Foil-Packing & shrinking equipment

Kallfass

Condition: like new (used), inline Foilsealer and Shrinking tunnel Make: Kallfass Type: semi/automatic shrinking tunnel Modell: Mat 1606-KS1600uni Codsg D Nv Tspfx Ad Aogt Capacity: 10-15packs/min (depends on product) Frame: Steel Range: 1600(belt)x600mm (W x H) Dimensions: L x W x H = 4000 x 2050 x 1750mm Weight: 900Kg Electric: 380V+N+E, 65Kw Condition: As-is, working condition

Condition: reconditioned (used), Shrinking tunnel / foil wrapper Cgedpfx Asg D Nyhjd Aot Make: Kallfass Type: semi/automatic shrinking tunnel Model: Combimatic 600 Frame: steel painted Range: max. packet W x L x H = 600 x 380 x 400 mm Capacity: max. 600 packs/min Dimensions: L x W x H = 4 200 x 1 550 x 2 000 mm Weight: 850 kg Power-supply: 380 Volt - 50Hz - 23,5 kW Features: mobile water-cooled welding beam automatic / semi-automatic 2 hand control Remark: excellent condition

Condition: ready for operation (used), Year of construction: 2003, functionality: unexamined, total length: 2,400 mm, total height: 1,400 mm, total width: 1,300 mm, Kallfass Shrink Tunnel STANDARD 650 NT Universally applicable high-performance shrink tunnel with side-adjustable air flaps and externally adjustable bottom air outlets for precise control of the hot air flow, ensuring optimal shrink results even with challenging product contours. The recirculation system, a tunnel hood with an additional double-chamber system, and significantly enhanced all-round insulation provide energy-efficient operation. Equipped with infinitely variable rod chain conveyor. This tunnel is suitable for use with all shrink films, especially polyethylene (LDPE) or polyolefin films, in medium to high performance ranges. Comprehensive standard features: • Silicone-coated transport rods, rod spacing 25 mm, rod diameter 12 mm • Infinitely variable speed adjustment for the rod chain conveyor • Wear-free, contactless temperature control • Energy-saving, highly effective thermal insulation of the tunnel hood • Temperature control via electronic thermostat • Air outlet flaps adjustable from outside during operation • Fixed clearance height 200 mm • Adjustable working height • Safety equipment in accordance with EC Directive EN 60204: over-temperature monitoring Cgsdpfx Adey Ic Hij Aot • Machine design complies with EC Machinery Directive 98/37/EC (CE mark), built to EN/VDE standards and relevant accident prevention regulations for the food and beverage industry (GS test mark) Technical Data of Base Machine: Tunnel passage width: 650 mm Tunnel passage height: 200 mm (fixed) Length of heated tunnel hood: 1400 mm Extended tunnel outfeed: approx. 500 mm Working height, adjustable: 800 - 900 mm Product transport: rod chain conveyor, silicone-coated rods, rod spacing 25 mm, rod diameter 12 mm Transport speed, variable: 6 - 22 m/min Drive: three-phase geared motor 0.37 kW, frequency-controlled Heater blower output: constant Airflow adjustment: sliding dampers underneath and side air flaps, externally adjustable Temperature control: electronic thermostat, switching accuracy ± 0.2°C Control voltage: 24 V DC Power supply: 400 V three-phase current, 50 Hz with protective earth Installed heating capacity: 18 kW (average continuous consumption approx. 40%) Power rating: 20.5 + 11.1 kVA Nominal current at 400 V: 29.6 A in standalone mode Max. total connected load: 45.6 A incl. additional three-phase connection Control cabinet position and operator side: on the left in working direction Paint finish: Kallfass anthracite

Condition: ready for operation (used), Year of construction: 2003, functionality: unexamined, total length: 1,800 mm, total height: 1,400 mm, total width: 1,000 mm, KALLFASS Shrink Tunnel COMPACT 450 SO (Used machine, year of manufacture 2003; sold as is, where is) On consignment from customer Description: Compact and economical shrink tunnel featuring the patented ring nozzle heating system with highly effective air flow regulation. Equipped with infinitely variable rod chain conveyor. The rotatable rod device prevents undesirable marks on the bottom of the packaged goods when using technical films such as Clysar ®, Cryovac ®, and others. This tunnel is particularly suited for shrinking small to medium format products with moderate throughput requirements. Comprehensive standard equipment includes: • Silicone-coated transport rods, rod spacing 25 mm, rod diameter 12 mm • Optional device for rotating transport rods • Infinitely variable speed control for the rod chain conveyor • Infinitely variable tunnel fan power, adjustable according to film quality • Energy-saving 2-stage heating system with highly effective thermal insulation of the tunnel hood • Temperature control via electronic thermostat • Adjustable tunnel clearance height • Adjustable working height Technical data: Tunnel passage width: 450 mm Tunnel passage height, adjustable: 100 - 400 mm Length of heated tunnel hood: 1,400 mm Working height, adjustable: 800 - 900 mm Conveyor speed, variable: 2.5 - 12 m/min Drive: AC motor 0.25 kW Airflow regulation: Patented ring nozzle system Temperature control: Electronic thermostat Power supply: 400 Volt three-phase, 50 Hz with protective earth Installed heating capacity, 2-stage switchable: 9 + 4.5 kW (continuous operation consumption approx. 40%) Cjdpfoy Ic Akjx Ad Ajgt Rated power: 24 kW Rated current: 36.0 A Control cabinet position and operator side: Left, in direction of operation Finish: Kallfass anthracite Additional equipment: • 300 mm cooling station with ball-bearing mounted aluminium rollers at the tunnel outlet • Special cooling fan mounted above the tunnel outlet

Condition: not inspected (used), Year of construction: 2003, functionality: limited functionality, total length: 1,950 mm, total height: 1,850 mm, total width: 1,650 mm, type of input current: three-phase, product height (max.): 100 mm, product length (min.): 50 mm, product length (max.): 5,000 mm, product width (max.): 450 mm, product width (min.): 20 mm, input voltage: 400 V, input current: 5 A, working height: 800 mm, width of welding knife: 450 mm, passage height: 150 mm, overall weight: 800 kg, power: 3 kW (4.08 HP), Fully Automatic Side Sealing Machine UNIVERSA 400NT Used Machine; Year of Manufacture: 06/2003 Description: Fully automatic L-seal flow packaging machine for packaging products—regardless of their length—with a full wrap and without film overlap. Maximum output is approx. 85 cycles/min. Product feeding is carried out via a conveyor belt, simultaneously wrapping the item in a centre-folded film using a forming shoulder. Product indexing is managed by photoelectric sensors. The feed conveyor can be smoothly adjusted for different product widths. After the product is wrapped in film, the cross sealing is performed by a permanently heated sealing system. Longitudinal sealing is achieved via a continuous side sealing unit. The height of both the forming shoulder and sealing systems can be manually adjusted. The remaining film trim is collected on a film winding device. Suitable for all standard centre-folded films from approx. 12 – 80 µm, e.g. polyethylene (LDPE) and polyolefin films. Comprehensive standard equipment: • Motor-driven film holder, located near the floor for easy loading • Film tear and end-of-film detection • Product indexing selectable via horizontal or vertical photoelectric sensor • Product protection in the sealing area with special safety light barrier • Conveyor belts at the sealing transition point equipped with knife edges • Infeed conveyor extendable for easy, quick threading of film • Permanently heated sealing bar with exchangeable sealing strip; available in various profiles for optimal seam quality depending on product and film type • Electromechanical sealing bar drive • Continuous side sealing • Motor-driven film transport with automatic film trim winding • Operator guidance and fault diagnosis via multilingual text display (languages: German, English) • Programmable logic controller: SIEMENS S5 • Adjustable working height • Machine built in accordance with EU Machinery Directive 98/37/EC (CE sign), EN/VDE standards, and relevant accident prevention regulations of the Employers’ Liability Insurance Association for Food and Luxury Goods Industry (GS mark) Additional features: • Infinitely variable speed control for both conveyor belts with frequency inverter, adjustment range approx. 10–35 m/min, including soft start • Film shortage monitoring Codpfxey Icr Sj Ad Aegt Technical data of the base machine: Cross sealing bar length: 450 mm Minimum product length: 80 mm Film: Centre-folded film, approx. 12–80 µm Film roll support: Near floor level for easy loading Film roll outside diameter: max. 400 mm Film core diameter: approx. 76 mm Film roll width: max. 600 mm Working height: 780–930 mm Conveying speed: Adjustable 10–35 m/min Sealing system: Permanently heated sealing bar with exchangeable sealing strip, completely odourless operation, temperature control and monitoring via PLC PLC: Siemens S5 Sealing bar clearance height: max. 150 mm Power supply: 400 V three-phase, 50 Hz with protective conductor Rated power: 3.5 kVA Rated current: 5.1 A Control cabinet position: To the right in working direction Finish: Kallfass anthracite Dimensions: L = 1,975 x W = 1,170 mm x H = 1,400 mm

Condition: ready for operation (used), Year of construction: 1982, functionality: unexamined, length of welding knife: 560 mm, passage height: 230 mm, passage width: 430 mm, Equipment: documentation/manual, KALLFASS Compact Shrink Wrapper KC 5040/450 - Used unit, year of manufacture 1982 Description: Cjdpfoy H Evdsx Ad Aogt Easy-to-use L-sealer combined with a shrink tunnel. Exceptionally robust design for industrial use. Sealing frame dimensions: 500 x 400 mm. Proven impulse sealing technology with PTFE-coated sealing wire for absolutely odorless operation. Performance up to approx. 20 cycles/min. Sealing frame can be closed manually with minimal effort. Equipped with a closure mechanism featuring an automatic pressure system for precise compliance with set sealing times and reliable separation, even for thicker films. Product transfer conveyor for automatic feed of sealed packages into the shrink tunnel. Suitable for all standard centerfold shrink films from approx. 12 - 80 µm, e.g. polyethylene or polyolefin films. Standard basic equipment: • Film roll holder for setting film reels • Feed table complete with film separator bar and separator sheet • Air support plate for automatic opening of the centerfold film • Film hold-down plates on the sealing frame • Base heating for the sealing wires to increase packing performance • Automatic product transfer conveyor into the shrink tunnel, height adjustable for seal placement at half product height • 1 transition roller at the tunnel entrance • Adjustable rod-chain transport through the shrink tunnel • Silicone-coated conveyor rods, rod spacing 25 mm, rod diameter 12 mm • Energy-saving 2-stage heating • Highly effective thermal insulation on the tunnel hood for energy saving • Infinitely adjustable tunnel blower power • Temperature control via electronic thermostat • Adjustable tunnel passage height • Adjustable working height • Machine mounted on castors for mobile use Included additional equipment: • Automatic product transport into the shrink tunnel • 300 mm cooling station with ball-bearing aluminium rollers at tunnel exit • Special cooling fan at top of tunnel exit Technical specifications: Sealing frame dimensions: 500 x 400 mm Film: Centerfold film, approx. 12 - 80 µm Max. outer diameter of film rolls: 300 mm Film core diameter approx.: 76 mm Max. film roll width: 550 mm Adjustable working height: 870 - 970 mm Tunnel passage width: 450 mm Adjustable tunnel passage height: 100 - 400 mm Heated tunnel hood length: 900 mm Product transport: Rod-chain conveyor Variable conveyor speed: 2.5 - 12 m/min Drive: AC gear motor 0.25 kW Temperature control: Electronic thermostat Heater blower output: Infinitely adjustable Electrical connection: 400 V 3-phase, 50 Hz, with protective earth Installed heating power, 2-stage switchable: 4.5 + 1.5 kW (continuous operation consumption approx. 40%) Nominal power: 8.5 kW Nominal current: 12.3 A Control cabinet and operator side: Left, in working direction Paint finish: Kallfass green, similar to RAL 6011 Dimensions: L = 2,500 mm x W = 1,050 mm

Condition: ready for operation (used), Year of construction: 2002, functionality: fully functional, Modular gripping chain feeding system Kallfass MGZ 400 manual unit - Used machine, year of manufacture: 2002 - On wheels, lockable with spindle feet Cgedpjy H Ep Dofx Ad Ajt Chain gripper feeder with centrally positioned, interchangeable pushers and side guides in modular design. The pusher pitch is approx. 460 mm, with a maximum pusher height of 145 mm. The usable width is 500 mm. The drive is frequency-controlled and equipped with an overload clutch. The pusher spacing is adjustable. The chain gripper feeder is mobile. Total length is approx. 4,800 mm, providing space for 4 working or loading stations. Total length: 4800 mm Total width: 800 mm Working height: approx. 860-1000 mm Side guides adjustable, height 70 mm.

Condition: used, functionality: fully functional, Kallfass shrink wrapping machine – indestructible and fully operational Cgsdpoxz Tryofx Ad Aot

Condition: excellent (used), Dimensions of the entrance opening 400x200 Codpfxjtrtztj Ad Asgt Dimensions Length 2995 mm Width 1250 mm Height 1550 mm

Condition: used, Year of construction: 2010, functionality: fully functional, Manufacturer: KALLFASS Model: UNIVERSA 500, year 2010 Model: Shrink Tunnel COMPACT 650 SO, year 2010 SPECIFICATIONS KALLFASS UNIVERSA 500 - fully-automatic side sealer Transverse seal bar, length: 500 mm Product clearance height: up to 200 mm Power supply: 208 - 480 volt Film, center-folded film: 12 - 80 μm Transport speed: 10 - 35 meter / minute Packaging capacity, max.: 85 cycles / minute Technical Data Compact 650 SO Tunnel clearance in width: 650 mm Tunnel clearance in height, adjustable: 100 - 400 mm Length of the heated tunnel hood: 1100 mm Air-flow regulation with patented ring nozzle system: standard Maintenance free plastic-mesh-belt: standard Transport speed infinitely variable, frequency controlled: approx. 10 – 35 m/min. Capacity of the tunnel blower infinitely variable, frequency controlled: standard Energy saving 2-stage heating with special insulation in tunnel hood: standard Temperature control by means of electronic thermostat: switching precision +/- 0.2° C Wear resistant and contactless temperature control: standard safety device according to EC regulation machines EN 60204: limit temperature control: standard Working height, adjustable: 800 - 900 mm Power supply: 400 Volts, 50 Hz, with protective earth conductor Heating capacity, installed, 2-stage switchable: 9.0 + 4.5 kW Rated capacity: 14.5 kVA Codpsxnzlhofx Ad Asgt Nominal current at 400 V: 21.0 amps Total connected load: max. 37.0 amps (incl. add. three phase power supply) Position of control cabinet and operating side: left hand side in working direction
