Planer-type milling machine - double column

HEYLIGENSTAEDT Heynumill 3200-P CNC

Year of construction: 2016, condition: new, 1 piece reconditioned unused industrial bevel helical gearbox from ASUG. TGL 21815 All parts of the gearbox are renewed, except the housing !!! Claw coupling: 800 mm (only one half available) Maximum torque: 27.829 Nm Gear ratio: i= 1:80 max. power: 51 kW oil filling: 170 kg Speed: n1= 1400 Speed: n2= 17,5 weight: 1450 Kg Shaft diameter d1: 65mm Shaft diameter d2: 160 mm Shaft height h1: 500 mm Hsdogwlrdopfx Ad Hoff Total height h2: 925mm Length from base: 1170 mm !! Gearbox has no oil cooler !

Condition: used, Year of construction: 1976, cone distance min./max. 0/108 mm Pitch angle min/max 5°/84° Pitch diameter (1:1 ratio) 152 mm pitch diameter (10:1 ratio) 216 mm Diametral pitch (finest/coarsest) 1.3/8.5 Mod. Face width gear wheel max. 35 mm speeds: 98-286 weight of the machine ca. 6577 kg dimensions of the machine ca. 1560 x 2140 x 2200 mm Equipment/accessories: -Cutting tools Hfsdjyh Rmtepfx Ad Hof -Spacer angle -Technical documentation

Year of construction: 1971, condition: used, Technical details: max. wheel diameter: 300 mm max. module: 5 module min. : 0,5 max. workpiece weight: 60 kg weight of the machine ca.: 4,0 t dimensions of machine: 1800x1850x2500 mm dimensions electric cabinet: Nr. 1: 1930x400x1920 mm dimensions electric cabinet: Nr. 2: 800x230x1950 mm dimensions:: Abluftanlage: 1400x700x560 mm dimension cooling device LxWxH: 1,2 x 1,0 x 0,45 m Hfedpfevc Apbox Ad Hef Electronically controlled tooth flank grinding machine up to module 5 and a Ø of 240 - 300 mm feed speed per workpiece revolution infinitely variable 0.4 - 3.2 mm max./min. Number of teeth: 130 / 12 max./min. Pressure angle: 30° / 14°30` max./min. Spiral pitch with 24 teeth: 6000 / 200 mm max. tooth helix angle, both sides: 45° Speed of the grinding worm: 1900 rpm without dressing device Equipment: approx. 77x change transmission wheels, pipe extensions and various tools Two of these machines are for sale. Both machines are supplied via two common control cabinets and an exhaust air system. *

Condition: excellent (used), The HURTH MODUL ZSTK 251 bevel gear planing machine was designed as a special machine and is used by manufacturers of drive systems in the drive technology, automotive, agricultural machinery, machine tools, mining technology, aviation and textile machinery sectors for the gear shaping of straight-toothed bevel gears with a short run-out. We still have 1 of these machines in stock, which, in conjunction with the Klingelnberg BF 203 bevel gear milling machine, can also produce crowned bevel gear sets in high quality. Technical data Workpiece diameter: 315 mm Hjdpfx Asup T Rled Heff Module max.: 10 mm Tooth width: 45 mm Dimensions: 2.7 x 2.3 x 2.1 m Weight: 7,000 kg *Information and data are non-binding and subject to prior sale Viewing under operating conditions possible after consultation.

Condition: excellent (used), Year of construction: 2006, operating hours: 53,244 h, functionality: fully functional, Technical Data – Gleason Phoenix II 600HC (CNC Hypoid Gear Cutting Machine) Working Area Max. workpiece diameter: Ø 600 mm Max. tooth depth: 24.6 mm Hsdpfjxwzu Isx Ad Hjff Max. gear width: 110 mm Number of teeth: 1–300 Cutterhead size face milling (FM): 18" diameter Cutterhead size hobbing (FH): 210 mm radius Max. cutter spindle speed: 600 min⁻¹ Work Spindle Front taper diameter: Ø 203 mm Taper bore diameter: Ø 181 mm Bore depth: 884 mm Max. work spindle speed: 600 min⁻¹ Dimensions and Weight Footprint L × W × H: 4.4 × 3.5 × 3.5 m (incl. peripherals) Machine weight: 26,000 kg Connection Data Total connected load: 139 kVA Main fuse: 200 A Operating voltage: 400 V Mains frequency: 50 Hz Control voltage: 24 V DC

Condition: used, cone distance min./max. 0-108 mm Pitch angle min/max 5°/84° Control GE Fanuc Series 0-GC Pitch diameter (1:1 ratio) 152 mm pitch diameter (10:1 ratio) 216 mm Diametral pitch (finest/coarsest) 1.3/8.5 Mod. Face width gear wheel max. 35 mm Knife spindle - Speed range 41-121 U/min working spindle speed range 0-33.33 U/min weight 9025 kg dimensions of the machine ca. 2707 x 2720 x 2200 mmxmmxmm Equipment/accessories: -Knife -Chip conveyor -Technical documentation Hjdpfx Adoyh Rmmo Hjff

Condition: good (used), Year of construction: 1992, functionality: fully functional, machine/vehicle number: 68910, workpiece weight (max.): 5,100 kg, wheel width: 180 mm, grinding wheel diameter: 330 mm, helix angle: 45 °, rotational speed (min.): 1,100 rpm, rotational speed (max.): 1,900 rpm, type of input current: AC, wheel diameter: 10 mm, gear diameter: 330 mm, overall weight: 5,100 kg, total height: 2,300 mm, total length: 6,000 mm, total width: 4,500 mm, Wheel diameter - max. 10 - 330 mm Wheel width 180 mm Module - max. 7 Module - min. 0.5 Clamping length 420 mm Number of teeth 10 - 600 Helix angle - max. +/- 45° Speed 1100 - 1900 rpm Grinding wheel diameter 280 - 350 mm Grinding wheel width 84 - 104 mm Machine weight approx. 5.1 t Hfedpoykrmcjfx Ad Hjf Required space approx. 4.5 x 6.0 x 2.3 m Grinding oil filtration unit Reishauer AF

Condition: used, Year of construction: 1988, functionality: limited functionality, gear diameter: 320 mm, workpiece weight (max.): 10,000 kg, total height: 2,000 mm, total length: 2,900 mm, total width: 2,000 mm, workpiece diameter (max.): 320 mm, Straight bevel gear machines type 5C267P, made Stanko in 1988 year, completed, need starting works for electric and hydraulic part. Slightly used, mechanical part in good condition. Available for sale two pieces. Price is 35000 Euro for 1 machine. Hfedpfsykmdiox Ad Hsf

Condition: ready for operation (used), Year of construction: 2011, functionality: fully functional, CNC Spiral Bevel Gear Cutting Machine Hfedpfx Adew Tfb Sj Hsf Gleason No 631 Year of manufacture: 2011 Control: SIEMENS 840d Retrofitted in 2011/2012 with new control, drives, etc. The machine was fully overhauled in 2011. A new control system and drives were installed.

Condition: ready for operation (used), functionality: fully functional, One used CNC gear grinding machine OERLIKON Opal 800 Max. tip diameter: 1000 mm Hfodpfx Adeyucd Hs Hef Min. root diameter: 40 mm Min. module: 1 Max. module: 16 Number of teeth: 999 Max. gear width: 630 mm Opal grinding wheel and diamond disk Only single profile grinding possible, see photo.
