Milling

Condition: defective spare-parts repository (used), Year of construction: 2007, functionality: not functional, grinding length: 3,150 mm, grinding width: 800 mm, table load: 6,000 kg, grinding spindle motor power: 22,000 W, workpiece height (max.): 650 mm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Grinding length: 3,150 mm Grinding width: 800 mm Max. workpiece height: 650 mm Table surface dimensions: 3,150 x 600 mm Magnetic chuck dimensions: 3,000 x 600 mm Grinding wheel dimensions: 450 x 100 x 127 mm Max. table load: 6 t MACHINE DETAILS Control system: SIEMENS 840D Total power requirement: 70.6 kW Spindle power: 22 kW Dimensions & Weight Installation space required: approx. 11 x 3 x 2.4 m Bodpfx Afeylk E Hecjcw Machine weight: approx. 15 t EQUIPMENT Coolant system 2,500 l Magnetic holding force regulation Semi-automatic balancing system Note: The control unit boots up, but the MININI grinding software does not load for unknown reasons. The control hardware has been checked and is in order. Backup files are available.

Condition: ready for operation (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: H-H20140, travel distance X-axis: 610 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 610 mm, rotational speed (max.): 15,000 rpm, number of slots in tool magazine: 24, TECHNICAL DETAILS X-axis travel: 610 mm Y-axis travel: 510 mm Z-axis travel: 610 mm Table size: 760 mm x 510 mm System: SK40 Speed: 15,000 rpm MACHINE DETAILS Machine weight: 4,700 kg Control: Ultimax Bcodsylk Eyspfx Afcsw EQUIPMENT 24-position tool changer Internal coolant supply (IKZ) Chip conveyor Electronic handwheel

Condition: ready for operation (used), Year of construction: 2012, functionality: fully functional, total length: 90,000 mm, travel distance X-axis: 2,600 mm, travel distance Y-axis: 4,000 mm, table length: 4,000 mm, table width: 2,600 mm, TECHNICAL DETAILS Travel distance X-axis: 2,600 mm Travel distance Y-axis: 4,000 mm Table length: 4,000 mm Table width: 2,600 mm Maximum glass weight: 260 kg Glass thickness: 4 - 10 mm MACHINE DETAILS Cycle time: 10 pieces/hour Cabin type: SUP-E2-D107/20000 + "D" Total production line length: 90 m Installed power: 1,100 kW EQUIPMENT Loading station with lifter Bcjdpfjyk S Uyex Afcjw Vertical inlet conveyor WM Vertical washing machine with dryer Vertical inspection conveyor with activation section Tilting table with horizontal transport and vertical inspection Pre-heating section Powder section with belt cleaning Cleaning conveyor Cooling section Tilting table with vertical and horizontal transport Vertical inspection station Unloading station Electrical distribution Deionized water system for the washing machine supply The ovens that may be visible in the pictures are not included in the scope of sale and delivery.

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, travel distance Z-axis: 185 mm, workpiece length (max.): 3,000 mm, workpiece width (max.): 1,500 mm, TECHNICAL DETAILS Bcodpfx Aeyk S I Hofcsw Maximum glass dimensions: 1,500 x 3,000 mm Z-axis travel (vertical): 185 mm Work table: 3,250 x 1,620 mm

Condition: ready for operation (used), Year of construction: 2004, functionality: fully functional, year of last overhaul: 2022, The machine was completely overhauled in 2022! TECHNICAL DETAILS Bodsyk Stpepfx Afcscw Variable angle: 0-45°

Condition: ready for operation (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: 112672, total length: 6,700 mm, working height: 840 mm, workpiece weight (max.): 350 kg, controller model: RS150, workpiece height (max.): 35 mm, TECHNICAL DETAILS Processable glass thickness: 3-35 mm Processable dimensions (with corner bevel 15 mm) min.: 45 mm Processable dimensions (without corner bevel) min.: 35 mm Permissible weight per conveyor meter max.: 200 kg/m Total load: 350 kg Working speed: 0.5-5 m/min Pneumatic feed pressure: 6 bar Water tank capacity: 360 L MACHINE DETAILS Bodpoyk Spwofx Afcocw Control system: RS150 Total installed power: 16.5 kW Pneumatic feed pressure: 6 bar Water tank capacity: 360 L Dimensions & Weight Dimensions (L x W x H): 6,700 x 1,300 x 2,300 mm Height of working level: 840 mm Total weight (with empty water tank): 2,600 kg EQUIPMENT NC with automatic speed adjustment ABS covers for sound insulation and safety Multi-functional NC Centralized lubrication Adjustable glass removal rate Front adjustment of the rear arrising wheel Stainless steel housing and tanks CN 23 operator interface Programmable logic controller (PLC) integrated in NC Liquid crystal display (LCD) Control keypad with sensitive keys

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, machine/vehicle number: 806, overall weight: 4,600 kg, workpiece weight (max.): 2,000 kg, workpiece height (max.): 55 mm, number of spindles: 13, TECHNICAL SPECIFICATIONS Glass thickness: 3–55 mm Minimum glass size: 35 x 150 mm Maximum glass weight: 2,000 kg Speed: 0.3–5 m/min Number of spindles: 13 MACHINE DETAILS Power: 26 kW Operating pressure: 8 bar Voltage: 400 V Frequency: 50 Hz Bedeyk Skzepfx Afcocw Dimensions & Weight Dimensions (L x W x H): 9,590 x 1,350 x 3,700 mm Machine weight: 4,600 kg

Year of construction: 2012, condition: ready for operation (used), functionality: fully functional, total length: 10,200 mm, total height: 2,600 mm, workpiece length (max.): 4,000 mm, The washing machine consists of the following components: Pre-wash zone Washing zone Rinse zone Acid zone Drying Silane application Bjdpjyk Sgvjfx Afcscw TECHNICAL DETAILS Maximum length of sheets to be washed: 4,000 mm MACHINE DETAILS Total length: 10,200 mm Total height: 2,600 mm

Year of construction: 2019, condition: ready for operation (used), functionality: fully functional, workpiece height (max.): 10 mm, operating speed: 50 mm/s, TECHNICAL DETAILS Minimum processing size: 100 mm x 400 mm Processing thickness: 2 - 10 mm Bodpfjyk Sgijx Afcocw Maximum speed: 3 m/min MACHINE DETAILS Power: 45 kW DIMENSIONS Dimensions of the enclosure (L x W x H): 6,260 x 1,280 x 1,750 mm Dimensions of the control cabinet: 1,000 x 480 mm

Condition: ready for operation (used), Year of construction: 2021, functionality: fully functional, temperature: 250 °C, power: 30 kW (40.79 HP), Curing oven with two chambers (one programmable heat cycle per chamber)! Equipped with conveyor belt and cleanroom classification! TECHNICAL DETAILS Process area (minimum): 1,700 x 1,400 mm (2.40 m²) MACHINE DETAILS Electrical Data Main power supply: 3x400 V ±5%, 50 Hz ±5% Control voltage: 230 Vac 50 Hz and 24 Vdc Main fuse: 140 A Motor Output Circulating fan motor: 2.2 kW (2 units) Drive motor for vertical transport: 0.39 kW Drive motor for horizontal transport: 0.09 kW Heating Bcedpfx Aeyk Sd Uofcow Heating type: Electric with sealed tubular elements Output: 30 kW per chamber Temperature range: 50 °C to 250 °C EQUIPMENT Conveyor system Cleanroom classification
