Veneer saw with planing unit

Langzauner

Condition: excellent (used), Year of construction: 2003, Langzauner LZ 5/2 - 3500 Veneer saw, precision cutting saw with jointing unit (planing unit) and veneer stop table. Robust machine construction by Langzauner. A video of the machine in operation can be sent upon request. For tear-free and gap-free cutting of veneer, including thick-cut veneer. Cutting length max. 3500mm Cutting and jointing height max. 40mm Easy-to-guide unit, runs on two hardened, ground linear guide shafts Rear support table with continuous finger stop, adjustable from approx. 2 - 56cm, with pneumatic clamping and digital display The stop table is very robustly built and runs on parallel round guides; it is slightly offset to the right so that cross-cuts can be made on the left side of the veneer packs. Angle stop on the stop table and on the front support for head cuts of the veneer packs Special equipment with rack and pinion compensation for the pressure bar, which prevents the pressure bar from skewing Pneumatic workpiece clamping, also holds in the center position Drive motor saw 2.2kW, milling unit 1.1kW The motors can be practically switched on at the handle, so they only run when needed. When switched on, the saw and milling unit are automatically engaged by compressed air; the cutting height can be selected in three positions via a revolving stop. Carbide-tipped precision cutting blade, sharpened Planer head Z4 with pull-cut, equipped with new carbide reversible inserts and spare blades included Practical front veneer support, automatically pneumatically extended when using the planing unit Dust extraction connection 150mm with dust extraction duct V-belt renewed CE marking Emergency stop cable Nsdpfx Abs Afznuj Rolh Operating manual Onboard tools Original paint, only a few spots have been touched up. The machine is in excellent condition and has obviously been used only rarely. Dimensions approx. 5050 x 1500 x 1450mm (LxWxH). Weight approx. 1000kg. The machine can be demonstrated on-site by appointment. We only offer machines that are ready for demonstration in our warehouse, see "other offers from this supplier".

Condition: excellent (used), Year of construction: 1999, Pressing area: 2500 x 1300 mm Opening width: 400 mm Number of press cylinders: 6 Total pressing force: 90 t Operating voltage: 3 x 400 V + N, 50 Hz Total connected load approx.: 20.0 kW Space requirement (L x W x H) approx.: 3000 x 1500 x 1950 mm Weight: approx. 3800 kg Hydraulic heating plate press, with lower plunger design BUSSE electric heating plates, gold anodized, lower plate NEW Digital temperature display and control for heating plates Pressing pressure can be continuously adjusted by means of a pressure switch Two-stage hydraulic pump with automatic switching valve from low to high pressure Central control panel at the front Rack and pinion compensation for uniform closing Safety release cord Main switch, lockable Opening automation Stroke limitation Lateral table extension with roller, extendable CE Note regarding used machines: Njdpfx Abez Ua R Uo Rolh • Errors in technical specifications and prior sale reserved. • Stated prices are ex-works prices – free loading! • The machine has been cleaned and functionally tested. • All machines are sold as is, as viewed, without any warranty claims. The buyer is free to inspect the machines on site. • Special agreements are only possible in written form. (We will only answer inquiries if you provide your address and telephone number!)

Condition: excellent (used), Heavy-duty double-sided edge sanding machine, oscillating Motor power approx. 3.0 kW Oscillation with own motor approx. 0.2 kW Sanding belt dimensions 3000 mm x 200 mm Front sanding table 980 x 340 mm rear sanding table 750 x 300 Space requirement L x W x H approx. = 1800 x 1500 x 1000 mm Weight approx. 600 kg Front sanding table with veneer edge sanding device Rear sanding table with infinitely variable angle adjustment Angle stop on rear work table Oscillation by means of gear motor Pneumatically height-adjustable sanding beam Interchangeable radius sanding discs Pneumatic belt tension, adjustable Extraction with blower Attachment option for feed unit 2 lateral support tables for radius sanding Note on used machines: Nlodpfsuxqzuex Ab Roh - Subject to errors in technical specifications and prior sale. - Prices quoted are ex location - free loading! - The machines have been cleaned and functionally tested. - All machines are purchased as seen without any warranty. The buyer is free to inspect the machines on site. - Special agreements are only possible in written form. (Inquiries will only be answered with your address and telephone number).

Condition: excellent (used), Year of construction: 1992, Belt dimensions: 2600 x 150 mm Sanding belt motor power: 2.2 kW Operating voltage: 3 x 400 V + PE / 50 Hz Sanding table height-adjustable via handwheel Table size: 975 x 340 mm Height-adjustable sanding table for radii; size: 400 x 200 mm Sanding beam can be swiveled 90 ° - 0 ° Suction connection Ø 120 mm CE Space requirement (L x W): approx. 1600 x 725 mm Weight: approx. 320 kg Note for used machines: - Subject to errors in technical specifications and prior sale. - Prices quoted are ex location - free loading! - The machines have been cleaned and functionally tested. Nljdpfxjtt Da De Ab Reh - All machines are purchased as seen without any warranty. The buyer is free to inspect the machines on site. - Special agreements are only possible in written form. (Inquiries will only be answered with your address and telephone number).

Condition: used, Year of construction: 2010, power: 6.5 kW (8.84 HP), Long-belt sanding machine suitable for sanding both large containers as well as standard sheets and smaller components. The machine can also be used as a standard-height machine! Nsdeywzvhopfx Ab Rjlh

Condition: excellent (used), Year of construction: 1999, Double-sided multipurpose edge sanding machine with oscillation and 200mm sanding height Langzauner LZK 4-S with veneer edge sanding side and solid wood sanding side 200mm sanding width Motorized sanding belt oscillation, therefore no compressed air connection required Drive motor 400V / 3kW Front work table for sanding veneer edges with a grooved stop guide (for veneer overhang) Veneer sanding device with fine adjustment, foldable Spring-loaded table, adjustable in height and can be positioned to the side Angle stop Rear adjustable work table for sanding solid wood Both tables are height-adjustable to utilize the sanding belt Belt dimensions 3000 x 200mm Side extension table for radius sanding on the 150mm belt roller Feed support holder 68mm Central dust extraction connection 140mm Njdpfxjz I T Apj Ab Rslh Very stable frame, 2 swivel casters, 2 steering casters, and a lever brake for locking CE marking All graphite pads and dust extraction hoses have been replaced Original paint, only touched up in a few places Excellent condition from a small restoration workshop Some sanding belts are included Dimensions approx. 1800 x 1000 x 1250mm (LxWxH). Weight approx. 650kg. The machine can be demonstrated on site by appointment. We only offer machines that are ready for demonstration in our warehouse, see "other offers from this seller".

Condition: excellent (used), Year of construction: 1998, functionality: fully functional, cutting length (max.): 3,050 mm, cutting height (max.): 45 mm, type of input current: three-phase, saw blade diameter: 180 mm, rotational speed (max.): 9,000 rpm, input current: 8 A, input voltage: 400 V, milling height: 45 mm, power: 3.7 kW (5.03 HP), input frequency: 50 Hz, number of digital displays: 1, We offer this very well-maintained Langzauner edge, veneer, and panel cutting machine, model LZ 5/2E - 3050. Available in a combined saw-milling version. CE version. Longitudinal design of the tool carriage on hardened and ground guide rails, lifting and lowering of the saw and milling unit is pneumatic, as well as pneumatic saw blade adjustment, adjustment range 2mm, cable guide for the tool carriage in a plastic energy chain, guidance of the unit by compact LM linear guide units. Central control panel directly in the handling area, electronically adjustable feed speed with soft start and rapid return when the tools are lowered, dust extraction channel with connection socket 150mm, prepared for connection to a central or existing dust extraction system. Special accessories: - Parallel rack compensation in the pressure beam. Prevents tilting of the pressure beam. - Movable, front support table 200mm wide - Rear sizing table for veneer processing, size 3050 x 500 mm, with parallel guidance and pneumatic stop lock - Foldable inserts for stop depth 800mm - Digital width display. Quick and accurate setting of the stop depth. Type: LZ 5/2E - 3050 Nlsdez Ikupepfx Ab Roh Factory number: 2/4717 Year of manufacture: 1998 Power: 3.7 kW Rated voltage: 3 x 400V + N Rated current: A Frequency: 50 Hz If you have any questions or require further information, please do not hesitate to send us a message or call us.

Condition: excellent (used), Year of construction: 1997, functionality: fully functional, type of input current: three-phase, input voltage: 400 V, grinding belt length: 3,000 mm, grinding belt width: 150 mm, table height adjustment: 180 mm, input frequency: 50 Hz, Langzauner LZK 3/4 oscillating edge sanding machine, with veneer edge sanding attachment and feed console Sanding unit adjustable from 0-45° Oscillation Miter stop Height-adjustable sanding table (180 mm) for utilizing the full width of the sanding belt Table size (front) 1000 x 350 mm Nljdpfxjz D Auts Ab Reh Table size (side) 400 x 250 mm Connection power 4.6 kW Belt length 3000 mm Belt width 150 mm Belt speed 22 m/s Weight approx. 350 kg Space requirement 1770 x 730 mm Year of manufacture 1997 Condition: Functionality tested

Condition: excellent (used), Year of construction: 2007, machine/vehicle number: 21370-07-1268, functionality: fully functional, Available from April 1, 2027, for self-dismantling and self-collection. Langzauner heating press / veneer press, type LZT 100-SF, manufactured in 2007. The machine is suitable for pressing and gluing sheet materials, veneers, and comparable workpieces. It features heated press surfaces and a hydraulic pressing device. The upper and lower heating elements can be switched on separately. Technical data • Manufacturer: Langzauner • Type: LZT 100-SF • Year of manufacture: 2007 • Factory number: 21370-07-1268 • Heating: upper and lower heating • Temperature display: separate for top and bottom • Pressing time: adjustable • Opening time: adjustable • Automatic opening: available Nlodpfx Ajz Dai Uob Rsh • Electrical connection: 3 × 400 V + N • Frequency: 50 Hz • Rated current: 42.2 A • Connected power: approximately 27 kW according to the nameplate • Hydraulic press with 6 press cylinders • Safety cable / safety device • Press surface heating plates in top condition, no damage • Heating plate size: 3,000 × 1,300 mm • Max. press opening / stage clearance: 400 mm • Total pressing force: 100 tons • 6 press cylinders • Electric heating plates

Condition: good (used), Year of construction: 1985, For sale is a used Langzauner LZK 3/2 wide belt grinding machine with a grinding belt length of 6200 mm. The machine is in good condition and has been inspected by our qualified technicians. Technical data: Nledpjz Anwmofx Ab Reh - Table size 2500 x 800 mm - Height adjustable - Grinding belt length 6800 mm - Dust extraction connection Ø 150 mm - Motor power 3 kW / 4.1 hp - Year of manufacture 1985 The machine is located in A-5431 Kuchl and can be inspected at any time during our opening hours. Related terms: Grinding machine, wide belt, wide belt sander Reference: R-N0131
