Wide-belt sander

HEESEMANN EH52.13 Lw/Lk Bw

Condition: reconditioned (used), Year of construction: 1987, functionality: fully functional, machine/vehicle number: 9673240, grinding width: 1,100 mm, power: 15 kW (20.39 HP), height adjustment type: electric, grinding belt length: 1,900 mm, compressed air connection: 6 bar, grinding belt width: 1,120 mm, Combination sanding unit with contact roller and air sanding pad Brush roller Pneumatic sanding belt tensioning Motorized thickness adjustment Technical data max. working width 1100 mm max. workpiece thickness 150 mm min. workpiece thickness 3 mm Sanding belt dimensions 1900 x 1120 mm Feed speed 5/10 m/min. Motor power sanding unit 15 kW Motor power height adjustment 0.50 kW Motor power feed carpet 0.5/1.0 kW Operating pressure 6 bar Air consumption approx. 20 l/min Suction nozzle 2 x 200 mm Weight approx. 2100 kg Machine width approx. 1750 mm Machine depth approx. 1700 mm Machine height approx. 1900 mm Ppodpfx Afjtppzvopjp

Year of construction: 1997, condition: good (used), - Working width (mm): 1300 - CSD system - Cross sanding unit Ppsdoidi Ivspfx Afpep - Longitudinal sanding unit - Shoe - Brush unit - Ionization

Condition: used, Supply air unit type 3072 A 7300/3650 m³/h, max. heating capacity 83 kW, hot water 90/70 °C. Exhaust air unit type 72 7000/3500 m³/h. Storage location: Nattheim. Pjdpjw I A N Ajfx Afpopp

Condition: excellent (used), Year of construction: 2003, total height: 2,950 mm, total length: 3,300 mm, total width: 1,350 mm, Complete clean air extraction system with briquette press and piping with sliders etc. Extraction system for woodworking companies with a briquette press underneath. Extraction system ALKO Type: MOBIL-JET 250 Year of manufacture 2003 Extraction diameter 250 mm Rated output 4900 m³/h Motor output 6.5 KW Dimensions approx. 330 x 135 x 2.95 cm With extraction control for automatic slider control. Briquette press WEIMA/ALKO Type: APC30S Year of manufacture 2007 Motor output 5.5 KW Pressing capacity 30 - 50 kg/h Briquette diameter approx. 50 mm Incl. complete piping with branches, bends, sliders. There is another item of suction pipes with fittings available that can be purchased cheaply. The system has been dismantled and packed ready for loading. Ppjdpfxjvr S Ncj Afpep See pictures for condition, or refer to the item description. Parts can also be picked up yourself. All dimensions are approximate. All information is provided to the best of our knowledge but without guarantee. Subject to prior sale. The items can be picked up yourself or shipping is at the buyer's expense. Shipping costs are a guideline and may vary depending on distance and unloading options. The stated sales price is the net final amount plus VAT. An invoice with VAT identification will be issued.

Condition: used, Year of construction: 2008, machine/vehicle number: 0-411-49-1873, Technical data:- Manufacturer: Bütfering - Type: Optimat SGO 211/RC - Number of grinding units: 2 - Year of manufacture: 2008 - Working width: 1.100 mm - Grinding belt width: 1.120 mm - Grinding belt length: 1.900 mm - Workpiece thickness: 3-160 mm - Feed speed: 2,5-13 m/min. - Table height adjustment Standard equipment: - Automatic workpiece thickness adjustment - Stepless feed speed via requency converter. - 125 grinding programs can be stored - Wear-free braking system 1. Grinding unit (R) - Calibration roller - Profiled steel contact roller - Diameter 160 mm - Drive motor: 15 kW 2nd grinding unit (C) - Combination unit with roller and grinding shoe - Rubberized contact roller 65 Shore - Contact roller diameter 160 mm - Electronic link pressure bar with segment Ppsdeyh Hwuspfx Afpop width 35 mm. - Belt speed: 12 and 21 m/s - Tolerance compensation up to 1 mm - Suitable for veneered surfaces and solid wood. - Drive motor: 11 kW - Total connected load: approx. 28 kW - Operating voltage: 400 V / 50 Hz. - Compressed air consumption at 6 bar, 20 L/min. - Belt blow-off device per pressure surge 440 L/min. - Extraction volume: approx. 2,880 m3/h/ at 20 m/s - Extraction connection: Dedusting: 1 x Ø 160 mm (grinding unit, roller) 1 x Ø 160 mm (grinding unit, shoe) Dimensions: - Length: 1,700 mm - Width: 1,850 mm - Height: 2,100 mm - Location: not in stock - Available from April 2026

Condition: used, Year of construction: 2001, Abrasive belt length, 1st unit: 2150 mm Max. working width: 1300 mm Number of belts: 3-belt 1st unit: Cross belt design 1st unit: Cross belt sanding shoe 1st unit: Electronic segmented shoe Abrasive belt width, 1st unit: 150 x 4800 mm Ppedexzi S Nepfx Afpsp Drive, 1st unit: kW 2nd unit: Longitudinal roller design 2nd unit: Steel calibrating roller Abrasive belt length, 2nd unit: 2150 mm Abrasive belt width, 2nd unit: 1350 mm Abrasive belt speed, 2nd unit: 18 m/sec 3rd unit: Shoe unit design 3rd roller: Electronic segmented pressure beam SDS Sy Sanding shoe, 3rd unit: Electronic individual segments, 32 mm width Abrasive belt length, 3rd unit: 2150 mm Abrasive belt width, 3rd unit: 1350 mm Suitable for lacquer sanding: Yes Belt blow-off: Yes Vacuum conveyor belt: Yes Feed speed, fixed: stepless 5-15 m/min Control: Touchscreen control Electr./pneum. belt oscillation: electric Infeed height: variable (lower table runs) Table stroke: electro-motor Digital table display Working height or feed table height: 880 mm Location: Nattheim

Condition: reconditioned (used), Year of construction: 2003, functionality: fully functional, briquette diameter: 60 mm, Refurbished machine suitable for smaller, single-shift carpentry operations. It offers a robust construction while providing solid performance. Maximum briquette output: 70 kg/h. Year of manufacture: 2003. In very good and well-maintained condition. Original warranty and post-warranty service available directly from our company. Professional PRODECO hydraulic briquetting presses are ideal for small and medium-sized woodworking operations. They enable efficient processing of waste into environmentally clean, high-calorific fuel without the need for binders. These machines are characterized by compact space requirements, low energy consumption, and easy operation. Technical specifications: - Motor power: 5.5 kW - Briquette output: 35 to 70 kg/h (depending on material) - Briquette diameter: 60 mm - Briquette stroke length up to 60 mm (so-called endless briquette) - Hopper diameter: 1000 mm - Weight: 650 kg - Machine dimensions: 1170 x 1700 x 1510 mm Features: - Hydraulic unit with 7 pressing cycles/min - Dual manometer for improved pressure monitoring - Level sensor for the height of briquetted material Ppsdpfxovva Rpo Afpep - Oil level sensor - Inspection window - CE safety standard compliant - Moisture content of processed material must not exceed 18% The machine is refurbished, calibrated, and tested.

Condition: used, Year of construction: 1985, Used machine Year of manufacture: 1991 Plate size: 2200 x 1100 mm Equipped with Busse aluminum energy-saving plates (The spots visible in the photos are purely optical; the plates are in perfect condition) Psdox Enp Ropfx Afpopp Total pressing force: 80 t Press cylinders: 4 x 90 mm Opening stroke: 400 mm Weight approx. 3,100 kg Overall length: 2,610 mm Overall width: 1,240 mm Overall height: 1,890 mm Motor power connection: 1.1 kW Connection per electric heating plate: approx. 6.6 kW Weight approx. 3.1 t Availability: short notice Location: Röllbach

Condition: good (used), Year of construction: 2001, • Sanding width (mm): 1100 • Workpiece thickness (mm): 3 - 150 • Total sanding units: 1 • Longitudinal belt: 1 • Calibration roller • Cleaning brush: 1 x diameter = 120 mm • Vacuum table • Intermediate lacquer sanding • Constant table height • Carpet cleaning • Longitudinal unit, motor: 15 kW, 1.8 - 18 m/s • Feed rate: 3 - 11 m/min. • Sanding belt length (longitudinal unit) (mm): 1,900 x 1,120 • Pressure beam: CSD system, electromagnetic, wear-free Pedpfxeww Iate Afpspp • Availability: checked, in stock

Condition: refurbished (used), functionality: fully functional, Refurbished automatic wide belt sander suitable for solid wood calibration and sanding of veneered panels. The Sandya belongs to the compact range of automatic wide belt sanders from SCM, known for its exceptionally robust and rigid machine frame and excellent sanding quality. 2 sanding units with 11 kW motor each 1. Calibration roller: steel 2. Sanding roller: semi-hard rubber with pneumatic pad — with lifting and lowering function Sanding width: 920 mm Working thickness: 3–160 mm 2 feed speeds: 4.5 and 9 m/min Motorized adjustment of working thickness with digital display Ammeter for motor load monitoring Air consumption: 200 l/min Extraction requirement: 3000 m³/h Table extensions Pneumatic belt oscillation Dimensions (WxDxH): 1460 x 1700 x 1750 mm Weight: 1100 kg Excellent technical condition Czech manual available Ppsdjvxt D Iopfx Afpjp The machine has been fully refurbished, adjusted, and tested.
