HOMAG CNC CLAMP FOR NARROW PIECES

HOMAG

Condition: ready for operation (used), Year of construction: 2013, functionality: fully functional, overall weight: 6,000 kg, No minimum price – guaranteed sale to the highest bidder! Assemblies and Units Number of units: 9 1st unit – Pre-milling assembly 2nd unit – Gluing assembly Manufacturer of the gluing assembly: Nordson 3rd unit – Pressure rollers 4th unit – Cutting assembly 5th unit – Rough milling assembly 6th unit – Milling assembly 7th unit – Fine milling assembly 8th unit – Milling assembly 9th unit – Milling assembly TECHNICAL DETAILS Gluing system: Glue pot MACHINE DETAILS Voltage: 400 V Current consumption: 69 A Fuse rating: 80 A Pgode Af Hp Dopfx Ai Tju Dimensions & Weight Dimensions (L x W x H): 9,000 x 1,050 x 2,100 mm Weight: 6,000 kg Number of transport packages: 4 EQUIPMENT Tools for pre-milling assembly Tools for pressure rollers Tools for milling assembly Includes PUR unit

Condition: used, Year of construction: 2012, Edge banding machine Manufacturer: Homag Type: KAL 211 Year of manufacture: 2012 Technical data Pgsdpfxj Af Ip Dj Ai Teu Feed rate: 18-25 m/min; with FK11 max. 20 m/min Working height: approx. 950 mm Machine length: approx. 7,845 mm Workpiece thickness: 12-40 mm standard; version up to 60 mm Edge material roll: approx. 0.3-3 mm Edge material strip: approx. 0.4-6 mm Roll diameter: max. 830 mm Pneumatics: 6 bar, Electrical: 400 V / 230 V, 3 phases, 50 Hz Units / Equipment - Release agent spray unit top/bottom - Joining milling unit - Gluing unit - 2-roll edge magazine - Pressure zone - Trimming unit HL81 - Pre-milling unit BF10 - Profile milling unit FK11 - Profile drawing blade PN10 - Finishing unit with glue joint drawing blade and buffing unit - Preparation for HOMAG 1 laserTec - powerControl PC22 with touchscreen - Automation packages - In addition, drawing blades for both 2mm and 1mm edges are available. PUR retrofit 2023 In 2023, the machine was retrofitted with a PUR gluing system from GP Service, type EasyPUR AC 34, as well as a RIEPE spray system, type LP289/99 24 V. Note: The technical data and descriptions are copies of the original order confirmation. The information is provided for informational purposes only and is not binding.

Condition: used, machine/vehicle number: 006253, Type of edging: Thin edge, Thick edge, Solid wood Gluing System: EVA Hotmelt, PUR Premilling Unit: yes Corner Rounding Unit: yes Max feed speed: 40 m/min Maximum panel thickness: 60 mm Operating Units: 10 nr Pgedpfxol Txxgs Ai Tou

Condition: used, machine/vehicle number: 008729, Type of edging: Thin edge, Thick edge Gluing System: EVA Hotmelt Grooving Unit: yes Pjdjzylv Ispfx Ai Tjgu Max feed speed: 40 m/min Maximum panel thickness: 60 mm Operating Units: 8 nr

Condition: used, Year of construction: 2015, axis stroke (X,Y,Z) 6175x1550x300 mm Number of spindle head vertical 20 St. Number of spindles head horizontal 10 St. Number of milling agregates 1 St. Speed 24.000 U/min. Capacity 300 kg/h Sawing unit ja_yes 0 Control Homag PC85 CNC powerTouch HOMAG BMG 511 /60/12/F/K Profi ----- Machine already professionally dismantled and stored at our warehouse in Oberkochen: - 5-axis CNC processing center - Moving gantry machine (dual-drive gantry system) - 1 HOMAG DRIVE 5 C+ routing spindle, 5-axis, HSK-F63, 15 kW, max. 24,000 rpm - 1 HOMAG Multi Processing Unit Drilling head with 30 spindles: V20 / H10 / S360° "MPU" MultiProcessingUnit with C-axis +/- 185° - 1 Chain tool changer, 30-position - Includes SL laser projector - Includes vacuum suction cups (as available) - Spare parts and accessories as shown in photos - Last HOMAG 5-axis service: 2024 - Last HOMAG service: 2025 - Price includes professional dismantling and loading onto customer's truck - Costs for loading frames/transport securing devices NOT included; see note at the end of the description Technical Data ----- Max. workpiece lengths: All aggregates: Single 6,000 mm; Pendulum min. 1,550 mm, max. 3,200 mm Tool dia. 25 mm: Single 6,175 mm; Pendulum min. 1,550 mm, max. 3,200 mm Max. workpiece width: All aggregates, front stop 1,100 mm Milling operation tool dia. 25 mm: Front stop 1,325 mm, rear stop 1,550 mm Workpiece thickness: Max. 300 mm including clamping devices Routing spindle and drilling head ----- 2 independent Z-axes 1 HOMAG DRIVE 5 C+ routing spindle, 5-axis, HSK-F63, 15 kW, max. 24,000 rpm Liquid-cooled routing spindle, DRIVE5C+ aggregate interface with 3-point torque support 1 HOMAG Multi Processing Unit Drilling head with 30 spindles: V20 / H10 / S360° "MPU" MultiProcessingUnit with C-axis +/- 185° for drilling and sawing operations at any angle 1 motor 2.3 kW, frequency-controlled, max. speed 7,500 rpm selectable via program for rapid processing even with small diameters 20 vertical HIGH-SPEED spindles 10 horizontal spindles 1 grooving and parting saw Includes Z-axis module Includes extraction hood Tool changer: ----- 1 Pick-up station for 350 mm saw blade for DRIVE5(C)+ 1 Chain tool changer, 30-position, D=80 For tools and aggregates with HSK-F63 Chain changer with 30 tool/aggregate positions for use with machines featuring 1 main spindle 1 upstream double gripper for rapid tool changing Console table with ----- 12 consoles, Y=1,500 mm for K-table 6 lifting rails (HPL), lift 100 mm Additional accessories: ----- SPEED PACK: Increase in... Max. traverse speed of X-axis: 80 m/min; vector speed = 110 m/min Contour laser positioning aid 1 vacuum pump (300 m³/h) Chip conveyor belt with extension Vacuum clamping system SL-Laser Pjdpfx Aozqggvei Tjgu Energy-efficient 5-axis extraction hood Safety equipment: ----- Laser, bumper SAFESCAN for Speed ??Pack CE mark HOMAG Speed ??Pack HOMAG Quality Package Enclosed energy chain Control system ----- PowerControl PC85 HOMAG powerTouch Handheld terminal HOMAG IPC Powerpack Software ----- HOMAG woodWOP 7.1 WoodScout diagnostic system MMR B...

Condition: excellent (used), Year of construction: 2016, operating hours: 1,198 h, Brandt Ambition 1120 c edge banding machine with 2 glue tanks, joining, corner copying, and two trimming blades. A good entry-level machine with extensive features. A video of the machine in operation can be sent upon request. Edge thickness: approx. 0.4 - 3 mm Workpiece height: approx. 10 - 40 mm Feed rate: approx. 8 m/min Noise protection hood Extendable workpiece support Dust extraction connection 1x100mm, 4x80mm including the piping shown, connected to 200mm Easy-Touch control with color screen for easy operation of the machine 10 programs can be stored Units: Upper pressure, manual adjustment with crank and SIKO counter Infeed guide, manual adjustment with SIKO counter Jointing cutter with diamond cutters, sharpened A total of 2 replaceable glue tanks for quick color change from white to transparent Gluing unit with automatic edge feed for roll material up to 3 mm Pressure zone with 3 rollers Crosscut saw with 2 motors Podpfxezn Afpj Ai Tegu Combination milling unit, easily adjustable by hand for flush trimming, chamfering and radius Corner rounding cutter R2 with diamond cutter, 1 motor Radius trimming blade R2, manually adjustable Glue joint trimming blade with large roller, pneumatically controlled Hood locking mechanism CE marking Operating manual in folder format All indexable inserts of the milling units and trimming blades have been replaced or resharpened, saws sharpened, diamond jointing cutters sharpened. The machine is therefore ready for immediate use. Only the diamond cutter of the profiling cutter has not been replaced, but it is still sharp. Original paint, only a few spots have been touched up. Dust extraction hoses renewed. Approx. 1200 operating hours, i.e. only 1/2 hour per day. Machine dimensions approx. 4300 (with table) x 1250 x 1600 mm (L x W x H) Weight approx. 950 kg. The machine can be demonstrated on site by appointment. We only offer machines that are ready for demonstration and are in our warehouse, see "other offers from this provider".

Condition: ready for operation (used), Year of construction: 2019, functionality: fully functional, workpiece length (max.): 2,800 mm, workpiece width (max.): 850 mm, number of slots in tool magazine: 13, actuation type: electric, total height: 1,895 mm, total length: 2,920 mm, total width: 1,890 mm, overall weight: 1,580 kg, year of last overhaul: 2026, Equipment: CE marking, documentation/manual, The Drillteq V-200 is in continuous use, which means the number of parts being processed is increasing. The machine is in good condition and is regularly serviced. Podpo Afm Itjfx Ai Togu For more information, please call 601 548 875.

Condition: used, Year of construction: 2002, functionality: fully functional, 4-axis machine with WOODWOP 4.5, from a carpentry workshop Working dimensions: X-axis 3,200 mm Y-axis 1,250 mm Work table: 6 pcs workpiece supports, each with 3 vacuum cups Pods Afh Izjpfx Ai Tjgu 4 pcs lifting rails for heavy workpieces 1 rear and 1 front stop row Vacuum pump 100 m³/h Tool arrangement: Main spindle 7.5 kW HSK 63 F with water cooling Speed 1,500 - 18,000 rpm with C-axis / positioning axis for adapter tools Drilling unit with 18 vertical spindles 6 drilling spindles horizontally Dado saw unit fixed in the X-direction Tool changer magazine, 8 positions, mounted at the rear of the support, moving in the X-direction, for milling tools and units Control: HOMATIC 2000 with WOOD WOP 4.5 Safety equipment: ----- * Foot mat protection in front of the machine Without tools

Condition: good (used), Year of construction: 2013, machine/vehicle number: 0-201-24-0260, functionality: fully functional, input voltage: 400 V, type of input current: three-phase, travel distance Z-axis: 600 mm, workpiece length (max.): 3,470 mm, workpiece width (max.): 1,550 mm, number of slots in tool magazine: 18, controller manufacturer: HOMATIC, controller model: PC85, spindle motor power: 15,000 W, Equipment: CE marking, documentation/manual, Machine with shuttle console tables Workpiece length X max. (all units) - max. 3470 mm with single workpiece placement - max. 1700 mm with alternating workpiece placement Workpiece length max. (milling cutter D=25 mm) - max. 3470 mm with single workpiece placement - max. 1700 mm with alternating workpiece placement Workpiece width Y max. (all units) - max. 1300 mm Workpiece width Y max. (milling cutter D=25 mm) - max. 1550 mm 2 individually movable console clamping tables - 4-position workpiece placement possible - 8 movable consoles (4 per table) each with 1 front stop - Console length 1490 mm Pgjdpfo Afabajx Ai Tou - 4 lifting rails - Side stops 4 x left, 4 x right (mirror image) - 1 vacuum circuit per table - 2 vacuum pumps, 140 m3/h each - Chip conveyor belt Equipment / Units: - Milling spindle 15 kW, liquid cooling - Tool changer, 18-position carousel - C-axis with electrical interface - C-axis extension for FLEX-5 unit - Drilling unit 2.7 kW, 20 spindles vertical / 10 spindles horizontal - Swiveling sawing/drilling unit - Sawing unit D=1200 - FLEX5 sawing, milling, drilling unit for multi-tool - 16 pcs. suction cups 160x115 mm - 8 pcs. suction cups 125x75 mm Control / Software: - PC85 control system - WoodWop 5.1 - Wood Design Package - CAD plugin - DXF import - Schuler MDE Available from week 46/2026.

Condition: used, Year of construction: 2007, HOMAG OPTIMAT BAZ 211 Venture 21M, manufactured in 2007. CNC machining center with C-axis, Flex5, and cantilever table. Equipment: - Workpiece length 3,050 mm with all units; up to 3,225 mm when milling with a Ø25 mm tool - Workpiece width front 1,150 mm / rear 1,400 mm with all units - Z-axis travel 600 mm - Main spindle 18.5 kW S6 / 14.5 kW S1, HSK-F63, up to 24,000 rpm - 6 manually adjustable cantilevers with LED positioning aid - MPU drilling head: 20 vertical and 10 horizontal drilling spindles, as well as a pivoting nut saw S360° - Flex5 sawing/milling/drilling unit for positioned angled machining - Two-spindle lock miter unit - Tool changer 10 + 18 positions, total 28 - Retrofitted Busch-Mink vacuum pump and HYDAC coolant unit Pgsdpfx Ae Ad Uyuji Teu - powerControl PC85 with woodWOP Working ranges depend on the tool, unit, and clamping device. Pendulum machining depending on the configuration. Machine location: Switzerland. Inspection and sales processing by appointment only through DS-Maschinen in Stuttgart. Price on request. Detailed scope of supply, availability, inspection, loading, and transport to be agreed upon. DS-Maschinen – Owner David Schulz.
