Bookbinding machine

Kolbus

Year of construction: 1999, condition: used, Embossing machine Chslhezvd U Ijcdw Esc Kolbus PE 312 Year: 1999 - Case pre-stacking conveyor - Feeder for cases - Case bending station: DBA - Foil transporting device - Case set up outside machine - Matrix plate 2 - Counter stacker

Condition: used, Year of construction: 2022, Maximum parent roll width: 1420 mm Minimum parent roll width: 600 mm Maximum parent roll diameter: 1500 mm Maximum parent roll weight: 2500 kg Maximum unwinding tension (Ø1500 mm): 600 N Minimum unwinding tension (Ø1000 mm): 40 N Minimum standard slitting width: 100 mm Maximum rewinding width: 1400 mm Maximum rewinding diameter: 1050 mm Maximum rewinding weight: • Ø76 mm shaft: 600 kg • Ø152 mm shaft: 1000 kg Maximum rewinding tension: 600 N Maximum production speed: 600 m/min Power supply: 3 x 400V 50Hz Installed power: 30 kW Compressed air: 6 bar, dry Materials to be slit: • Paper-based / liner-based packaging laminates. • Board from 80 to 300 g/m². Unwind section: A separate between-centers unwinder, type T9, 1500 mm diameter, including: • Hydraulic cylinder control for lifting parent rolls from the floor. • Two motors driving the unwinding roll, controlled by an ultrasonic diameter sensor and a tension-control dancer roller. • Two pneumatic expanding adapters, SVECOM, for 70/76 mm (3”) cores. • Two pneumatic expanding adapters, SVECOM, for 150/152 mm (6”) cores (mounted on the pneumatic end adapters). • Floating edge-correction roller. • Automatic web guiding system, FIFE DP20, with SE26A photoelectric sensor, ±100 mm correction via electric actuator — for controlling sheet edge or continuous printed line. Chjlhcdoyx Uy Aew Esc • Connecting walkway allowing web threading at floor level while keeping full access to the slitting station. • All web path rollers are anodized. • Safety guarding for operator protection. Slitting section: A slitting station with individual pneumatic knives and circular counter-knives: • Shear cut performed against the counter-knives. • Counter-knife shaft driven by an independent motor; counter-knife shaft is pneumatic. • Pneumatic knife holders mounted on a beam with a dovetail guide (TIDLAND) and an air supply manifold for individual activation. • 10 slitting sets, each including: Individual TIDLAND pneumatic knife holder (25 mm width) and double-bevel circular knife Ø 90/60 mm. • Set of multi-groove counter-knife rings, 5 mm pitch, 50 mm length. Web separation section: • A separator roller driven by the slitting motor; angle and curvature fully adjustable. Lay-on roller: • Lay-on roller made of anodized ground aluminum or polyurethane (depending on materials). • Pressure is adjustable and synchronized with winding diameter. • Roller is removable. Automatic splicing / transverse cutting system: • Hydraulically operated pivoting arm including a transverse knife with linear motion and a backing plate for securing the web onto new cores. Trim extraction system: • Trim suction unit with two width-adjustable nozzles. • Turbine enclosed in a sound-insulated cabinet, conveying trim to a centralized system or container (not included). Rewinding section: • Motorized turret (two-position) supporting two rewinding shafts. • Rewinding shaft drive by an oversized asynchronous motor. • Hydraulic centering point for the active rewinding roll. • Two pneumatic expanding shafts Ø76 mm (3”), max load 600 kg each, equipped with full-width rubber strips with individual bladders. • Two pneumatic expanding shafts Ø152 mm (6”), max load 1000 kg each, also equipped with full-width rubber strips with individual bladders.

Condition: used, Year of construction: 2004, Format: 310 x 430 mm Celhcdey Tacxsw Eehc Equipment: Counter 22 Mio Co-Pilot with Touchscreen Infeed conveyor from the right Automatic Magazine for In-line Production Counting Stacker Product Counter Tool Presetter Total number of knife sets: 1 Interchangeable Cutting Cassettes (Standard Set)

Condition: used, Year of construction: 2007, Format: 1360 x 1200 mm Cjlhcdweyxqvge Ejhc Equipment: Fully automated palletizing of loose stacks and solid containers at a speed of up to 1,800 stacks/hr Automatic Palletizing product infeed via accumulating conveyor Pallet dimensions: 1360 x 1200 - 1000 x 800 travel stop for dropping of very smooth products pallet removal in moving direction Pallet sizes 1,360 x 1,200 or 1,000 x 800mm Speed 30 Stacks/min

Year of construction: 2022, condition: ready for operation (used), There is a Baumann Perfecta 115 high-speed cutter with Baumann Perfecta BSB 3L jogger, Schneider SENATOR unloader and Schneider SENATOR pile hoist available. 1) Baumann Perfecta 115 high-speed cutter, working height: 900mm, cutting width: 1150mm, insertion depth: 1150mm, max. layer height: 165mm, residual cut: 20mm, residual cut without cover plate: 77mm, weight: 3.2t, year of manufacture: 2022, 2) Baumann Perfecta BSB 3L jogger, load capacity: 1500N, connected load: 2.5kVA, year of manufacture: 2022, 3) Schneider SENATOR unloader, load capacity: 1t, lifting height: 900mm, year of manufacture: 1990, 4) Schneider SENATOR pile hoist, year of manufacture: 2022. An on-site inspection is possible. Celey Tx R Ijhcdw Eohc

Condition: used, Year of construction: 1982, Format: 0x0 Equipment: Corner cutter, manual Cholhjx Rh Dxocdw Esc

Condition: used, Card and Product Sample Adhesive Kolbus KI 224 ZU Karten- und Warenprobenkleber - Card and Product Sample Adhesive Kolbus KI 224 ZU Baujahr / Year 2003 - Serial-No. 356009 For cards, envelopes, bags and booklets of the following formats: Für Karten, Umschläge, Taschen und Hefte in folgenden Formaten: Format / Size min. 40 x 60mm - max. 220 x 350mm Geschwindigkeit / Mech.Output 18.000 Ex/h (depending on type, size and  properties of base and product up to) Heißleim Schmelzgerät / Hot Glue (commercial products) Nordon 3100V-3EA Chelhcdwoz H A N As Ejc Aufbau, zum Anbau an der Zusammentragmaschine, Design / compat appliance for attachment to a collating machine Antrieb über Zahnriemen von der Hauptwelle zur ZU 840 / Drive toothed belt from main shaft to ZU 840 Steuerung: Elektronische, interaktive Mikroprozessor-basierte Steuerung mit Einstellung von Vorlaufzeit und Leimstreifenlänge /  Control: micro-processor based control unit with adjustment of lead-time and length of the glue  Online-Video-Inspection by WhatsApp - MS Zoom - Telegram On Stock Emskirchen/Nürnberg - Available Immediately - Can be test

Condition: used, Year of construction: 2014, Material: PET aluminum-metallized film Material thickness: 9–50 μm Chslhex Ez Umocdw Ejc Web width: 500–2000 mm Roll width: 2100 mm Web diameter (unwind): max. φ1150 mm Web weight (unwind): max. 1500 kg Product winding diameter: • φ600 mm (3” friction shaft) • φ750 mm (6” air shaft) Winding shaft load: max. 500 kg/shaft (center-supported) Core dimensions: • Web core: 3” (φ76.2–76.5 mm), 6” (φ152.4– 153 mm) • Product core width: 100–1050 mm Slit width: 200–1950 mm (up to 5 slits) Machine speed: max. 400 m/min Typical operating speed: 200–250 m/min Unwinding tension: • 50–500 N (φ650 mm or less) 1. Unwinding Section • Shaftless single-axis fixed unwind • Direction: upward or downward • Automatic tension control with feedback detector • Dancer roll included • Core clamping: rotary mechanical chuck • Core sizes: 3” standard, 6” via adapter • Web alignment: manual ±5 mm, automatic ±100 mm 2. Main Drive Rollers • Multiple rollers with specified diameters and surface finishes • Nip and touch rollers with pneumatic pressure control 3. Slitting Mechanism • Upper/lower NC shear cutter • Number of blade units: 6 upper + 6 lower • Slit width adjustment via touch panel • Accuracy: ±0.1–0.2 mm • Dust suction: upper blade nozzles + lower blade suction • Optional razor cutter (manual adjustment) 4. Mini Winder Placement: below slitter Units: 2 (left / right) Drive: AC servo motor Tension: dancer roll control Traverse width: 300 mm Winding diameter: φ500 mm 5. Winding Section • Duplex center drive • 3” air friction shaft + 6” air shaft • Automatic tension control linked to winding diameter • Touch roll with pressure control • Core positioning via collar bar 6. Product Discharge • Hydraulic lift tray • Motorized slide-out with tilt mechanism Electrical & control: Line motor: 7.5 kW AC servo Winding motor: 11 kW AC induction Unwinding motor: 11 kW AC servo Static eliminators: 5 units (Keyence SJ-HA) Control panels: main panel, winding panel, unwind panel, mini winder panel, auxiliary panel PLC: Fuji Electric Utilities, dimensions & environment: Power supply: AC 200 V, 60 Hz, 3-phase Power consumption: 70 kVA Air supply: 0.5 MPa, 500 L/min (dry air) Machine weight: approx. 12 tons Paint color: urethane coating (E-31872) Installation environment: cleanroom Class 10,000 Floor load capacity requirement: ≥ 2 ton/m²

Condition: good (used), Year of construction: 2014, functionality: fully functional, machine/vehicle number: 337, Kolbus DA 260 case-making machine - Device for applying inner lining with hot glue - Automatic case counter - Single case request for control purposes, initiated from the operating side - Infinitely variable drive - Safety standard compliant with CE directives and specifications Technical data: Size range of open case: min.: 205 x 140 mm max.: 670 x 390 mm Joint width: 4 – 15 mm Width between boards: 14 – 120 mm Turn-in width, closed: 8 – 15 mm Cloth: width: 223 – 708 mm height: 130 – 428 mm Boards: thickness: 1 – 4 mm width: 95 – 328 mm height: 140 – 390 mm Board center strip: thickness: 1 – 4 mm width: 6 – 90 mm Center strip roll: thickness: 0.3 – 0.6 mm width: 6 – 90 mm Inner lining dimensions, dependent on glue processing: width: 195 – 670 mm Choloz Hlywohcdw Eoc height: 130 – 390 mm Do not hesitate to contact us for more information. The machine is still in production.

Year of construction: 2024, condition: used, KOLBUS Box Production Line BLP 500 + BLF 500 year 2024 The corner punch BLP 500 is used for punching cross grooved boards and the box line former BLF 500 is used for production of rigid boxes from cross grooved and corner punched boards. Chjlhcez E Riuodw Ejc Overview: BLP 500 box line puncher BLF 500 box line former Configuration: BLP 500 box line puncher · copilot system with touch screen · 1 set (4 pieces) of knife holders · 5 sets (40 pieces) of knives · 3 sets (12 pieces) of cutting sticks · waste delivery out of the machine via transport conveyor · servo-controlled drive technology based on Siemens technology · infeed with cardboard feeder CF 500 · delivery incl. inline coupling with box line former BLF 500 Technical specifications: mechanical speed: up to 40 cycles/min cardboard height max.: 525 mm cardboard height min.: 140 mm cardboard width max.: 735 mm cardboard width: min.: 140 mm cardboard thickness max.: 4 mm cardboard thickness min.: 1,5 mm box length max.: 570 mm box length min.: 56 mm box width max.: 360 mm box width min.: 56 mm box height max.: 170 mm box height min.: 15 mm BLF 500 box line former · copilot system with touch screen · cold glue device with 1 set (4 pieces) 0,3 mm gluing nozzles for gluing grooves · box forming device to turn-up of the side panels · holding station for glue drying · servo-controlled drive technology based on Siemens technology · infeed incl. inline coupling with box line puncher BLP 500 · delivery via conveyor belt Technical specifications: mechanical speed: up to 40 cycles/min cardboard height max.: 525 mm cardboard height min.: 140 mm cardboard width max.: 735 mm cardboard width: min.: 140 mm cardboard thickness max.: 4 mm cardboard thickness min.: 1,5 mm box length max.: 570 mm box length min.: 56 mm box width max.: 360 mm box width min.: 56 mm box height max.: 170 mm box height min.: 15 mm

Condition: ready for operation (used), Year of construction: 2009, functionality: fully functional, Heidelberg Stahlfolder TD-112 Year: 2009 Mach. no. 1224427271 PD 112 Topline pallet feeder Performance package PD 112 (double valve suction wheel, more powerful compressor, additional hold-down device) 1st station 4 folding pockets 2nd station 112cm 4 folding pockets Twin system in the 2nd station for double-flow production including transfer table, short feed ruler, 2x split sheet stop pocket, 1x split separate switch, second light sensor each at the folding unit output 1st and 2nd station, additional transport and drive rollers 3rd station 78 cm 4 folding pockets Cjlhcdwowpgpdo Ejhc SBP 86 Delivery Automatic sizes Soundhoods Compressor Machine is in very good condition!!!

Year of construction: 2023, condition: used, KOLBUS Grooving Machine NM 101 year 2023 For cutting grooves into cardboards. Configuration: - adjustable knife mountings with knife head from 90° to 110° (2 pcs.) - v-groove knife blades (16 pieces) - setting device for the knife mountings - stack/stream cover delivery by means of a conveyor belt - automatic chip removal from the machine - servo-controlled drive technology based on Siemens technology - infeed with cardboard feeder CF 750 - processing in the double magazine - product outfeed with 1.500 mm roller conveyor Chjljz E Nyxjhcdw Eoc - digital display of the knife positions for one knife holder - grinding device for sharpening the knives Technical specifications: number of grooves per operating step: 1 - 8 grooves in transport direction cardboard thickness max.: 4 mm cardboard thickness min.: 1 mm distance between grooves (single cut) on 2 knife holders min.: 1 mm distance between grooves on one knife holder min.: 40 mm spacing from the first groove to the outer edge of the cardboard min.: 15 mm

Year of construction: 2022, condition: used, KOLBUS Box Production Line BLT 200 + BLW 200 year 2022 For the automatic production of raw boxes from cardboard blanks as well as the lamination of the boxes. The BLT 200 is used for uprighting punched and grooved cardboards and the BLW 200 is used for laminating boxes. Overview: BLT 200 box line taper BLW 200 box line wrapper Configuration: BLT 200 box line taper · copilot system with touch screen · cardboard feeder · uprighting channel · 4 heat-sealing tape stations · 2 sets of knives (4 pcs. each) · 2 sets of counter knives (4 pcs. each) · servo-controlled drive technology based on Siemens technology · delivery incl. inline coupling with box line wrapper BLW 200 Technical specifications: mechanical speed: up to 40 cycles/min cardboard height max.: 525 mm cardboard height min.: 140 mm cardboard width max.: 735 mm cardboard width: min.: 140 mm cardboard thickness max.: 3 mm cardboard thickness min.: 1 mm box length max.: 570 mm box length min.: 56 mm box width max.: 360 mm box width min.: 56 mm box height max.: 170 mm box height min.: 20 mm BLW 200 box line wrapper · copilot system with touch screen · cloth feeder · hot gluing station with premelter · glue application adjustment from the outside · viscosity controls · buffer zone for feeding the boxes · cloth transport with vacuum conveyor · camera system for precise positioning of the boxes on the cloth · robot for positioning the boxes on the cloth · rub down station · 4 laminating stations for laminating boxes · 10 format plates (1.000 mm x 215 mm x 15 mm) · servo-controlled drive technology based on Siemens technology · infeed incl. inline coupling with box line taper BLT 200 · delivery via conveyor belt Technical specifications: mechanical speed: up to 40 cycles/min box length max.: 570 mm box length min.: 56 mm box width max.: 360 mm box width min.: 56 mm box height max.: 170 mm box height min.: 20 mm cardboard thickness max.: 3,0 mm cardboard thickness min.: 1,5 mm cloth length max.: 815 mm Chslhsz E Npmjcdw Eoc cloth length min.: 120 mm cloth width max.: 605 mm cloth width min.: 120 mm

Condition: excellent (used), functionality: fully functional, machine/vehicle number: S8758, A machine for gluing cardboard books. Gluing is done using 16 heads. This allows selective application of glue where it is needed. Ideal for gluing board books with flaps, board books with puzzles Chslhowhc U Tecdw Ejc

Year of construction: 2022, condition: used, KOLBUS Box Line Taper BLT 200 year 2022 For the automatic production of raw boxes from cardboard blanks. Colhoz E Npgecdw Eohc The BLT 200 is used for uprighting punched and grooved cardboard. Configuration: copilot system with touch screen cardboard feeder uprighting channel 4 heat-sealing tape stations 2 sets of knives (4 pcs. each) 2 sets of counter knives (4 pcs. each) servo-controlled drive technology based on Siemens technology Technical specifications: mechanical speed: up to 40 cycles/min cardboard height max.: 525 mm cardboard height min.: 140 mm cardboard width max.: 735 mm cardboard width: min.: 140 mm cardboard thickness max.: 3 mm cardboard thickness min.: 1 mm box length max.: 570 mm box length min.: 56 mm box width max.: 360 mm box width min.: 56 mm box height max.: 170 mm box height min.: 20 mm
