Envelope inserting machine

Kern 3000

Condition: good (used), Year of construction: 2009, 1 used CNC lathe Brand DMT/Kern Type CD 480 x 3000 Year of manufacture 2009 Control Manual Plus 620 Technical specifications: Center height 230 mm Turning diameter over bed 475 mm Center distance 3000 mm Cross travel 255 mm Spindle head DIN 55026/6 Spindle bore 82 mm Power consumption 30 kW Tool holder turret VDI 40 Gsdou A Ducspfx Aa Iott Equipped with Turret Hinged belt conveyor Complete documentation available! Machine is ready for use and can be tested on-site!

Condition: ready for operation (used), Year of construction: 1991, Envelopes (wallet): min.: 127mm/150mm, max.: 255mm/420mm, pockets: Center seam: min.: 228mm/127mm, max. 420mm/305mm, Side seam: min.: 228mm/127mm, max.: 420mm/262mm. Speed: 500 pockets/min, paper weight: 80g/m²-150g/m². Gtsdpfstqnu Aox Aa Ist

Condition: used, Year of construction: 2010, Technical details: turning diameter: 1000 / 700 mm turning length: 3000 mm face slide travel: 600 mm turning diameter over slide: 700 mm turning speeds: 1-1.800 1/min transmission ratio: 2 spindle: 46 (60%) kW spindle bore: 132 mm Gtsdpfxjr U Skho Aa Iet quill stroke: 280 mm workpiece weight max.: 2.560 kg total power requirement: 38 kW weight of the machine ca.: 6 t dimensions of the machine ca.: 5 x 2,6 x 1,9 m teach in lathe, PARAT tooling system, SCHUNK ROTA NC 500-160 power chuck, tailstock, chipconveyor *

Condition: good (used), Year of construction: 2010, Horizontal bed - Prismatic/flat guideway hardened and ground Working range - Swing diameter over bed mm 1000 - Swing diameter over cross slide mm 700 - Slide path flat mm 600 Main spindle drive - Digital AC motor - 60% ED kW 46 Gearbox - ZF planetary gear stages 2 - electrically switched - Mounted outside the headstock Headstock - Spindle head DIN 55026 size A11 - Spindle diameter in front bearing mm 190 - Spindle bore mm 132 - Spindle taper metr 140 - Speed range rpm 1-1800 Cross slide - Feed range flat mm/rev 0.001-1000 - Feed range longitudinal mm/rev 0.001-2000 - Thread pitches mm 0.01-999.9 - Rapid traverse plan/longitudinal m/min 5/10 - from center distance 4000mm m/min 5/7 - Automatic central lubrication - Digital AC servo motors plan and longitudinal Tailstock - Quill diameter mm 125 Gsdper D Nmyjfx Aa Iett - Quill stroke mm 280 - Mounting taper MK 6 - Clamping on the bed with clamping screws - Quill actuation and clamping manual - Tailstock roller guide

Condition: excellent (used), Year of construction: 2005, functionality: fully functional, TUNKERS Proliner - VKM 1150 Machine in production, can be inspected in Bucharest, Romania. Technische Daten_GE/ Technical Data_EN Allgemeines/ General Anlagenbezeichnung : Vollautomatische/ Plant designation : Fully automatic Bogenkaschiermaschine/ Sheet Laminating Machine Maschinenname/ Machine name : Proliner VKM 1150, TVA, PW, AS-12 Fabriknummer/ Factory number : 3.9000.1150.001 Auftragsnummer/ Order number : 70224 Baujahr/ Construction year : 06/2005 Deckbogeneinleger/ Cover sheet insert Bogenformate/ sheet formats Formatbereich Länge max./ Format range length max. : 1600 mm Länge/ Length, min. : 400 mm Breite/ Width, max. : 1150 mm Breite/ Width, min. : 400 mm Materialstärke/ Material thickness, min/max. : 100/500 g/m2 Stapelgewicht/ Stack weight max. : 2.500 kg Stapelhöhe inkl. Palette/ Stack height including pallet : 1500 mm Trägerbogeneinleger/ Carrier sheet insert Bogenformate/ Sheet formats Formatbereich Länge/ Format range length, max. : 16400 mm Länge/ Length, min. : 400 mm Breite/ Width, max. : 1250 mm Breite/ Width, min. : 400 mm Materialstärke/ Material thickness, min . : 250 g/m2 Materialstärke/ Material thickness, max : 8 mm Stapelgewicht/ Stack weight ,max. : 500 kg Leimstation/ Glue station Leistung (format- und materialabhängig)/ Performance (depending on format and material) : 5000 Bögen/Std Gewicht/ Weight : 800 kg Kaschierstation/ Laminating station Deckmaterial/ Cover material, min : 250 g/m2 Deckmaterial/ Cover material, max : 8 mm Leistung/ Performance : 5000 Bögen/Std Gewicht/ Weight : 1150 kg Elektrik/ Electrics Betriebsspannung/ Operating voltage : 400 V AC Steuerspannung/ Control voltage : 24 V DC Ventilspannung/ Valve voltage : 24 V DC Frequenz/ Frequency : 50 Hz Antriebsleistung/ Drive power : 40kW Gesamtleistung/ Overall performance : 50 KW Pneumatik/ Pneumatics Gjdpopkx S Dsfx Aa Iett Druckluft/ Compressed air : 6 bar Verbrauch/ Consumption, max. : 450 m /Std

Condition: excellent (used), Year of construction: 2010, Very nice inserting system for DL, C5 and C4 envelopes which has only 1 mil cycles, 2D Data Matrix camera reading code, accumulator, double fold unit, turnover and shingling conveyor. Godpfx Aaoh H Iuaj Ijtt

Condition: used, Complete machine: - 5510 sheet feeder - 4720 Reader module with VEKTOR camera - 4810 Mounting module - 6015 Folding module - 4507 Sequencer module, - 4806 pre-assembly module, - 5552 Insert module - 5552 Insert module - 501 Base unit module - 5571 Envelope feeder module, - 7512 Bypass module Gtsdpoqzhr Iofx Aa Iot - 5535 Stacker module - Bicos 2009 operating system - ANV/DBDI PC for the control integrity system. Reading: VEKTOR camera Can read all types of barcodes, OCR, Datamatrix, barcodes and OME. Bicos version 2009 and ANV/DBDI version V 9.1.5.0 The entire system is configured to read Datamatrix. All modules are tested and packaged. Meter readings can be requested.

Condition: refurbished (used), Year of construction: 2013, functionality: fully functional, machine/vehicle number: 6671C/6975C/6822C/6989D/6815C, warranty duration: 6 months, year of last overhaul: 2024, Müller online channel for connection to an inserting machine - collect, fold A4 single sheets - Condition: completely overhauled with guarantee (6 months) Consisting of: Gtodpfx Aaevdrx Io Ijt - 1 x 6798 Autoloader (S/N: 64580) - 1 x 6686D-30K Feeder single sheet vacuum (P/N: 67159) - 1 x 6995 transfer unit incl. 6815 reading unit with large reading area (P/N: 69016) - 1 x 6671C Collecting tray straight ahead 11"-12" (P/N: 69695) - 1 x 6975C Distance module for RU100 (P/N: 69215) - 1 x 6822C Double folding machine upwards (P/N: 69755) - 1 x 6989D Transfer unit (P/N: 69086) - 1 x 6815C STOP function for transfer unit with blower (P/N: 69208) +++Refurbished appliance with 6 months warranty according to our enclosed warranty conditions +++ +++Installment purchase and rental possible on request+++
