Drying chamber burner

Condition: ready for operation (used), Year of construction: 1998, operating hours: 26,000 h, functionality: fully functional, machine/vehicle number: J0124, travel distance X-axis: 1,800 mm, travel distance Y-axis: 850 mm, travel distance Z-axis: 750 mm, controller model: Heidenhain iTNC 426, rotational speed (max.): 6,000 rpm, TECHNICAL DETAILS Travel range X-axis: 1,800 mm Travel range Y-axis: 850 mm Travel range Z-axis: 750 mm Spindle nose to table distance range: 200 mm - 950 mm Spindle center to column distance: 920 mm Table dimensions X: 2,000 mm Table dimensions Y: 800 mm Max. table load: 2,200 kg Tool interface: SK50 Magazine capacity: 30 Pgodpfjzdpqwjx Ap Een Spindle speed: 6,000 rpm Feed rate: 5 m/min Rapid traverse: 12 m/min MACHINE DETAILS Control system: Heidenhain iTNC 426 Dimensions & Weight Dimensions (L x W x H): approx. 5,700 x 3,850 x 3,350 mm Weight: approx. 16,500 kg Operating Hours Total operating hours: approx. 51,000 h Spindle operating hours: approx. 26,000 h EQUIPMENT 4th axis installed as a rotary table Documentation/Manual Spindle speed infinitely adjustable Chip conveyor Coolant system Vices

Condition: ready for operation (used), Year of construction: 2007, pressing force: 28 t, stroke length: 200 mm, throat depth: 200 mm, installation height: 325 mm, working length: 835 mm, TECHNICAL DETAILS Pressing force: 28 t Bending length: 835 mm Travel range of the back gauge: 0 - 370 mm Stroke: 200 mm Distance between frames: 890 mm Support table: 200 x 275 mm Overhang: 200 mm Installation height: 325 mm Number of cylinders: 1 Working speed Pressing speed: 8-10 mm/s Retraction: max. 35 mm/s Positioning accuracy: +/- 0.05 mm Pjdpszdd Rgofx Ap Eogn MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 1,600 x 1,500 x 2,200 mm Total weight: 3,500 kg EQUIPMENT Operating manual Safety device Mechanical tool clamping system (top)

Condition: ready for operation (used), Year of construction: 2012, controller model: NR4000.2.1 IPC, Equipment: documentation/manual, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Engraving area, X-axis: 100 mm Engraving area, Y-axis: 150 mm Pgsdpfx Apjzddzro Een CNC engraving and embossing machine – TSM series Type: TSM 15-10-UG Year of manufacture: 2012 Control system type: NR4000.2.1 IPC EQUIPMENT Operating manual available Documentation and software available

Condition: defective spare-parts repository (used), Year of construction: 2020, spindle speed (max.): 18,000 rpm, travel distance X-axis: 500 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 150 mm, table load: 20 kg, No minimum price – guaranteed sale to the highest bidder! The new price of the machine was 39,875 EUR! TECHNICAL DETAILS Travel range, X-axis: 500 mm Travel range, Y-axis: 500 mm Travel range, Z-axis: 150 mm Dimensions of the T-slot table (L x W): 700 x 570 mm Maximum table load: 20 kg Pedpfx Aezddwmsp Eegn HFS spindle power: 80 W HFS spindle speed: 60,000 rpm Motion Rapid traverse: 100 mm/s Repeatability: 0.01 mm Tool holder: 6 mm MACHINE DETAILS Electrical connection: 240 V Software: Signumeric EQUIPMENT Bellows covers Energy guide chains Jäger engraving spindle 42-2 W27 FS incl. frequency converter Reinforced base frame Heat dissipation via spindle carrier 2 m cable outlet Quick-change system for on-site electric engraver Documentation and software available Note: without monitor and without PCA control module (engraving computer)

Year of construction: 2018, condition: ready for operation (used), operating temperature: 950 °C, ambient temperature (max.): 70 °C, nominal flow rate: 40 m³/h, overpressure (max.): 0.2 bar, machine/vehicle number: 220173941, TECHNICAL DETAILS Maximum overpressure in the pipes: 0.2 bar Pgsdpozddb Esfx Ap Een Maximum operating temperature in the pipes: 950°C Maximum ambient temperature: 70°C Pipe volume: 40 l EQUIPMENT Dew point or cp control Soot filter in duplex version Fully automatic power control in the range of 50-100%

Condition: ready for operation (used), Year of construction: 2004, functionality: fully functional, machine/vehicle number: 665100, overall weight: 4,700 kg, center height: 125 mm, Round grinding machine with robot! TECHNICAL DETAILS Center height: 125 mm MACHINE DETAILS Control: Fanuc 18i-T Total weight: 4,700 kg Operating hours Automatic cycle time (according to diagram): 41,411 h Feed time (according to diagram): 14,251 h EQUIPMENT Universal Robots UR5 robot Standard accessories 1 grinding wheel set, right-hand, 500 x 110 x 203.2 mm 1 manual swivel chuck for turning parts with manual indexing every 2.5 degrees Automatic balancing device MARPOSS type E 82 Pjdezcwfuopfx Ap Eogn Hydraulic quill retraction for the tailstock Stroke monitoring for the tailstock Standard workpiece spindle MK 5 DIN 55026 size 5”

Condition: ready for operation (used), Year of construction: 1989, functionality: fully functional, machine/vehicle number: 32.469.3143, center height: 125 mm, grinding length: 1,000 mm, The machine underwent a partial overhaul in 2009. TECHNICAL DETAILS Maximum height: 125 mm Maximum width: 1,000 mm EQUIPMENT Automatic working cycle Intermediate plates 50 mm for a maximum height of 175 mm Vibration-damping pads Machine light Pgsdpozcwfnofx Ap Ejn Internal grinding device for a maximum diameter of 70 mm Internal grinding spindle UJ7P Coolant supply through the workpiece spindle, including protective cover Side and angled dressing device Swiveling dressing device for internal grinding Dressing stop for internal grinding Collet chuck Set of collets Dial indicator stop for table swiveling with a 1/100 mm dial indicator Sine bar Table fixed stop Strip-type filter system SONY digital measuring system, 2 axes Documentation

Condition: ready for operation (used), Year of construction: 2014, functionality: fully functional, travel distance X-axis: 2,134 mm, travel distance Y-axis: 813 mm, travel distance Z-axis: 762 mm, table load: 1,814 kg, spindle speed (max.): 8,100 rpm, The machine can be inspected while powered on during production! TECHNICAL DETAILS Travel range, X-axis: 2,134 mm Travel range, Y-axis: 813 mm Travel range, Z-axis: 762 mm Max. spindle speed: 8,100 rpm Spindle motor power: 22.4 kW Max. torque: 122.0 Nm at 2,000 rpm Table dimensions: 2,134 x 711 mm Max. load capacity on table: 1,814 kg Number of tool magazine slots: 31 Distance from spindle nose to machine table (max.): 864 mm Podpfxezg Drze Ap Ejgn Distance from spindle nose to table (min.): 102 mm MACHINE DETAILS Control system: HAAS Table dimensions: 2,134 x 711 mm Max. load capacity on table: 1,814 kg EQUIPMENT Documentation/Manual Chip conveyor

Condition: ready for operation (used), Year of construction: 2004, functionality: fully functional, travel distance X-axis: 2,700 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,050 mm, spindle speed (max.): 3,000 rpm, controller model: HEIDENHAIN iTNC530, The machine can be inspected while powered on during production! TECHNICAL DETAILS Travel range X-axis: 2,700 mm Travel range Y-axis: 1,000 mm Travel range Z-axis: 1,050 mm Max. feed rate X/Y/Z: 10,000 mm/min Table dimensions: 3,300 x 1,000 mm T-slots: 7 x 22 2-axis diagonal milling head: 1 x 2.5 Spindle speed: 60 - 3,000 rpm Motor power: 22/30 kW Tool holder: ISO 50 (DIN69872-B) MACHINE DETAILS Control system: HEIDENHAIN iTNC530 Coolant pressure through the spindle: 19 bar EQUIPMENT Adjustable control panel in front of the machine Enclosure with front-facing doors Machine documentation Pjdpfxjzg Dq Do Ap Esgn Cooling and chip disposal Chain conveyor in the longitudinal direction

Condition: ready for operation (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: 020033, spindle speed (max.): 5,000 rpm, spindle diameter: 110 mm, controller model: Siemens SINUMERIK, empty load weight: 11,000 kg, counter spindle speed (max.): 5,000 rpm, The machine is expected to be available for approximately €4,000, including loading onto a truck (FOB). TECHNICAL DETAILS Working area X1-axis: 1,190 mm Working area Y1-axis: 120 mm Working area Z1-axis: 260 mm Working area X3-axis: 540 mm Working area Y3-axis: 120 mm Working area Z3-axis: 260 mm Handling space X1-axis: 490 mm Axes and Feed Feed force X1/Z1/Y1: approx. 8/10/10 kN Feed force X3/Z3/Y3: approx. 8/10/10 kN Rapid traverse speed X1/Z1/Y1: approx. 80/40/7.5 m/min Rapid traverse speed X3/Z3/Y3: approx. 40/40/7.5 m/min Acceleration X1/Z1/Y1: 7/7/7 m/s² Acceleration X3/Z3/Y3: 7/7/7 m/s² Spindle Speed at main and counter spindle: 5,000 RPM Power at 100% duty cycle, main spindle: 20 kW Torque at 100% duty cycle: 105 Nm Power at 40% duty cycle: 27 kW Torque at 40% duty cycle: 145 Nm Spindle bore: 65 mm Spindle diameter at front bearing: 110 mm Spindle nose diameter (cylindrical): 140 mm Hydraulic full-stroke cylinder OVS80 - Main spindle Piston stroke: 32 mm Piston area: 34.36 cm² Clamping pressure: 8 to 80 bar Tensile or compressive force at 80 bar: max. 27.2 kN Leakage oil volume at operating pressure 80 bar: max. 2.2 l/min Hydraulic full-stroke cylinder OVS65 - Counter spindle Piston stroke: 32 mm Piston area: 26.1 cm² Clamping pressure: 8 to 100 bar Tensile or compressive force at 100 bar: max. 26.1 kN Leakage oil volume at operating pressure 100 bar: max. 3 l/min Y-axis Slide travel: 120 mm Feed force: 10 kN Rapid traverse: 7.5 m/min Resolution: 0.05 mm Speed of driven tools: 6,000 RPM MACHINE DETAILS Control system: Siemens SINUMERIK Unloading device Swivel angle: 90 degrees Swivel time: 2 s Slide travel: 100 mm Rapid traverse speed: 6 m/min Workpiece weight: approx. 10 kg Workpiece diameter: 200 mm Pgedpezdqdfefx Ap Esn Electrical data Rated power: 45 kW Apparent power: 53 kVA Rated current: 76 A Voltage: 400 V Frequency: 50/60 Hz Dimensions and weight Dimensions with chip conveyor (L x W x H): 2,770 x 4,435 x 2,750 mm Weight: approx. 11,000 kg EQUIPMENT Two tool holders with 12 tool positions each, VDI 30 Note: Further technical data can be found in the attached data sheet. The machine is not equipped with a B-axis.
