Wide planing machines Kupfermühle Doin-Vuin 605 1972

Kupfermühle Doin-Vuin 605 Doin-Vuin

Condition: good (used), Code: 0046 Crodpfx Agjv D N Efsmoh Brand: KUPFERMUEHLE - GERMANY Model: DOIN - VUIN 605 2-shaft planing machine + multi rip saw for wood carpentry, wood beams, roofing, sawmill, coffins and various Technical data: Heavy cast iron structure Working width mm 605 Min/max working height mm 3/200 Min workpiece length mm 350 Automatic group lifting with possibility of manual adjustment Feed speed mt/min 7 - 9 - 11,5 - 14 - 18 - 23 Infeed table with 3 support guides and motorized top feed rollers Height adjustable guide saw unit - Motor Hp 2,5 - Blade diameter mm 180 - Suction port mm 120 Motorized towing roller on the table 1° shaft surface planer with 4 knives - Motor Hp 7,5 - Suction port mm 120 2° shaft thickness planer with 4 knives - Motor Hp 12 - Suction port mm 160 - Motorized towing roller on the table 3° Multiblade saw shaft - Motor Hp 40 - Blade diameter mm 230 - Cutting height mm 50 - Upper suction port mm 160 - Lower suction port mm 160 N° 2 upper motorized towing rollers and N°1 lower roller Control panel Overall dimensions mm 3300 x 1650 x 1600 h Weight kg 4000
