Thermoforming machine

Illig UA 200 G Solo/BE

Condition: excellent (used), Year of construction: 2000, machine/vehicle number: 403, THERMO FORMING MACHINE TFT IMC 5030 (WITH TOOLS) Equipment / Additional information: unwinding: Roll recording: easy Max roll diameter: mm 1000 Settlement: automatically Thermoforming machine: Maximum tool dimensions: mm 520x330 Pos. Molding height max .: 15 mm Neg. Molding height max .: 120 mm Sheet width: mm 150/760 Movement Step: mm 50/330 Max HIPS film thickness: 1.8 mm Ksdpfx Ahsn D Ew Ioyjdw Hub of the sub-table: 150 mm Clamping force: 7500 Kg Inst power top heater: 18.8 Kw Inst power under heater: 14.1 Kw Idle clock speed: per minute 40th power main drive motor: 2.2 Kw Engine power. Film feed: 0.75 Kw Air operating pressure: Kg / cm2 7 Water consumption at 12 °: 1t / 1` approx.30 Air consump. at 7 kg / cm2: 1t / cycle 125 Installed power: Kw 50 9xTool: Article no. // Tool no. // Cavities // Description / Product: 3599 // 457 // 10 // Vending machine cup capacity/capacity/contenance=223ml 593 // 460 // 8 // Coffee-to-go / thermo mug / thermo cup Filling capacity / Capacity / Contenance=300ml / 12 oz 509 // 452 // 6 // Ice cream cup: filled to the brim=140ml / Filling capacity with headspace 6mm: 120 ml 591 // 459 // 10 // Thermo mug ⌀ 81/180ml 740 // - // - // Standard cup with sealing edge ⌀ 75-120ml 3589 // 458 // 12 // Coffee-to-go / thermo mug / thermo cup: Filling capacity / Capacity / Contenance=80ml 595 // 456 // 10 // Vending cup / Gobelet pour automate: Filling capacity / Capacity / Contenance=150ml 210 // - // - // Baking case / technical part / plate or tray 8000 // 455 // - // Granule cup 180 ml / technical part with flat sealing edge

Condition: excellent (used), Year of construction: 2013, operating hours: 24,666 h, functionality: fully functional, - Top functional packaging machine (thermoforming machine) of the PowerPak series. - Perfect for packaging pasta products. - Viewing under production conditions (packaging of gnocchi) possible at any time. - With matching feed belt and ExaktaPack brand scale (included). Technical details GEA PowerPak: - Film width: 350 mm lower web, 334 upper web - Approx. 12 cycles / minute - Forming tools: 1.1, 2.1, 2.2 - Rigid film, PP, PET, etc. - Bottom web preheating - Longitudinal and cross cutting with silent edge strip winding - Machine length approx. 9m - Draw-off: 60 mm - Busch vacuum pump (included) Ksdpjua Hchjfx Ahyedw - Eject station and distribution pneumatic - Flow cooler for cooling form and seal stations. Additional information on request and/or inspection gladly possible.

Condition: excellent (used), Year of construction: 1992, operating hours: 41,685 h, Technical specifications: Rated power, kW: 11,3 Mold area, mm: 475 x 250 Max. film width, mm: 495 Kdjdsq A Um Repfx Ahyjw Min. film width, mm: 150 Max. feed length, mm: 280 Min. feed length, mm: 50 Max. drawing depth/negative, mm: 100 Number of cycles/min.-max.: 48 Consumption of air/cycle at 6 bar: 100 Nl (net-pressurized air) Heat energy to be dissipated: with top heating ca. 10 260 KJ/h with top and bottom heating ca.: 17 715 KJ/h Special equipment: Hollow floor facility available Control cabinet: included

Condition: new, Year of construction: 2017, operating hours: 25 h, functionality: fully functional, saw band length: 520 mm, saw band width: 580 mm, total height: 1,500 mm, total length: 5,200 mm, total width: 2,350 mm, type of input current: three-phase, overall weight: 2,500 kg, input voltage: 380 V, New machine. Kedpfx Aounia Hjhyodw

Year of construction: 2006, condition: ready for operation (used), Additional Equipment Machine includes an SA 500 extractor built in 2006 and a 6m long cooling section. Kdjdpfov Sfw Hjx Ahysw This KUHNE KS45-24D compounding extruder was manufactured in 2006. Ideal for processing a variety of materials, it offers robust construction and reliable performance. Consider the opportunity to buy this KUHNE KS45-24D compounding extruder. Contact us for more information. Application Types Extrusion

Condition: excellent (used), Year of construction: 2014, operating hours: 19,000 h, functionality: fully functional, Gabler M92L thermoforming machine, in excellent running condition. Kjdpfxjwcdvne Ahysdw

Condition: reconditioned (used), functionality: fully functional, Plate size: 1250 x 1500 mm Forming area: 1200 x 1460 mm Drawing depth: 700 mm If you would like further details or a quote, please contact us. Kdedpfx Aewf Ea Tohyow

Year of construction: 1997, operating hours: 76,200 h, condition: good (used), This WEBER extruder is in machine storage at Plastima Used Machinery. The machine is from 1997 and is in great condition. Make: Hans Weber GmbH Model: NE 7 048 Screw type: single screw Year of construction: 1997 Kdedpfx Ahotpg D Ujyjw Propeller Ø: 75mm Working hours: 76,200

Condition: reconditioned (used), functionality: fully functional, Technical Specifications: - Maximum material size: 2500 x 1500 mm - Maximum forming area: 2450 x 1450 mm - Maximum tool height: 600 mm - Maximum material thickness: 12 mm Equipment: Forming Station - Schleicher P03 control system - Automatic setup function - Top heater: ceramic emitters (500 W) with 4-zone control - Individual selection of upper heating elements, including lowering - Bottom heater: ceramic emitters (300 W) with 4-zone control - Individual selection of lower heating elements, including lowering Kdedpfswf Eb Rox Ahyow - Program and heating settings storage - Clamping frame with quick-change system - Parallel upper frame, longitudinal runners for use of fixed format frames - Lower clamping frame for frame installation from below, central clamping via E-motor - Pneumatic lower table with rapid/creep speed, adjustable in 15 steps via control panel - Upper punch with rapid/creep speed, adjustable in 7 steps - Vacuum pump with cascade control, adjustable in 15 steps via control panel - Pre-blow automation, percentage adjustable - Pre-vacuum adjustment, percentage adjustable - Automatic demolding, percentage adjustable - Plate sag control via light barrier with support air - 8-fold cooling fan with spray nozzle cooling - Large front opening for tool change Loading - Automatic sheet loading system - Centering table for precise positioning of sheets in the feeder - Motorized sheet lifter - Motorized sheet positioning adjustment - Motorized transport lifter - Motorized adjustment of transport width

Condition: like new (used), Year of construction: 2021, operating hours: 337 h, Multivac R535 Thermoformer The R 535 thermoforming packaging machine is the largest configurable machine system from MULTIVAC. It offers a uniquely wide range of equipment options as well as an extremely high packaging output. Thanks to the unique diversity of the R 535, MULTIVAC is able to meet the most challenging of customer requirements. Kodpfxoxfq D Ue Ahyedw This R 535 is from 2021 and has only 337 production hours and is in new condition. The machine is including the following equipment: - Bell Mark – IntelliJet TSX 10” Thermal Inkjet Printer; - Chilly 45 chiller Manufacturer: Multivac Model: R535 Year: 2021 Production Hours: 337 Film Width: 645mm (Top)  / 645mm (Bottom) Stroke Length: 500 mm Max. Forming Depth: 75 mm Vacuum Pump: Busch 105m3/h Capacity: Max. 12 cycles/min Machine Dimensions LxWxH: 1.050x175x225 cm Machine Weight: 2.000 kg.
