Form carrier, tool carrier, closing unit

KraussMaffei

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, clamping force: 9,500 kN, screw diameter: 120 mm, ejector stroke: 300 mm, opening stroke: 1,900 mm, TECHNICAL DETAILS Clamping force: 9,500 kN Opening force: 665 kN Tie bar distance: 1,400 x 1,150 mm Clamping plates: 1,960 x 1,710 mm Opening stroke: 1,900 mm Min. mould height: 500 mm Max. mould height: 1,200 mm Max. opening width: 2,400 mm Ejector stroke: 300 mm High-performance screw HPS-UN, diameter: 120 mm Nozzle radius: 30 mm Nozzle opening: 12 mm Screw diameter: 120 mm Shot weight (HDPE): 5,420 g Shot volume: 7,634 cm³ Specific injection pressure: 2,257 bar MACHINE DETAILS Dkodpfx Asy T H A Eokton Dimensions & Weight Dimensions (L x W x H): 12,770 x 3,420 x 2,750 mm Machine weight: 61.5 t

Condition: ready for operation (used), Year of construction: 2002, functionality: fully functional, machine/vehicle number: 424227, clamping force: 4,200 kN, screw diameter: 80 mm, injection pressure: 1,829 bar, injection weight: 1,304 g, opening stroke: 1,400 mm, TECHNICAL DETAILS Clamping force: 4,200 kN Platen size (H x W): 1,270 x 1,200 mm Tie bar spacing (H x W): 800 x 800 mm Minimum mold height: 380 mm Maximum mold height: 1,020 mm Max. opening stroke: 1,400 mm Screw diameter: 80 mm Dkjdpfx Aoy T Hwiokton Injection volume: 1,433 cm³ Shot weight: 1,304 g (PS) Max. injection pressure: 1,829 bar Max. temperature: 375 °C MACHINE DETAILS Supply voltage: 400 V Phases: 3~ Frequency: 50 Hz Total current consumption: 237 A Fuse rating: 250 A Pump power: 75 kW Heating power: 36 kW Dimensions & Weight Dimensions (L x W x H): 7.06 x 2.33 x 2.51 m Machine weight: approx. 22,000 kg

Condition: ready for operation (used), Year of construction: 2011, functionality: fully functional, clamping force: 8,500 kN, screw diameter: 135 mm, clearance between the columns: 1,140 mm, ejector stroke: 300 mm, TECHNICAL DETAILS Mold closing force: 8,500 kN Mold opening force: 560 kN Djdjy T Hmkepfx Aktokn Dimensions of the mounting plate (h x w): 1,600 mm x 1,600 mm Distance between columns (h x w): 1,140 mm x 1,140 mm Mold opening distance: 1,600 mm Mold height (min-max.): 500 mm - 1,100 mm Opening width: 2,100 mm Ejector stroke: 300 mm Ejector force: 200 kN / 100 kN Screw diameter: 135 mm Injection pressure: 1,389 bar Injection volume: 8,588 cm³ Injection weight per part: 6,098 g Injection rate: 1,414 cm³/s MACHINE DETAILS Electro-hydraulic system Motor rated power of the pump: 132 kW Dry cycle time according to Euromap 6: 965 1/h Oil tank capacity: 2,440 l Open nozzle with nozzle radius: 25 mm Nozzle opening: 9 mm Dimensions & Weight Installation space dimensions (L x W x H): 11.72 m x 2.92 m x 2.71 m Net weight with control unit: 49 t EQUIPMENT Krauss Maffei robot LRX 500 MC 5 control system with color monitor Integrated control panel and USB data storage Complete plasticizing unit for thermoplastics Check valve

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, clamping force: 11,000 kN, screw diameter: 120 mm, injection pressure: 1,758 bar, injection weight: 6,175 g, opening stroke: 2,000 mm, KraussMaffei KM 1100–12000 MX including WITTMANN robot! TECHNICAL DETAILS Clamping force: 11,000 kN Opening force: 770 kN Platen size (H × V): 2,210 × 1,910 mm Tie bar distance (H × V): 1,550 × 1,250 mm Opening stroke: 2,000 mm Tool height (min. - max.): 600 - 1,200 mm Platen stroke: 2,600 mm Ejector stroke: 300 mm Ejector force: 220 / 110 kN Screw diameter: 120 mm Injection pressure: 1,758 bar Shot volume: 6,786 cm³ Shot weight (PS): 6,175 g Screw speed (Standard / Option): 103 / 145 rpm Injection rate (Standard): 1,118 cm³/s Injection rate (Accumulator): 1,696 cm³/s MACHINE DETAILS Electro-hydraulic system Rated power of pump motors: 132 kW Installed heating capacity: 82 kW Number of heating circuits on the cylinder: 7 Cycle time (Euromap): 802 1/h Oil tank volume: 2,440 l Dimensions & Weight Machine dimensions (L × W × H): 12.47 × 3.65 × 2.82 m Net weight with control cabinet: 73 t Djdpjy T Hd Nofx Aktokn EQUIPMENT Robot: Wittmann MC5 control system with color monitor, integrated control panel and three USB ports

Condition: ready for operation (used), Year of construction: 2001, functionality: fully functional, clamping force: 8,000 kN, screw diameter: 95 mm, clearance between the columns: 1,120 mm, injection pressure: 1,795 bar, ejector stroke: 250 mm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Clamping Unit Injection force: 8,000 kN Distance between columns (h x v): 1,120 mm x 1,000 mm Maximum mold opening distance: 1,400 mm Minimum/maximum tool mounting height: 600 mm / 1,100 mm Opening stroke of the clamping plate: 2,000 mm Ejector stroke: 250 mm Ejector force: 226 kN (rearward: 59 kN) Injection Unit Screw diameter: 95 mm L/D ratio: 23 Injection pressure: 1,795 bar Injection volume: 3,367 cm³ Injection size for PS: 3,064 g Injection rate: 690 cm³/s Nozzle clamping force: 166 kN MACHINE DETAILS Control model: MC4 Connected power of pumps: 90 kW Heating capacity: 61 kW Dkodoy Ulhcjpfx Aktsn Dimensions & Weight Machine dimensions (L x W x H): 10.4 m x 2.86 m x 2.39 m Net weight: 45 t

Condition: excellent (used), Year of construction: 2008, Krauss Maffei KM 1100 – 12000 MX injection molding machine Robot - Wittmann Year of production - 2008 Fully hydraulic closing system. MC5 control system with color monitor, integrated control panel and built-in 3 USB ports. Plasticizing system complete plasticizing system for thermoplastics in the version with abrasion protection, screw diameter 120 mm, with non-return lock and open nozzle TECHNICAL DATA Closing unit - Mold closing force: kN 11000 - Mold opening force: kN 770 - Dimensions of the mounting plate (h x v): mm 2210 x 1910 - Clearance between columns (h x v): mm 1550 x 1250 - Mold opening path: mm 2000 - Mold installation height (min - max): mm 600 - 1200 - Plate opening stroke: mm 2600 - Ejector stroke: mm 300 - Ejector force: kN 220/110 Injection unit - Screw diameter: mm 120 - Pressure injection: bar 1758 - Injection volume: cm3 6786 - Injection weight for PS: g 6175 - Number of screw revolutions, standard/option: rpm 103/145 - Injection efficiency (standard) ccm/s 1118 - Injection efficiency (accumulator) ccm/s 1696 Electric-hydraulic equipment - Nominal power of the pump motor: kW 132 - Installed power of heaters: kW 82 Dodpfxovu Hp Aj Aktjkn - Number of cylinder heating zones: - 7 - Number of dry cycles according to Euromap: 1/h 802 - Oil tank capacity: l 2440 Dimensions and weight - Net weight with control cabinet: t 73 - Machine dimensions (length x width x height): m 12.47 x 3.65 x 2.82

Condition: good (used), Year of construction: 2004, functionality: fully functional, Clamping force: 1250 kN Screw diameter: 35 mm Tie bar spacing: 470 mm Shot weight: 142 g Minimum mould height: 300 mm Djdswthfuopfx Aktjkn Total weight: approx. 6,000 kg

Condition: ready for operation (used), Year of construction: 2011, clamping force: 4,200 kN, screw diameter: 80 mm, injection weight: 1,464 g, total height: 2,500 mm, overall weight: 25,500 kg, controller manufacturer: KRAUSS MAFFEI, controller model: MC5, product length (max.): 7,300 mm, This Krauss Maffei 420-3000 CX was manufactured in 2011. A robust hydraulic injection molding machine from Germany, it features a clamping force of 4200 kN and a screw diameter of 80 mm. It supports a shot weight for PS of 1464 g and an injection rate of 478 cm³/s. Ideal for high-volume production with its 1200 cycles/h dry cycle rate. Contact us for more information about this machine. • Electrical data: • Power supply: 400 V / 3N~ / 50 Hz • Installed heating power: 36 kW • Rated pump motor power: 75 kW • Number of barrel heating zones: 7 • Performance and control: • Dry cycles (Euromap 6): 1,200 cycles/h • Control system/version: MC5 3.3 • Machine color: grey / white / blue • Clamping unit: • Mold opening force: 249.6 kN • Distance between tie bars: 800 × 800 mm • Moving platen force (open/close): 124.7 / 102.4 kN • Platen dimensions: 1270 × 1200 mm • Mold opening stroke: 1020 mm • Minimum mold height: 380 mm • Ejector stroke: 250 mm • Platen opening stroke: 1400 mm • Injection unit: • Nozzle tip radius: 15 mm Dsdpfx Akoydnp Hjtokn • Nozzle orifice diameter: 6 mm • Injection pressure: 1856 bar • Injection volume: 1608 cm³ • Injection rate: 478 cm³/s

Condition: used, Year of construction: 1998, operating hours: 99,161 h, clamping force: 32,000 kN, screw diameter: 130 mm, injection weight: 8,100 g, total length: 4,900 mm, total height: 4,200 mm, overall weight: 230,000 kg, # Sales Description A high-performance injection molding machine from the German manufacturer KraussMaffei is available for sale. This is the KM 3200-19000 MC model, specifically designed for the production of large-sized plastic components and industrial series manufacturing. The machine offers very high clamping force and is particularly suitable for applications involving technical plastic parts or large-scale items. The machine features a clamping force of 32,000 kN, a screw diameter of 130 mm, and a maximum shot weight of 8,100 g. This allows for the efficient production of large parts with high material requirements. Dksdpfx Aeyt H Dhoktjn In addition, the system is equipped with extensive peripheral equipment, including a robot interface for KUKA KRC4, a S.I.S.E. IS’Tech sequential injection controller, GWK temperature control units, and a Motan Colormetric dosing and mixing system. A belt conveyor is also included in the package. Technical Data * Manufacturer: KraussMaffei * Model: KM 3200-19000 MC * Machine No.: IMM MC3F No.12 * Year of manufacture: 1998 * Operating hours: approx. 99,161 h Performance * Clamping force: 32,000 kN * Screw diameter: 130 mm * Max. shot weight: 8,100 g Dimensions and Weight * Machine weight: approx. 230,000 kg * Machine depth: approx. 4,900 mm * Machine height: approx. 4,200 mm The machine represents a robust and proven solution for industrial plastics processing and is especially suitable for manufacturers requiring large-format injection molding capacity. Further information, photos, or inspection appointments are available upon request.

Condition: used, Year of construction: 1998, operating hours: 98,806 h, clamping force: 40,000 kN, screw diameter: 130 mm, injection weight: 8,100 g, total length: 4,900 mm, total height: 4,200 mm, overall weight: 255,000 kg, 2x KraussMaffei KM 4000-19000 MC – Injection Moulding Machines – Year 1998 For sale are two identical injection moulding machines manufactured by KraussMaffei, model KM 4000-19000 MC equipped with MC3F control system. These machines are particularly suitable for producing large plastic components that require very high clamping force. The systems are fully equipped and include several peripheral devices for material feeding and process control. ## Technical Data * Manufacturer: KraussMaffei * Model: KM 4000-19000 MC Dedpeyt Hy Nefx Aktjkn * Control: MC3F * Year of manufacture: 1998 * Operating hours: approx. 98,806 h * Clamping force: 40,000 kN * Maximum shot weight: 8,100 g * Screw diameter: 130 mm ## Dimensions & Weight * Machine depth: 4,900 mm * Machine height: 4,200 mm * Machine weight: approx. 255,000 kg ## Equipment * Robot interface: KUKA KRC4 * Sequential injection controller: S.I.S.E. IS-Tech * Temperature control units: GWK * Dosing and mixing system: Motan Colormetric * Belt conveyor ## Available Machines * Machine No. 14 * Machine No. 15 The machines can be purchased individually or as a package. Inspection by appointment is possible.
