Centerless grinding machine

HERMINGHAUSEN SR40 III CNC

Condition: used, O F F E R We can offer you ex stock, subject to prior sale and errors: TSCHUDIN (CH) Centerless cylindrical grinding machine Model TC-300 Year of manufacture 2001 Grinding range – Ø 0.5 – 25 mm (30) Max. workpiece length for plunge grinding 125 mm (140) Max. workpiece length for through-feed grinding 300 mm Grinding wheel dimensions: Ø x width Ø 300 x 125 mm (140) Regulating wheel dimensions: Ø x width Ø 225 x 125 mm (140) Grinding wheel peripheral speed 35 m/sec Grinding wheel infeed 3 mm Regulating wheel speeds, steplessly adjustable 0 – 444 rpm Regulating wheel inclination Degrees Psdpfx Amjwftt Uoxegt Grinding wheel drive approx. 7.5 kW Total connected load approx. 13 kW – 380 V – 50 Hz Weight 2,500 kg Accessories / Special equipment: • The machine operates with a fixed workpiece position, allowing both the grinding spindle and the regulating spindle units to be adjustable. This simplifies machine setup as well as automatic workpiece loading and unloading. • SIEMENS PLC control for automatic operation with SIEMENS touchscreen. Complete electrics and PLC control renewed in 2016! • Electromechanical profile dressing device for the regulating wheel • Regulating and grinding wheel speeds are steplessly adjustable. • Adjustable plunge guide bridge with mounted plunge workpiece rest • Electromechanically controlled workpiece pusher & automatic pneumatic workpiece ejector • Additional outfeed cylinder for automatic tilting of workpieces after plunge grinding (adjustable 4–30 mm) • Machine is prepared for use with a HELP-TEC bar loader MSHL08/400P, which is currently not present. • Complete enclosure of working area with monitoring technology • Separate control cabinet, operating and electrical manuals for the retrofit Condition: Very good! Fitted with new electronics in 2016! Click here for a video of the machine: Delivery: ex stock, immediately available, FCA Metzingen Payment: strictly net – after receipt of invoice Always a large selection of grinding machines in stock – please inquire for your requirements!

Condition: reconditioned (used), functionality: fully functional, Herminghausen SR2 High-precision and conventional centerless cylindrical grinding machine. The machine is suitable for grinding workpieces up to 40 mm in diameter. High machine and grinding stability due to a robust cast iron bed and hydrodynamic segmental chuck bearing. Its low height provides excellent access to all important functions. Quick and easy changeover for different workpieces and materials. Overhauled: July 2026 Workpiece diameter: 0.5 - 40 mm Grinding wheel dimensions (D x W x H): 290 x 100 x 150 mm Regulating wheel dimensions (D x W x H): 200 x 100 x 120 mm Total weight: 1,200 kg Pgedpjzpf H Sofx Amxst Total power: 5.5 kW / 400 V / 50 Hz

Condition: used, Year of construction: 1980, weight of the machine ca. 6 t Podpfjxzu Ayox Amxegt

Condition: ready for operation (used), Year of construction: 1993, number of axes: 3, This 3-axis GHIRINGHELLI M300SP610 CNC3A was manufactured in 1993. It features a grinding wheel diameter of 610 mm and a maximum wheel speed of 35 m/s. The machine is equipped with an automatic loading and unloading system, enhancing productivity. If you are looking to get high-quality centerless grinding capabilities, consider the GHIRINGHELLI M300SP610 CNC3A machine we have for sale. Contact us for further details. Pgodpsy S A T Dofx Amxot • Installed Power: 54 kW • Grinding Wheel Diameter: 610 mm • Max Wheel Speed: 35 m/s • Precision Correction Capability: 0.5 micron • Machine Configuration: Converted from plunge grinding to through-feed grinding • Automatic loading system with elevators • Automatic unloading system SIRIO • Piece conveyor around machine back to loading zone • Full mechanical overhaul: 2009 / 2010 • Guideways revised: 2018 • V-axis screw replaced: 2021 • Electrical Data: • Voltage: 380 V • Frequency: 50 Hz • Auxiliary Circuits: 110V / 24V • Line Current: 100 A • Coolant: • No standalone coolant filtration tank included • Connected to seller centralized coolant system • Currently operational • Main machine mass: 10200 kg • Electrical cabinet mass: 470 kg • Very good condition
