Premilling unit

Holz-Her

Condition: excellent (used), Year of construction: 2011, functionality: fully functional, Working range X: 6000 mm Working range Y: 1400 mm 4-axis electro-spindle, power 16 kW Fixedly installed saw blade Fixedly installed clamping unit Vertical drilling bits: 18 Horizontal drilling bits X: 6 Horizontal drilling bits Y: 2 Pick-up tool changer, 1 position Linear tool changer, 16 positions Linear tool changer, 6 positions Circular tool changer, 18 positions Worktable with 10 rails WS10 "MultiClamp" frame clamping device Software: Campus Crodpfey Um Nzjx Afwei Manual control panel for remote operation 250 m3/h vacuum pump Safety mats Includes 2 aggregate heads (1 Vario NC and 1 with 4 horizontal outlets) and suction cups Only 943 operating hours Available February 2027

Condition: excellent (used), Year of construction: 2005, functionality: fully functional, Cutting length: 4250 mm Cutting depth: 4250 mm Maximum blade overhang: 97 mm Maximum blade diameter: 350 mm Scoring unit Grooving function Cedpfe Ah Rzqjx Afwori Control: CUTCONTROL 2 Available starting in early February 2027.

Condition: ready for operation (used), Year of construction: 2015, functionality: fully functional, Equipment: CE marking, documentation/manual, Holzher Auriga 1308 XL Suitable for polyurethane coatings. Crodpfx Afj Ah Hi Iswei

Condition: not inspected (used), Year of construction: 1995, functionality: unexamined, power: 7.5 kW (10.20 HP), type of input current: three-phase, actuation type: electric, total height: 1,400 mm, total length: 5,200 mm, total width: 1,400 mm, overall weight: 1,500 kg, year of last overhaul: 2021, Edge gluing from 0.6 to 13 mm Cartridge gluing Crodpfxoz A Dhro Afwei Pre-milling Fine milling Cutting twice Pull knife Smoothing Year of manufacture is estimated Machine was stored a year ago Until that time, it was fully functional.

Condition: used, operating hours: 335 h, total height: 2,100 mm, total length: 6,500 mm, total width: 1,500 mm, Year of manufacture: 2009 Colour: White Weight: 2.200 kg - Year: 2009 - Documentation available: Yes - CE marking present: Yes - Serial number: 74 - Operating hours: 335 - Number of units [pcs]: 9 - └ 1st unit type: Pre-milling unit - - Type/Brand: 1856 - - Tools available: Yes Crjdpfxe Ahygns Afwoi - └ 2nd unit type: Glue unit - └ 3rd unit type: Pressure rollers - - Type/Brand: 1913 - - Tools available: Yes - └ 4th unit type: Cap unit - - Type/Brand: 1918 - - Tools available: Yes - └ 5th unit type: Rough milling unit - - Type/Brand: 1826 - - Tools available: Yes - └ 6th unit type: Corner rounding unit - - Type/Brand: 1833 - - Tools available: Yes - └ 7th unit type: Radius scraping unit - - Type/Brand: 1929 - - Tools available: Yes - └ 8th unit type: Flat scraping unit - - Type/Brand: 1964 - - Tools available: Yes - └ 9th unit type: Brushing unit - - Type/Brand: 1940 - - Tools available: Yes - Max. edge band thickness [mm]: 8 - Min. panel thickness [mm]: 6 - Max. panel thickness [mm]: 60 - Min. panel width [mm]: 60 - Min. panel length [mm]: 180 - Min. feed speed [m/min]: 10 - Max. feed speed [m/min]: 18 - Glue system: Glue pot - Type of glue: PUR - Voltage [V]: 400 - Current consumption [A]: 56.95 - Fuse [A]: 80 - Transport dimensions: 6500mm x 1500mm x 2100mm (l x w x h) - Transport weight [kg]: 2200kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: excellent (used), HOLZ-HER TRIATHLON 1486 V – Industrial Edge Banding Machine For sale: a professional, industrial single-sided edge banding machine from the German company HOLZ-HER, model TRIATHLON 1486 V. Identification data: Manufacturer: HOLZ-HER Model: TRIATHLON 1486 V Year of manufacture: 2003 Identification number: 172-0312 Machine number: M 109 Type: industrial single-sided edge banding machine Equipment and machining capabilities: pre-milling unit, gluing station, edge trimming units, cutoff saws, corner rounding unit, profile sanding unit, oscillating unit, polishing brushes, programmable control with operator panel. The machine is designed for industrial edge banding of furniture panels and carpentry elements. Technical condition: Crjde Ahlyrepfx Afwsi The machine is in good working order. It can be inspected before purchase.

Condition: ready for operation (used), Year of construction: 2020, machine/vehicle number: 210/2003, functionality: fully functional, operating hours: 6,635 h, power: 29 kW (39.43 HP), input voltage: 400 V, input current: 50 A, input frequency: 50 Hz, type of input current: three-phase, workpiece height (max.): 60 mm, workpiece width (max.): 3,000 mm, workpiece length (max.): 5,000 mm, edge thickness (max.): 3 mm, height adjustment type: electric, feed rate X-axis: 25 m/min, actuation type: electric, total height: 2,223 mm, total length: 9,420 mm, total width: 1,368 mm, overall weight: 4,350 kg, Equipment: CE marking, documentation/manual, HOLZ-HER ACCURA 1556 Premium – Year of manufacture 2020 – Very well maintained We are offering our HOLZ-HER ACCURA 1556 Premium edge banding machine, manufactured in 2020, for sale. The machine has always been treated with great care by its dedicated operator and has been fully maintained by the supplier throughout its entire service life. The machine has always been kept in excellent condition, and there have never been any major incidents or serious machine damage. Technical improvements and upgrades Reinforced pre-milling motors: The originally installed pre-milling motors were generally too light. Therefore, approximately two years ago, these were replaced with a heavier and improved type. These motors function excellently and represent a significant technical improvement compared to the original design. Automatically switchable profile milling cutters (factory option): The machine is equipped as standard with the option to automatically switch between the profile milling cutters with a radius of 1 mm (R1), a radius of 2 mm (R2), and chamfer milling cutters. This allows for easy and quick switching between different edge finishing operations without manual adjustment of the milling heads. Additional Riepe brush system: Riepe has installed an additional brush system specifically for cleaning and processing edge material with a deep surface texture. Condition and maintenance The machine has always been operated carefully, well maintained, and serviced according to the maintenance instructions by the supplier. Thanks to the consistent maintenance, careful operation, and implemented technical improvements, this is a well-maintained edge banding machine with extensive equipment. Codpfx Afs Ahhwzswsri The machine can be viewed and demonstrated in working order by appointment. If you are seriously interested, we will be happy to provide additional information and photos.

Condition: used, Year of construction: 2014, Processing length 3200 mm. Vertical machining center for drilling, milling, and grooving. Maximum flexibility and versatile applications with minimal space requirements. Modern industrial design, built with high-quality components, offering an optimal view of the machining process and perfect access to the tools. Machine frame in welded construction with ground and hardened prism guides. Ball screw spindles in the X, Y, and Z axes for precise positioning and perfectly fitting workpieces. Workpiece-friendly clamping system using vacuum cups with automatic cup positioning. Extremely short setup times. Workpiece fixing on the back allows machining of the entire circumference without additional re-clamping (up to workpiece lengths of 1300 mm). This ensures the fastest machining cycles and the highest accuracy. Program-controlled adjustment of workpiece thickness; material thicknesses from 8 to 70 mm are possible. 1 machining field with length stop. Material support. 1 roller track for supporting the workpieces downwards. 4 roller tracks for gentle support of sheet material. Height-adjustable infeed roller track for 4-sided milling. Complete finishing of the workpieces through precise milling of all 4 workpiece edges. Extraction: Machining head extraction with extraction nozzle Ø 120 mm and extraction nozzle in front of the drilling head Ø 140 mm, both leading upwards. Underfloor extraction with extraction nozzle Ø 120 mm; connection at the bottom on the left side or from the top of the machine. Safety guard according to CE standard. Enclosing guard with viewing window and safety interlock on the door. TECHNICAL DATA Workpiece size: X = 200 - 3200 mm (longer with additional support); Y = 70 - 920 mm. Material thickness: Z = 8 to 70 mm. Max. travel in X-direction without reclamping: X = 1500 mm. Z-travel: Z = 240 mm. Maximum programmable speed: Vector speed: 68 m/min; X = 25 m/min, Y = 60 m/min, Z = 20 m/min. MACHINE OPERATION / SOFTWARE CAMPUS V6 - Single Evolution. Software for CNC machines of the Evolution type with automatic generation of the division of workpieces for machining. 1 software license for the machine - secured via a license plug. Consisting of: 1. CAMPUS NC-HOPS; 2. CAMPUS aCADemy; 3. CAMPUS MT-Manager; 4. CAMPUS Workcenter; 5. CAMPUS process simulation. CAMPUS NC-HOPS: Graphical variant system with WOP and CAD/CAM features for creating part variants and macro technology. Csdpfe Ahhmbjx Afwjri CONTROL PC control. Remote maintenance: Integrated network card for data transfer of control and program data. Data transfer takes place via a high-speed internet connection. Requirement: High-speed internet connection at the machine. The use within the warranty period for warranty cases is free of charge. 19" flat screen for easy and clear machine operation. USB port for data backup or for direct input of machining programs at the control panel. DRILLING UNIT Drilling unit 7883, 15 spindles. Drive power 1.7 kW. 9 vertical spindles, individually selectable. Arrangement in L-shape, 5 in X and 4(5) in Y direction, 32 mm pitch. Max. drilling diameter: 35 mm. Total drill length: 70 mm from the mounting end (depending on plate thickness). Spindle extension stroke: 70 mm. Rotation direction: Alternating right/left. n(max.) 1000 - 4400 min-1, continuously adjustable. Mounting: M 10 thread - 11 mm smooth shank, without tool, without chuck. 6 horizontal spindles. 2 double drilling spindles in X direction. 1 double drilling spindle in Y direction. Mounting: M 10

Condition: used, Year of construction: 2009, HOLZ-HER edge banding machine CONTRIGA 1366 Edge thickness: 0.4-30 mm (depending on equipment) Edge height: 51/66 mm (depending on equipment) Panel thickness: 6-45/60 mm (depending on equipment) Edge types: Rolls and strips Feed speeds: Continuous feed from 12-30 m/min (depending on equipment) With adjustable infeed level in the magazine area (max. adjustment range 30 mm) With height-adjustable magazine plate for changing the lower edge overhang With large magazine plate Ø 820 mm for edge rolls up to Ø 800 mm With transport chain including automatic central lubrication With motor-driven, position-controlled bridge height adjustment With pneumatic locking roller for the shortest workpiece sequence With extendable workpiece support (extension width 1600 mm) With space-saving, pneumatically controlled sliding hoods over the entire machine (Deviations for individual units are possible) with motorized infeed guide with injection oiler for lubricating all joints and bolts (including operating hours counter) with central connection for extraction (2x Ø 200 mm) with integrated chip collection box at the end of the machine (when radius scraper unit is installed) PPC 231 control system - Power PC for efficient setup and changeover - 15" SVGA screen with touchscreen - 128 MB CF memory card - USB connector on board - Ethernet network connection - Keyboard connector on board - Windows-like user interface - all information in plain text and/or graphics - Rotatable and pivoting control panel at eye level - Dust-proof membrane keyboard with softkeys (pushbuttons) - LED display for unit preselection - Program list with program names and numbers - Extensive program memory - Individual selection of the units with the functions as basic setting options for setpoints, route points and tool corrections as well as the fixed route points - Centralized and clear setup processes for units and their axis settings via fine adjustment (depending on the equipment) - Interval display for the shortest workpiece distance - Integrated path control - Path points are controlled generally or program-specifically - Clear and complete recording of all operating data - Service messages in plain text - Diagnostic system - including integrated synchronous bus system for high precision in unit control - Individual administration for up to ten users, including password protection - Online maintenance (optional), data exchange with HOLZ-HER Service - Barcode interface (optional) BASIC MACHINE CONTRIGA 1366 - Belt bridge Options and accessories for the basic machine Spraying device 1856 for the inlet and outlet area For the inlet area: Electronically controlled release agent sprayer with Riepe-LPZ/II release agent For the outlet area: Electronically controlled cleaning agent sprayer with Riepe-LP163/93 cleaning agent (only in conjunction with pre-milling unit 1961 and surface scraper 1964) Joint milling unit Joint milling station 1803 (2x 2.6 kW, 200 Hz, 12000 min-1) With two plunge-controlled milling units 1 unit in up-cutting direction 1 unit in down-cutting direction Plunge path 5 mm With static frequency converter 200 Hz Without milling tool With ProLock screw-in clamp for fast tool changes Tool for 1803 (workpiece height up to 60 mm) Diamond milling cutter PRO UT 2 pieces (front and rear) including protective covers Ø 100-63 - Ø 30 mm, Z = 3 + 3 + 3, 1x left-hand rotation, 1x right-hand rotation Noise-reduced milling cutter with integrated chip guide DFC technology (Leitz syst Codpfsvvkfdjx Afweri

Condition: used, Year of construction: 2002, Machining dimensions (tool diameter 25mm): X=3015 mm Y=1483 mm Z=325 mm Max. travels: X=3268 mm Y=1483 mm Z=325 mm Max. programming speed: X/Y = 75 m/min / Z = 30m/min Tool holder HSK 63F Drilling unit 7964, 14 vertical drilling spindles with 32 mm grid (10 in x / 4 in y) Sawing unit 7946 3.6 kW, 90° pneumatically pivotable Milling unit 7933 9 kW Wood Her Vector axis (C-axis) Tool magazine (6 disk places) Hand control unit Laser device (positioning of the suction cups) PC control panel with 17" monitor Operating system Windows 2000 Software: TwinCAM32 - office version Vacuum pump 100 m³/h Dry running Selective safety mats (3-field division) Storage location: Nattheim Cjdpfevvi Nbox Afweri
