Heuft InLine IXs reflexx Empty Bottle Inspector

Heuft EBI (Leerflascheninspektion)

Condition: used, Year of construction: 2013, Overview The Heuft InLine IR – high speed empty bottle inspector is characterized by its compact installation dimensions. High-speed inspection of empty bottles is easily possible (up to 50,000 bottles/h). It can perform all standard inspections (sidewall inspection, infeed inspection, neck finish inspection, base inspection, discharge inspection, HF caustic and IR residual liquid detection). In addition, it has a separate module for foreign bottle detection (height, contour, color). In 2016 it was overhauled and modified installed including conveyor control. Tech Specs: Capacity: 5,000 – 50,000 bottles / h Compact installation dimensions 2016 overhauled and modified Features: Processes all standard inspections: sidewall, infeed, neck finish, bottom, discharge, HF caustic and IR residual liquid detection Separate module for foreign bottle detection (height, contour, color) Iodpjukafrefx Ac Hjbf

Condition: used, maximum load weight: 31,420 kg, overall weight: 39,000 kg, axle configuration: 3 axles, first registration: 01/2023, next inspection (TÜV): 01/2026, loading space volume: 32 m³, total width: 2,550 mm, total height: 3,750 mm, Year of construction: 2023, Equipment: ABS, 3-axle KA?SSBOHRER food pressure tank 3-chamber 32,000 liters with diesel heating and UNIBLOCK pump First registered 01/ 2023, as good as new Fifth wheel height approx. 1,180 mm Empty weight approx. 7,580 kg VA tank AISI 304 3-chamber with division 12,500 / 7,500 / 12,000 liters Insulation 100 mm glass wool, jacket sheets stainless steel mirror sheet, end floor GRP Ijdpfx Acop R Drgs Hsbf Pneumatic bottom valves DN80 3 INDIVIDUAL OUTLETS insulated, ending in the rear cabinet with collector 3 = 1 UNIBLOCK food pump type 551M2 stainless steel, electric motor 7.5 kW, with frequency converter Tank diameter 2,000 mm Test foot pressure 3.0 bar Operating pressure 2.0 bar 3x dome cover DN 500 with overflow box Stainless steel cleaning/air line DN50 with microfilter Diesel tank heater EBERSACHER Hydronic 30 kW Stainless steel hose pipes left and right, length approx. 6 meters Chassis stainless steel BPW axles with large disc brakes, 430 mm 1st axle LIFT AXLE KNORR Trailer EBS with stability program RSS Air tank aluminum Tires 6-fold 385/65 R 22.5 BRIDGESTONE Aluminum rims RENT is the new BUYING, also available immediately with us in full-service rental-----

Condition: used, Year of construction: 2009, Overview  This empty bottle inspector was built in 2009 by the German manufacturer Heuft and is still in operation until the end of October. The machine is available as it is being converted to a new inspection solution as part of a line modernization. The system includes the Heuft InLine reflexx Release 9 empty bottle inspector, the Heuft Spectrum SX TB 72 pre-sorter and the associated Heuft Gateway II for network connection. Interested parties have the opportunity to view the inspection line in operation by prior arrangement. Technical details Output: up to 72,000 bottles per hour Year of construction: 2009 Bottle types that can currently be processed: 0.33 l ale / green / crown caps 0.33 l ale / brown / crown cap 0.50 l NRW / brown / crown cap 0.50 l NRW / clear / screw cap 0.50 l Euro / brown / crown cap 0.33 l Krombacher-Bügel / brown / with embossing 0.50 l swing top / brown Control functions: Pre-sorting (Heuft Spectrum SX TB 72): Bottle shape Bottle height Inspection (Heuft InLine reflexx Release 9): Side wall inspection (inlet & outlet) Mouth & thread inspection Bottom inspection Residual liquid detection (IR/HF) Label residues in the neck area Test bottle detection Scope of delivery Heuft InLine reflexx Release 9 Heuft Spectrum SX TB 72 (pre-sorting) Heuft Gateway II (network connection) Rejection table and piece of infeed and outfeed conveyor Rejection of defective bottles Iodpfxswr Aado Ac Hobf

Condition: used, Year of construction: 2006, Overview  The Heuft InLine TI 60 BFS2-r is an inspection system for empty PET bottles that was manufactured in 2006. With a maximum output of 36,000 bottles per hour, the machine is ideal for the efficient inspection and quality control of empty bottles in filling lines. The empty bottle inspector is equipped with several rejections and a wide range of accessories. Technical details  Output: Up to 36,000 bottles/hour Location: Germany Installation location: In front of the filler Immediately available Inspection functions  Bottom inspection: 1st bottom-IN-r Mouth inspection: Mouth-IN-r Side wall inspection: 1. sidewall-IN-r 2nd side wall IN-r Side wall with double resolution-r Support ring inspection: PET-r Abrasion inspection: RefPet Abrasion-r Ventslot inspection: RefPet Ventslot-r Stress crack detection: Stress Crack Detection-r Residual liquid detection: IR Rejection and adjustment options  Rejection: mono-X, DELTA-K-X Inlet control: mono-X Height adjustment: For rejections Cross adjustment: For rejections Accessories  Height-adjustable transport belts Cooling units for base housing and side wall Mouth outlet Ibodpfxsu Scr Ej Ac Hsf

Year of construction: 2000, condition: ready for operation (used), Compressed air supply: 6-12bar, running direction: right to left, inspection of: 2x sides, bottom, opening, 2x thread, residual liquid (HF and IR). Ibjdpfxjfgwtfo Ac Hsf

Condition: used, Year of construction: 2011, Overview  This Heuft Glas InLine reflexx IR is an inspection machine for empty bottles, designed for quality control in filling lines. The machine has a maximum output of 46,000 bottles per hour and was originally delivered in December 2011. It is in very good condition and ready for use at short notice. The flow direction is from left to right and it is equipped with a Secomak blower instead of a compressed air blow-off system. Technical details  Output: Maximum 46,000 bottles/hour Flow direction: Left to right Equipment: Two triggers Secomak blower Transponder recognition for RFID test bottles Rejection monitoring Heuft HLAN network (can be retrofitted as an option) Two-way rejection Delta K to the right Four type licenses Delta K tripods for belt height of 1130 mm Two fluids for lye detection Missing components Infeed control (must be added if required) Thread blow-off (must be added if required) Documentation (not available, can be replaced) Controls  Monitoring of the incoming bottle flow (optional) Output of a stop signal if bottles are too high, too wide or lying down Inspection of the bottle base Inspection of the mouth sealing surface Inspection of the thread Inspection of the inner and outer side wall Detection of conductive liquids (e.g. lye) Detection of residual liquids (e.g. oils, paints) using IR technology Rejection of faulty containers or output of a rejection signal Monitoring of the rejection process Iodpfx Aceu N Snke Hsbf

Condition: used, Year of construction: 2018, Overview The crater was manufactured and taken into operation in 2018 by the German company Sema Maschinenbau GmbH. Till now it was used in a filling line for fresh milk in glass bottles in a German dairy company. The line capacity was 7,700 bph. As the request for milk in bottles was increasing during the lat year, the owner decided to purchase a new line with increased capacity. Therefore this machine has become available. The machine is still in very good condition, as it is still young and only with a low number of operating hours.   Tech Specs: Capacity: 695 crates (of 12 bottles) per hour  1333 crates (of 6 bottles) per hour Formation: 2x3 (1l bottle) 4x6 (0,5l bottle) Gripper heads: for wide bottle neck (can be adapted)     Ijdpel Hx Dmofx Ac Hsbf

Condition: used, Year of construction: 2005, Overview The swing-top closing machine was manufactured by the Austrian manufacturer AMS in 2005. As the current owner has decided not to use swing-top closures anymore, this machine is for sale. Currently the machine is still installed in a brewery. Documentation is available. Tech Specs: Capacity: 12,000 bph Control: Siemens S7 Formats: 0,3 l 0,5 l Number of closing positions: 16 Documentation available Iodpjl Hxmpjfx Ac Hsbf

Condition: used, Year of construction: 2018, Overview  The crater was used in a Belgian brewery and was stopped in Summer 2024. It was used to put 330ml bottles with mechanical closure into a wooden or plastic crate. Technical Details  Manufacturer: TMG Year of manufacture: 2018 Model: IEC 61439-2 Bottle Format: 330ml Crate format: 4x3 wooden or plastic crate Capacity: 8 cycles per minute Ibodpfsuhthtsx Ac Hof

Condition: ready for operation (used), Year of construction: 2004, Here is some information about the swing top bottle capper: Iedjxyux Ejpfx Ac Hebf - Current bottle format: Steinie 0.33 l. The machine features height adjustment and can also accommodate other bottle sizes. - Year of manufacture: 2004 - Height adjustment available - Capacity: 12,000 bottles/hour The machine can be scheduled, installed, and commissioned by our team.
