HERMLE c40u

HERMLE c40u

Condition: good (used), Year of construction: 2003, For technical data, see images.... Isdox R S R Nepfx Ahuetb

Condition: used, Year of construction: 2007, functionality: fully functional, machine/vehicle number: 18780, travel distance X-axis: 850 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 500 mm, rotary table diameter: 800 mm, spindle speed (min.): 18,000 rpm, Technical Details: Used Universal Machining Centre HERMLE C 40U DYNAMIC Control: HEIDENHAIN iTNC 530 X-travel: 850 mm Y-travel: 700 mm Z-travel: 500 mm NC rotary swivel table: Ø800 mm 6-way rotary feedthrough Spindle speed: 18,000 rpm Air blast through spindle center Tool holder: HSK-A 63 Iedpfx Ahjx Ecmhjuotb Tool magazine: 38 positions Internal coolant supply: 80 bar Handwheel HR-410 Total power consumption: 41 kVA Machine weight: approx. 10.5 t Equipment/Features - Paper band filter - Coolant system - Chip conveyor - Sealed air for scales - Heidenhain infrared probe - Blum A2 laser tool measurement system - 3D Quick Set - Electronic handwheel

Condition: used, Year of construction: 2006, x-travel 850 mm y-travel 700 mm z-travel 500 mm Control HEIDENHAIN iTNC 530 rotary table 800 mm c-axis 0.001º ( ±360º) 0 B-axis (table) º mm number of spindle speeds 18.000 U/min/rpm tool taper SK 40 DIN 69871 spindle drive 15 kW Iodpsxrvldjfx Ahuotb max. torque on the spindle 130 Nm Tools changer 38 fach/tools Internal cooling system 80 bar handwheel HR- 410 total power requirement 41 kVA weight of the machine ca. 10,5 t Equipment- Paper belt filter – 200 l tank- Active control cabinet cooling- Infrared probe M&H (Heidenhain)- Laser tool measuring system Blum- Chip conveyor- Cleaning pistol with pump 2 bar / 40 l min- 3D Quick Set- Electronic handwheel
