CNC press brake PETERZEN MORICO 70065

High performance CNC press brake PETERZEN model MORICO 70065 6 axis + 2 + 1

Rigid S355 steel frame
Workbench structure and Ram manufactured from laminated S355 steel
Symetric renforced Throats
Heavy grey cast iron slydways with automatic lubrication system
CNC Controller CYBELEC VisiPac 8 axis + 1
Bosch Rexroth servo valves
Inovance servo drive systems
DIEMA high resolution glass scales for high bending precision

Bending force 700T
Bending lenght 6500 mm
Distance between columns 5100 mm
Depth throat 420 mm
Ram stroke 400 mm
Closing Ram approach speed limited to 30 mm/s for human operation
Closing Ram working speed 7 mm/s
Return-speed 40 mm/s
Main hydraulic motor 45 kW
Machine weight 62,000 kg

8 Axes + 1 CNC controller Cybelec VisiPac Touchscreen monitor with vivid colors and high contrast
3D graphical profile drawing (Touch Profile) and precise 2D program creation
The opening value can be setted individually in each sequence
Machine can be inferfaced with different CAM software
Easy single bends with the EasyBend page
Correction menu
Many languages available

Centered lower die system 60 mm AMADA / WILA- tool or COLLY Standard
Ram featured with intermittant tool holder for punches with AMADA or COLLY Standard dimensions and Fall down security
All toolings adopt 42CrMo4 steel, induction hardened and cnc grinded

4 Axis Back gauge adopts linear guides and Ballscrews
Back gauge travel X axis 1000 mm
2 automatic widened back gauge fingers on linear guide rails with helical rack and pinions (Axis Z1 and Z2)
Automatic height adjustment (Axis R)

2 CNC Bending Followers 400 kg up to 60° angle
Motorised displacement of bending followers and parking area on the right of the bending table

Strong automatic mechanical crowning table. The compensation value is calculated and set by the CNC system.

Safety Equipment :
3-position Foot switch with Emergency Stop Position
Closing approaching speed limited to 30 mm/s for human operation
Laser safety protection and permanent speed monitoring
Closing bending (working) speed 7 mm/s
Side covers with safety switch
Rear-protection with sliding door and safety switch
Fedpswd I Svsfx Af Ejga
Low control Voltage (24V)
Safety control unit category IV

Standard configuration and equipment :
Electric control cabinet on left side
CNC user interface with Aluminium - arm
1 Line of punches (Upper tools) 85° R1, Height 200 mm
1 Line of centred lower Dies (to be defined)

Place of manufacture : Douarnenez (Britanny) in Northwest FRANCE
Customisation available
CE Certification in respect of CE2006/42 directive and EN12622+A1 European Standard
Operation manual in English, German and French language

Delivery and Services available worldwide
Customized Quotation
