Swivel spindle milling machine

Hofmann TFS 107

Condition: new, Year of construction: 2025, functionality: fully functional, power: 7.5 kW (10.20 HP), height adjustment type: electric, Tiltable spindle moulder HOFMANN TFS 107 Basic equipment: 7.5 kW motor, 400 V, 50 Hz, table size 1,200 x 815 mm, heavily ribbed cast iron table, with table rings Electronic starting and braking device Electric height and swivel adjustment in rapid and creep speed accurate to 1/10, height adjustment approx. 145 mm, swivel adjustment +/- 45.5° 4 speeds 3,000/4,500/6,000/9,000 Milling fence type 2601 Efficient with multiplex fence jaws Fixed milling spindle Ø 30 mm with "fix" quick-release nut left/right rotation, machine socket, arc milling guard type TAPOA, Hofmann "Centrex". Paint finish: gray-white/signal blue Electrical connection value: Motor power 7.5 kW - Minimum fuse (A) slow blow 30 Additional equipment installed in this machine: - Table size 2000 x 815 mm with extendable support by 480 mm, instead of standard table Ppedju Nz Ndspfx Afpjp - Infinitely variable speed control TFS 107 from 1,500 to 10,000 rpm incl. 7.5 kW motor, instead of standard motor with soft start - HOFMANN milling fence type 2620 instead of standard fence 2601 Efficient Total adjustment via handwheel according to display incl. option to switch to tool zero dimension. Digital display for individual jaw adjustment. Including quick clamping system for the fence jaws - 2 cast iron fence jaws 500/500 mm - Guide rails and fillet board, consisting of 5 rulers, 1 fillet board, 10 sliding blocks - Control panel upwards - Tool compartment for TFS 107 (only possible with top console) - Operating instructions TFS 107 German

Condition: new, Year of construction: 2024, TECHNICAL DATA Table size 1100 x 760 mm table height 870 mm milling spindle not interchangeable 30 mm clamping height 140 mm height adjustment 125 mm suction socket 2 x Ø 120 mm speed 3000 / 4500 / 6000 / 9000 rpm Colour RAL 7035 light grey and RAL 5000 violet blue Net weight approx. 800 kg TECHNICAL DESCRIPTION Solid German mechanical engineering Table milling machine with one-sided swivelling fixed milling spindle for swivelling range from -5° to +45.5 Positioning control for height and swivel adjustment with zeroing of the height and offset measurement travel Electronic position and speed displays 4 speeds 3000 / 4500 / 6000 / 9000 rpm Belt quick tensioning device Push button for spindle start and stop Left and right rotation Cutter quick clamping device Fine planed cast iron table with rigid frame support Control panel at the bottom of rigid frame support Milling stop 216 total adjustment via handwheel and LCD display incl. cast stop plates and aluminium splitter tongues Machine socket Lockable main switch Mechanical motor brake Milling protection and pressure device GAMMA V 1629 Curved milling fence 1639 Tapoa Milling spindle 30 mm, not exchangeable CE-conform GS tested Pedpfx Afjfpb Nmepepp

Year of construction: 2003, condition: reconditioned (used), longitudinal saw for cutting boards 4 meters main engine 400V, 7.5kW - blade feed motor 400V, 2.2 kW - extending the pneumatic saw - working pressure 6bar - cutting length 4020 mm - cutting height approx. 170mm - machine length 5.5 m - machine width 1.6 m Podohbp T Sjpfx Afpspp

Condition: excellent (used), Year of construction: 2016, functionality: fully functional, Fixed shaft Extended tables both left and right Ppsdpfx Ajw Rftisfpsp Aigner integral fence Maggi Steff 2034 Power feed unit

Condition: excellent (used), Technical data: Max planing width: 230 mm Max planing height: 130 mm Spindle diameter: 40 mm Number of spindles: 5 1, 4, 5 spindle on a separate engine 2, 3 spindle on one engine Number of upper steel pulling rollers: 4 Number of upper rubber pulling rollers: 3 Diameter of the extraction nozzle: 100, 110, 140 mm Smooth feed adjustment: Feed on cardans Work table lubrication pump 1 smooth roller in the table top Pressure: 6 atm. Electric lifting of the body Power supply: 400 V Total power: 35 kW Overall dimensions: Length: 4860 mm Width: 1640 mm Ppodpfjv Tyg Ejx Afpsp Height: 1670 mm

Condition: used, used, good condition Make Steton Type SC 400 / 3200 CE type tested Motor boosted 6.5 kW Trolley length approx. 3200 mm Cutting width approx. 1300 mm max. blade diameter 400 mm swiveling up to 45° scoring unit parallelogram protection control panel above Rip fence with electrical adjustment Table top extension approx. 400 x 800 mm Electric height adjustment Swivel adjustment electric Digital display: - cutting angle - Rip fence - Rotational speed Extraction connection D 120 / 60 mm Space requirement approx. LxWxH mm Ppsdpfx Afovyt D Djpop 3400x2300x1700 Weight approx. 1000 kg Storage location 97447 Gerolzhofen Handover in the current condition as seen - free loaded -

Condition: used, Year of construction: 1993, machine/vehicle number: 315 AE 0643 V 02 85, ACMA DM82 – Single-Blade Rip Saw (Délingeuse monolame) The ACMA DM82 is a robust French single-blade rip saw for professional longitudinal splitting of boards and strips in sawmills and woodworking shops. Featuring hydraulic feed and INRS safety approval (Visa No. 315 AE 0643 V 02 85) from 1993, it is ideal for precise wood cutting up to 160 mm height. Cutting length: 4000–5200 mm Cutting height: 140–160 mm Cutting width: 370–600 mm Saw blade Ø max.: 600 mm (min. 450 mm) Saw motor power: 9–13.2 kW (12–18 HP), 380 V 3~ RPM: 3000 rpm Hydraulic motor: 2.2 kW Table height approx.: 820 mm Ppedjyrnxkepfx Afpsp Dimensions (L×W×H): 4800–6600 × 1500–2300 × 800–1500 mm Weight: approx. 1350 kg

Condition: used, Tilting Blade Circular Saw (for precise angled cuts) Sliding table: 3800 mm Electric adjustment for blade lifting and tilting Cutting capacity Cutting width between blade and parallel guide: 1250 mm Cutting height with Ø 450 mm blade (90°): 155 mm Cutting height with Ø 450 mm blade at 45°: 115 mm Blade tilt: 0° – 45° Main blade Max blade diameter: Ø 450 mm Blade shaft diameter: 30 mm Rotation speed: 3200 / 4000 / 6000 rpm Main motor power: 5.5 kW (7.5 HP) Dust extraction Extraction outlet: Ø 120 mm Scoring unit Podpfxeywt Ago Afpjpp Scoring blade diameter: Ø 125 mm Scoring shaft diameter: 20 mm Rotation speed: 8000 rpm Scoring motor power: 0.5 kW (0.75 HP)

Condition: as good as new (ex-display), Year of construction: 2025, Spindle tilting: Yes, 0 to 45° Height adjustment: Electric / Position control Swivel adjustment: Electric / Position control Milling stop adjustment: Electric / Position control Milling jaw adjustment: Manual / Handwheel Height display: Digital display Swivel angle display: Digital display Milling stop display: Mechanical counter Aigner integral stop: Yes Milling spindle diameter: 30 mm Speeds: 3000, 4500, 6000, 7000, 10000 Motor power: 7 kW Motor brake: Yes, automatic Extraction connection: 2 x 120 mm Machine length: 2599 mm Machine depth: 900 mm Weight: 655 kg Pedpswhuvcjfx Afpopp
