Plants

INDEX

Condition: ready for operation (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: 020033, spindle speed (max.): 5,000 rpm, spindle diameter: 110 mm, controller model: Siemens SINUMERIK, empty load weight: 11,000 kg, counter spindle speed (max.): 5,000 rpm, TECHNICAL DETAILS Working area X1 axis: 1,190 mm Working area Y1 axis: 120 mm Working area Z1 axis: 260 mm Working area X3 axis: 540 mm Working area Y3 axis: 120 mm Working area Z3 axis: 260 mm Handling space X1 axis: 490 mm Axes and Feed Feed force X1/Z1/Y1: approx. 8/10/10 kN Feed force X3/Z3/Y3: approx. 8/10/10 kN Rapid traverse speed X1/Z1/Y1: approx. 80/40/7.5 m/min Rapid traverse speed X3/Z3/Y3: approx. 40/40/7.5 m/min Acceleration X1/Z1/Y1: 7/7/7 m/s² Acceleration X3/Z3/Y3: 7/7/7 m/s² Spindle Speed at main and counter spindle: 5,000 rpm Power at 100% duty cycle, main spindle: 20 kW Torque at 100% duty cycle: 105 Nm Power at 40% duty cycle: 27 kW Torque at 40% duty cycle: 145 Nm Spindle bore: 65 mm Spindle diameter in the front bearing: 110 mm Spindle nose diameter (cylindrical): 140 mm Hydraulic full-stroke cylinder OVS80 - Main spindle Piston stroke: 32 mm Piston area: 34.36 cm² Clamping pressure: 8 to 80 bar Tensile or compressive force at 80 bar: max. 27.2 kN Leakage oil volume at operating pressure 80 bar: max. 2.2 l/min Hydraulic full-stroke cylinder OVS65 - Counter spindle Hedpfxezdqdfs Ap Hsnn Piston stroke: 32 mm Piston area: 26.1 cm² Clamping pressure: 8 to 100 bar Tensile or compressive force at 100 bar: max. 26.1 kN Leakage oil volume at operating pressure 100 bar: max. 3 l/min Y-axis Saddle travel: 120 mm Feed force: 10 kN Rapid traverse: 7.5 m/min Resolution: 0.05 mm Speed of driven tools: 6,000 rpm MACHINE DETAILS Control system: Siemens SINUMERIK Unloading device Swivel angle: 90 degrees Swivel time: 2 s Saddle travel: 100 mm Rapid traverse speed: 6 m/min Workpiece weight: approx. 10 kg Workpiece diameter: 200 mm Electrical data Rated power: 45 kW Apparent power: 53 kVA Rated current: 76 A Voltage: 400 V Frequency: 50/60 Hz Dimensions and weight Dimensions with conveyor belt (L x W x H): 2,770 x 4,435 x 2,750 mm Weight: approx. 11,000 kg EQUIPMENT Two tool holders, each with 12 VDI 30 stations Note: Further technical data can be found in the attached data sheet. The machine is not equipped with a B-axis.

Condition: good (used), Tool package 23 pieces various driven and rigid tool holders VDI 30 were mounted on Index C 200 Hedsiludzjpfx Ap Henn

Condition: ready for operation (used), Year of construction: 2012, operating hours: 75,685 h, spindle speed (max.): 6,000 rpm, travel distance X-axis: 85 mm, travel distance Z-axis: 280 mm, spindle motor power: 20,000 W, number of axes: 7, This 7-axis Index ABC horizontal turning machine was manufactured in 2012. It features a main spindle with a maximum speed of 6000 rpm and a sub spindle with a speed of 4500 rpm. The machine includes two turrets, each equipped with X and Z axes, and a powerful tool drive. If you are looking to get high-quality turning capabilities, consider the Index ABC machine we have for sale. Contact us for further details. • Main spindle: D65, spindle interface AD140, ID83, max speed 6000 rpm; max power 20 kW at 100% duty cycle; C-axis; electronic synchronization between spindles • Sub spindle: 7.5" chuck interface, max speed 4500 rpm • Spindle hours: • S1 – 18914h • S2 – 661h • S3 – 3h • S4 – 29211h • S5 – 2413h • S7 – 1250h • Chuck: 3-jaw KFN95/3, clamping force 480 daN, max 4000 rpm • Turrets: two turrets each with X and Z axis; tool drive on turret 6000 rpm, 3.3 kW • Rear working attachment: without quill, 5 quill positions • Coolant: 80 l/min at 8 bar and 20 l/min at 18 bar; system prepared for emulsion; coolant return at spindle end D60 (without bar feed) • Control: INDEX C200-4D based on Siemens 840D; color display 26 cm; thread cutting without compensating chuck; motor-current-based tool monitoring; internal tool management and setup dialog; extended machining cycles; parts counter and production monitoring • Power/connection data: 400 V, 50 Hz TN network; total connected load 45 kVA; rated power 38 kW; rated current 65 A; max fuse protection 100 A • Hydraulic hollow clamping cylinder D65 Additional equipment • Chip conveyor: hinged belt, discharge height 1250 mm • Bar feeder: MBL 65/3700 for spindle height 1010 mm; bar diameters up to 65 mm; bar feeder length 3700 mm; guide channel system with rolling bearings; loading rods (Ø12 mm and Ø20 mm, length 1400 mm); guide sets for 14–18 mm, 18–22 mm, 22–65 mm • Workpiece unloading device for main and sub spindle with part catcher Hnedpfx Apey Sg Dao Hon • Teleservice preparation (ISDN) with software • Machine prepared for extraction system 230 V • Working area light • Two electrical cabinet cooling units • Transformer 3 kVA Technical Specification Counter Spindle Yes Driven Tools Yes

Condition: excellent (used), Year of construction: 1998, Machine in very good condition. It has worked to the end, now it is on warehouse not connected to power. Machine in 100% completed Parts conveyor, chips conveyor, available. Spindels bore 42 mm 2x 3 jaws chuck 160 mm Hnodjwq Rwnepfx Ap Hjn 2x Hainbuch collets chuck 42 mm

Condition: used, Year of construction: 2015, Technical details: number of spindles: 6 spindle passage: 22 mm ?Bar feeder complete is 4.70 meters - for 3 meters of material ?The machine is still on ?Materail to be processed on the machine: Steel ?Production with OIL Machine has only Single-NCU without PCU. The complete energy supply of all 6 main spindles was replaced in April 25. No socket for powered tools! Hedpfx Ajxc Idmsp Hjnn *

Condition: ready for operation (used), Year of construction: 2012, spindle speed (max.): 7,000 rpm, travel distance X-axis: 70 mm, travel distance Y-axis: 70 mm, travel distance Z-axis: 250 mm, spindle motor power: 22,000 W, controller manufacturer: INDEX, controller model: C200-4D Control, number of axes: 9, This 9-axis Index C100 was manufactured in 2012. It features a robust cast iron machine frame and a powerful main spindle with a maximum speed of 7000 rpm and a bar diameter of 42 mm. The machine includes three turrets with live tools, offering versatile machining capabilities. If you are looking to get high-quality turning capabilities, consider the Index C100 horizontal turning machine we have for sale. Contact us for further details regarding this machine. Hjdpfxjzcykgs Ap Hsnn - Machine Frame: Cast iron machine frame in vertical bed design- Tool Carrier Guides: Plate guides with high level of rigidity and dampening- Axis Drives: Double-scissor kinematics for tool carriers; AC synchronous drive technology- Headstock Design: Thermo-symmetrical design- Main Spindle (D42): Spindle head size 5 (DIN 55026 and ISO 702), max. bar diameter 42 mm, max. speed 7000 rpm, front bearing diameter 75 mm- Main Spindle Power: 22/29 kW (at 100%/40% duty cycle)- Main Spindle Torque: 50/65 Nm (at 100%/40% max.)- Main Spindle Clamping Cylinder: Hollow clamping cylinder D42/14 for collet or chuck clamping, hydraulic operation, stroke 12 mm, clamping pressure 8/80 bar, max. thrust 34 kN, max. pull 34 kN- C-Axis Drive (Main & Counter Spindle): Hollow shaft motor, angular gauging system on spindle, resolution 0.00014 degrees, repeatability scatter Psmax = 0.01 degrees- Main Spindle Clamping Unit: Single pressure clamping unit, adjustable from 8 to 75 bar- Counter Spindle (D42): Spindle head size 5 (DIN 55026 and ISO 702), max. bar diameter 42 mm, max. speed 7000 rpm, collet chuck diameter 110 mm, front bearing diameter 75 mm- Counter Spindle Power: 16.5/19 kW (at 100%/40% duty cycle)- Counter Spindle Torque: 32/43 Nm (at 100%/40% max.)- Counter Spindle Slides (Z-axis): AC motor and ball screws drive, working travel 500 mm, rapid traverse 60 m/min, acceleration 10 m/s^2, feed thrust 3000 N- Counter Spindle Clamping Cylinder: Hollow clamping cylinder D42/14, hydraulic operation, stroke 12 mm, clamping pressure 8/80 bar, max. thrust 34 kN, max. pull 34 kN- Counter Spindle Clamping Device: Single pressure clamping device, adjustable from 8 to 75 bar- Tool Carrier 1: X-axis travel 70 mm (rapid 30 m/min, acc. 9 m/s^2, feed force 3000 N); Z-axis travel 250 mm (rapid 60 m/min, acc. 9 m/s^2, feed force 3000 N); Y-axis travel 70 mm (rapid 15 m/min, acc. 5 m/s^2, feed force 3000 N). Turret 1 with 10 stations, parallel shank mountings D25x48 (DIN 69880), live tools on all stations (Power 4.2 kW, Torque 11 Nm, max. speed 8000 rpm)- Tool Carrier 2: X-axis travel 70 mm (rapid 30 m/min, acc. 9 m/s^2, feed force 3000 N); Z-axis travel 400 mm (rapid 60 m/min, acc. 9 m/s^2, feed force 3000 N); Y-axis travel 70 mm (rapid 15 m/min, acc. 5 m/s^2, feed force 3000 N). Turret 2 with 10 stations, parallel shank mountings D25x48 (DIN 69880), live tools on all stations (Power 4.2 kW, Torque 11 Nm, max. speed 8000 rpm)- Tool Carrier 3: X-axis travel 125 mm (rapid 30 m/min, acc. 10 m/s^2, feed force 3000 N). Turret 3 with 10 stations, parallel shank mountings D25x48 (DIN 69880), live tools on all stations (Power 4.2 kW, Torque 11 Nm, max.

Condition: excellent (used), Year of construction: 2009, operating hours: 28,742 h, functionality: fully functional, bar passage: 65 mm, FANUC Series 31i-Model A 3 turrets Hnedpfx Apeydmbue Hsn Parts conveyor Magazine Further details on request

Condition: used, Year of construction: 2007, functionality: fully functional, 6-spindle Hainbuch Spanntop Axfix D22 ARTIS integrated process monitoring system Slide units Hedpfoyymbzsx Ap Hjnn - Slide unit 1.1: X-axis fixed, Z-axis NC-controlled - Slide unit 2.1: X-axis fixed, Z-axis NC-controlled - Slide unit 1.2: X-axis and Z-axis NC-controlled - Slide unit 2.2: X-axis and Z-axis NC-controlled - Slide unit 3.1: X-axis and Z-axis NC-controlled - Slide unit 3.2: X-axis and Z-axis NC-controlled - Slide unit 4.1: X-axis and Z-axis NC-controlled - Slide unit 4.2: X-axis and Z-axis NC-controlled - Slide unit 5.1: X-axis and Z-axis NC-controlled - Slide unit 5.2: X-axis and Z-axis NC-controlled - Slide unit 6.1: swiveling axis and Z-axis NC-controlled - Slide unit 6.2: X-axis and Z-axis NC-controlled Synchronization device, position 6.1 Part discharge via chute Workpiece conveyor belt at spindle position 6 High-pressure pump Fire extinguishing system Coolant cleaning system Hinged belt chip conveyor Flat loading magazine: IEMCA SIR MS 22/33 P

Condition: good (used), Year of construction: 1997, functionality: fully functional, Siemens control system, spindle bore 65 mm, Hnodpfx Aezcxk Eep Hjn two turrets, live tooling spindle, Hainbuch collet chuck, MBL bar loader laser, chip conveyor.

Condition: good (used), Year of construction: 2013, functionality: fully functional, Siemens control system, 14-position turret, tool holder VDI30, powered tools, spindle bore 65mm, bar feed MBF, Hnsdpjzcxi Iefx Ap Hjn chip conveyor. The machine was completely overhauled in 2013.
