SERGI 1550X5 HYDRAULIC CALENDER

Condition: ready for operation (used), Year of construction: 2001, functionality: fully functional, machine/vehicle number: 331965, workpiece weight (max.): 500 kg, travel distance X-axis: 400 mm, travel distance Y-axis: 250 mm, travel distance Z-axis: 200 mm, wire diameter (max.): 0.25 mm, No reserve price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Podpjyz Rxaefx Ag Djgk X-axis travel: 400 mm Y-axis travel: 250 mm Z-axis travel: 200 mm (U/V) axis travel: 400 x 250 mm Taper angle: +/- 30° at 200 mm height Workpiece weight: 500 kg Workpiece height (max): 200 mm Workpiece width (max): 500 mm Workpiece length (max): 850 mm MACHINE DETAILS Standard wire guides: 0.25 mm Dimensions & weight Dimensions (L x W x H): 1,800 x 1,600 x 2,180 mm Machine weight: 2,190 kg Injection pressure upper nozzle: 0 - 11.5 bar Injection pressure lower nozzle: 0 - 11.5 bar

Condition: ready for operation (used), Year of construction: 1995, functionality: fully functional, machine/vehicle number: 350900, workpiece weight (max.): 1,000 kg, travel distance X-axis: 400 mm, travel distance Y-axis: 250 mm, travel distance Z-axis: 400 mm, wire diameter (max.): 0.25 mm, No reserve price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel X-axis: 400 mm Travel Y-axis: 250 mm Travel Z-axis: 400 mm Travel U-axis: 400 mm Travel V-axis: 250 mm Psdpfx Agoyz Rvle Djgk Workpiece weight: 1,000 kg Workpiece height (max.): 400 mm Workpiece width (max.): 500 mm Workpiece length (max.): 850 mm Taper angle: +/- 30° at 400 mm height MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 1,800 x 1,600 x 2,230 mm Machine weight: 2,500 kg Standard wire guides: 0.25 mm EQUIPMENT Collision protection in X/Y/U/V/Z

Condition: ready for operation (used), Year of construction: 2008, operating hours: 3,858 h, functionality: fully functional, turning length: 705 mm, turning diameter: 275 mm, travel distance X-axis: 260 mm, travel distance Z-axis: 795 mm, controller model: MSX-850III, TECHNICAL DETAILS Travel X-axis: 260 mm Travel Z-axis: 795 mm Turning length: 705 mm Max. turning diameter: 275 mm Swing over bed: 923.8 mm Swing over cross slide: 755 mm Bar work capacity diameter: 80 mm Upper turret Pgjdpfx Aeyz Aq Ieg Dsk Number of tool stations: 12 Main spindle Spindle speed: 4,000 rpm Spindle drive power: 18.5/18.5/15 kW (10 min/30 min/cont) Spindle nose: JIS A2-8 Tailstock Tailstock travel: 734 mm Taper: MT5 MACHINE DETAILS CNC control: MSX-850III Dimensions & Weight Dimensions (L x W x H): 3,100 x 1,922 x 2,120 mm Weight: 5,800 kg Operating Hours Main spindle hours: 3,858 h Power-on hours: 21,543 EQUIPMENT Chip conveyor Tool measuring arm

Year of construction: 2007, condition: not inspected (used), functionality: unexamined, total length: 5,700 mm, total width: 1,000 mm, workpiece length (max.): 2,000 mm, workpiece width (max.): 800 mm, Equipment: CE marking, TECHNICAL DETAILS Maximum panel width: 800 mm Minimum panel length: 140 mm Maximum panel length: 2,000 mm Conveyor length: 5,700 mm MACHINE DETAILS Dimensions (L x W): 5,700 x 1,000 mm Return of parts to edge banding machine: Left Panel outfeed: via air cushion table Panel feed: via motorized conveyor belt EQUIPMENT CE Safety Standard Pgedpfx Ageyzzhxj Dek The machine is sold and delivered in its actual and legal condition ("as seen and approved"), based on photographic documentation and technical/commercial descriptive documents. The buyer has the right to inspect the goods prior to collection and assumes responsibility for the installation, securing, and use of the machine at the destination. External reference: 6200

Condition: not inspected (used), Year of construction: 2006, functionality: unexamined, rotational speed (max.): 2,970 rpm, workpiece length (max.): 2,500 mm, workpiece width (max.): 1,000 mm, Equipment: CE marking, TECHNICAL DETAILS Max. panel width: 1,000 mm Max. panel length: 2,500 mm Min. panel length: 250 mm Min. panel width: 100 mm Number of vertical lower groups: 5 Number of vertical upper groups: 1 Lateral horizontal groups: yes Number of pressure elements: 5 Number of horizontal lateral groups: 2 Motor power: 1.5 kW Speed: 2,970 rpm MACHINE DETAILS System control: TOPDRILL Machine programming software: WOODWOP Total installed power: 35 kW EQUIPMENT Lateral horizontal groups CNC positioning of the groups CNC positioning of the Z-axis Safety standards with CE marking Safety light barriers Automatic chip extraction The machine is sold and delivered in its actual and legal condition ("as seen and approved") based on photo documentation and technical/commercial reference documents of a descriptive nature. The buyer has the right to inspect the goods before collection and assumes responsibility for installation, securing, and operation of the machine at the destination. Pgedpoyzy T Tefx Ag Dok External reference: 6157

Condition: not inspected (used), Year of construction: 2006, functionality: unexamined, travel distance X-axis: 4,400 mm, travel distance Y-axis: 1,300 mm, feed rate X-axis: 40 m/min, feed rate Y-axis: 45 m/min, Equipment: CE marking, The machine has the following configuration: Drilling units: Upper unit with 30 vertical and 6 horizontal spindles Milling unit 1: Upper unit, 5 controlled axes, 7.5 kW motor power, liquid cooling system Milling unit 2: Upper unit, 11 kW motor power, 18,000 rpm, liquid cooling system Tool magazine 1: 24 positions, mounted at the rear of the machine Tool magazine 2: 6 positions, mounted on the working head TECHNICAL DETAILS X-axis travel: 4,400 mm Y-axis travel: 1,300 mm Maximum workpiece pass-through height: 400 mm X-axis traversal speed: 40 m/min Y-axis traversal speed: 45 m/min Z-axis traversal speed: 22.5 m/min Pgsdpoyzy S Nsfx Ag Djk MACHINE DETAILS Control system: WINDOWS Machine programming software: XILOG Vacuum pump individual capacity: 250 m³/h Connected load: 35 kW EQUIPMENT Worktable with vacuum rail supports Number of vacuum rails: 8 Vacuum clamping for workpiece CE safety standards Automatic chip extraction The machine is sold and delivered in its actual and legal condition ("as seen and approved") based on photographic documentation and technical/commercial documents of a descriptive nature. The buyer has the right to inspect the goods prior to collection and assumes responsibility for installation, securing, and operation of the machine at the destination. External reference: 8340

Year of construction: 1998, condition: not inspected (used), functionality: unexamined, workpiece length (max.): 4,200 mm, workpiece width (max.): 2,200 mm, stack height: 1,000 mm, TECHNICAL DETAILS Max. panel length: 4,200 mm Max. panel width: 2,200 mm Max. stack height from floor: 1,000 mm Lifting capacity: 200 kg Number of vacuum suction cups: 32 MACHINE DETAILS Pgsdpsyzy Rxofx Ag Dek Number of pick-up stations: 2 EQUIPMENT Pick-up station for panel stacks Vacuum system Feeding of panel stacks Feeding of panel stacks via motorized roller conveyor Frame system Vacuum pump The machine is sold and delivered in its actual and legal condition ('as seen and approved') based on photographic documentation and technical/commercial data sheets of a descriptive nature. The buyer has the right to inspect the goods prior to collection and is responsible for the installation, securing, and use of the machine at the destination. External reference: 5934

Condition: not inspected (used), Year of construction: 2014, functionality: unexamined, workpiece height (max.): 60 mm, edge thickness (max.): 20 mm, feed rate X-axis: 30 m/min, controller model: ICOS OPEN, The machine has the following configuration: Unit: Pre-milling Manufacturer model: 08.379 Motor power: 4 kW Speed: 8,800 rpm Unit: Cut-off saw unit Manufacturer model: 08.42 / 30 / B Number of motors: 2 Motor power: 0.660 kW Unit: Corner rounding unit Manufacturer model: 08.055 Number of motors: 2 Motor power: 1.850 kW Speed: 12,000 rpm Unit: Profile trimming unit Manufacturer model: SKF-L Number of motors: 4 Max. machining speed: 20 m/min Motor power: 0.180 kW Speed: 12,000 rpm Unit: Scraper blade unit Manufacturer model: 08.519 Unit: Glue scraper unit Manufacturer model: 08.521 Unit: Brushing unit Manufacturer model: 08.617-2 Number of motors: 2 Motor power: 0.180 kW Speed: 1,400 rpm TECHNICAL DETAILS Min. panel height: 8 mm Max. panel height: 60 mm Min. panel length: 150 mm Min. panel width: 65 mm Min. edge thickness: 0.3 mm Max. edge thickness: 20 mm Max. feed speed: 30 m/min MACHINE DETAILS Control: ICOS OPEN Podpfxsyzy Iws Ag Dsgk EQUIPMENT Magazine for coil material Tank for hot-melt adhesive Edge pressure roller unit Pressure by rubberized belt The machine is sold and delivered in its actual and legal condition ("as seen and approved") based on photographic documentation and technical/commercial documents of descriptive character. The buyer has the right to inspect the goods prior to collection and assumes responsibility for the installation, securing, and operation of the machine at the destination. External reference: 6089

Condition: ready for operation (used), Year of construction: 2022, functionality: fully functional, machine/vehicle number: 02DC2563, workpiece weight (max.): 1,500 kg, travel distance X-axis: 600 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 310 mm, wire diameter (max.): 0.3 mm, The machine will remain in operation until 08/04/2026! TECHNICAL DETAILS X-axis travel: 600 mm Y-axis travel: 400 mm Z-axis travel: 310 mm U/V-axis travel: 150 mm Max. workpiece weight: 1,500 kg Maximum workpiece dimensions: 1,050 x 820 x 305 mm Taper angle (workpiece height): 15 mm / 260 mm or 30 mm / 110 mm Table dimensions: 840 x 560 mm Possible wire diameters: 0.10 - 0.30 mm Pgodjyzh Dajpfx Ag Djk Wire spool capacity: 10 kg MACHINE DETAILS Dimensions & Weight Machine dimensions: 2,687 x 3,030 x 2,150 mm Machine weight: 3,500 kg EQUIPMENT Hardened 3-sided table

Condition: ready for operation (used), Year of construction: 2017, functionality: fully functional, machine/vehicle number: 100281518, total height: 2,260 mm, total width: 1,550 mm, total length: 1,685 mm, product height (max.): 310 mm, product width (max.): 150 mm, No reserve price – guaranteed sale to the highest bidder! The original price was over 100,000 EUR! The device is ready for loading & packed for transport! Loading can be handled by the seller. TECHNICAL DETAILS Maximum inspection width: 150 mm Maximum inspection height: 310 mm CONVEYOR SYSTEM Conveyor type: Turn table Speed: 12 – 45 m/min MACHINE DETAILS X-ray Generator Voltage: 30 – 75 kV Current: 1 – 8 mA Power: max. 300 W Dimensions (L x W x H): 1,685 x 1,550 x 2,260 mm Protection class: IP65 / IP66 Electrical data Pjdpoy Ath Hsfx Ag Djgk Power supply: 200 – 240 V Frequency: 50 / 60 Hz EQUIPMENT Rotary table conveyor Hermetic air cooling X-ray inspection system
