Cylindrical grinding machine

KELLENBERGER Rundschleimaschine UR125-600

Condition: refurbished (used), Year of construction: 2025, functionality: fully functional, machine/vehicle number: 1315/451, Completely overhauled: Mechanics, geometry, hydraulics, and electrical parts (checked and/or replaced) Wheelhead: Disassembled, parts cleaned, worn or defective components replaced, motor overhauled, bearings replaced, belts replaced, spindle disassembled, seals and O-rings replaced, adjustments made. Newly painted. Workhead: Disassembled, parts cleaned, worn or defective components replaced, motor overhauled, belts replaced. New spindle bearings. Newly painted. Tailstock: Disassembled, inspected, overhauled. Hydraulics: Disassembled, motor checked, hoses replaced, defective and worn parts replaced. Hydraulic block checked. X-axis: Disassembled, all worn parts such as O-rings, seals, segments, etc. replaced, hydraulic piston overhauled, table ground. Z-axis: Disassembled, table ground, worn or defective parts replaced, hydraulic piston overhauled, newly painted. Electrical cabinet: Completely checked, various relays replaced. Paintwork: Colors: White RAL 9003 and Grey RAL 7011 Geometry according to manufacturer's protocol. Various accessories checked and cleaned. Origin: CH Voltage: 380 / 50 / 3 Net weight: approx. 2,200 kg Customs tariff number: 8460.2920 TECHNICAL SPECIFICATIONS Nominal distance between centers: 600 mm Max. distance between centers (with extended headstock): 750 mm Center height, standard: 125 mm Center height with interchangeable pads for heads: 175–250 mm Max. workpiece diameter (125 mm center height): 250 mm Max. workpiece diameter with interchangeable pads: 350–500 mm Swiveling range of table in each direction: 10° Max. grinding length for flat surfaces (max. width = 200 mm): 900 mm Continuously variable hydraulic table speed: up to approx. 6 m/min Table reversal delay: 0–5 sec Grinding wheel for external grinding, diameter - width - bore: 400x50x127 mm Grinding wheel for flat surface grinding: 250x13x76 mm Wheelhead spindle speed: 1,500/1,700/2,200/3,600 rpm Wheelhead swiveling range: 270°, with indexing every 90° Vertical travel of wheelhead, center height: 125–350 mm Isdpfow U Ry Njx Agdjap Transverse travel of wheelhead: 285 mm Hydraulic rapid traverse stroke: 40 mm Intermittent infeed of wheel by table reversal: 0.001–0.03 mm/dia Continuous infeed for plunge grinding: 0–0.9 mm/dia Micrometric infeed stop, by division: 0.001 mm/dia Workhead swiveling range: 360° Workhead spindle speed, stepless: normal/special: 20–400 / 10–400 rpm Internal taper of workhead/tailstock: Morse 5/3 Wheelhead motor: approx. 4 HP All technical specifications are given without obligation and subject to errors or omissions.

Condition: used, Technical details: swing diameter: 200 mm centre distance: 450 mm cross travel: 245 mm longitudinal feed: 830 mm table speed: 0,05-4,5 stufenlos m/min revolution per minute: Schleifspindel 1780, 2050 U/min revolution per minute: Werkstückspindel 50-500 U/min dimensions of grinding wheel: 350x32x127 mm Table dimensions: 2200x280 mm table swivelling to both sides: 9°vor+10°zurück Grad total power requirement: 6,0 kW weight of the machine ca.: 2,2 t dimensions of machine: 2,2x2,05x1,6 m Iaedpfsu Ng Dgjx Agdsp Universal Center Grinding Machine without internal grinding device! - for precision grinding of outer, inner such as cone surfaces - feed of grinding headstock via hydr. or manual possible - table feed hydraulic stepless - grinding spindle swivelable with 60 degrees - workpiece headstock 90 degress swiveable with tapper MK4 - tailstock tapper MK 3 equipment: - dressing device/extruder - coolant tank incl. pump and supply i.D. *

Condition: used, Year of construction: 1979, Cylindrical Grinding Machine SKF with Internal Grinding Unit Hydraulic Iaodpfx Aegt Ea Regdep

Condition: used, STUDER S 40-2 is a Cylindrical grinder designed for precision, high accuracy and reliability. Working capacities: centre height 175 mm, distance between centres 650 mm, max longitudinal travel 700 mm; wheels Ø400 mm (width 80/40 mm) bore 127 mm; workpiece max 130 kg; hydraulic cross travel 300 mm; wheelhead swivel 180°; table angle 12°. Main specs: wheel speeds 6 steps 1500–2400 t/min (35 m/s); work spindle stepless 60–600 t/min, rotatable 0–90°; wheel motor 3 kW, work spindle motor 1 kW; 3×400 V 50 Hz; total 13 kVA; weight ≈3100 kg; dims 2150×2000×1800 mm. Accessories: 2‑axis DRO, internal grinding attachment, magnetic chuck Ø150 mm, paper filtration, flanges, lamp, balancing arbor, safety device. Achieves tight tolerances; suited to automotive, aerospace, tooling and medical sectors Ijdsx S N D Aspfx Agdjap

Condition: excellent (used), Year of construction: 1978, Machine can be inspected under power Iodpfxswz Emle Agdeap

Condition: reconditioned (used), Year of construction: 1985, functionality: fully functional, Completely overhauled by the original manufacturer's staff. Max. grinding diameter: 250 mm Grindable length: 750 mm Accessories: Iodpfjychhtsx Agdsap - Auxiliary hydraulic unit and control cabinet - Tailstock - Work spindle - Wet grinding attachment - Internal grinding unit - Balancing mandrel - Further accessories available upon request The machine is currently powered up and located in Hungary. An inspection is possible by appointment. The overhaul warranty is 6 months within Hungary.
