KRONES bottling line carbonated bottling plant

Krones

Condition: new, Year of construction: 2019, Filter tank / gravel filter tank made of stainless steel (V2A), unused Technical data / dimensions Available quantity: 2 Volume: approx. 21,800 liters Tank type: Pressure tank Condition: unused Suitable for food: yes Design: upright Diameter inside: approx. 2,384 mm External diameter: approx. 2,396 mm Cylindrical height: approx. 4,000 mm Total height: approx. 6,576 mm Operating pressure: Overpressure Operating pressure: 6 bar Test pressure: 8 bar Wall thickness bottom: approx. 7 mm Wall thickness top: approx. 8 mm Wall thickness jacket / cylinder: approx. 6 mm Ground clearance: approx. 1,114 mm Operating temperature: 35 degrees Celsius Notes: Filter tank (gravel/water) with nozzle base, Filter area: approx. 4.5 m² Material / properties Material inner casing: V2A (1.4301) Feet material: V2A (1.4301) Surface outside: Glass bead blasted Surface inside: Rolled bright (2B) Features Stand shape: Feet Number: 4 Fastening: fixed Top shelf type: Basket arch base Bottom shelf type: Basket arch shelf Shelf type: Basket arch shelf Bodpfxjty Tido Ah Isld Top floor: 1 x flange DN 600 with hinged cover 1 x DN 150 hole in the hinged cover 2 x crane eye Jacket: 1 x flange DN 200 with internal distributor pipe with 3 inlet nozzles 1 x type plate 1 x DN 500 manhole with hinged cover 1 x flange DN 100 in the cover of the manhole flange Underbody: 1 x flange DN 600 with hinged cover 1 x flange DN 100 in the cover Internal: 1 x nozzle base with filter nozzles (filter area approx. 4.5 m²) Documentation Drawing Test certificate Other: Material certificates Manufacturer's declaration

Condition: new, Year of construction: 2025, Applicable Material: metal Condition: New Laser Type: Fiber Laser Cutting Area: 3000*1500mm Cutting Speed: 0-40000mm/min Graphic Format Supported: AI, BMP, Dst, Dwg, DXF, DXP, LAS, PLT Cutting Thickness: 0-30mm CNC or Not: Yes Cooling Mode: WATER COOLING Control Software: Bodor Thinker Place of Origin: China Brand Name: Bodor Certification: CCC, CE, GS, ISO, Sgs Bledpfx Ahjg Eghdo Isd Laser Source Brand: Bodor Laser Head Brand: bodorgenius Control System Brand: bodorpro Weight (KG): 2200 KG Key Selling Points: Tenon-and-mortise type plate welding structure bed Warranty: 3 years Laser power: 1000W Power supply: 110V/220V/380V 50Hz/60Hz

Condition: used, Year of construction: 2006, Overview  This blowing machine was manufactured in 2006 by German manufacturer KRONES. The machine was part of a complete non‑returnable PET bottle filling line dedicated to fresh milk production. It was used to produce 1.0 L PET bottles and operated at a nominal speed of 9,000 bottles per hour. The machine is described as being in good condition. The equipment becomes available as the seller decided to outsource milk production and continue only cheese production at the site. Technical data  Capacity: 9,000 bottles/hour Formats: 1.0 L Application: Fresh milk Container material: PET Neck finish: 38 mm Bsdpfx Aoym D U Rsh Iold

Condition: used, Year of construction: 2006, Overview  This complete filling line for non-returnable PET bottles was manufactured 2006 by the german manufacturer KRONES. The line was running as a non returnable bottle filling line and dedicated to produce fresh milk. The line is designed for milk production, handling up to 9,000 b/h and is in a good condition. The equipment becomes available as the seller dediced to commit the milk production to an external company and continue only the cheese production in the factory. Technical Information Product: Fresh Milk Container Material: PET Bottle Format: 1,0 L Nominal Speed: 9.000 BPH Neck Finish: 38 mm Label Type: OPP Rollfed Packaging: 16 bottles per crate Pallet Type: Europallet 800 x 1200 Scope of Delivery  Blowing Machine | Krones | Contiform S8 | 2006 Preform Tipper | TM | KPT | 2012 Air Conveyors (~100 m, 9 fans) | Krones | AirCo | 2009 Filling Monoblock (Neck Handling, 32 valves) | Krones | Volumetic | 2006 Capper (8 heads) | Krones | 2006 Ink Bottles Marker | VideoJet | 2006 Labelling Machine | Krones | Contiroll | 2004 Case Packer | CMT | IFL3T | 2004 Palletizer (Fanuc M-410 Robot) | Elettric 80 | 2009 LGV Pallet Transport Shuttle (Optional) | Elettric 80 | 2009 Bljdpfxeym D Ukj Ah Ijd

Condition: like new (used), Year of construction: 2008, AGRICULTURAL MACHINERY BUCHER CROSS-FLOW-FILTER FM 20 Bodpsgy T Dzjfx Ah Ijld

Condition: used, Year of construction: 2000, operating hours: 34,364 h, functionality: limited functionality, machine/vehicle number: 960-08, total width: 2,550 mm, total length: 3,600 mm, total height: 2,300 mm, type of input current: three-phase, outer diameter of label roll: 400 mm, inside diameter of label roll: 80 mm, overall weight: 4,000 kg, input voltage: 400 V, year of last overhaul: 2025, operating temperature: 25 °C, height adjustment type: electric, input frequency: 50 Hz, Equipment: documentation/manual, Krones Variomatic Machine for Sale A Krones AG Variomatic machine is offered for sale, designed for industrial use in bottling and winery environments. Manufacturer: Krones AG Year of manufacture: 2000 Serial number: 733-048 Quality management / origin: ISO 9001 Technical specifications: Supply voltage: 400 V Bodpfxsyb Db Hs Ah Isld Power type: 3-phase (3~) Frequency: 50 Hz Rated current: 20 A Capacity: approx. 6,000 bottles/hour Features: Krones Variomatic control / drive system Robust industrial design Reliable operation and long service life Can be integrated into bottling lines Applications: Wineries Beverage bottling plants Small to medium-capacity filling and bottling lines The machine comes from an industrial operating environment. Viewing is possible by prior arrangement. 📍 For further information, please feel free to contact us.

Condition: used, Year of construction: 1991, Nominal capacity of filler: 60000 b/h Power: 10,7 kW Water: max. 4 bar, consumption: 1,3 l/min Compressed air: 6 bar, consumption: 2,5 bar, 30 N/m³/h Length: approx. 2.995 mm Blsdpfxovcqyhs Ah Isd Width: approx. 2.370 mm Height: approx. 2.600 mm Weight: 5200 kg Formats: 0,33 l LongNeck-, 0,5 l NRW-bottles, bottle height: min. 150 mm/ max. 350 mm, diameter: 71 mm Machine partitioning: 94 mm Operation / Control: Siemens S5 Features: inspections: bottom inspection, mouth inspection, sidewall inspection, caustic detection High frequency, residual fluid detection Infrared, evaluation for detection and separation of bottles with heavy abrasion, height detection

Condition: used, Year of construction: 1994, Technical details: production capacity: 2x 4,8 MW number of Generators: 2 Stück fuel tank capacity: 480 m³ type of fuel: Gas + Öl Complete Power Plant 2 combustion engines 12 cyl V -Motor Make Maschinenwerke Halberstadt Type: 12 VDG for oil and gas Bedpfx Ahou Nxate Isld 2 Generators Make Leo Somer with: - electrical capacity 4,6 MW each - mechanical capacity 4,8 MW each - thermal capacity 4,8 MW each - 2 recovery boiler - Stromeinspeisung: Mittelspannung 10 KV (direkt ins Netz) furthermore: heat exchanger, catalyst, control room, medium high voltage system, oil preparation plant, intermediate storage tank + fuel depot tanks 4,8 m³ *

Condition: used, Year of construction: 1995, Capacity: 20000 l/h CO2 connection pressure: 10 bar Current: 69 A Voltage: 230/400 V Frequency: 50 Hz Heating / Cooling: Connection pressure steam: min. 0.5, max. 1 bar Water: Connection pressure: min. 4, max. 5 bar Bsdpfxevcqwgo Ah Isld Compressed air: min. 7, max. 10 bar Length: 2 m Width: 2,4 m Height: 2,5 m Weight: 4000 kg Operation / Control: Siemens Simatic S5 Features: Saturation Tank (d = 750 mm) with fill level detectors as a carbonisation tank, measuring writer (ABB), circulating pump (Hilge), various ventils

Condition: used, Bottle filling line with an output of 30,000 bottles/h. 0.33l Vichy, 0.33l Euro, 0.35l Frucade and 0.5l NRW single-use and reusable bottles are used. The system consists of the following machines/components: -Unpalletizing system Manufacturer: Radenska & Steinle -Unpacker Manufacturer: SZA Federspiel -New glass lifter Manufacturer: Steinle Fördertechnik -Uncorker Manufacturer: Rink -Bottle washing machine Manufacturer: Krones -Crate washer -Bottle inspector Manufacturer: Krones -Beer preheater Manufacturer: Fischer -Bottle filler Manufacturer: Krones -Crown cap filling bunker with magnetic transport Manufacturer: Gassner -Bottle level control Manufacturer: Metec -Labeler Manufacturer: Krones/Renner -Label control Manufacturer: Miho -Packer Manufacturer: SZA Federspiel -Full crate inspection Manufacturer: Metec -Bottle carrier unfolder -Palletizing and palletizing system Manufacturer: Radenska & Steinle Additional title: with palletising and depalletising, years of manufacture 1993 - 2009 Capacity: 30000 bottles/h Formats: 0,33 L Vichy, 0,33 L Euro, 0,35 L Frucade und 0,5 L NRW Running direction: anticlockwise Operation / Control: mainly Siemens S7 Blsdpfx Ahovu Tt Ie Isd Features: Unpacking and palletizing system; unpacker; new glass remover; corker; bottle washing machine; crate washer; bottle inspector; beer preheater; bottle filler; crown cap feeder; fill level control; labeler; label control; packer full crate inspection; bottle carrier erector Layer patterns: 4x20, or 4x24, bottles, 4x8 boxes, 5 layers, on Euro pallet

Condition: used, D-6886-Delford Type SP 800 Bljdpfjc Nlxpjx Ah Ijd Delford SP800, Film wrapping machine, Packing materials: stretch films 12,5 – 25 micron (50-100 gauge) P.V.C. or any suitable heat sealable types. Max. roll with 450 mm, max. roll dia. 250 mm. Speed of operation: 40 – 80 packs per minute. Max. Packs sizes: L 300 mm, W 200 mm, H 120 mm, Girth 420 mm, Min. Packs sizes: L 130 mm, W 90 mm, H 10 mm, Girth 200 mm, Dimension: 5290 x 1049 x 1430. Machine weight: approx. 1400 kg.

Condition: used, Year of construction: 1991, Additional title: cold glue labeling Nominal capacity of filler: 50000 b/h Formats: Neck-/ breast-/ body-/ back-labels Running direction: left -> right Operation / Control: Siemens S5 Bledpsvcqwtsfx Ah Iod Features: 2 cold glue stations

Condition: used, Year of construction: 2001, Overview This Krones rinser-filler-capper block was manufactured in 2001 and consists of a Volumetic filling system combined with a Variojet rinser and a screw-capping machine. The machine is designed for PET multiway bottles (GDB PET-MW) in 1.0 L and 0.5 L formats. The system is equipped with 120 filling valves and 88 rinsing stations. The rinser operates with 2 rinsing channels, currently configured for ClO₂ and fresh water. The machine runs clockwise and achieves a production capacity of up to 32,000 bottles per hour at 1.0 L. The machine will be available from October 2026 and will be exchanged parallel to the installation of the new line.  Technical Data manufacturer: Krones model: Volumetic (filler) / Variojet (rinser) year of manufacture: 2001 filling valves: 120 rinsing stations: 88 rinsing channels: 2 (currently ClO₂ and fresh water) formats: 1.0 L GDB PET-MW 0.5 L GDB PET-MW POC 1810 closures production capacity: 32,000 bph at 1.0 L direction of rotation: clockwise availability: beginning of October 2026 Bedpoyluwtjfx Ah Iold

Condition: excellent (used), Year of construction: 2004, WIRE BELT BLAST MACHINE MANUFACTURER: RÖSLER WIRE BELT BLAST MACHINE BRAND: RÖSLER Manufacturer: Rösler Type: RDGE 800-4 Year of manufacture: 2004 Passage width: 800mm Passage height: 550mm Spinning wheel: 4 pieces with frequency converter, Filter system: wet filter system With several inlet and outlet belts. Incl., control cabinet, complete documentation, etc. TOP condition! System is dismantled! WIRE BELT BLAST MACHINE BRAND : RÖSLER Brand: Rösler Type: RDGE 800-4 Year: 2004 Belt Width : 800mm Inlethigh: 550mm Turbine: 4 Pieces with Drivers Filter: Wet Filter With many inlet- and outlet transport belt Incld. Main Panel, complete Doku Very good condition! Machine it s now desmantly Price: Loading on Truck Price: Loading on Truck Warranty: 6-month function and warranty guarantee when commissioned by DECK Sarl. Spare parts supply for the next 10 years Warranty: 6-month Functions- and warranty from DECK Sarl. When DECK Sarl. make the assembly OPTIONAL: Delivery to your factory: Bljdev Idf Ijpfx Ah Isd Assembly / commissioning / training Assembly by foreman We also offer spare parts for Rösler, Schlick, Wheelabrator, Gietart etc. blasting machines! We can offert for spare parts for Rösler, Shot Blasting Machines!

Condition: used, Year of construction: 2000, functionality: unexamined, Bottle labelling machine for plastic labels from roll. Manufacturer: KRONES Model: Contiroll K 745 - 978 Nominal output: from 3,000 bph to 15,000 bph. Max. 18,000 bph Year of manufacture: 2000 Bsdpfxsxpg Hmj Ah Ield Condition: used, regularly serviced, currently dismantled, requires technical inspection.
