Cnc lathe

HAAS ST-20

Year of construction: 2019, operating hours: 3,728 h, condition: ready for operation (used), Control Unit Brand HAAS Model NGC Main Drive Spindle speed range 4000 rpm Spindle bore 88.9 mm Number of axis 3 Nlsdpfsxq Htiex Afxoh Movement X-Axis Movement 213 mm Y-Axis Movement 51 mm Z-Axis Movement 572 mm This 3-axis HAAS ST-20Y was manufactured in 2019, featuring a chuck size of 210 mm and a maximum turning diameter of 298 mm. It includes a hydraulically controlled tailstock, automatic tool probe, and a chip conveyor. With a spindle speed up to 4000 rpm and driven tools with a C-axis, consider the opportunity to buy this HAAS ST-20Y horizontal turning machine. Contact us for more information about this machine. Application Types Turning

Condition: like new (used), Year of construction: 2023, operating hours: 800 h, functionality: fully functional, machine/vehicle number: SN3128158, turning diameter over cross slide: 533 mm, turning length: 572 mm, spindle bore: 63 mm, spindle speed (max.): 4,000 rpm, New condition + tooling + bar fender Nodpfx Asvwz T Ujfxjlh

Year of construction: 2019, operating hours: 3,934 h, condition: ready for operation (used), Control Unit Brand HAAS Model NGC Main Drive Nlodpfx Afsxqiarjxjh Spindle speed range 4000 Spindle motor power 14.9 kW14.9 kW Movement X-Axis Movement 213 mm Y-Axis Movement ±51 mm Z-Axis Movement 572 mm Media Chip conveyor Yes Additional Equipment ATP – Automatic tool probe Install Kit – Bar feeder installation kit with adapters for bar diameters 9–44 mm / Programmable, pneumatically operated finished part catcher (max. part dimensions: 108 mm x 54 mm, max. weight: 2.27 kg) CONVEYOR – Chip conveyor (belt type) LINER ADAPTER 2.00 – Haas liner adapter for spindle with bar diameter 2" (51 mm) HAAS Bar Feeder – Compatible with HAAS lathes (ST-10 to ST-35), for automatic bar feeding LT-6K-UP – Option to increase the speed of driven tools up to 6000 rpm PCAT – Pneumatic part catcher, programmable, for parts up to 96 mm x 152 mm PTS – Hydraulic tailstock This 3-axis HAAS ST-20Y was manufactured in 2019. A robust horizontal turning machine, it offers reliable performance for precision machining. Consider the opportunity to buy this HAAS ST-20Y horizontal turning machine. Contact us for more information. Application Types Turning

Year of construction: 2014, operating hours: 5,316 h, condition: ready for operation (used), Main Drive Spindle speed range 4000 Spindle bore 52 mm Number of axis 3 Movement X-Axis Movement 213 mm Y-Axis Movement ±51 mm Z-Axis Movement 572 mm Nedpfxoxn Uzps Afxolh Turret Tool taper VDI/BOT Tools Number of station 12 This 3-axis HAAS ST-20Y was manufactured in 2014. It features a CNC lathe with C and Y-axis capabilities, a spindle speed of 4000 rpm, and a chuck size of 8 inches. Additional features include a 12-station turret, chip conveyor, and a programmable hydraulic tailstock. Ideal for precision turning operations. If you are looking to get high-quality turning capabilities consider the HAAS ST-20Y machine we have for sale. Contact us for more information about this machine. Application Types Turning

Year of construction: 2019, operating hours: 11,111 h, condition: ready for operation (used), Control Unit Brand HAAS Model n/a Main Drive Spindle speed range 4000 rpm Nedpfx Afew Nb R Usxslh Additional Equipment Additional Options: Driven 4000 rpm tool and C-axis, 12 stations BMT65, Automatic tool presetting arm Features: Hinged belt chip conveyor, Lathe parts catcher Coolant System: 208l coolant tank, Variable coolant flow Other Features: Visual part programming system (1GB), Hydraulically actuated 210mm chuck A2-6, Early detection module for power failure, Synchronized tapping, safe running, Control touchscreen, Ethernet, HaasConnect, HaasDrop, M130, WLAN Additional Features: Macros, SOM This HAAS ST-20 was manufactured in 2019. A robust horizontal turning machine featuring a 210mm hydraulically actuated chuck, a VDI turret with 12 tool stations, and a spindle speed of 4,000 rpm. It supports a maximum load of 330 x 572 mm and bar diameters up to 64 mm. Ideal for precision turning operations. Contact us for more information about this machine. Application Types Turning

Year of construction: 2021, operating hours: 6,500 h, condition: ready for operation (used), Control Unit Brand HAAS Model na Main Drive Spindle speed range 3500 Number of axis 2 This HAAS ST-20 was manufactured in 2021. A robust horizontal turning machine featuring a HAAS control unit, likely the Next Gen Control, and a maximum spindle speed of 3500 rpm. It comes with a tailstock and includes tool holders and tools. With approximately 6500 operating hours, consider the opportunity to buy this HAAS ST-20 horizontal turning machine. Contact us for more information about this machine. Application Types Turning Nledpewt Em Asfx Afxeh
