CIRCULAR SAW

KALTENBACH HDM 1300

Year of construction: 2009, Condition: used, machine/vehicle number: 0301-230036, Kaltenbach drill saw system as a combination for use in light to heavy steel construction. With this Kaltenbach system, steel profiles can be drilled, center-punched and sawn to length in a single operation. Rolled profiles such as double T-steel, T-steel, U-steel, angle steel, hollow profiles and flat steel are processed here. The Kaltenbach drilling unit has an automatic tool changing device on three drilling spindles for five tool sizes each. The tools are positioned with high precision using ball screws and servomotors. The entire system is equipped with a length measuring device. Gislhccorr Sq Njqteu Technical information KDXS 1215 drilling machine: - Working area min. 80 x 65 x 10 mm - Working area max. 1200 x 450 mm - 3 drilling units (vertical Y-axis, horizontal Z- and W-axis) each 11.0 kW frequency-controlled: 33.0 kW - Automatic tool changer (3x5) - Frequency-controlled drive power 78 kW - Working height 640 mm - Machine dimensions 6100 x 1300 x 3730 mm (LxWxH) - CNC control with Profiline 3 software Kaltenbach HDM 1432 High-performance circular saw as vertical saw with swivel bearing for high sawing performance of medium and heavy steel profiles, working area at 90° saw cut: 1200 x 450 mm, mitre adjustment for mitre cuts of -45°/90°/+35°, this circular saw system is equipped with a segment saw blade diameter 1430 mm. High cutting performance thanks to powerful drive NC-controlled cutting angle adjustment Feed via ball screw for ideal cutting results and short idle times
