Edgebander

HOMAG

Condition: excellent (used), Year of construction: 2021, functionality: fully functional, machine/vehicle number: 0-256-73-1249, working width: 1,350 mm, grinding belt length: 2,150 mm, workpiece height (max.): 160 mm, grinding belt width: 1,370 mm, volume flow: 3,660 m³/h, TECHNICAL DETAILS Working width: 1,350 mm Workpiece thickness: min. 3 mm / max. 160 mm Sanding belt width: 1,370 mm Sanding belt length: 2,150 mm Unit 1 – Contact cylinder Sanding belt cutting speed: 18 m/s Rubber cylinder: 65° Cylinder diameter: 240 mm Combination sanding unit Sanding belt speed: 12 m/min Rubber cylinder: 55° Shore Cylinder diameter: 140 mm Width of pneumatic foot: 80 mm MACHINE DETAILS Voltage: 400 V / 50 Hz Drive power Unit 1: 15 kW Pgsdpfx Aozvnfwsb Ssr Drive power Unit 2: 15 kW Total power consumption: 33 kW Dust extraction connection Unit 1: Ø 180 mm Dust extraction connection Unit 2: Ø 180 mm Dust extraction volume: 3,660 m³/h Recommended dust extraction speed: 20 m/s Compressed air requirement: 20 l/min at 6 bar EQUIPMENT Sanding belt change on the left side Automatic clamping of the contact cylinder, e.g., during belt change Automatically adjustable rubber cylinder Grain size compensation on the contact cylinder Combination sanding unit L with pneumatic foot for calibration Automatic anchoring/fastening Grain size compensation on the rubber cylinder Automatically adjustable pneumatic foot

Condition: good (used), Double-end tenoner, edge processing machine, scoring motor, cutting motor, electric motor, spindle motor, milling motor -1x motor: 0.3 kW 12000 rpm at 200 Hz -Indexable insert milling cutter -Motor: mounted on guides -Number: 3x motors available Pgsdpeb A Nlxsfx Ab Sjr -Price: per piece -Weight: 5 kg/piece

Condition: used, PDF listing included! Extensive spare parts package – HOMAG / Homatic / Industrial Electronics For sale is a comprehensive collection of industrial and machine spare parts, primarily from the HOMAG / Homatic range, supplemented by components from Josting, Ferrocontrol, Heesemann/Kuhnke, Vero, Lenze, Brandt, Kuper and other manufacturers. The package comprises a total of over 500 individual items, offering an interesting selection of spare parts, modules and electronic components – particularly for the maintenance, repair and spare parts supply of older machines and control systems. Included are, among others: HOMAG / Homatic input and output cards PLC controllers and CPU cards PLC and program memory / EPROMs / flash modules Mini controllers and axis processors Servo and axis processors Frequency inverters / converters Encoder drivers Time and counter cards PC control units Control panels, keyboards and terminals VME bus and interface cards Power supplies and DC/DC converters Adapter and graphics modules various machine spare parts and circuit boards components from the Ferrocontrol / Josting range additional modules for HOMAG, Brandt and Heesemann machines The collection is particularly interesting due to the large number of different modules and the partially multiple availability of spare parts. It also includes many older or currently difficult-to-source components, which may be of interest for the repair and continued operation of the corresponding machines. Some of the included part numbers / modules: HOMAG / Homatic 2-083-01-5403/04 – 16 × 24 V output card 2-083-01-5406 – Homatic 16 × 24 V output card 2-083-01-5407 – 24 V NPN HC020 FET output card 2-083-01-5408 – 16 × 24 V output card 2-083-01-5101 – 16E 24 V input card 2-083-01-5105 – 32 × 24 V input card, PNP 2-083-01-5423 – Input/Output card HC010 2-083-01-5004 – CPU transfer RAM / auxiliary memory 2-083-01-6902 – PC control unit Pedozw N Sbjpfx Ab Ssgr 2-083-02-7006 – Axis processor 6809 2-083-02-7010 – Encoder driver 2-083-02-7420 / 7421 – Conversion processors 2-083-02-8000 – Axis processor for 6 axes 2-083-02-8068 – Servo 4-axis 2-083-03-0046 – CPU30 E16-103 2-083-03-0202 – SECO 6×RS232 VME bus and numerous other Homatic modules and control components. Josting / Ferrocontrol Input-80 0990 0741 – Input cards Output-80T 09900762 – Output cards Ferrocontrol ORE-80 circuit boards E² PRGR 0990 0591 EFR 0990690 other control and electronics modules Heesemann / Kuhnke various input and output cards Delay cards CPU cards Power supplies and other machine components Power supplies / power units Vero Monovolt PK60 Vero Trivolt HOMAG / Homatic 5 V / 12 A or 20 A power supplies Schroff Switchpac-Triple power supplies Condition The parts come from an extensive spare parts stock. The condition and functionality may vary depending on the item. A complete technical inspection of all individual parts has not been carried out. The existing list with 513 items can be provided upon request. Due to the large quantity, the collection is preferably offered as a complete package. If you are seriously interested, further information, photos and the complete item list can be provided.

Condition: used, machine/vehicle number: 008495, X axis working area: 4175 mm Y axis working area: 1550 mm Working Table: Pod and Rail Main Electrospindle power: 11 KW Number of controlled axes: 4 axes Maximum edge height: 45 mm Total number of drilling spindles: 21 Total number of tool changer positions: 12 Pgedpfxey Edqqo Ab Ser

Condition: ready for operation (used), Year of construction: 1993, functionality: fully functional, We are offering this ready-to-use HOMAG KR 79/02/PU/S2 edge banding machine, manufactured in 1993. Podpfozwunbex Ab Segr Manufacturer: HOMAG Type/Model: KR 79/02/PU/S2 Year of manufacture: 1993 If you have any questions or require further information, please do not hesitate to send us a message or call us.

Condition: used, Year of construction: 2000, machine/vehicle number: 0-201-21-369, functionality: fully functional, operating hours: 999,999 h, power: 25 kW (33.99 HP), input voltage: 400 V, input current: 45 A, input frequency: 50 Hz, type of input current: three-phase, travel distance X-axis: 4,700 mm, travel distance Y-axis: 1,350 mm, travel distance Z-axis: 400 mm, workpiece length (max.): 4,500 mm, workpiece width (max.): 1,150 mm, workpiece height (max.): 200 mm, number of axes: 4, number of slots in tool magazine: 12, controller manufacturer: Homag, actuation type: electric, total height: 2,400 mm, total length: 7,250 mm, total width: 4,000 mm, overall weight: 7,500 kg, table length: 4,500 mm, table width: 1,150 mm, Equipment: CE marking, documentation/manual, We are offering this used HOMAG BOF 41/45/R machining center, manufactured in 2000. Manufacturer: HOMAG Model: BOF 41/45/R Year of manufacture: 2000 Condition: used Category ID: 2076 Type ID: 970 Machine type: Machining center Includes 3 vacuum pumps: 2 Siemens Elmo (Elmo Rietschle) vacuum pumps, type: 2BL2141-2AH50-4A-ZN01 + 1 Rietschle VTA140 vacuum pump Psdpfezwm Rbjx Ab Segr The machine is connected and still in use. Inspections are welcome! Available from mid-December! If you have any questions or require further information, please do not hesitate to send us a message or call us.

Condition: ready for operation (used), Year of construction: 2015, travel distance X-axis: 4,200 mm, travel distance Y-axis: 1,550 mm, travel distance Z-axis: 270 mm, number of axes: 5, spindle motor power: 10,000 W, spindle speed (max.): 24,000 rpm, This 5-axis HOMAG V BMG 311/42/F/K Venture was manufactured in 2015. It features a working dimension of 4,200 mm in X, 1,550 mm in Y, and 270 mm in Z. The machine is equipped with a powerful 10 kW main motor and a maximum rotation speed of 24,000 rpm. If you are looking to get high-quality CNC wood machining capabilities, consider the HOMAG V BMG 311/42/F/K Venture machine we have for sale. Contact us for further details. • Tool clamping: HSK-F63 • Tool changer: 18 positions • Vertical drilling spindles: 17 • Horizontal drilling spindles: X = 2, Y = 2 • Groove saw: 90° turnable • Machine type: Gantry • Machine table: Pod and rail • Number of consoles: 6 • Positioning aid • Crosshair laser • Vacuum pumps: 2 units, total capacity 180 m³/h • Safety device: Bumper • Stops: Two rows of stops • Workpiece support aids: Stop for top layer protrusion • Control: HOMAG powerTouch • Software: HOMAG WOODWOP 7.0 Pjdpfxjzwmu To Ab Ssgr • Declaration of CE-conformity

Condition: excellent (used), FULL (4-SIDES) FLEXIBLE LINE of Sizing-Milling & Edge Banding, with completely automatic handling and PC53 Line Control. With HIGH-PERFORMANCE PACKET (feeding speed up to 60 m/min) Composed of the following machines: 206026A) Loader (double station) "BARGSTEDT (HOMAG)" Mod. TBH 501/D/25/12 206026B) 1st Single-side (Left) Sizing & Edge Banding machine "HOMAG" Mod. KFL 612/16/A3 206026C) 2nd Single-side (Right) Sizing & Edge Banding machine "HOMAG" Mod. KFR 612/18/A3 206026D) Conveyor (motorized rollers) "HOMAG" Mod. TRL 100/35/12 206026E) Curved transfer (90°) with a 90° motorised carpet "HOMAG" Mod. TRL 100/35/12 206026F) High-performance 90° angle transfer "HOMAG" Mod. TWR 320/30/12 206026G) Double-side Sizing & Edge Banding machine "HOMAG" Mod. KFR 526/9/A3/30 Psdpjzwlabefx Ab Sogr 206026H) Turning Station "HOMAG" Mod. TDR 510/30/12 (with WANDRES cleaning unit) 206026I) Stacker (double station) "BARGSTEDT (HOMAG)" Mod. TSH 501/D/25/12

Condition: excellent (used), A complete furniture production plant, composed of the following main machines: 293000) “HOMAG” KFL flexible Sizing-Milling & Edge Banding line (with HIGH-PERFORMANCE PAKET) 239100) Flexible CNC Drilling Line “MORBIDELLI+MAHROS” PowerFlex with CELASCHI splitter 231200) Flexible CNC Drilling Line “MORBIDELLI+MAHROS” PowerFlex 238000) Flexible CNC Drilling Line “MORBIDELLI+MAHROS+RBO” Flexa 912 238400+200027) 2 x Flexible CNC Drilling Lines “MORBIDELLI+MAHROS” Author 912/924 231200) Flexible CNC Drilling Line “COMEC+KUKA” Frontal for front doors (of furniture) 214000) Digital Printing Line “PROJECTA+GIARDINA+UNIVERSAL+KUKA” 200002) Laminating (coating) Line “HYMMEN-KONTRA” 200037) Production Line “OMGA+BALESTRINI+GANNOMAT+DOUCET” for cabinet front doors/drawers (5 pieces) 200006) “HOLZMA” panel saw, Mod. HPL 400/43, with KUKA robot for unloading and stacking Pgedpfx Aezwk Idjb Sor 237100+237200) 2xCNC machines “BIESSE” Skipper 130 CNC+237000+200028) 2x“BIESSE” Skipper 100 237300+200078) 2 x CNC machines “MORBIDELLI” CX 200 + CX 210 CNC machines 200034+200033) 2 x CNC drilling and dowel inserting machines “KOCH+BIESSE” Sprint PTP + HELIX K3 200029 + 200030) 2 x CNC Nesting machines “BIESSE” Rover A FT 1531 CNC (1 with loading and unloading) 200031A + 200032A) 2 x CNC machines “BIESSE” Rover B 1967 Edge (with KUKA robot) 200035) CNC machine “BIESSE” Excel (4 vertical electric spindles) for cabinet front doors 220700) Edge Banding machine “HOMAG” KAL 330 (with LIGMATECH workpiece return system) 200009+200010) 2 x Edge Banding machines “SCM” STEFANI XD (1 with workpiece return system) 200018+200019) 2 x Edge Banding machines “HOMAG-BRANDT” KDF 440 C and KDF 650 261200 + 261300) 2 Cardboard Packaging Lines “DYNATEC+ROBOPAK+KUKA” 2VAC01 + 2VAC02) Extraction systems (AIREX, TECO Westinghouse, Ingersoll-Rand) And many other machines (various ATLAS COPCOM and INGERSOLL RAND compressors, HOMAL KL/KR edge banding machines, HOLZMA and SELCO panel saws, ROBOPAC packaging machines), as well as roller conveyors, shelving, etc. The machines are still installed at the former owner’s premises and can be viewed by appointment.

Condition: excellent (used), Year of construction: 2016, operating hours: 1,198 h, Brandt Ambition 1120 c edge banding machine with 2 glue tanks, joining, corner copying, and two trimming blades. A good entry-level machine with extensive features. A video of the machine in operation can be sent upon request. Edge thickness: approx. 0.4 - 3 mm Workpiece height: approx. 10 - 40 mm Feed speed: approx. 8 m/min Noise protection hood Extendable workpiece support Dust extraction connection: 1x100mm, 4x80mm, including the piping shown, leading to 200mm Easy-Touch control with color screen for easy machine operation 10 programs can be saved Units: Top pressure with manual adjustment using a crank and SIKO counter Infeed guide with manual adjustment and SIKO counter Joining cutter with diamond cutters, sharpened A total of 2 interchangeable glue tanks for quick color changes from white to transparent Gluing unit with automatic edge feed for roll material up to 3 mm Pressure zone with 3 rollers Miter saw with 2 motors Combination milling unit, easily adjustable by hand for flush trimming, chamfering, and radius Corner rounding cutter R2 with diamond cutter, 1 motor-driven Radius trimming blade R2, manually adjustable Glue seam trimming blade with large roller, pneumatically controlled Pjdpfx Abezn Afpo Sjgr Hood locking mechanism CE marking Operating manual as a folder All cutting inserts of the milling units and the trimming blades have been replaced or re-sharpened, saws sharpened, diamond joining cutters sharpened. The machine is therefore ready for immediate use. Only the diamond cutter of the shaping cutter has not been replaced, but it is still sharp. Original paint, only a few spots have been touched up. Dust extraction hoses replaced. Approx. 1200 operating hours, which is only 1/2 hour per day. Machine dimensions: approx. 4300 (with table) x 1250 x 1600 mm (LxWxH) Weight: approx. 950 kg. The machine can be demonstrated on-site by appointment. We only offer machines that are ready for demonstration and are in our warehouse, see "other offers from this provider."
