PET filling line

KHS

Year of construction: 2006, condition: used, machine/vehicle number: PX20, Used KHS INNOPRO CMX-18 mixer 18 m³-h - Year 2006Technical Specifications & Performance DataThe KHS INNOPRO CMX-18 is a premix mixer designed for beverage production and integration into an industrial packaging or used bottling line. Manufactured in 2006, this process unit has a nominal capacity of 18 m³/h and is engineered to prepare, deaerate, mix and transfer beverage product toward the filling area.Manufacturer: KHSModel: INNOPRO CMX-18Manufacturing year: 2006Nominal capacity: 18 m³/hBuffer tank capacity: 850 LMaximum pressure: 8 barTest pressure: 11.44 barTemperature range: 20 / 100 °CAdvanced Automation & Control SystemsThe premix system includes process instrumentation for pressure, flow and level monitoring. Flow transmitters, flow-indicating controllers, pressure indicators, pressure alarms, pressure switches, level switches and level alarms support controlled product handling through the deaeration, transfer and buffer stages.Control air is supplied at 4–5 bar, with an associated gas or air line indicated at 6–6.5 bar. The process arrangement includes controlled flow sections and valve manifolds for product routing, CIP circulation and syrup-return functions.Production Line Integration CapabilitiesThis KHS premix mixer is suited to installation upstream of a filler in a beverage production line. The process schematic shows a dedicated outlet connection to the filler, allowing the prepared product to be transferred from the buffer tank to downstream filling equipment.Water and CIP connections are integrated into the valve manifold, while dedicated CIP syrup-return branches support cleaning and product-return operations. The system uses carbon dioxide supply connections for deaeration and beverage preparation, making it appropriate for production environments where controlled mixing and gas management are required.Water connection: Ø2.1/2"CIP connection: Ø2.1/2"CIP syrup-return connections: Ø1.1/2"Filler outlet connection: Ø4"Sealing-water connection: DN15Machine Condition & Maintenance HistoryThis second hand KHS premix mixer was manufactured in 2006. The available technical documentation identifies the process configuration, vessel ratings, utility connections and instrumentation layout. The equipment is configured as a complete mixing and transfer unit with deaeration, buffer storage, pumps and process-control instruments.Operational Performance & VersatilityThe INNOPRO CMX-18 incorporates a deaeration vessel, buffer tank, six pumps and a product-transfer circuit. Product passes through controlled flow sections before entering the buffer tank and being pumped toward the filler. Carbon dioxide connections, deaeration capability and a dedicated buffer stage support stable product preparation before packaging.The integrated CIP and syrup-return manifold enables cleaning circulation through the process circuit. This configuration is valuable for beverage production operations requiring hygienic product changeover and e... Ndsdpfj Adtqrox Afioc

Condition: used, Year of construction: 1998, Automatic PET bottle blowing machine Njdpsutni Rsfx Afisdc Manufacturer: SIDEL Type: SBO 16/16 S1 Year of manufacture 1998 Capacity: 16,000 for 1.5 L bottles and up to 19,000 bph for 0.5 L bottles Installed power: 347 kW Includes 1.5 L moulds Preform feeder Chiller cooling unit Technical condition: used machine, functional until dismantled. The machine is currently dismantled, assembled in elements and prepared for transport. Full and original technical documentation.

Condition: used, Complete PET bottling line for still and carbonated water, with a capacity of 14,400 bottles per hour for 0.5 L bottles. Technical Data Capacity: 14,400 bottles/hour for 0.5 L bottles Products: Still and carbonated water Containers: PET bottles Bottle formats: 0.33 L, 0.5 L, 1.0 L, 1.5 L and 2.0 L; currently running 0.5 L bottles Njdpfxsz Ri N Eo Afijdc Labelling: PE Roll-Line Cap feeding system: Gravity 26 Pack formats: * Packs of 12 for 0.5 L and 1.0 L bottles * Packs of 24 for 0.5 L bottles * Packs of 6 for 1.5 L bottles Pallet formats: Euro pallets measuring 800 × 1,200 mm and Düsseldorf pallets measuring 800 × 600 mm Condition: Used line Video: Machines and Equipment 1. PET blow moulding machine – Sidel SBO 8, year 2006 Including preform tipper, preform hopper, elevator, orienter and feed chute 2. Air conveyor – Lanfranchi, year 2006 3. Chiller – MTA, year 2026 4. Filling machine – SACMI Blu Star 28/40/10, year 1997 5. Capping machine – Arol, year 2011 6. Cap and fill-level inspection system – KBB, year 2023 7. Carbonator – SACMI, year 1997 8. Bottle conveyor – Sipac, year 2012 9. Labelling machine – PE Roll-Line, year 2020 10. Shrink wrapper – SMI LSK 45, year 2001 11. Pack conveyor – ACMI, year 2000 12. Handle applicator – COMAG H50, year 1998 13. Palletiser – KHS, year 2002 14. Pallet wrapper – Tosa, year 1994 Technical documentation is available. Price on request.

Condition: used, Year of construction: 2007, Overview Complete wine bottling line with KHS and Krones machines for 0.75 l glass bottles, rated at 12,000 bottles per hour. The line runs from depalletizing, bottle washing and empty bottle inspection through the KHS Innofill NRF filler-closer monoblock (natural cork or aluminium screw caps) to capsuling, labelling, case packing and robotic palletizing. A KHS process area with cartridge filtration and a wine warmer-cooler prepares the wine ahead of the filler. The line is still installed and can be inspected on site. Technical data - Product: still wine - Containers: glass bottles, design bottle 0.75 l - Line output: 12,000 bottles/h - Closures: natural cork, aluminium roll-on screw caps, shrink capsules - Years of manufacture: 2006 - 2023 Scope of Delivery Type | Manufacturer | Model | Description | Year | Listing Bottling line - Glass depalletizer | Krones | PRESSANT UNIVERSAL 1N | sweep-off depalletizer, layer-pad and empty-pallet handling, 14,000 containers/h | 2023 | - Bottle washer | KHS | INNOCLEAN | single-end washer for returnable glass, up to 14,500 bottles/h, drive and panel modernised in 2022 | 2007 | - Empty bottle inspector | Krones | LINATRONIC M | base, finish, thread, sidewall and residual liquid inspection | 2018 | - Filler-closer monoblock | KHS | INNOFILL NRF | 50 filling valves, cork closer and Zalkin roll-on capper with 10 heads each, CIP, 12,000 bottles/h | 2007 | - Capsuling machine | Kematec | MBK 12 AS | shrink capsules, 12 heating stations, up to 12,000 bottles/h | 2006 | - Bottle dryer | Kematec | T20-3 KMT | air-knife tunnel | 2006 | - Labeller | Krones | ERGOMODUL | 2 cold-glue and 2 self-adhesive stations | 2020 | - Case packer | KHS | INNOPACK SP | pick-and-place packer, KUKA controller | 2006 | - Palletizer and stretch wrapper | ABB, Strapex | FLEXPALLETIZER, SWR 30 | 2 robot cells, pallet destacker, ring wrapper | 2007 | - Pallet labeller | Logopak | LOGOMATIC 920 II PF | print-and-apply | 2007 | - Conveyors | all connecting bottle, case and pallet conveyors of the line Process area - Filtration system | KHS | CORVUS | cartridge microfiltration, 4 housings | 2007 | - Wine warmer-cooler | KHS | INNOPRO | plate heat exchanger, up to 9,900 l/h | 2006 | Condition Used, still installed. Each machine is also listed on its own page with full technical data and photos - follow the link at the end of each row in the scope of delivery. Availability Available immediately. Location: Belgium. Delivery terms: Ex Works Belgium. Ndsdpez I Rcasfx Afiec

Condition: like new (used), Year of construction: 2020, operating hours: 400 h, functionality: fully functional, total width: 2,438 mm, total length: 6,058 mm, total height: 2,591 mm, empty load weight: 9,500 kg, input voltage: 400 V, Complete PET blow molding and water bottling line for 1L bottles. Enclosed in a container, self-sufficient with generator, water treatment unit, compressor, and all necessary infrastructure. Additional information available in the photos and YouTube videos. Ndjdpfxjx Hqrwe Afiec

Condition: used, Year of construction: 2006, Overview This KHS Innopro warmer-cooler is a skid-mounted thermoregulator for wine, built in 2006 by KHS AG in Dortmund, Germany. It brings wine to a set temperature, heating or cooling as required, at up to 9,900 l/h (99 hl/h), designed for an outlet temperature of 18 °C. The core is a three-section Thermowave plate heat exchanger; stainless steel piping, pumps, pneumatically operated valves and instrumentation are mounted on one frame and run from a freestanding KHS stainless steel control cabinet with touch panel. The unit was last used in a wine bottling line. Technical data - Manufacturer: KHS AG (Dortmund, Germany) - Model: Innopro warmer-cooler - Year of manufacture: 2006 (control cabinet 2007) - Machine type: thermoregulator for heating or cooling wine, skid-mounted - Product: wine - Throughput: 9,900 l/h (99 hl/h) - Cooling section: wine from 26 °C to 18 °C, cold water 10 °C to 14 °C at 18,328 l/h Ndsdpoz Hckmjfx Afijc - Heating section: wine from 9 °C to 18 °C via a warm-water circuit (25 °C to 21 °C, 20,516 l/h), which is heated by hot water from 100 °C to 55 °C - Plate heat exchanger: Thermowave, 3 sections, 71 plates, total heat transfer area 6.1 m² - Plate heat exchanger ratings: operating pressure 10 bar, test pressure 12.5 bar, max. operating temperature 100 °C - Power supply: 400 V, 50 Hz, 3/N/PE, rated current 25 A; control voltage 24 V DC - Overall dimensions: approx. 3,100 x 1,850 x H 2,330 mm Equipment - Thermowave plate heat exchanger with cooling, wine heating and warm-water heating sections - Warm-water circuit and membrane expansion vessel - Centrifugal pumps, including a Hilge stainless steel pump - Pneumatically operated valves and a pneumatic control valve with positioner - Pressure gauges and process instrumentation - Freestanding KHS stainless steel control cabinet with touch panel - Stainless steel skid frame with interconnecting piping Condition Used. Still installed and can be inspected by appointment. Availability Immediately. Location: Belgium.

Condition: used, Year of construction: 2006, Overview This KHS Innopack CA-1, built in 2006, is a carton erector that forms cartons from flat blanks and closes their bottom with hot-melt glue. Blank stacks are fed on a roller conveyor into the magazine; suction grippers pick each blank, erect it, fold the inner bottom flaps, apply glue with a Robatech hot-melt unit, close and press the outer flaps and discharge the carton onto the outfeed roller conveyor. The machine is still installed in a wine bottling and packaging line and can be inspected on site. Technical data - Manufacturer: KHS - Model: Innopack CA-1 - Year of manufacture: 2006 - Machine type: carton erector with bottom gluing - Glue system: Robatech Concept hot-melt unit with glue nozzles for the bottom flaps - Power supply: 400 V, 3 Ph, 50 Hz, 15 A - Compressed air: min. 5 bar operating pressure - Overall dimensions (L x W x H): 4,550 x 3,450 x 2,720 mm - Blank infeed: roller conveyor with stainless steel rollers, roller width 1,000 mm, infeed clearance 800 x 450 mm - Outfeed: roller conveyor with stainless steel rollers, roller width 300 mm, 3,050 x 650 x 880 mm Equipment - Stack preparation with automatic loading of the blank magazine - Blank magazine with lifting device, side guides and front and rear stops - Pick-up and erecting stations with vacuum suction grippers and vacuum unit - Folding, gluing, closing and pressing devices for the carton bottom - Side and height adjustment by handwheel for different carton sizes - Enclosure with windowed safety doors - Operator panel with display, keypad, start/stop, key switch and emergency stop; operator texts in French - Control cabinet and pneumatic service unit Ndsdpfx Afjz Hcivoijc - CE marked; operating manual (Dutch) available Condition Still installed. An inspection on site is possible. Availability Available immediately. Location: Belgium.

Year of construction: 2000, condition: excellent (used), Capacity: Nedpfx Aozc H Hhsfisdc 6.000 kg per hour butter out. 12.000 liter per hour cream in.

Condition: used, Year of construction: 2007, Overview KHS Innofill NRF filling and closing monoblock for still wine in glass bottles, built in 2007. A 50-valve filler is followed by two 10-head closers: a KHS natural-cork closer with vacuum device and an aluminium roll-on capper by Zalkin, so the machine closes either corks or screw caps. Output 12,000 bottles per hour. The operator panel and software were updated by KHS in 2022. Technical data - Manufacturer: KHS - Model: Innofill NRF - Year of manufacture: 2007 - Output: 12,000 bottles/h - Filler: 50 filling valves, pitch circle 1,800 mm, filling tube diameter 20 mm - Cork closer: KHS, 10 heads, pitch circle 360 mm, electrically heated cork jaws, cork sorter mounted on top - Vacuum device with vacuum pump - Screw-cap closer: Zalkin aluminium roll-on capper, 10 heads, pitch circle 360 mm, for 31.4 x 24.2 mm aluminium caps - Machine pitch 36π, running direction left to right - Conveyor: stainless steel slat chain, 85 mm wide, conveyor height 1,250 mm - Power supply: 400 V, 3/N/PE, 50 Hz, 90 A nominal current, 100 A slow fuse; control voltage 24 V DC - Enclosure type 12 Nedez Hcauopfx Afijdc - Overall dimensions approx. 5,300 x 3,600 x H 4,400 mm Scope of delivery - Filler-closer monoblock with guarding, front panels slide up - Automatic central lubrication - Two infeed hoppers for corks and caps with elevating feed, approx. 1,600 x 1,200 x 1,720 mm and 1,500 x 1,250 x 1,550 mm - Stainless steel CIP unit, approx. 3,000 x 1,300 x 1,900 mm - Stainless steel control cabinet, approx. 2,500 x 750 x 2,100 mm - Stainless steel trolley, approx. 800 x 750 x 1,650 mm - Two trolleys with change parts, colour-coded format sets - KHS documentation: operating manuals, spare parts list, 2022 operator-panel supplement Condition Used. The machine is still installed at its production site and can be inspected by appointment. Availability Immediately.

Condition: used, Year of construction: 2007, Overview This KHS Corvus is a skid-mounted cartridge filtration system (microfiltration), built in 2007 by KHS AG in Dortmund, Germany. Four stainless steel KHS cartridge filter housings for 40-inch cartridges are connected through a pneumatically operated valve manifold and controlled from the skid's own stainless steel control cabinet with Siemens PLC. The Corvus range is designed for clarifying filtration, cold sterile filtration and safety filtration of wine, beer and water ahead of the filler. This unit was last used for wine filtration in a bottling line. Technical data - Manufacturer: KHS AG (Dortmund, Germany) - Model: Corvus Ndjdoz Hb Scepfx Afioc - Year of manufacture: 2007 (filter housings 2006) - Machine type: cartridge filtration system (microfiltration), skid-mounted - Filter housings: 2 housings for 19 cartridges of 40 inch, 143 L each; 2 housings for 12 cartridges of 40 inch, 108 L each - Housing design ratings: max. 10 bar at up to 90 °C, max. 2 bar at 121 °C - Material: stainless steel - Overall dimensions: approx. 3,600 x 1,700 x H 3,750 mm Equipment - 4 CE-marked KHS cartridge filter housings - Pneumatically operated valve manifold with stainless steel piping - Pressure gauges and process instrumentation - Stainless steel control cabinet with Siemens PLC and pneumatic valve terminals - Stainless steel skid frame with mesh safety guarding Condition Used. Still installed and can be inspected by appointment. Availability Immediately. Location: Belgium.

Condition: used, Year of construction: 2013, Overview This KHS Innopro KZE 72 is a flash pasteurizer (short-time heating system) for beer, cider and other carbonated beverages, built in 2013 by KHS GmbH (Dortmund, Germany). Working with a plate heat exchanger, it gently pasteurizes at a nominal capacity of 72 hl/h and is designed for a product flow between 24 and 72 hl/h with a maximum CO₂ content of 6.5 g/l. The system comes complete with its 50.8 hl buffer tank and the control cabinet with touchscreen HMI. The unit comes out of a large brewery, is still installed and can be visited on request. Technical data - Manufacturer: KHS GmbH (Dortmund, Germany) - Model: Innopro KZE 72/T4-72-12/PT45A - Year of manufacture: 2013 - Machine type: flash pasteurizer with plate heat exchanger - Nominal capacity: 72 hl/h - Minimum adjustable capacity: 24 hl/h Njdpfx Ajzvfbcofiodc - Capacity during CIP cleaning: 85 hl/h - Maximum CO₂ content in the product: 6.5 g/l - Pasteurization temperature: 72 °C (beer) / 85 °C (cider) - Holding time: 30 s - Product inlet temperature: 4 °C; product outlet temperature: max. 4 °C - Supply pressures: product 3.5 bar(g), steam 3 - 6 bar(g), coolant 1.5 - 2 bar(g), CIP 4 bar(g) - Electrical connection: 400 V, 50 Hz, 3-phase - Dimensions pasteurizer skid: approx. 4,600 x 3,500 x H 2,900 mm - Weight pasteurizer skid: approx. 3,100 kg (frame incl. plate heat exchanger) Equipment - Pasteurizer skid with plate heat exchanger type PT45A, pumps and valve manifold - Buffer tank: 50.8 hl gross / 45.5 hl working volume, inner Ø 1,600 mm, H 3,420 mm, approx. 1,120 kg, operating pressure up to 5 bar(g), CO₂ and sterile air connections 6 - 8 bar(g) - Control cabinet with touchscreen HMI - OEM technical documentation (operating manual) Condition Used - good working condition. The system was in production in a large brewery until recently, is still installed and can be inspected. Availability Immediately. Location: Netherlands. Dismantling and loading by arrangement.

Condition: used, Year of construction: 2006, Overview This KHS Innopack SP, built in 2006, is a pick-and-place case packer for bottles. Empty cases run on the case conveyor into the packing zone, where they are stopped and centred; the gripper head picks the bottle formation from the four-lane infeed table and sets it into the cases. The lifting unit travels on a vertical lifting column with counterweight, and the motion is controlled by a KUKA KR C2 controller with KCP teach pendant. Four change-part trolleys with gripper heads for different bottle sizes are included. The packer is still installed in a wine bottling and packaging line and can be inspected on site. Ndodpfx Aez Hbxijfisc Technical data - Manufacturer: KHS - Model: Innopack SP - Year of manufacture: 2006 - Machine type: pick-and-place case packer - Bottle infeed: 4 lanes, lane width 85 mm - Gripper head: 2 x 18 bottle tulips, formation 3 x 6 bottles - Case clearance: 175 x 400 mm - Power supply packer: 400 V, 3 Ph, 50 Hz, 27 A - Robot controller: KUKA KR C2, 400 V, 3 Ph, 50/60 Hz, 8 A - Overall dimensions (L x W x H): 6,000 x 3,250 x 3,650 mm - Change-part trolleys: 4 units, each 2,050 x 1,300 x 2,100 mm Equipment - Base frame with lifting column, counterweight and lifting unit - Cross conveyor and shifting carriage for the gripper head - Gripper head with pneumatic bottle tulips - Centring device for the cases in the packing zone - Four-lane bottle infeed table with lane guides - Case infeed and outfeed conveyors - Enclosure with windowed doors and safety fencing - KUKA KR C2 controller cabinet and KCP teach pendant on stand - KHS control cabinet - 4 change-part trolleys with gripper heads for different bottle sizes - Operating manual (Dutch) available Condition Still installed. An inspection on site is possible. Availability Available immediately. Location: Belgium.

Condition: excellent (used), Year of construction: 2015, KHS INNOFILL DVD 40 CAN FILLING LINE MAX SPEED: 34,000 CPH 330ML IN 24 PACK WRAPAROUND CARTON CURRENT SPEED: 24,000- 28,000 CPH IN SMALL WRAPAROUND CARTON 4/6/8/10/12 PACKS LOCATION: UK STANDARD CAN 330ML & 440ML LID 202 SLEEK CHANGEPARTS FOR FILLING BLOC AVAILABLE GPI PACKER ADDED IN 2018 ROBOPAC PACKER ADDED IN 2022 EQUIPMENT LIST: FIPAL MINIDEPAL 20 LA DEPALLETISER • TWIN LANE RINSER • KHS INNOFILL CAN DVD 40 FILLING BLOC 34,000 CPH • FERRUM F6 6 HEAD SEAMER • CSW DEVENTER LID FEED SYSTEM • HEUFT SPECTRUM TX • EURO SISTEMI CAN DRYERS • TELEDYNE TAPTONE INSPECTION • ROBOPAC PRASMATIC TC400 COMPACT CASE PACKER • FT SYSTEM CP600 TP TUR300 Z200 RAS001 • GPI QUICKFLEX 300 MULTI-PACKER • HITACHI INK JET PRINTER • PACKITAL LANER • COMPLETE CONVEYOR SYSTEM • FIPAL PAL 80 F PALLETISER • ATLANTA STRETCH REVOLUTION LS STRETCH WRAPPER LOCATION: UK VIEWINGS BY APPOINTMENT WELCOME. PLEASE GET IN TOUCH TO ARRANGE AN INSPECTION. Nedpjtraaasfx Afijdc INDASSOL.COM

Condition: excellent (used), 2 x KHS / GEA High Speed Keg Filling Lines Capacity: 1,000 kph Sizes: 15L, 20L, 30L, 50L 60L Ndsdsxcinmjpfx Afijc Keg Palletiser System also available. Location: Dublin Please contact Indassol for further details & pricing.
