CNC Lathe

INDEX C200

Condition: excellent (used), Year of construction: 2009, operating hours: 28,742 h, functionality: fully functional, bar passage: 65 mm, FANUC Series 31i-Model A 3 turrets Parts conveyor Magazine Further details on request Nodpfxeydmbuo Ac Tocu

Condition: good (used), Year of construction: 2007, travel distance X-axis: 750 mm, travel distance Y-axis: 750 mm, travel distance Z-axis: 725 mm, CNC control Sinumerik 840D NC-rotary table B-axis automatic tool changer for 320 tools pallet changing device, 2 pallets 500 mm x 500mm coolant through spindle device IKZ (80 bar) chip conveyor coolant device Nodpfjq Ui Hqsx Ac Tecu Technische Daten / technical details: X-Weg längs / X-travel longitudinal 750 mm Y-Weg senkrecht / Y-travel vertical 750 mm Z-Weg quer / Z-travel cross 725 mm B-Achse / B-axis 360 ° Spindelaufnahme / spindle taper HSK 63A Drehzahlbereich Spindel / spindle speed 50-10000 Upm /rpm Werkzeugplätze / tool places in changer 320 Vorschub / infeed 60000 mm/min Eilgang / rapid feed 60 m/min Antriebsleistung Spindel 40/100% ED / drive capacity spindle 40/100%ED 37/24 kW Gewicht der Maschine ca. / weight ca. 15000 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.

Condition: used, Year of construction: 2017, INDEX C200 Mfd. 2017 Tooling in photos to be divided between 3 C200 machines available. Power-on hours: ~49,960 h Hydraulic hours: ~48,700 h Main spindle hours: ~24,800 h Counter spindle hours: ~24,000 h Stroke mm 20 Clamping pressure min.Max. bar 8/80 Piston Area pressure cm^2 57 Area piston thrust cm^2 57 pressure Force Max. CN 45,6 Tensile force Max. CN 45,6 10350989 1 INDEX C200 CNC-turning machine with 3 revolvers with Siemens-Based Index C200 control system SINUMERIK 840D SolutionLine - Rigid cast iron bed, perpendicular angle to the ground, excellent gradient chips - The kinematics of tool head movements guarantees maximum damping, reducing tool wear - Patented plate supports with excellent properties damping and stiffness The motion of the X-axis is derived through kinematics. "double scissors" guaranteeing high dynamics - Thermosymmetric spindle Control system Index C200 Identical to SIEMENS SINUMERIK 840d SolutionLine - Modular multiprocessor control system, SINAMICS with 120 drives - Siemens Operate control box, display in language Germany - language switching WINDOWS and flat screen - 2x USB 2.0 connection on the control panel, 2x USB connection on the control panel - NCU 720.3 B PN NCK - Integrated PLC 317-3 PNDP and ET200S - Security features implemented in software through SIEMENS Safety-Integrated and ProfiSave Extended machining cycles consisting of: Einstechzyklus Freistechzyklus Gewindestrehlen with 4 point move Lighting work. space in LED design 1 flat color TFT screen, 18.5" PCT-Touch IP65 front panel 10142338 1 Main spindle dia 65 Spindle end AD140mm, ID 85mm Material passage Max. mm 65 Speed max. 1 / min 5000 Front bearing diameter mm 110 Power 100% / 40% kW 31,5/32 Torque Max. 100%/40% Nm 125/170 Continuously synchronous variable speed drives Main spindle with hollow clamping cylinder D65/20 for pincer clamping or Chuck clamping Hydraulic control with clamp metering C axis of main spindle Drive: hollow spindle motor clamping cylinder, metering system directly on the spindle Njdpfx Aoy Um Rroc Tscu Resolution 0.00014 degrees Positionsstreubreite (VDI/DGQ 3441) Psmax = 0.01 degree 11040430 pressure clamping device Clamping pressure 8-75 bar adjustable For anti-spindle clamping cylinder 10038475 1 tool carrier 1 X-axis work vehicle mm 110 X-axis quick shift m / min 30 X-axis acceleration m / s^2 9 X-axis shear force N 5000 Z-axis work vehicle mm 320 Z-axis quick feed m / min 50 Z-axis acceleration m / s^2 9 Z-axis shear force N 5000 Y-axis working vehicle mm 100 Y-axis quick feed m / min 15 Y-axis acceleration m / s^2 9 Y-axis shear force N 5000 Offer: 1702114 - 02 / 30.3.2017 CNC-lathe INDEX C200 (GP3790. 0000F) Revolver 1: 14 stations with cylindrical shank clamping D25x48 (DIN 69880), W-grooves on the revolver-higher repeated accuracy when replacing the tool. Centering plate set, V-strips, not content of delivery, must be ordered separately. Gearshift revolver AC motor, hydraulic locking A driven tool is possible in each station of the revolver 1 . Power 25% kW 10 Torque 25% Nm 16 Speed max. 1 / min 8000 10720950 1 tool carrier 2 X-axis working vehicle mm 110 X-axis quick shift m / min 30 X-axis acceleration m / s^2 9 X-axis shear force N 5000

Condition: used, Year of construction: 2014, INDEX C200 CNC Lathe 3 Turrets 2 spindles Fanuc Control: 31i-Model B Axial Motorized Switches: 6 pcs Radial Motorized Switches: 13 pcs Tool Holders: 11 pcs Boring Bar Holders: 21 pcs Ncjdpfxoxxm Hfe Ac Tsu Pin: 1 pcs Loader Bushings + Sleeves: Ø51/Ø46/Ø41 New MBL loader bushings: 2 sets 2 optical scales overhauled by HEIDENHAIN 1 Balluff Socket Gantry Arms Box with various sensors and proximity switches and cables Motorized Belts: 6 pcs Set of anti-vibration bushings for MBL loaders Start-up time: On time: 37946 Hydraulic hours: 37,500 Production time: 26,500 With MBL Bar Feed

Condition: used, TECHNICAL DETAILS - Number of axes : 4 MILLING SPINDLE - Tool holder type : BT30 - Spindle power : 4,9 [kW] - Spindle speeds : 16.000 [rpm] LINEAR AXES - Travels on X/Y/Z axes : 700 x 400 x 300 [mm] - Rapid traverses rates (X/Y/Z) : 50 / 50 /56 [m/min] - Cutting feed rates (X/Y/Z) : 1 - 30.000 [mm/min] - Distance table / spindle nose (min./max.) : 330 - 630 [mm] TOOL CHANGER - Auto. Tool Changer type : Parapluie - Tool magazine capacity : 21 - Tool exchange time : 0,8 [sec] Ncsdpfjxzu T Sex Ac Teu TABLE - Table dimensions : 800 x 400 [mm] - Maximum weight upon table : 250 [kg] POWER SUPPLY - Supply voltage : 220 [V] - Total installed power : 9,5 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 2.050 x 2.220 [mm] - Machine height : 2.497 [mm] - Machine weight : 2.400 [kg] MACHINE HOURS - Number of hours under power : 23.456 [h] - Number of working hours : 16.703 [h] EQUIPMENT - CNC : Brother CNC-C00 - Interface : Ethernet / USB - Electronic handwheel - CNC option : extanded Memory 500 Mo - CNC option : High accuracy mode BⅡ - Type of divisor : 4e axe CNC intégré * manufacturer : YUKIWA * model : DRC170-EU * travel 4th axis : 360 [°] * indexing precision 4th axis : 0,001 [°] * clamping diameter : 140 [mm] * center height : 135 [mm] * with counter bearing * Coolant tank : 150 [l] * with high-pressure pump : 15 [bars] * With cabin washing - Coolant through spindle - Tool probe - Electric transformer

Condition: excellent (used), Year of construction: 2009, operating hours: 29,000 h, functionality: fully functional, Equipment: documentation/manual, The INDEX C200 – manufactured in 2009 – is a powerful CNC production turning center with a FANUC 31i control, main and counter spindle, and a 65 mm bar capacity. The machine features a high-quality 3-turret design, with turrets 1 and 2 each equipped with X, Z, and Y axes, and turret 3 used for machining on the counter spindle. All three disc turrets are equipped with 10 stations and, with driven tools up to 6,000 rpm, enable highly flexible complete machining. With a portal parts handler, conveyor belt, C-axes on the main and counter spindles, and powerful spindle drives, the machine is particularly suitable for productive series production of complex turned/milled parts. Control: FANUC 31i Design: Machine with 3 tool holders / 3 disc turrets Bar capacity: 65 mm Machine bed: Vertically arranged gray cast iron machine bed Main spindle: Spindle 4 Counter spindle: Spindle 5 with Z-axis Spindles Main spindle Bar capacity: 65 mm Spindle diameter at front bearing: 110 mm Spindle nose: ISO 702/1, Size 140 Cyl. Chuck diameter: 160 mm Power: 25 kW at 100% ED / 33 kW at 40% ED Torque: 112 Nm at 100% ED / 150 Nm at 40% ED Speed: 5,000 rpm C-axis: Resolution 0.001° Counter spindle Bar capacity: 65 mm Spindle diameter at front bearing: 110 mm Spindle nose: ISO 702/1, Size 140 Cyl. Chuck diameter: 160 mm Power: 25 kW at 100% ED / 33 kW at 40% ED Torque: 112 Nm at 100% ED / 150 Nm at 40% ED Speed: 5,000 rpm C-axis: Resolution 0.001° Counter spindle Z-axis: 700 mm travel Rapid traverse Z-axis: 50 m/min Tool holder / Turret Design with 3 disc turrets, each with 10 stations. Tool system with 10 stations: Cylindrical shank DIN 69880 – Ø30 x 55 mm. Tool holder 1 X, Z, Y axes 10 stations X-axis: 110 mm Z-axis: 320 / 550 mm (according to documentation) Y-axis: 100 mm, ±50 mm Driven tools: 6.5 kW / 16 Nm / 6,000 rpm Tool holder 2 X, Z, Y axes 10 stations X-axis: 110 mm Z-axis: 550 mm Y-axis: 100 mm, ±50 mm Driven tools: 6.5 kW / 16 Nm / 6,000 rpm Tool holder 3 X-axis 10 stations Used exclusively for machining on the counter spindle X-axis: 180 mm Driven tools: 6.5 kW / 16 Nm / 6,000 rpm Further technical equipment according to documentation Portal parts handling system with numerically controlled Z-axis Workpiece removal from main or counter spindle to conveyor belt Removal of scrap material from the main spindle into a scrap container Portal parts handler: Traverse speed: 100 m/min Traverse range: 70 mm Workpiece diameter max.: 90 mm Workpiece length max.: 250 mm Nodpfx Aey Tmhzoc Tscu Scrap length max.: 250 mm Workpiece weight max.: 3.5 kg Hydraulic system: Flow rate: 19 l/min System pressure: 90 bar Hydraulic tank: 40 l Coolant circuit: Flow rate: 19 l/min Coolant unit power: 13 kW Coolant system: Pump output: 80 l/min / 8 bar Tank capacity: 300 l Chip conveyor: Chip discharge height: 1,250 mm

Condition: excellent (used), Year of construction: 2014, operating hours: 27,000 h, functionality: fully functional, Pump + Filter + Cooler No. 06 Axial Driven Tools Ncjdjy Rlbzspfx Ac Teu No. 13 Radial Driven Tools Toolholder Boring Bar Holder Steady Rest: Magazine Bushings + Sleeves: Ø51/ Ø46 / Ø41 No. 02 new sets of MBL magazine bushings No. 02 optical scales overhauled by HEIDENHAIN 1 Baluff socket Grippers for Gantry Various sensors, proximity, cables Belts for driven tools: 6 pcs Set of anti-vibration bushings for MBL magazines

Condition: good (used), CHARACTERISTICS Plate diameter ⌀; 3200 mm Maximum turning/turning diameter ⌀; 3300 mm Ncodpfx Acor I Aykj Tsu - With upright forward; 3300 mm - With upright set back; 5600 mm Min. turning/turning diameter ⌀ - With advanced upright; 800 mm - With upright set back; 3100 mm Max turning height; 750 mm Control; FAGOR 8025 Spindle RPM (2 ranges); - 0,5 - 10 rpm - 10 - 40 rpm Motor Power; 80 hp Maximum table load; 30.000 kg

Condition: ready for operation (used), Year of construction: 2000, spindle motor power: 22,000 W, total height: 2,050 mm, overall weight: 4,000 kg, controller manufacturer: INDEX, controller model: C200-4 / C200-8, This 5-axis Index G200 C turn-mill centre was manufactured in 2000. Consider the opportunity to buy this Index G200 C turn-mill centre. Contact us for more information. Additional equipment • Synchronous device for counter spindle machining • Tool carrier 3 for synchronous spindle (rear end machining) • Additional milling spindle • Thread milling and polygon turning device • Gripperless tool changer (6 tools, HKS-50 B, KM40) • Workpiece handling WHU100 • with c-axis • no driven tools Machine Benefits Technical Machine Benefits • Space requirement (without material guide): 3580 x 3108 mm • Control unit: resolution: 0. 001 mm (input/output/correction) • Comprehensive movement range with multiple axes configuration • High precision with 0. 001 mm resolution in numerical control • Versatile expansion stages and additional equipment for enhanced functionality Extra Information Nedsyailzepfx Ac Tjcu Movement Cross slide 1 (top) - XYZB axes: X-axis: Slide path 155 mm, feed force 5000 N, rapid traverse 20 m/min, resolution 0.0005 mm Y-axis: Slide travel 120 mm, feed force 10000 N, rapid traverse 7.5 m/min, resolution 0.0005 mm Z-axis: Slide path 590 mm, feed force 5000 N, rapid traverse 30 m/min, resolution 0.001 mm B-axis (rotating): 360° swivel range, angular steps 5° (with locking), resolution 0.001° (with clamping), switching time for 180°: 1 s Cross slide 2 (bottom) - XZ axes: X-axis: Slide travel 105 mm, feed force 5000 N, rapid traverse 20 m/min, resolution 0.0005 mm Z-axis: Slide path 307 mm, feed force 5000 N, rapid traverse 30 m/min, resolution 0.001 mm Turret Turret right: X-axis: Slide path 120 mm Z-axis: Slide travel 400 mm Tail Stock Center distance: 400 mm Pressure force (max): 5500 N Drive: Hydraulic or electric Media Power supply: 400 V, 50/60 Hz Connected load: 20-45 kVA Current consumption: 35-80 A Hydraulic system: Delivery rate: 18 l/min System pressure: 90 bar Filling capacity: 70 liters Cooling lubricant system: Pump capacity (switchable): 20 l/min at 18 bar / 50 l/min at 3 bar / 60 l/min at 5-7 bar Filling quantity: Approx. 230 liters Chip conveyor: Hinged belt or scraper Workpiece holder: Main spindle: DB5 internal mount / D140 external mount, optional short taper Counter spindle: D140 external mount (only tensile clamping permitted for collet and chuck clamping) 1st spindle data (main/counter spindle): Spindle clearance (collet clamping): Variants: 30 mm / 42 mm / 60 mm / 65 mm Spindle Ø in front bearing: 75 mm (with 30 mm clearance) / 85 mm (42 mm) / 100 mm (60+65 mm) Speed (max): 7500 rpm (30 mm) / 6300 rpm (42 mm) / 5000 rpm (60 mm) Spindle nose: ISO 702/1 (size 4 or 5) Chip diameter (workpiece Ø): 110-130 mm (30 mm) / 140-160 mm (42 mm) / 165 mm (60 mm) Torque (Md max 100%): 33-62 Nm (30 mm) / 35-95 Nm (42 mm) Power (P max 100%): 7-13 kW (30 mm) / 7.5-20 kW (42 mm) Dimensions Machine Depth 3580 mm

Year of construction: 1997, condition: ready for operation (used), Turning diameter: 200mm, turning length: 400mm, turning diameter: 420mm, bar diameter: 60mm, max. spindle chuck diameter: 160mm, speed: 5000rpm, turret: 2, positions: 2x14, rapid traverse X/Z: 20m/min/30m/min. Machine dimensions X/Y/Z: approx. 7500mm/2100mm/2100mm, weight: approx. 4500kg. Documentation available. On-site inspection is possible. Ncjdpfx Acju T Rgke Tou

Condition: used, TECHNICAL DETAILS Nodpfx Aeuhb Uhsc Tocu - max. power : 40 [t] - max. workpiece diameter : 40 [mm] - spindle diameter : 80 [mm] - spindle length : 120 [mm] - max. tool diameter : 250 [mm] - dimensions : 2400 x 2100 x 2200 [mm] - weight : 7100 [kg] EQUIPMENT - control CNC (base Siemens) - tail stock device - coolant tank with pump - 2 boring wheel 80, diameter : 260 [mm]
