HS 850 Holzknecht forestry winch SET - 1 pc

Holzknecht

Condition: new, The new generation of winches from HOLZKNECHT features the classic design with a rope drum installed transversely to the direction of travel, enabling a large rope core diameter, a wide rope drum, and, in conjunction with a rope winding arm, a perfect rope spooling. - Low weight - Perfect rope spooling thanks to a rope distributor - Standard with proportional brake - Central PTO connection - Low drawbar pull loss due to the large drum core diameter - Transversely mounted rope drum (in the direction of the rope) - Two shield widths possible: 1,900 mm or 2,100 mm - Electro-hydraulic control with self-supply - Folding protective grid - Standard with Holzknecht tilt-stop system - Standard with Holzknecht radio system "AUTEC" proportional Pulling force: 7.7 tons Max. rope length: 100 m / 12 mm, 120 m / 11 mm (Recommended: 80 m / 12 mm) Rope inhaul speed: 26 m / min Shield width: 1,900 mm (2,100 mm optional) Height incl. protective grid: 2,440 mm Rope inhaul height: 1,350 mm Weight: 540 kg Ledpfo Adg Taex Ahaeah For tractors from: 50 kW

Condition: new, - Low weight - Perfect cable spooling thanks to cable distributor Lsdo Adg S Nepfx Ahasah - Hydraulic cable payout with cable infeed brake - Transversely mounted cable drum (in the direction of the cable) - Electro-hydraulic control with self-contained power supply - Folding protective grid - 80 m / 12 mm hammered cable incl. loop crimped with swivel hook - Loop crimped with swivel hook - Incl. Holzknecht Funk AuTec - Incl. Tilt Stop System Traction force 7.5 tons Max. cable length 8 m / 12 mm Ø Cable infeed speed 26 m/min Shield width 1,900 mm Cable infeed height 1,200 mm Weight 490 kg For tractors from 40 kW The expansion of the new Holzknecht winch generation in the classic design with a cable drum mounted transversely to the direction of travel enables a large cable core diameter (low loss of pulling power), a wide cable drum and, in conjunction with a cable winding arm, perfect cable spooling.

Condition: new, The expansion of the new winch generation from Holzknecht, featuring the classic design with a cable drum installed transversely to the direction of travel, enables a large cable core diameter (resulting in low traction power loss), a wide cable drum, and, in conjunction with a cable winding arm, provides perfect cable spooling. - 6.5 tons pulling force at the drum core - 4.5 tons pulling force at the top cable layer - Electro-hydraulic control with self-contained oil supply - Optimal price-performance ratio - Standard equipment includes Holzknecht radio remote control "Autec" - Standard equipment includes tilt-stop system - Standard equipment includes hydraulic cable payout with cable infeed brake - Drive via bevel gearbox with reinforced duplex roller chain with load-switching safety clutch and automatic brake - Three-point frame made of welded steel construction (steel ST 52) - Shield width 1,750 mm - Folding protective grille - Low weight of 440 kg - Clean cable spooling due to cable distributor - Transversely mounted cable drum (in the cable direction) - Low cable infeed, height of the cable infeed roller 1,200 m - Incl. forestry cable 80m/11mm, highly compacted, Flemish eye with swivel hook - Maximum cable capacity 100m/10mm or 85m/11mm - Incl. storage compartment, chainsaw & axe holder - Cable infeed speed 26 m/min - For tractors from approx. 30 kW Pulling force 6.5 tons Max. cable length 100m/10mm or 85m/11mm Cable infeed speed Lajdpfx Ahe Adg Sveash 26 m/min Shield width 1,750 mm Cable infeed height 1,200 mm Weight 440 kg For tractors from 30 kW Advantages of the hydraulic cable payout with cable infeed brake: 1. Cable payout at the push of a button 2. No overrun of the cable drum 3. Always cleanly spooled cable (even when lowering loads) 4. No cable pinching due to permanent pre-tension 5. Extreme reduction in workload 6. Extended cable life Radio remote control "Autec" - Functions: Pull, release, short release, throttle +/- , engine start & engine stop, switch for cable payout - Scope of supply: Transmitter incl. antenna, receiver, 230V+12V charger, hip belt for transmitter

Condition: new, 100m / 10-strand hammered rope Holzknecht Funk Standard The new generation of winches from HOLZKNECHT features the classic design with a rope drum installed transversely to the direction of travel, enabling a large rope core diameter, a wide rope drum, and, in combination with a rope winding arm, perfect rope spooling. Tractive force 6.6 tons Lasdpfx Ahj Adg S Ajaoh Max. rope length 100m / 11mm diameter Rope infeed speed 26 m/min Shield width 1,750 mm Rope infeed height 1,250 mm Weight 450 kg For tractors with 35 kW and above

Condition: new, - 5.0 tons pulling force at the drum core - 3.0 tons pulling force of the top cable layer - Electro-hydraulic control - Hydraulic cable payout with cable infeed brake - Optimal price-performance ratio - Standard equipment includes Holzknecht radio remote control "Autec" - Standard equipment includes tilt-stop system - Standard equipment includes chainsaw and axe holder - Shield width 1,500 mm - Low weight of 290 kg - Clean cable spooling Lsdpfx Ae Adg Spjhajah - Low cable infeed, height of the cable infeed roller 1,250 m - Height including protective grille 2,150 mm - Includes forestry cable 70 m / 10 mm, highly compacted, Flemish eye with swivel hook - Maximum cable capacity 80 m / 10 mm or 100 m / 9 mm - Cable infeed speed 33 m/min - For tractors from approx. 20 kW (Delivery without cable remote control! Available as an option) Advantages of the hydraulic cable payout with cable infeed brake: 1. Cable payout at the push of a button 2. No after-running of the cable drum 3. Always cleanly spooled cable (even when lowering) 4. No cable pinching due to permanent pre-tensioning 5. Extreme reduction of workload 6. Extended cable life Radio remote control "Autec" - Functions: Pull, release, short release, throttle +/- , engine start & engine stop, switch for cable payout - Scope of delivery: Transmitter including antenna, receiver, 230V + 12V charger, waist belt for transmitter

Condition: new, The new generation of Holzknecht winches features a classic design with a cable drum mounted transversely to the direction of travel, allowing for a large cable core diameter (resulting in minimal loss of pulling power), a wide cable drum, and, in conjunction with a cable winding arm, perfect cable spooling. - 5.5 tons pulling power at the drum core - 3.0 tons pulling power at the top cable layer - Electro-hydraulic control with self-contained oil supply - Optimal price-performance ratio - Standard equipment includes Holzknecht "Autec" radio remote control - Standard equipment includes tilt-stop system - Standard equipment includes hydraulic cable payout with cable infeed brake - Drive via bevel gearbox with reinforced duplex roller chain with load-switching safety clutch and automatic brake - Three-point frame made of welded steel construction (steel ST 52) - Shield width 1,600 mm - Folding protective grille - Low weight of 370 kg - Clean cable spooling through a cable spreader - Transversely mounted cable drum (in the cable direction) - Low cable infeed, height of the cable infeed roller 1,150 m - Includes forestry cable 80 m / 10 mm, highly compacted, with Flemish eye and swivel hook - Maximum cable capacity 100 m / 10 mm - Includes storage compartment, chainsaw and axe holder - Cable infeed speed 26 m/min - For tractors from approx. 20 kW Pulling force 5.5 tons Max. cable length 100 m / 10 mm or 85 m / 11 mm Cable infeed speed 26 m/min Lsdpfxs Adg Sij Ahajah Shield width 1,600 mm Cable infeed height 1,150 mm Weight 370 kg For tractors from 20 kW Advantages of the hydraulic cable payout with cable infeed brake: 1. Cable payout at the push of a button 2. No overrun of the cable drum 3. Always neatly spooled cable (even when lowering the load) 4. No cable compression due to permanent pre-tensioning 5. Significant reduction in workload 6. Extended cable life Radio remote control "Autec" - Functions: Pull, release, short release, throttle +/- , engine start & engine stop, switch for cable payout - Scope of supply: Transmitter including antenna, receiver, 230V+12V charger, hip belt for transmitter

Condition: new, - 4.5 tons pulling force at the drum core - 3.8 tons pulling force of the top cable layer - Mechanical cable winch control with dead man’s switch - Blade width 1,600 mm - Low dead weight of 280 kg - Clean cable winding - Low cable entry point, height 1,350 mm - Incl. 70m/11mm high-density cable, Flemish eye with swivel hook - Maximum cable capacity 100m/10mm - Cable winch speed 40 m/min - Suitable for tractors from approx. 25 kW Ljdpfx Ahj Adg Scsasah - No electro-hydraulic control possible Min. pulling force: 3.8 t For tractors from: 25 kW Cable winch speed: 40 m/min Weight: 280 kg Max. cable capacity/diameter: 100m/10mm Blade width: 1600 mm Max. pulling force: 5.5 t Height of cable entry roller: 1350 mm

Condition: new, - 5.0 tons pulling force at the drum core - 3.0 tons pulling force of the uppermost rope layer - Mechanical rope pulling control with dead man's switch - Shield width 1,500 mm - Low own weight of 210 kg - Clean rope winding - Low rope inlet, height 1,250 mm - Includes rope 70 m/10 mm, highly compacted, with Flemish eye and swivel hook - Maximum rope capacity 100 m/10 mm - Rope inlet speed 40 m/min - For tractors from approx. 20 kW - No electro-hydraulic control possible Max. pulling force: 5.0 t Laodpfx Ahj Adg R Sjaeh Min. pulling force: 3.0 t For tractors from: 11 kW Rope capacity/diameter: 80 m/10 mm Height of the rope inlet roller: 1250 mm Shield width: 1500 mm Rope inlet speed: 40 m/min Weight: 210 kg

Condition: new, - High-quality product from Austria - 4.5 tons pulling force at the drum core Ljdpe Adg R Eofx Ahaeah - 3.0 tons pulling force of the uppermost cable layer - Mechanical cable winch control with dead man's switch - Shield width 1,250 mm - Low weight of 170 kg - Clean cable spooling - Low cable entry point, height 1,200 mm - Incl. 60m/10mm high-density cable with Flemish eye and swivel hook - Maximum cable capacity 80m/10mm - Cable winch speed 40m/min - Suitable for tractors with approximately 10 kW and above - No electro-hydraulic control possible Max. pulling force: 4.5 t Min. pulling force: 3.0 t Suitable for tractors from: 10 kW Weight: 170 kg Height of cable entry roller: 1200 mm Shield width: 1250 mm Max. cable capacity/diameter: 80m/10mm Cable winch speed: 40 m/min

Condition: new, - High-quality product from Austria - 3.5 tons pulling force at the drum core - 2.0 tons pulling force of the top rope layer - Mechanical rope winch control with dead man's switch - Shield width 1,000 mm - Low weight of 155 kg - Clean rope spooling - Low rope inlet, height 1,150 mm - Incl. 60m/10mm rope, highly compacted, with Flemish eye and swivel hook - Maximum rope capacity 60m/10mm - Rope inlet speed 40 m/min - For tractors from approx. 10 kW Ledpfx Aho Adg Rxsaoah - No electro-hydraulic control possible For tractors from: 10 kW Weight: 155 kg Shield width: 1000 mm Min. pulling force: 2.0 t Rope capacity/diameter: 60m/10mm Max. pulling force: 3.5 t Height of the rope inlet roller: 1150 mm Rope inlet speed: 40 m/min
