Silini Press S.R.L

Condition: used, Year of construction: 1961, Impact energy: 2040 Gsdpfxjzypd Ne Adtjug Stroke: 660 mm Strokes per minute: 100/min Throat depth: 750 mm Distance between lower anvil and ram guide edge: 660 mm Drive power: 75.0 kW Weight: 32 t Hammer weight: 16.5 t Anvil weight: 15.5 t Ram weight: 750 kg

Condition: excellent (used), functionality: fully functional, Manufacturer: Šmeral Type of machine: Hot forging press Rated pressing force: 1,000 t Gsdpfx Aezxhzwjdtjug Ram stroke: 220 mm Stroke rate: 100 strokes/min Table size: 995 × 950 mm Ram adjustment: 10 mm Stroke of upper ejector: 35 mm Drive power: 40 kW Weight: approx. 45 t

Condition: used, Year of construction: 1985, functionality: limited functionality, pressing force: 400 t, stroke length: 130 mm, table width: 500 mm, table length: 500 mm, overall weight: 8,500 kg, For sale knuckle-joint press type KB8336 made Stanko, effort 400 ton, year of manufacture 1985, table dimensions 500mm*500mm, stroke 130mm, total weight 8500kg. Price is 17500 Euro CIF. Gjdpezugawofx Adteug

Condition: used, Year of construction: 1983, nominal force 2500 t stroke 600 mm cycle time 13 - 18 s distance between columns 1720 mm Distance table/ram, max. stroke up, adjustment up 2600 mm table surface area 1720 x 1800 mm allowed max. force 4000 t blow die to die 5000 t ram surface 2100 x 1320 mm capacity of ejector in table 40 t ejector stroke in table 250 mm ejector surface area in table 900 x 820 mm capacity of ejector in ram 6 t Gsdpfx Aezrpulodtsug ejector stroke in ram 40 mm spindle diameter 425 mm power requirement 900,0 kW weight 335,0 t Dimensions (WxDxH) 3,4 x 4,6 x 9,7 m height over floor 8,3 m fully automated forging line / spindle press with automation for the production of flanged shafts for hot forming only with reversible AC motor, pneumatic brake, plate ejector in table (40 t / 250 mm), ejector in ram (6 t / 40 mm), lifting device for repositioning, marking, tool change, insertion device, tilting device, loading and unloading arm, rotary table, circular oil lubrication, centralised grease lubrication cycle time approx. 13 - 18 s as is where is, WITHOUT putting into operation

Condition: ready for operation (used), Year of construction: 1976, functionality: fully functional, hydraulic forging hammer (H5) Manufacturer: BECHE Type: KGH 31.5 Year of manufacture: 1976 Energy: 31.5 kJ Gjdpfx Adeziw N Eotsug Machine foundation with spring damping elements Forging furnace Gas-heated Power: 400 kW New Siemens S7 control system, refurbished

Condition: ready for operation (used), Year of construction: 1999, machine/vehicle number: 100.981.48, functionality: fully functional, hydraulic forging hammer (H1) Manufacturer: LASCO Type: HO - U 400 SO Guedpfsziw Nxjx Adtsg Year of manufacture: 1999 Impact energy: 40 kJ Ram stroke: 710 mm Ram weight: 3,000 kg Machine foundation with spring damping elements, forging furnace, gas-heated, power output: 800 kW, underfire zone, pre- and main chamber burner, work platform

Condition: ready for operation (used), Year of construction: 2008, machine/vehicle number: 100.06238, functionality: fully functional, hydraulic forging hammer (H2) Manufacturer: LASCO Type: HO - U 630 SO Year of manufacture: 2008 Impact energy: 63 kJ Impact frequency: approx. 85/min Ram speed: up to 5 m/s Ram stroke: 520 to 760 mm Ram depth: 750 mm Ram weight: 4,300 kg Central lubrication with hydraulic oil Filter circuit with cooling Guodpfx Adjziw Nletog

Condition: good (used), Year of construction: 2005, machine/vehicle number: 12345, functionality: fully functional, Used hydraulic forging hammer Manufacturer: LASCO Type: HOU 250 SO Year of manufacture: 2005 Gujdpjzidv Ssfx Adtog Impact energy 40 kJ, ram stroke 710 mm, ram weight 3,000 kg, machine foundation with spring damping elements, conveying system by STAHLMANN, two-module design, work platform, automatic feeding, infeed and outfeed, water cooling.

Condition: excellent (used), Year of construction: 1980, functionality: fully functional, input voltage: 380 V, input frequency: 50 Hz, pressing force: 4 t, stroke length: 1,200 mm, oil tank capacity: 700 l, total height: 7,480 mm, overall weight: 78,500 kg, year of last overhaul: 2023, Equipment: documentation/manual, Oil-hydraulic forging hammer Lasco type KH 400 Gujdpjzh Nchefx Adtjg YOM 1980 Fully retrofitted and modernized 2023. Work impact: 4,000 mkg Fall height in normal dies: 1,200 mm Ram weight: 3,350 kg Length between the guiding light: 725 mm Ram: 620 mm Motor power: 60 kW Weight of the anvil: 44,000 kg Total weight of the hammer: 78,500 kg Total height of the hammer: 7,480 mm Building height above floor level: 6,260 mm Oil tank capacity: 700 liters Piston rod Length: 500*2800 mm Rubber cushions: 90/2900*120 mm Operating voltage: 380 Volts Control voltage: 220 Volts Slowly ON: 0.62 m/min.

Condition: refurbished (used), Automatic line for forging / hot stamping Installed after refurbishing in 2015 and having run for not more than 1,000 hours, condition is excellent. ➢ ADIGE CM 500 AUTOMATIC SAW ➢ 50 KW INDUCTION OVEN ➢ ELECTRONIC AUTOMATION SYSTEM ➢ VACCARI SCREW PRESS 180 screw diameter ➢ 10-POINT AUTOMATIC LUBRICATION SYSTEM ➢ BALCONI 50T TRIMMING PRESS ADIGE CM 500 AUTOMATIC SAWING MACHINE WITH 3.5-METER AUTOMATIC BAR LOADER Technical specifications: -Min./max. cutting capacity: 8 mm / 60 mm diameter -Standard cutting speed: ADIGE SALA. -Head motor power: (50 Hz) 2.2 kW -End-of-bar scrap equal to or shorter than the usable piece -Central hydraulic tank capacity: 200 liters -Cutting emulsion tank capacity: 50 liters -Weight: approx. 1,200 kg Gusdpfx Aozcdlusdtjg -Siemens electrical components 50 kW INDUCTION OVEN WITH 1 INDUCTOR (8–20 mm) with ELECTRONIC LOADING ARM For horizontal and vertical loading of work pieces Features a brushless motor, programmable axes, and press interpolation with electric axes; electronic components: Siemens Load capacity: 4 kg; vertical stroke: 80 mm; power supply: Electro-pneumatic VACCARI SCREW PRESS 180 screw diameter Technical specifications: -Screw diameter: 180 mm -Theoretical pressure: 300 tons -Table dimensions: 430 x 550 mm -Slide dimensions: 500 x 650 mm -Ram stroke: 350 mm -Distance between uprights below the guides: 450 mm -Distance between uprights within the guides: 350 mm -Max. height between table and ram: 650 mm -Strokes per minute: 35 -Table height under the guides: 300 mm -Main motor: hp 30 -Machine dimensions: 4100 x 2600 x 2200 mm -Approximate weight: 11,000 kg NEW SIEMENS S7 ELECTRICAL SYSTEM NEW PNEUMATIC SYSTEM NEW LUBRICATION SYSTEM BALCONI 50T TRIMMING PRESS Technical specifications: -Power: 50 tons -Table dimensions: 800 x 500 mm -Ram dimensions: 440 x 380 mm -Max. die height: 400 mm -Adjustable stroke: 100 mm -Strokes per minute: 35–100 -Main motor power: 5.5 kW

Condition: used, pressure capacity max. 500 kg Gjdpfx Adoy S Dxueteug impact capacity / mkp table length / mm Air hammer The hammer is functional, due to age reasons, the Sealing sleeves are replaced. - More information will follow shortly -

Condition: excellent (used), functionality: fully functional, MINSTER DOUBLE GEARED STRAIGHT SIDE PRESS General Information Manufacturer: Minster Type: Double Geared Straight Side Press Model: 90K-1000-42 Serial No.: 90K-1000-26110 Capacity: 1000 Tons Specifications (Metric Conversion) Guodpjy Rb Abofx Adtog Capacity: 1000 Tons Stroke Speed: 25–50 Strokes/Min (SPM) Stroke Length: 203.2 mm Slide Adjustment: 12.7 mm Shut Height (Bolster): 660.4 mm Shut Height (Bed): 850.9 mm Clutch Type: Air Clutch Type (142-GC) Number of Clutch Discs: 3 Discs Lubrication System: Forced Recirculating Lubrication Tie Rod Stretch: 3.56 mm Machine is currently operational Used for warm forging and aluminum production (not used at the full capacity of the machine) Inspected the machine is in a fully running condition Production-capable condition maintained continuously Operating video is available upon request

Condition: good (used), Year of construction: 2014, Manufacturer: Hosung machinery industrial (S. KOREA) Model: HFP-750 Gedpfx Adoylr Rwetoug Manufactured year: 2014 Including the blanking press and the forging furnace

Condition: new, Year of construction: 2025, pressing force: 20 t, Forging Press – Manufacturer Durendus – DCS-20 – 5–20 t C-Frame Press – Table 500 × 600 mm For sale is a compact single-column forging press (C-frame) from the manufacturer Durendus, model DCS-20, with an adjustable pressing force of 5 to 20 t. This machine features a table size of 500 × 600 mm, a maximum installation height of 700 mm, high traverse speeds, and is ideally suited for small-scale forging, forming, and assembly work. ===== Technical Data & Information: Forging Press Durendus DCS-20 – 5–20 t Single-Column Press Gusdpoyght Rsfx Adtog ==== General Information - Manufacturer: Durendus - Model: DCS-20 - Design: Single-column press / C-frame - Pressing force: 5 – 20 t (adjustable) - Machine weight: approx. 1,900 kg - Dimensions (W × D × H): 1,450 × 1,500 × 2,400 mm ==== Working Area - Max. installation height: 700 mm - Stroke: 0 – 500 mm (adjustable) - Table height: 800 mm ==== Table and Ram - Table size: 500 × 600 mm - Ram size: 500 × 600 mm - T-slots: DIN 650 – 18 mm (or as per customer specification) ==== Hydraulic Cylinder - Cylinder diameter: Ø 90 mm - Piston rod diameter: Ø 60 mm - Rapid traverse cylinder: Ø 40 mm - Rapid traverse piston rod: Ø 25 mm - Operating pressure: max. 250 bar (adjustable) ==== Speeds - Return speed: 140 mm/s - Idle speed: 140 mm/s - Pressing speed: 4 – 10 mm/s (adjustable) - Pressure build-up time: max. 2 s (steel on steel) ==== Hydraulics - Hydraulic pump: Rexroth, 22 l/min - Motor power: 7.5 kW - Oil tank capacity: 150 l - Hydraulic block / valves: Hydropack - Filter: Filtrec - Oil level monitoring: electronic oil level switch - Hydraulic power unit: mounted at the upper rear ==== Electrical - Main power supply: 400 V AC - Control voltage: 24 V DC - Frequency: 50 Hz - Connected load: approx. 10 kW ===== Forging, forming technology, assembly work, small batch production, workshop applications, metalworking Forging press, single-column press, C-frame press, hydraulic press, forming press, workshop press, small press Are you looking for a hydraulic press tailored to your application? Contact us for a customized quote. Our hydraulic presses are manufactured according to German machinery directives, as well as European machine guidelines (Directive 2006/42/EC), EC standards, and EU safety regulations. Furthermore, our presses exceed both Canadian and European safety requirements as they fully comply with the Brazilian national safety directive NR 12, which is based on these standards. Our key strengths are special machine construction and press automation. We supply custom-made hydraulic presses at surprisingly affordable prices. The hydraulic systems of our presses are predominantly equipped with components from leading European manufacturers.

Condition: used, Year of construction: 2002, functionality: fully functional, The machine worked perfectly before disassembly. It is in good condition and free of any cracks. Gjdpfx Adjyacyxeteug

Condition: used, machine/vehicle number: J36860, National Machinery double-pressure press type M56, good condition, 3 pieces available Gedpswiwpuofx Adteug

Condition: used, TECHNICAL DETAILS - Parts per minute : 400 - Rivet length : 12 [mm] - Drilling depth (max.) : 5 [mm] - Cutting diameter : 3 [mm] - Floor space (width) : 1.12 [m] - Floor space (length) : 2.21 [m] - Height : 1.77 [m] - Motor : 4 [hp/kW] - Net weight : 2,500 [kg] - Gross weight : 3,000 [kg] Gjdeuhb Tkepfx Adtjug EQUIPMENT - Tooling as per photo

Condition: good (used), Year of construction: 1973, functionality: fully functional, pressing force: 1,250 t, stroke length: 220 mm, table width: 260 mm, table length: 820 mm, throat depth: 700 mm, total length: 6,400 mm, total width: 4,365 mm, total height: 3,760 mm, overall weight: 135,000 kg, operating pressure: 7 bar, pressure: 7 bar, Upset slide nominal force: 12 500 kN /1 250 ton/ Maximal diameter of work piece: 140 mm Maximal diameter of upset flange: 180 mm Upset slide stroke: 460 mm Slide continuous idle strokes in minute: 35 Electric motor power: 75 kW Gujdpfx Ajuby N Djdtog Overall dimensions: - L-R: 6 400 mm - F-B: 4 3650 mm - Height: 3 760 mm Total weight, circa: 135 000 kg.

Condition: good (used), Year of construction: 1989, total height: 6,450 mm, For sale Beche short-stroke die hammer KGH 4B. Machine weight 65 t Gjdpfx Adjrt Uc Ejteug Working capacity 40 kJ max. impact frequency 98 min max. usable number of blows 41 min max. bear stroke 790 mm Machine is disassembled Technical data on request

Condition: used, Year of construction: 1999, ram hammer weight 26 kg ram hammer stroke 200 mm type KO 596 no. of strokes 220 Hub/min Gujdpfx Aeqwpxbodteg air hammer

Condition: new, Year of construction: 2018, machine/vehicle number: DF0163, pressing force: 800 t, pressure:800 t distance between columns:1200 mm stroke:500 mm total power requirement:85 kW weight of the machine ca.:40 t dimensions:4100 x 3500 x 6650 mm draw back pressure:80 t Master cylinder:1 Stück Gsdpfx Adsdxvfpjtjug column diameter:250 mm dayligth:1000 mm Table dimensions:1300 x 1100 mm ram surface:1300 x 1100 mm :800 mm table height over floor:950 mm table load:5 t pre-running speed:250 mm/sec return speed:150 mm/sec :1000 l :10 mm/sec :inbegriffen ? :inbegriffen ? :inbegriffen ? :inbegriffen ? :inbegriffen (800 x 530mm) ? :inbegriffen (800 x 530mm) ?
