis: 600 mm - Z-axis: 600 mm - Table size: 1200 mm x 550 mm - Spindle taper: ISO50 BT40 - Speed range: 50–3000 rpm - Rapid traverse: 10,000 mm/min The machine is equipped with a manual universal milling head and an enclosure. Nledexmhaijpfx Ah Dji The machine is in running condition and can be inspected under power.

Condition: used, functionality: fully functional, Spindle: Speed range: 45 – 2800 rpm Spindle mounting: 40 or Morse 4 Maximum spindle torque: 9000 kgcm Nsdpfjxg Icqex Ah Djli Table: Clamping surface: 1250 x 250 mm Max. table load: 3200 kg Number of T-slots: 3 pcs, 14 mm wide Slot spacing: 55 mm Travels: Longitudinal: 810 mm Cross: 275 mm Vertical: 400 mm Automatic feeds: 14 – 900 mm/min Rapid traverse: up to 2800 mm/min Motors: Spindle motor: 4.2 kW Feed motor: 0.75 kW Other: Machine weight approx. 1800 kg Dimensions: length: 1900 width: 1700 height: 1700 mm Financial information VAT/margin: Margin: The stated price includes VAT (VAT not deductible for businesses).

Condition: new, The KB 1400 is a high-performance Conventional Vertical Milling Machine within the Bed-Type Milling Machines group, designed by KNUTH for exceptional cutting capabilities. This heavy universal bed milling machine features wide guides and impressive drive power, making it ideal for plant and machine construction. Its vertical milling head, which can swivel ± 45°, along with a manually adjustable quill and infinitely variable spindle speed, provides versatility and precision for diverse machining tasks. The machine's robust gearbox allows for adjustable feeds in the Y- and X-axes, ensuring rapid traverse on all axes. With a table setup area of 1,400 x 400 mm and a travel distance of 950 mm, this machine can accommodate large workpieces and various clamping devices. The KB 1400 also boasts a solid Meehanite cast-iron frame, contributing to improved stability and reduced vibration, resulting in higher accuracy and productivity. Benefit from its extensive standard equipment including a 3-axis position indicator and coolant system. Experience the precision and robust performance of the KB 1400 – request a quote today to explore how this Conventional Vertical Milling Machine can enhance your operations. Nsdpfowubzlox Ah Doli

Condition: used, Year of construction: 2001, - 3-axis position display - Universal milling head - Hardened and ground guideways - Infinitely variable feeds Nledewkvlkspfx Ah Dei - Infinitely variable speeds with 2 speed ranges - Horizontal milling attachment - Hydraulic tool clamping - 11 kW drive - Automatic central lubrication - Coolant system - Table guard - CE certification - Including milling tools - Including operating manual and documentation - Year of manufacture: 2001 - Complete service performed Technical Data Work Table: - Clamping surface: 1500 x 360 mm - Table load capacity: 800 kg Travel: - X-axis longitudinal: 1000 mm - Y-axis cross: 540 mm - Z-axis vertical: 430 mm Working Area: - Distance spindle nose / table: 50 - 480 mm - Distance spindle center / column: 350 mm Feeds: - Number of feeds: infinitely variable - Feed longitudinal / cross: 16 - 1200 mm/min - Feed vertical: 8 - 450 mm/min - Rapid traverse longitudinal / cross: 2500 mm/min - Rapid traverse vertical: 1000 mm/min - Feed motors: 3 x 1.5 kW Main Spindle: - Number of speed steps: 12 - Speed range: 40 - 1750 rpm - Graduation: 160, 225, 315, 440, 620, 880, 1240, 1750 - Drive power: 11 kW - Spindle taper: ISO50 DIN2080 - Milling head overhang: 420 mm Dimensions and Weights: - Machine footprint: 3050 x 2150 mm - Machine dimensions: 2050 x 2210 x 1830 mm - Machine weight: 2800 kg

Condition: used, Year of construction: 2011, - Heidenhain TNC-320 CNC control - Electronic handwheel HR-410 - Heidenhain glass measuring rods on all axes - Ball screws - Hydraulic tool retractor - AC servo feed motors - Sliding doors with safety glass - Universal milling head - Hardened guideways - Plastic-coated counter guide - Electromagnet. Main spindle brake - Automatic central lubrication system - Integrated coolant system - Steel telescopic cover for transverse travel - Steel telescopic cover for longitudinal travel - Work light - Year of manufacture 2011 Specifications Worktable: - Table clamping area: 1800 x 500 mm - Max. workpiece weight: 1000 kg Travel paths: - X-axis - Longitudinal travel: 1250 mm - Y-axis - Transverse travel: 540 mm - Y-axis - Transverse travel with steel telescopic cover: 500 mm - Distance between spindle center and column: 500 mm Column: - Z-axis - Vertical travel: 550 mm - Distance between spindle nose and table with vertical head position: approx. 50 - 600 mm - Distance between spindle nose and table with horizontal head position: approx. 360 mm 910 mm Milling spindle: - Tool holder: DIN 2080 ISO 50 - Speed range: 40 - 2000 rpm Feeds and rapid traverse rates: - Longitudinal/transverse feed: 4000 mm/min - Vertical movement (column): 2000 mm/min - Rapid traverse longitudinal/transverse: 4000 mm/min - Rapid traverse vertical: 2000 mm/min Motors: - Milling spindle motor: 11 kW - Feed motors for X/Y/Z axes: 1.5 kW each - Coolant pump: 0.12 kW - Lubricant pump: 12 W Nedpfxjwf Ntqo Ah Djli Installation: - Dimensions W x H x D: 3000 x 1880 x 2660 mm - Net weight of the machine: approx. 3800 kg

Condition: excellent (used), CNC milling machine, ISO 40 spindle, rpm 60-3600, HP5, Strokes: x1200mm, Y550mm, Z600mm, Quill stroke 400mm. Table mm1470x350 mm CNC Heidenhain TNC 310 Nlsdpfjwcdwxox Ah Dsi

Year of construction: 1991, condition: good (used), Used fixed bed milling machine Brand: LAGUN Model: FBF 1200 Year: 1991 Serial number: B10109 Weight: 5,500kg Nlodpfx Aoh Rycfeh Dei Measurements: 2600x2300x2600(h)mm Control: HEIDENHAIN TNC 355 (New Screen) Table measurements: 1200x550mm Axis displacements: X-1100mm Y-600mm Z-600mm Ferret head with hydraulic mooring tool. Cone: ISO 50 Spindle speeds: 50 - 3000 rpm (2 speed ranges) Feedrates in the X Y Z axes: 1 - 3000 mm/min Rapid advance axes X Y Z: 10,000 mm/min Motor power: 15KW

Year of construction: 1983, condition: good (used), 1 Bracket milling machine make: RECKERMANN, type: KOMBI 900, year 1983 ser. no. 6367P, table size 1.000 x 310 mm, travel X/Y/Z 720 x 220 x 450 mm, Nledpfx Ahsh E Du Dj Dsi tool holders SK 50, HD machine vice, spindle speeds: 3...2800 rpm

Condition: new, WM5150 ROGI bed milling machine 400V-3F Motor ----- 2.4 KW Speed range vertical ----- 94 ~ 2256 rpm Spindle mounting ----- ISO 40 Table ----- 1220 x 360 mm Pinhole stroke ----- 180 mm Pinhole feed ----- 0,1 / 0,15 / 0,3 mm/rev Longitudinal displacement (x) ----- 600 mm Lateral displacement (y) ----- 360 mm Nledpjga T Dwjfx Ah Doi Height displacement (z) ----- 500 mm Unload ----- 370 mm Spindle head swivel range ----- -45 to +45 Distance spindle / table ----- 110 - 610 mm Feed range along / across ----- (8) 24 - 720 mm/min Weight ----- 1800 KG INCLUDED * 3-axis digital readout brand SINO * Automatic feeding of work table X,Y * Automatic spindle feeding * LED lighting * Cooling system * Luxury control box * Box with various tools

Year of construction: 2001, condition: good (used), CNC bed type milling machine Fabr.IBERIMEX-MVR Type: UH-1250 BJ. 2001 Control HEIDENHAIN TNC124 Procedures: X1250mm Y500mm 460 mm Clamping table: 360mmX1800mm Spindle retainer: ISO50 Machine with full enclosure. Machine card see more data. Nodpfed Eranjx Ah Djli Machine in good condition.

Condition: used, Year of construction: 1995, W A N D E R E R Model H 200 V/TNC 360 C Table size 1250 x 720 mm – Travels: X 1000 mm, Y transverse 500 mm – Max. distance from table to spindle (vertical reach 700 mm – max. reach from column face to spindle center – transverse 760 mm). Machine with automatic folding head for automatic swiveling from horizontal to vertical or vice versa – also available. Automatic tool clamping with SK 50 – Work area cabin – Electronic handwheel – Heidenhain 360-C contouring control with color graphics and electronic handwheel – Machine with approximately 30 cutter holders – Swiveling control panel, etc. 1 used, excellently preserved bed-type milling machine of very sturdy construction: The machine was overhauled in 1995 for *150,000.00 DM – the overhaul work included the complete restoration of the geometry to new machine accuracy and the conversion to TNC 360 contouring control. 8 mm infeed with cutter head is no problem! Numerous SK 50 holders – machine mounts, etc. Njdpfob I Iqcsx Ah Dsli Hand-scraped guideways in top quality.

Year of construction: 1990, condition: used, machine/vehicle number: 90030003, table size: 500 x 1200 mm movement x: 1000 mm movement y: 550 mm movement z: 600 mm spindle taper: ISO 40 spindle turning speed range: 60 - 2700 rpm spindle drive: 10 kW electrical connection: 380 V, 20 kVA kW space needed: 3200 x 2800 x 2650 mm Njdpfo Npwfjx Ah Dsli weight: 7,3 t
