Universal Milling Machine

Hermle UWF 900 W

Condition: excellent (used), Year of construction: 2010, functionality: fully functional, Tool Milling Machine Kunzmann WF4/3 with Heidenhain TNC 320 CNC Control – Excellent Condition, CE-Compliant, from Training Workshop! Technical Specifications: • Year of manufacture: 2010, Machine No. 347283 • Fixed angular table • Infinitely variable spindle speed up to 4,500 rpm • Infinitely variable feed in 3 axes from 0 to 2,000 mm/min • Rapid traverse X and Y axis: 5,000 mm/min Z axis: 4,000 mm/min • Travel X/Y/Z: 400/350/400 mm • Table size: 650 x 350 mm • Table load capacity: 250 kg • Vertical quill stroke: 60 mm • Vertical and horizontal quill – SK40 taper • Hydraulic clamping system • Weight approx. 1,800 kg • Space requirement approx.: 2.3 x 2 x 2 m • Drive power: 15 KVA Accessories and Equipment: Fjdoxuppuspfx Agmeft • Heidenhain TNC 320 CNC control • Hydraulic clamping, vertical and horizontal • Automatic central lubrication • Spindle brake • Technical documentation, spare parts diagrams, control manuals and programming examples • Handwheels • Coolant system • Electronic handwheel HR410 About the Machine: Offered for sale is a Kunzmann WF4/3 tool milling machine with Heidenhain TNC 320 CNC control. This universal milling machine is in excellent condition and has seen very few operating hours. It comes from a facility where it was used exclusively for training purposes. The control is very user-friendly. Additionally, the machine features hydraulic clamping both vertically and horizontally. Changing from vertical to horizontal operation is very straightforward by swinging away the vertical head. The ways are regularly lubricated via the central lubrication system. The Kunzmann has been mechanically and electrically inspected by us. You are welcome to view and test the Kunzmann on-site under power. There are 7 units of Kunzmann WF4/3 with the TNC 320 Heidenhain milling machines available. The machines are available immediately.

Condition: excellent (used), Year of construction: 2004, functionality: fully functional, Tool milling machine Kunzmann WF7/3 with Heidenhain TNC 310 path control Very good CONDITION CE-compliant!! Technical data: >> Year of manufacture 2004 Machine No. 370506 >> Milling table clamping surface 800 x 425 mm Ffjdpewpkchofx Agmet Clamping slots 6 Slot width 14 H 7 Slot distance 63 mm Maximum load 300 kg >> Speeds up to 4500 rpm >> Feed range up to 2000 mm/min. Rapid traverse up to 5000 mm/min. >> Travel distances X/Y/Z: 600/400/400 mm >> Vertical quill and horizontal quill - SK40 >> Hydraulic drawbar system >> Weight approx. 2000 Kg >> Dimensions approx.: 2 x 2 x 2 m >> Main drive motor: 5.5 KW Accessories and equipment: >> Heidenhain TNC 310 path control >> Hydraulic clamping vertical and horizontal >> Automatic central lubrication >> Spindle brake >> Electronic handwheel >> Heidenhain probe >> Technical documentation, spare part diagrams, operating manual >> Full protection cabin >> Coolant system About the machine: A Kunzmann WF7/3 tool milling machine with a Heidenhain TNC 310 path control is being offered. This universal milling machine is in very good condition. A very easy-to-use control system. Furthermore, the machine has hydraulic clamping both vertically and horizontally. Switching from vertical to horizontal is very simple thanks to the fold-away vertical head. The guides are regularly lubricated by the central lubrication system. The Kunzmann has been mechanically and electrically tested by us. Take the opportunity to view and test the Kunzmann on site under power.

Condition: good (used), Year of construction: 1990, CNC Universal Milling Machine MAHO MH600-C Control MAHO 432 with universal clamping table . Spindle holder : ISO 40 Fedourcybopfx Agmjft Travels : X 600 mm Y 400 mm Z 500 mm Spindle speeds up to 2 000 rpm with work area enclosure Machine documentation available . Machine from tool shop in good clean general condition Ready for demonstration under power .

Condition: used, Dimensions (HxWxD) 1700x1020x800 mm Fsdpfx Agswqg Sujmsft

Condition: new, 8 St. range L-W-H 710 x 510 x 900 mm weight 67 kg Schubladen schrank mit 8 Schubladen Schubladenabmessung 600 x 435mm Ffodpfx Aevblhqogmet Schubladenhöhe: Lade 1 - 8, 81mm

Condition: excellent (used), Year of construction: 2010, functionality: fully functional, Kunzmann WF4/3 Tool Milling Machine with Heidenhain TNC 320 Contouring Control – Excellent Condition, CE-compliant, from a Training Workshop!! Technical Data: >> Year of manufacture: 2010, Machine No. 347247 >> Fixed angle table >> Infinitely variable spindle speed up to 4,500 rpm >> Infinitely variable feed on 3 axes from 0 to 2,000 mm/min >> Rapid traverse X and Y axis: 5,000 mm/min Z axis: 4,000 mm/min >> Travel X/Y/Z: 400/350/400 mm >> Table surface: 650 x 350 mm >> Table load capacity: 250 kg >> Vertical quill stroke: 60 mm >> Vertical and horizontal quill - SK40 >> Hydraulic tool clamping system >> Weight: approx. 1,800 kg >> Space requirement: approx. 2.3 x 2 x 2 m >> Drive power: 15 KVA Accessories and Features: >> Heidenhain TNC 320 contouring control >> Hydraulic clamping for vertical and horizontal axes Fjdpfxexupc Us Agmeft >> Automatic central lubrication system >> Spindle brake >> Technical documentation, spare parts diagrams, operating manual for the control, and programming examples >> Handwheels >> Coolant system >> Electronic handwheel HR410 About the Machine: Offered here is a Kunzmann WF4/3 tool milling machine equipped with a Heidenhain TNC 320 contouring control. This universal milling machine is in excellent condition, with very few operating hours. Previously used exclusively for training purposes, it features a highly user-friendly control system. The machine offers hydraulic clamping for both vertical and horizontal operation. Conversion from vertical to horizontal milling is extremely easy via the tilting vertical head. Guideways are continuously lubricated via the central lubrication system. The Kunzmann has been mechanically and electrically inspected by us. You are welcome to view and test the Kunzmann machine under power at our facility. A total of 7 Kunzmann WF4/3 milling machines with TNC 320 Heidenhain controls are available. The machines are immediately available.

Condition: good (used), Year of construction: 2001, feed length X-axis: 600 mm, feed length Y-axis: 400 mm, feed length Z-axis: 400 mm, CNC milling machine KUNZMANN - WF7/3 X-Axis: 600mm Y-Axis: 400mm Z-Axis: 400mm Table Length:650mm Fodpfx Agswq Ndgomjft Table Width: 400mm Table load: 250 Stroke pinole:40mm Length: 2800mm Width: 2400mm Height: 2100mm Weight: 2000kg

Condition: used, Offer 35504 Technical data: - 7 pieces of ball-bearing drawers, each 90% extendable - Drawer size approx.: W 510 x D 600 mm each - Drawer heights: 1 x H 85 mm; 1 x H 65 mm; 5 x H 125 mm - No key available - Required cabinet space approx.: W 650 x D 700 x H 1020 mm - Weight: 80 kg Ffsdpfx Agjwzvlfjmjt

Condition: excellent (used), Year of construction: 2010, functionality: fully functional, Kunzmann WF4/3 Tool Milling Machine with Heidenhain TNC 320 Path Control – Excellent Condition, CE-Compliant, from Training Workshop! Technical Data: - Year of manufacture: 2010 Machine No. 347284 - Fixed angular table - Spindle speed: Infinitely variable up to 4500 rpm - Feed rate: Infinitely variable in 3 axes from 0 to 2000 mm/min - Rapid traverse X and Y axes: 5000 mm/min - Rapid traverse Z axis: 4000 mm/min - Travel distances X/Y/Z: 400/350/400 mm - Table surface: 650 x 350 mm - Table load: 250 kg - Vertical quill stroke: 60 mm - Vertical and horizontal quill – SK40 - Hydraulic clamping system - Weight approx. 1800 kg - Overall dimensions approx.: 2.3 x 2 x 2 m - Drive power: 15 KVA Accessories and Equipment: - Heidenhain TNC 320 path control - Hydraulic clamping vertical and horizontal - Automatic central lubrication - Spindle brake - Technical documentation, spare parts diagrams, control operating manual, and programming examples Fsdpfx Aexupdlsgmjft - Handwheels - Coolant system - Electronic handwheel HR410 About the Machine: For sale is a Kunzmann WF4/3 tool milling machine equipped with a Heidenhain TNC 320 path control. This universal milling machine is in excellent condition and has very low operating hours. It comes from a facility where it was used exclusively for training purposes. The control system is very user-friendly. Additionally, the machine offers hydraulic clamping both vertically and horizontally. Conversion from vertical to horizontal operation is very straightforward thanks to the folding vertical head. The guides are regularly lubricated by the central lubrication system. The Kunzmann has been mechanically and electrically tested by us. Take advantage of the opportunity to inspect and test the Kunzmann under power on site. Seven units of the Kunzmann WF4/3 with TNC 320 Heidenhain milling machines are available. The machines are ready for immediate delivery.

Condition: excellent (used), Year of construction: 2002, Used CNC tool milling machine Year of manufacture: 2002 Control manufacturer: Heidenhain Control type: TNC 426 Working area: X: 400 mm Y: 350 mm Z: 400 mm Ffedpfexz Rkyex Agmjt Clamping surface: 650 x 350 mm (fixed table) Milling spindle tool holder: SK40 Spindle speed range: 5 – 5000 rpm Feed rate: 0–2 m/min Tool changer: none Accessories: Standard, chip tray, handwheel & documentation including declaration of conformity and data backup
