HSK FLOATING IMA AGGREGATE

IMA

Condition: ready for operation (used), Year of construction: 2000, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,200 mm, number of axes: 3, This 3-axis IMA BIMA 410 CNC Wood Machining Centre was manufactured in 2000. It features a working area of 3000 mm in X and 1200 mm in Y, with a maximum clamping height of 100 mm. The machine is equipped with an automatic central lubrication system and AC servo motors for precise operation. If you are looking to get high-quality wood machining capabilities, consider the IMA BIMA 410 machine we have for sale. Contact us for further details. • Working area X: 3000 mm • Working area Y: 1200 mm • Max. clamping height Z1: 100 mm • Max. workpiece thickness Z2: depending on equipment/application • Table height: approx. 1000 mm • Pendulum operation X: 2 × 1400 mm • Free space center X: 200 mm • Pendulum operation alternative X: 2 × 900 mm • Free space center alternative X: 1200 mm • Machine weight: approx. 6000 kg • Guide system: precision linear guides hardened approx. 62 HRC • Central lubrication: automatic for all main axes and ball screw • Drive system: AC servo motors with encoder • X/Y drive: rack and pinion • Z drive: ball screw • Feed rate: 40 m/min • Rapid traverse X/Y: 80 m/min • Rapid traverse Z: 25 m/min • Acceleration: 3 m/s² • Extraction connection main spindle: 300 mm • Extraction connection drilling spindles: 120 mm • Air speed: approx. 28 m/s • Air volume: approx. 7080 m³/h • Vacuum pump capacity: 100 m³/h • Compressed air connection: 1/2" • Air pressure: 6 bar • Control voltage: 24 V DC • Connected load: approx. 24 kVA • Power supply: 3/N/PE 400/230 V 50 Hz • Frequency converter: 0–480 Hz • Ambient temperature: +15 to +35 °C • Control system: IMATRONIC NT 231 • Interpolation: linear all axes, circular 2.5D • Resolution: 0.001 mm • Spindle: HSK F63 • Tool clamping force: 11000 N • Max tool weight: 6 kg • Speed range: 1500–18000 rpm • Spindle power: 7.5 kW • Cooling: water cooled • CNC axis: 360° rotating • Tool magazine type: plate changer • Tool positions: 18 • Max tool length: 150 mm • Max tool diameter: 100 mm (150 mm with free сосед positions) • Max load: 60 kg • Saw unit motor: 1.5 kW • Saw speed: 5600 rpm • Saw blade diameter: max. 150 mm • Drilling unit: 14 spindles • Spindle stroke: 70 mm • Drive: 2.2 kW • Speed: 3150 rpm • Drill diameter max: 20 mm • Adapter head spindles: 4 • Speed max: 6000 rpm • Drill diameter max: 12 mm Lredpfx Amoy Aw N Ustjp Table equipment: • 6 adjustable support arms • 12 suction cups 114 × 159 × 100 mm • 6 suction cups 125 × 75 × 100 mm • Vacuum system: 2-circuit clamping system • Electrical cabinet size: 2000 × 1800 × 600 mm DEFECT: • The main spindle no longer releases the interchangeable drill head

Condition: used, Year of construction: 2008, machine/vehicle number: 50071, functionality: fully functional, power: 18 kW (24.47 HP), input voltage: 400 V, input current: 42 A, input frequency: 50 Hz, type of input current: three-phase, workpiece height (max.): 60 mm, edge thickness (max.): 8 mm, height adjustment type: electric, feed rate X-axis: 16 m/min, actuation type: pneumatic, total height: 1,600 mm, total length: 7,200 mm, total width: 1,600 mm, overall weight: 3,700 kg, Equipment: CE marking, documentation/manual, We offer this well maintained IMA Advantage 60 edgebander, year of manufacture 2008. Machine type: Advantage 60 Serial number: 50071 Year of manufacture: 2008 Ledpfx Amey Um Tmjtjrp Voltage: 400 V Frequency: 50 Hz Electrical supply: 3 N PE Nominal power: 18 kW Nominal current: 42 A The machine has the following groups: Premilling Blow-off nozzle for removing loose particles Heating unit Gluing unit End trimming unit MFA unit for milling/corner rounding Profile scrapper Cleaning agent application unit Riepe Flat scrapper Brushes Grooving unit With two interchangeable glue pots If you have any questions or need more information, feel free to send us a message or give us a call.

Condition: used, Year of construction: 2008, power: 41 kW (55.74 HP), edge thickness (max.): 3 mm, controller model: ICOS OPEN, The machine has the following configuration: Pre-milling unit Manufacturer model: R3 L20 Engagement control: Automatic, time-controlled Motor power: 4 kW Speed: 9,000 rpm Edge processing Number of edge processing units: 10 Crosscut saw unit Manufacturer model: 8.42/39/B Number of motors: 2 Motor power: 0.6 kW Speed: 12,000 rpm Flush trimming and rounding unit Manufacturer model: 08.055 Number of motors: 0.6 (?) Motor power: 1 kW Speed: 12,000 rpm Corner rounding unit Manufacturer model: 08.342 Number of motors: 2 Ljdjzmtkaopfx Amtjrp Motor power: 0.66 kW Speed: 12,000 rpm Scraper blade unit Manufacturer model: 08.50 Belt sanding unit 1 Manufacturer model: 08.62 Motor power: 0.18 kW Speed: 1,400 rpm Belt sanding unit 2 Manufacturer model: 08.062 Motor power: 0.18 kW Speed: 1,400 rpm Belt sanding unit 3 Manufacturer model: 08 Motor power: 0.18 kW Speed: 1,400 rpm Belt sanding unit 4 Manufacturer model: 08.617-2 Motor power: 0.18 kW Speed: 1,400 rpm Belt sanding unit 5 Manufacturer model: 08 Processing unit 10 Manufacturer model: 08.190 Motor power: 4.5 kW Speed: 9,000 rpm TECHNICAL DETAILS Workpiece dimensions Max. panel height: 60 mm Min. panel length: 130 mm Min. panel width: 65 mm Edge material Min. edge thickness: 0.4 mm Max. edge thickness: 3 mm Feed Max. feed rate: 30 m/min Pressure: Rubber belt Number of panel sizing/milling units: 1 MACHINE DETAILS Control system: ICOS OPEN Total connected power: 41 kW EQUIPMENT Number of panel sizing/milling units: 1 Lamps for preheating the panel side Edge roller magazine with 2 positions PUR pre-melting unit Pressure roller set with 5 pressure rollers Spraying unit The machine is sold and delivered in its actual and legal condition ("as is, where is") based on photo documentation and technical/commercial documents of a descriptive nature. The buyer has the right to inspect the goods before collection and assumes responsibility for the installation, securing, and use of the machine at its destination. External reference: 5657

Condition: used, machine/vehicle number: 008660, Type of edging: Thin edge, Thick edge Gluing System: EVA Hotmelt Premilling Unit: yes Corner Rounding Unit: yes Grooving Unit: yes Max feed speed: 30 m/min Maximum panel thickness: 60 mm Lsdpfx Ajzmmt Ujmtjrp Operating Units: 9 nr

Condition: used, machine/vehicle number: 008662, Position 1: Single Edgebanders IMA-NOVIMAT CONTOUR I/G80/790/R3 Position 2: Panel Return Systems IMA-NOVIMAT CONTOUR I/G80/790/R3 Lrodpfx Amszmmtnjtjp

Condition: used, functionality: fully functional, Manufacturer Code: 401110 - Condition: Used - Functionality: Fully operational - Compatible Machine: CNC IMA BIMA - If interested, we offer overhaul service, please contact us. Weight and dimensions for transport: 4KG 36X26X21 CM Lrjdpfjvu A A Sox Amtsp

Condition: used, functionality: unexamined, Ferwood code: AGG0125 - Manufacturer code: 147009FSQUM5R66I - Condition: Used - Functionality: Not tested - If interested, we offer an overhaul service, please contact us. Weight and transport dimensions: 6 kg, 36x26x21 cm Lrsdpfevu Dctsx Amtep

Condition: used, functionality: unexamined, Ferwood Code: RU0008884 - Manufacturer Code: - Condition: Used - Functionality: Not tested - Compatible Machine: IMA COMBIMA/NOVIMAT EDGE BANDING MACHINE - If interested, we offer a revision service, contact us. Lsdpfx Ajv Hgmfomtorp

Condition: used, functionality: unexamined, Ferwood Code: RU0000030 - Manufacturer Code: 10551904 - Condition: Used - Functionality: Not tested - Compatible Machine: IMA ADVANTAGE/NOVIMAT EDGE BANDING MACHINE - If interested, we offer a revision service, contact us. Lrsdpfev Azf Ijx Amtop

Condition: used, functionality: unexamined, Ferwood Code: RU0011433 - Manufacturer Code: - Condition: Used - Functionality: Not tested - Compatible Machine: - If interested, we offer an overhaul service, please contact us. 65KG 120X80X60 Lrodpfx Amjylaibetep
