HPT Kathenbach GmbH

Condition: used, Year of construction: 2000, table length 350 mm Fgjdpfoxmk Hlsx Afpeh table width 220 mm ampere 18 A Control FANUC 18i

Condition: good (used), Year of construction: 2013, Ref. no.: 18608 Hersteller: FANUC Type: Robocut C400IA CNC Year of construction: 2013 Further information: Operating Hours: 29,665 Control System: FANUC 310iS-WA Technical Specifications NUMBER OF AXIS: 5 Verfahrwege (Stroke): Fgedpfoxk Uwvsx Afpsh X: 370 mm / 900 mm/min Y: 270 mm / 900 mm/min Z: 255 mm / 900 mm/min U / V: ± 60 mm, 450 mm/min • Positioning accuracy: Glass scales 0.05 µm + Nano-interpolation • Max. workpiece weight: approx. 500 kg • Power requirement: 13 kVA (200 V, 50 Hz) • Machine dimensions (LxWxH): 2120 x 2050 x 2120 mm • Weight: 1200 kg Equipment & Features • Automatic Wire Threading System (AWF) • 25 kg Wire Loader • Heat Exchanger / Cooling Unit • 15” LCD Touchscreen CNC control • USB & Ethernet connectivity

Condition: used, Year of construction: 2002, workpiece weight (max.): 750 kg, travel distance X-axis: 350 mm, travel distance Y-axis: 220 mm, travel distance Z-axis: 220 mm, ★ TOP maintained machine from the liquidation of a renowned toolmaker – be sure to check out our other listings as well ★ ❗Wire EDM machine CHARMILLES ROBOFIL 240❗ - Year of manufacture: 2002 - Machine number: 920530 - Condition: Used, untested - Delivery terms: Free loading on truck – unpacked - Location: 73347 Mühlhausen Fgjdpfjxg N Axex Afpeh - Availability: Beginning of December 2025 – Items must be collected by the buyer in CW 49 / 2025 on a binding basis. The exact date will be specified by us. Earlier availability may be possible upon agreement. - Payment terms: Advance payment – by bank transfer - Internal ID: JO2 - Inspection under power: YES – by appointment Technical specifications: - Max. workpiece dimensions: 1000 x 550 x 220 mm - Max. workpiece weight: 750 kg - Table dimensions: 680 x 450 mm - Total dielectric fluid volume: 760 L - Travel paths X / Y / Z: 350 / 220 / 220 mm - Travel paths U / V: 350 / 220 mm - Max. taper angle: ± 30° / 220 mm - As the machine is connected to a central cooling system, the buyer will require a separate chiller - Further technical data available on request Scope of delivery: - Manuals - Miscellaneous accessories and spare parts as shown in the pictures Dimensions & weights: - Installation dimensions (L x W x H) approx.: 2000 x 2000 x 2100 mm - Weight approx.: 2500 kg ⚠️Please also check our other listings⚠️ Additional notes: ►We expressly recommend collection by direct transport (freight forwarding) ►Goods are sold with exclusion of any warranty ►Technical data subject to verification ►Subject to prior sale ❗Sale of goods exclusively to businesses❗

Condition: used, Year of construction: 2015, functionality: fully functional, Technical Specifications Fodpfx Afoxgphnspjgh Travels (X / Y / Z): 350 × 250 × 256 mm U / V Axis Travels: ± 70 mm Max. Workpiece Dimensions (LxWxH): approx. 750 × 550 × 250 mm Max. Workpiece Weight: approx. 450 kg Table Size: 620 × 400 mm Wire Diameter: 0.15 – 0.33 mm (commonly 0.25 mm) Max. Taper Cutting Angle: ± 30° at 100 mm height Positioning Accuracy: ± 2 µm Psw N Hjxdubzjl Icsrb Wire Threading System: Fully automatic, fast, reliable Generator: Intelligent GF AC Cut, real-time spark control Surface Finish: up to Ra 0.1–0.2 μm (after finishing cuts) Control System: AgieVision (ergonomic, touch display, 3D graphics) Dielectric: Deionized water Machine Dimensions (LxWxH): approx. 2200 × 2200 × 2200 mm Machine Weight: approx. 3500–4000 kg

Condition: refurbished (used), Year of construction: 2001, NICE MACHINE REFURBISHED Fodpfexc Elhex Afpegh

Condition: like new (used), Year of construction: 2004, operating hours: 35,000 h, functionality: fully functional, Charmilles robofil 440cc Year 2004 In very good condition, still in production Fgjdpfx Ajxb Dzfofpoh

Condition: refurbished (used), Year of construction: 2017, functionality: fully functional, GF MachiningSolutions CUT E350 Year of manufacture: 2017 Control: AC CUT HMI Travel distances (X/Y/Z): 350 x 250 x 250 mm Travel distances (U/V): +/- 45 mm Taper: +/- 30° at 77 mm height Workpiece dimensions: 820 x 680 x 250 mm Max. workpiece weight: 400 kg Collision protection on X/Y/Z axes Best surface finish on carbide/steel: 0.12/0.18 µm Maximum cutting speed: 300 mm²/min Fodpfexbzimsx Afpegh Overall dimensions: 1750 x 2470 x 2200 mm Total weight: 2525 kg The machine is cleaned, overhauled, and tested by us after receiving your order. We are happy to perform a test cut tailored to your needs. Optional services: - Commissioning and training - Transport - Warranty - Cooling unit

Condition: good (used), Travel on X axis (longitudinal) 400 mm Travel on Y axis (transverse) 250 mm Travel on Z axis (vertical) 400 mm Max. workpiece length 850 mm Max. workpiece width 500 mm Max. workpiece height 400 mm Max. workpiece weight 1000 kg CNC type CHARMILLES Fedpfx Afjxbm Uzopsgh Tank length 1200 mm Tank width 700 mm Tank height 400 mm Plant closure sale: various machines, accessories, cutting tools, tool holders, vices. Please call for contact; no replies to OLX messages. Prices are net and open to reasonable negotiation. 1. Bench drill press 2. Jungner surface grinder 3. SPC 20 surface grinder 4. Surface plate (layout table) 800x500 5. MAHO 800 6. 2D dividing head, diameter 300 mm 7. 3D dividing head, diameter 300 mm 8. Tesa 700 height gauge 9. Charmilles 200 die sinking EDM 10. Charmilles Drill 11 die sinking EDM 11. Metal bandsaw

Condition: excellent (used), Year of construction: 2001, functionality: fully functional, machine/vehicle number: 930088, Country of manufacture: CH Voltage: 400V / 50/60Hz / 3ph. Net weight (machine + control cabinet): 3,250 kg + 400 kg Customs tariff number: 8456.30 20 Dimensions: 260 x 281 x 225 cm TECHNICAL SPECIFICATIONS Fgjdpsw Ucyusfx Afpjh Machining type: immersion Maximum workpiece dimensions: 1200 x 700 x 400 mm Maximum workpiece weight: 1,500 kg Table size: 900 x 600 mm Floor to table distance: 900 mm Total dielectric volume: 1,200 L Axes X, Y, Z, U and V Travel on X, Y, Z axes: 550 x 350 x 400 mm Travel on U, V axes: 550 x 350 mm Anti-collision protection: X, Y, Z, U, and V axes Taper cutting, max. taper: +/- 30° / 400 mm Available wire diameters: Ø 0.25 mm (options: 0.1/0.2/0.3 mm) Wire guide type: closed diamond, gapless Available spool weights and types (DIN standard): 1.6 kg (K 100) to 8 kg (K 160) Available spool weights and types (JIS standard): 3 kg (P3) to 5 kg (P5) Dielectric Paper filters: 2 cartridges Dielectric temperature: +/- 1°C Total deionization resin volume: 20 L Maximum injection pressure: 20 bar Generator: dual Isopulse source Power supply: 380/400V 3-phase Total power: 10 KVA Maximum cutting speed: 400 mm²/min Minimum surface roughness: 0.20 micron Ra Measuring system: glass linear scales Measurement resolution: 0.5 micron Servo motors: AC type Unless otherwise stated, technical specifications are provided without commitment and subject to error or omission.

Condition: good (used), Year of construction: 2005, functionality: fully functional, machine/vehicle number: 10947, Wire EDM ONA AE 300 YEAR 2005 MACHINE DISCONNECTED AS OF TODAY Fgodpfx Ajw R Arpjfpjh

Condition: excellent (used), Year of construction: 2002, operating hours: 34,000 h, functionality: fully functional, Agie Excellence 2F, year 2002. Machine in excellent condition. Can be inspected at our premises in Semsales, Switzerland. Fgodpfxsw N Taze Afpjh

Condition: used, Year of construction: 1998, EDM machine Charmilles Robofil 4020 SI, year of manufacture 1998 Fsdpfx Afjw E Evuspsgh

Condition: used, Year of construction: 2003, Wire erosion / EDM Travel distance X: 350 mm Travel distance Y :250 mm Travel distance Z: 256 mm max. workpiece size X: 750 mm Fgedpfx Aew Ekr Ijfpoh max. workpiece size Y: 550 mm max. workpiece size Z: 250 mm max. workpiece weight: 450 kg with AWF ( Automatic Wire Feeding )

Condition: used, Year of construction: 1999, For sale: Agie Agiecut evol.2 wire EDM machine, year of manufacture 1999. Fodpfjw D Sqpox Afpsgh

Condition: used, Year of construction: 2004, The machine we would like to offer you is an Agie Hyperspark 2 from 2004. The machine is very well maintained and has received annual AGIE/GF service. Operating hours: 122,829 h and eroding hours: 23,101 h. Fjdpfew D Hcyex Afpjgh

Condition: refurbished (used), Year of construction: 2013, functionality: fully functional, workpiece weight (max.): 400 kg, travel distance X-axis: 350 mm, travel distance Y-axis: 250 mm, travel distance Z-axis: 250 mm, total height: 2,200 mm, total length: 2,500 mm, total width: 2,500 mm, workpiece height (max.): 250 mm, workpiece width (max.): 680 mm, workpiece length (max.): 900 mm, overall weight: 3,000 kg, The GF AgieCharmilles CUT 20P, manufactured in 2013, is a high-performance, precise used wire EDM machine specifically engineered for demanding applications in the metalworking industry. Thanks to advanced technology and intelligent control, the CUT 20P delivers outstanding cutting quality, minimal maintenance requirements, and excellent return on investment. Main Features & Advantages: ✅ Compact design: Workpiece dimensions: max. 900 x 680 x 250 mm Maximum workpiece weight: 400 kg Travel ranges X/Y/Z: 350 x 250 x 250 mm U/V: ± 45 mm Taper cutting up to ± 25° / 80 mm ✅ High-precision machining: Positioning accuracy via glass scales Automatic wire tensioning for consistently precise cuts Surface finish quality up to Ra < 0.25 µm ✅ Efficient wire system: Wire diameter: 0.15–0.30 mm Automatic wire threading and re-threading 25 kg wire spool for extended operating periods ✅ Intelligent control & user-friendly operation: Windows-based control system with intuitive user interface 15” LCD display for easy programming DXF import & 3D graphic check for precise simulations ✅ Reliability & low operating costs: Energy-efficient generator with low power consumption (9 kVA) Low maintenance costs due to robust construction and durable wear parts Integrated collision protection for maximum safety Ideal for: ✔ Tool & mould making ✔ High-precision components ✔ Series production & prototyping Achieve maximum productivity with the GF AgieCharmilles CUT 20P – The optimal choice for precise and cost-effective wire EDM! Fgedpfxjw Dn Rls Afpeh 📌 Our used machine from 2013 is professionally cleaned, overhauled, and thoroughly tested prior to sale in order to ensure the highest quality and reliability. 📩 Contact us for a tailored quote or to arrange a demonstration! We are also happy to offer commissioning and on-site training on the machine.

Condition: used, Year of construction: 2003, functionality: fully functional, Controller FANUC 180 iS-W X travel 320 mm Fodpfxjw Afyzj Afpogh Y travel 220 mm Z travel 180 mm U travel 120 mm V travel 120 mm Rapid speed (X,Y,Z/U,V) 900 mm/min / 450 mm/min Max size of wpc. = L x W x H = 600 x 400 x 180 mm Max weight of wpcs. 500 kgs Dimensions of dielectricum tank = 800 x 600 x 470 mm Power required 13 kVA Weight 1200 kgs

Condition: used, Year of construction: 2008, operating hours: 5,900 h, travel distance X-axis: 350 mm, travel distance Y-axis: 220 mm, travel distance Z-axis: 220 mm, Wire Diameter 0,1-0,3 mm Automatik Threading Fjdpewzyr Ajfx Afpogh Working Hours 5900 Std Verfahrwege X 350 mm Y 220 mm Z 220 mm U 350 mm V 220 mm Year 2008

Condition: refurbished (used), Year of construction: 2006, functionality: fully functional, AGIECUT Excellence 2F eCUT Year of manufacture: 2006 Travel paths (X/Y/Z): 350 x 250 x 256 mm Travel paths (U/V): +/- 70 mm Maximum taper: 30° at 100 mm Maximum workpiece dimensions (length/width/height): 750 x 550 x 250 mm Maximum workpiece weight (with/without bath): 200/450 kg Best achievable surface finish: 0.1 µm Ra Max. cutting rate in cylindrical cut: 300 mm²/min Fsdpfxowwr H Re Afpegh Available wire diameters: 0.07 – 0.33 mm Includes AGIE universal clamping frame Includes AGIE JOGGER handbox Includes console with 4x USB ports Includes AGIE-Setup 3D The machine has been cleaned, overhauled and thoroughly tested by our technicians. We are happy to offer commissioning and training as well.

Condition: refurbished (used), Year of construction: 2004, functionality: fully functional, workpiece weight (max.): 450 kg, travel distance X-axis: 350 mm, travel distance Y-axis: 250 mm, travel distance Z-axis: 256 mm, total height: 2,220 mm, total length: 1,640 mm, total width: 2,040 mm, workpiece height (max.): 250 mm, workpiece width (max.): 750 mm, workpiece length (max.): 550 mm, empty load weight: 2,580 kg, Equipment: documentation/manual, AGIECUT Progress 2 Year of manufacture: 2004 Travel path: X = 350 mm, Y = 250 mm, Z = 256 mm Fedewvqk Sspfx Afpogh U/V-Axis travel path: +/- 70 mm Maximum taper angle: 30° at 100 mm height Maximum workpiece dimensions: 750 x 550 x 250 mm Maximum workpiece weight: 200 kg (submerged) / 450 kg (dry) Achievable surface quality: Ra: 0.30 µm Maximum cutting speed: 500 mm²/min Glass scales on X and Y axes for increased precision Available wire diameters: 0.20 – 0.33 mm Submerged wire EDM machine with automatic wire threading and re-threading after wire breakage Manual front door (accessible from one side) Including AGIEJOGGER handbox for convenient setup AGIE IPG generator with power module AGIEVISION control system Dimensions (L x W x H): 1640 x 2040 x 2220 mm Net weight: 2580 kg Our machines are cleaned and thoroughly overhauled upon receipt of an order. A test cut with optimal surface finish is performed for final approval. We are happy to offer on-site commissioning and training. Optional: - Transport - Chiller unit - Clamping devices

Condition: used, Year of construction: 1993, travel distance X-axis: 320 mm, travel distance Y-axis: 220 mm, travel distance Z-axis: 116 mm, workpiece height (max.): 150 mm, workpiece width (max.): 990 mm, workpiece length (max.): 505 mm, table width: 420 mm, table load: 500 kg, Equipment: cooling unit, documentation/manual, Taken out of production in working condition, removed due to the purchase of a new machine. The machine is currently disconnected and dismantled in our warehouse. All cables are numbered and photographed; these can be shared after payment for the machine to ensure correct installation at the new location. Fgedpfowu Shpex Afpsh

Condition: excellent (used), Year of construction: 1999, functionality: fully functional, workpiece weight (max.): 70 kg, wire diameter (max.): 10 mm, type of input current: three-phase, input frequency: 50 Hz, Equipment: cooling unit, OMEGA CM43 Submerged EDM The OMEGA CM43 submerged EDM is still connected and working perfectly. This machine achieves the highest precision and is an ideal choice for smaller workshops. Working area (mm) 500 x 350 x 300 Electrode size (mm) 100 x 100 x 100 Capacity (kg) 70 Electrode mass (kg) 10 Axis travel: X430, Y320 mm dieletric tank: T4 model power supply: 50A Omega Pulse If you need more information. We are here to help! Please contact us using the contact form or give us a call Your ad has been automatically translated. Translation errors are possible. Fgjdpewr Utisfx Afpoh

Condition: excellent (used), Year of construction: 2001, EDM drilling machine Sodick K1BL, year of manufacture 2001 Description: XYZ: 120 x 150 x 300 mm Table: 200 x 250 Workpiece dimensions: max 240 x 290 x 95 Workpiece weight: max 50 kg Electrode diameter: 0.08 – 0.25 mm Distance spindle housing to table: 60-220 mm Required space: 2700 x 2900 mm Fgedpfxjwqg Ebj Afpsh

Condition: refurbished (used), Year of construction: 2007, functionality: fully functional, travel distance X-axis: 350 mm, travel distance Y-axis: 250 mm, travel distance Z-axis: 256 mm, AGIECUT Challenge V2 Year of construction 2007 Travels (X/Y/Z): 350 x 250 x 256 mm Travels (U/V): +/- 70 mm Maximum taper: 30° at 100 mm Maximum workpiece dimensions (length/width/height): 750 x 550 x 250 mm Maximum workpiece weight (with/without bath): 200/450 kg Fsdswqcm Uopfx Afpogh Best achievable surface: 0.2 µm Ra Available wire diameters 0.10 - 0.33 mm Incl. AGIE universal clamping frame Incl. AGIE JOGGER handbox Incl. console with USB connection The machine will be cleaned, overhauled and tested by us upon receipt of order. We are also happy to offer commissioning and training.

Condition: excellent (used), Year of construction: 2023, Electrode changer: X-Axis Travel (mm): X-Axis Travel (mm): X-Axis Travel (mm): CNC Type: Worktank length: Fgedpfxjwnfcgj Afpsh Worktank width: Worktank height: Table length: Table width: Max. workpiece length: Max. workpiece width: Max. workpiece height: Max. workpiece weight (kg): Max. machining current (A): Length x width x height: Weight (kg): Worked power hours: The technical data and illustrations are not binding. They are not warranted characteristics and are subject to change.
