Honing machine

LAM PLAN M.M. 992

Condition: reconditioned (used), Max. forming area: 960 x 660 mm Min. forming area: 210 x 170 mm Max. sheet size: 1000 x 700 mm Min. sheet size: 310 x 210 mm Max. sheet thickness (manual feeding): 12 mm Max. sheet thickness (automatic feeding): 10 mm Max. tool height: 490 mm Ppodpowf Dvasfx Al Sjr Max. draw depth: 300 mm (positive/negative) Total power consumption: approx. 64.0 kW / 115 A Technical features: - Siemens Simatic S7-300 control, OP 37 panel - Air-conditioned control cabinet - Top heater with 5 temperature control circuits via pilot emitters - Bottom heater with 5 temperature control circuits via pilot emitters - Individually switchable top heating elements - Individually switchable bottom heating elements - Parallel clamping frame - Pneumatic motor locking for the upper reduction frame - Cylinder locking for the lower reduction frame - 4 cooling fans - Adjustable vacuum for the lower table via cascade control - Pre-blow and demolding adjustable via cascade control - Large front opening for tool change - Film sag control by photocell with support air - Automatic tool change system Lower table: 1. Tool clamping via vacuum 2. Tool change via pneumatically operated ball rollers Upper punch: 1. Motorized remote adjustment for stroke limitation 2. Pneumatic quick-change system for tools Sheet feeding: - Automatic motorized lifting of the film transport chain - With pneumatic quick-clamping system for vacuum plates - Motorized centering of plastic sheets - Separate vacuum pump for grained material Optional preheating retrofit: - Pneumatically moved top heater, complete zone control, each emitter individually switchable via toggle switch - Pneumatically moved bottom heater, complete zone control, each emitter individually switchable via toggle switch - Temperature control of top and bottom heating via separate heating controllers in the BE control cabinet (temperature setting not via UA control panel) Optional retrofit for roll processing: - Cross cutter and feeding rollers in feed area - RO 800 roll stand

Year of construction: 2024, condition: new, Cutting force 30 Tons or 60 Tons Table surface 1000x600mm or 1600x800 mm The electro-hydraulic upstroke cutting machine with motorized moveable beam type USC is a machine which has been constructed due to our long experience on this area of cutting machines. They are characterized by maximum operational reliability and an optimal overview onto the working table when the cutting beam is retracted. Podpfx Aonfu Nwjl Sjpr In the standard version of machine the working cycle is released by the contactless operating security light curtain or via the 2 start buttons mounted on the left and right of the machine. The stroke and passage of the machine are continuously adjustable within the specified limits via an electronic measuring system / potentiometer. An eccentric load on the machine is possible due to the extremely stable central guide column and the arrangement of the two hydraulic punching cylinders. The hydraulic power unit in the modular system is housed entirely at the rear of the machine and is easy to access for maintenance purposes. An automatic central lubrication supplies all lubrication points in the stand with a sufficient quantity of lubricating oil. The electrical switching devices are housed in a separate control cabinet, which is permanently installed on the machine. The setting of the machine by means of clear operator guidance is carried out via the touch panel on the side of the machine. A freely programmable controller processes the processes reliably and quickly.

Condition: ready for operation (used), Year of construction: 2002, functionality: fully functional, machine/vehicle number: 02 2406, GEISS DU 2400 X 2400 T8 YEAR OF MANUFACTURE: 2002 SERIAL NUMBER: 02 2406 TOTAL POWER CONSUMPTION: 517.9 kW RATED CURRENT: 750 A HEATING POWER INPUT (upper - lower): 462.9 kW RATED VOLTAGE: 230/240 V FREQUENCY: 50 Hz TOTAL WEIGHT: 141.1 kN AIR CONSUMPTION: 3315 liters/cycle AIR CONNECTION: 6 x 10/5 to 8 x 10/5 Pa Psdpsyin Ugjfx Al Sjpr WATER CONNECTION: min. 1.5 x 10/5 to max. 2.5 x 10/5 Pa A Geiss large-format vacuum thermoforming machine is available. Minimum panel cutting: 1100 mm / 1300 mm, maximum panel cutting: 2100 mm / 1800 mm, maximum forming depth: 620 mm. Additional sheet format 1: min. 850 mm / 750 mm, max. 1850 mm / 1250 mm. Additional sheet format 2: min. 1050 mm / 800 mm, max. 2050 mm / 1300 mm. Includes a separate loading unit with pneumatic panel separation equipment, automatic aligner for longitudinal and crosswise sheet cutting, pneumatic pusher for removing molded parts from the loading table, fully automatic central lubrication system for the loader, and several interchangeable pallets for window panel sets. Documentation available. On-site inspection possible.
