Planing and Moulding Machine Guilliet KXK

Condition: ready for operation (used), Year of construction: 2008, operating hours: 10,294 h, functionality: fully functional, machine/vehicle number: P087WH855, travel distance X-axis: 700 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 300 mm, table load: 300 kg, spindle speed (max.): 10,000 rpm, TECHNICAL DETAILS Travel range, X-axis: 700 mm Travel range, Y-axis: 400 mm Travel range, Z-axis: 330 mm Rapid traverse speed: 54 m/min Pjdpjzul Tcjfx Adxjgr Spindle speed: 100–10,000 RPM Distance spindle–baseplate: 250–580 mm Main spindle power: 5.5 kW Table area: 650 × 400 mm Table load: 300 kg Tool positions: 21 MACHINE DETAILS Dimensions & Weight Dimensions: 1,565 × 2,027 × 2,336 mm Machine weight: approx. 2,200 kg Control system operating hours: 24,164 h Operating hours: 10,295 h EQUIPMENT Central oil interval lubrication 100 mm column extension Interior lighting 16 additional I/O Rapid traverse with bell-shaped acceleration and deceleration Manual handwheel feed Directory display from memory card 1,000 storable programs Multilingual display Thermal compensation of XYZ axes Parameter back-up function Retraction cycle for tapping without a collet MANUAL GUIDE Background editing Extended part program editing Coordinate system selection G92 Workpiece coordinate system G52–G59 48 additional workpiece coordinate systems G54.1 Return to reference point G28 Quick Editor Setup file Production counter Tool correction memory C for D/H code and wear Thread cutting without a collet M29 Subprogram call M98/M198/M99 Customer macro B G65, G66/G67 Drilling cycles G73, G74, G76, G81, G89/G80 Coordinate system rotation G68/G69 Circular interpolation with R programming AI Contour Control I G05.1 Helical interpolation Skip function G31 Multi-step skip G31 P1–P4 Check of travel limit before movement Check of stored travel limit 1 Check of stored travel limit 2 G22/G23 Customer PMC Real-time customer macro

Condition: ready for operation (used), Year of construction: 2017, functionality: fully functional, turning length: 50 mm, turning diameter: 40 mm, spindle speed (max.): 8,000 rpm, controller model: Fanuc 0i-TD, TECHNICAL DETAILS Turning diameter: 40 mm Turning length: 50 mm Travel range X-axis: 180 mm Travel range Z-axis: 200 mm Psdszul Srspfx Adxsgr Rapid traverse rate X/Z-axis: 15 m/min Spindle speed: 8,000 rpm MACHINE DETAILS Control system: Fanuc 0i-TD Dimensions & Weight Footprint: approx. 1,500 × 700 × 1,600 mm Machine weight: approx. 1,500 kg

Condition: ready for operation (used), Year of construction: 2017, functionality: fully functional, turning length: 50 mm, turning diameter: 45 mm, travel distance X-axis: 180 mm, travel distance Y-axis: 200 mm, controller model: Mitsubishi FCA70LPC-V, TECHNICAL DETAILS Turning diameter: 45 mm Turning length: 50 mm Travel range X-axis: 180 mm Travel range Z-axis: 200 mm Rapid traverse X/Z-axis: 20 / 30 m/min Spindle speed: 8,000 rpm MACHINE DETAILS Pjdpfx Adszul R Uexogr Control system: Mitsubishi FCA70LPC-V Dimensions & Weight Machine weight: approx. 1,600 kg Footprint: approx. 1,700 × 700 × 1,700 mm

Condition: ready for operation (used), Year of construction: 2018, operating hours: 14,317 h, functionality: fully functional, travel distance X-axis: 520 mm, travel distance Y-axis: 360 mm, travel distance Z-axis: 350 mm, controller model: Fanuc i, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Travel range, X-axis: 520 mm Travel range, Y-axis: 360 mm Travel range, Z-axis: 350 mm Spindle speed: 12,000 rpm Distance spindle to base plate: min. 150 mm / max. 500 mm Table area: 650 × 375 mm Table load: 2 × 200 kg Tool weight: max. 2.8 kg Tool magazine: 14 positions MACHINE DETAILS Control system: Fanuc i Dimensions & Weight Dimensions (L x W x H): 3,230 × 1,620 × 2,507 mm Machine weight: approx. 5,200 kg Operating hours: 14,317 h EQUIPMENT Rigid tapping – thread drilling without compensation chuck Spindle overspeed and power display Pjdpfszul R Iex Adxsgr Telescopic guards on the X, Y, and Z axes Rapid traverse in the X, Y, and Z axes Door safety switch 3-color indicator light Work area lighting Coolant supply from a 200-liter tank via adjustable coolant nozzles at the spindle nose Internal cooling Machine cover, closed on top / Top cover Oil skimmer Pneumatic clamping system A, 1 pair per pallet Automatic work area door with safety strip Coolant system with delivery pressure: 4.5 bar

Condition: ready for operation (used), Year of construction: 2012, functionality: fully functional, turning length: 145 mm, turning diameter: 168 mm, travel distance X-axis: 130 mm, travel distance Y-axis: 110 mm, controller model: FANUC 31i-TA, TECHNICAL DETAILS Pgodpszul Ruofx Adxjr Turning diameter: 168 mm Turning length: 145 mm X-axis travel: 130 mm Z-axis travel: 110 mm Spindle speed: 45–6,000 rpm MACHINE DETAILS Control system: FANUC 31i-TA EQUIPMENT 2 × Portal clamping system 2 × Part chute for inspected parts 2 × 3-jaw chuck, SMW Autoblok, Type BHM 165, 152.4 mm (6 inches) SMW Autoblok hydraulic cylinder, Type SIN-S 100, left SMW Autoblok hydraulic cylinder, Type VNK 70/37, right Chip conveyor, discharging to the rear of the machine Air-controlled part clamping monitoring, right Part clamping monitoring, on both sides 4-position spindle orientation, on both sides Coolant injection in the chuck via Deublin rotary distributor, on both sides Automatic coolant pump with 200 l tank capacity 2 × 8-station turret Signal light with traffic light design Preparation for oil mist extraction Automatic machine shutdown Automatic central lubrication RS-232-C interface External transformer 10 × Boring bar holders 3 × Turning tool holders, right 3 × Turning tool holders, left Customer macro B Turning cycles

Condition: repair required (used), Year of construction: 2005, functionality: not functional, machine/vehicle number: 15125250184, travel distance X-axis: 2,500 mm, travel distance Y-axis: 920 mm, travel distance Z-axis: 820 mm, controller model: Heidenhain iTNC 530, spindle speed (max.): 18,000 rpm, Note: Error in the magnetic linear measuring system of the X-axis TECHNICAL DETAILS Number of axes: 3 Travel range of X-axis: 2,500 mm Travel range of Y-axis: 920 mm Travel range of Z-axis: 820 mm B-axis rotation: 105° Table length: 3,100 mm Table width: 900 mm Table length: 3,100 mm Table width: 900 mm Tool holder: SK40 Max. spindle speed: 18,000 rpm MACHINE DETAILS Control system: Heidenhain iTNC 530 Dimensions & Weight Dimensions (L x W x H): 7,500 x 4,500 x 300 mm Net weight: 22,000 kg Transport packages: 3 EQUIPMENT External cooling Podpfjzu Nyaox Adxegr Chip conveyor Tool magazine (30 pieces)

Condition: ready for operation (used), Year of construction: 2005, laser power: 2,000 W, ITEC Automation & Laser AG: Gantry Portal for Coil Line with Trumpf TCF 1 Laser + GSW AG Reel MHR 2.5 / 1250 + Straightening Machine VRMA 80 / 76 + Motoman ERCS-HP20-AE00 Robot The system will remain in operation until week 35. The system has been continuously maintained and partially overhauled in 2022. Sale is without extraction system and platform! TECHNICAL DETAILS Trumpf TCF 1 MHR 2.5 / 1250 Wavelength: 10.6 µm Max. Output Power: 2,000 W Continuously adjustable power range: 100–2,000 W Power stability relative to rated power: ±2% Beam diameter at the output window: 26 mm Divergence angle (half angle): 0 mrad Power distribution: TEM₀₀ Pulse frequency: 10 Hz–100 kHz Marking mode frequency: 10 Hz Marking mode power: 80 W Pulse width: 10 µs–CW Reel MHR 2.5 / 1250 Load capacity: max. 2,500 kg Coil outer diameter: max. 1,250 mm Strip width: max. 600 mm Spreading range: min. 380 (480) mm Spreading range: max. 430 (530) mm Mandrel height: 1,000 mm Drive and Speed Speed: approx. 17.5 rpm Electrical drive power auxiliary drive: 1.1 kW Electrical Connection Connection voltage: 3 × 400 V Frequency: 50 Hz Noise Emission Noise level: 70 dB(A) EQUIPMENT Fixed rear edge Neutral conductor (N) and protective conductor (PE) Straightening Machine VRMA 80 / 76 Passage width: max. 100–800 mm Strip thickness: min. 0.4 mm Strip thickness: max. 1.5 mm Strip thickness at full width: max. 1.0 mm Number of straightening rolls: 7 Number of tension rolls: 2 Roller diameter: 60 mm Straightening roll spacing: 130 mm Speed: approx. 15 m/min Passing height above the floor: approx. 1,000 mm Drive type: Servo motor Electrical drive power: 2.2 kW Drive speed: 3,000 rpm Connection voltage: 3 × 400 V Frequency: 50 Hz Conductors: N, PE Noise level: 70 dB(A) Robot Motoman ERCS-HP20-AE00 Number of axes: 6 Load capacity: 20 kg Positioning repeatability: ±0.06 mm Weight: approx. 280 kg S-axis (rotation): ±180° L-axis (lower arm): +155° / -110° U-axis (upper arm): +255° / -165° R-axis (wrist rotation): ±200° B-axis (wrist bending): ±140° T-axis (wrist rotation): ±360° Speed S-axis: max. 2.96 rad/s / 170 °/s Speed L-axis: max. 2.96 rad/s / 170 °/s Speed U-axis: max. 3.05 rad/s / 175 °/s Speed R-axis: max. 6.20 rad/s / 355 °/s Speed B-axis: max. 6.02 rad/s / 345 °/s Pedpfxezu Avzs Adxjgr Speed T-axis: max. 9.16 rad/s / 525 °/s The height and weight of the asset must be considered when selecting the transport vehicle. A forklift is available for loading. If collection is not carried out on time, a storage fee of €20.00 per lot and day started will be charged. The fee must be paid before collection. The sale is made without any guarantee or warranty. The information on the technical data comes from the original offer. No guarantee is given for printing and measurement errors. If in doubt, please compare the information with the provided photos or inspect the goods on site before the end of the auction.

Condition: not inspected (used), machine/vehicle number: AAC3021001514, No minimum price – guaranteed sale to the highest bidder! For sale is a digital color laser printing machine from Konica Minolta, model AccurioPress C3070. TECHNICAL DETAILS Manufacturer/Model: Konica Minolta AccurioPress C3070 Equipment Class: Digital Color Printing System / Production Printing System Serial Number: AAC3021001514 Printing Technology: Color Laser Maximum Format: DIN A3 Page Counter: 1,184,396 pages Network: Yes WLAN: Yes Duplex Printing: No MACHINE DETAILS The machine is offered expressly in an untested condition. A function test is not currently possible due to the missing hard drives or SSDs. This also applies to the printer controller. Therefore, the technical functionality of the main unit and the accessory components could not be confirmed. Hard Drives / SSDs: Missing Function Test: Not possible Technical Condition of Main Unit: Untested Technical Condition of Accessories: Untested Cosmetic Condition of Main Unit: Moderate signs of wear in the upper and front area Paper tray drawer: Opening or handle torn off Cosmetic Condition of PF-602: Moderate signs of wear in the upper and front area EQUIPMENT Konica Minolta AccurioPress C3070 Printer Controller Serial Number: A00043842 Finisher FS-532 Serial Number: 75710 Paper Feeder PF-602 Serial Number: 75711 Booklet/Finishing Unit SD-506 Serial Number: 75712 RU-518 Serial Number: 75713 Please note the following: The height and weight of the asset must be considered when selecting the transport vehicle. A forklift is available for loading. If the item is not collected on time, a storage fee of €20.00 per lot and commenced day will be charged. The fee must be paid before collection. Pedpfx Adjzu Arisxegr The sale is made excluding any guarantee or warranty. The information on the technical data comes from the original offer. No guarantee is given for typing or measurement errors. If in doubt, please compare the information with the provided photos or inspect the goods on site before the end of the auction.

Condition: not inspected (used), machine/vehicle number: 698501644, No minimum price – guaranteed sale to the highest bidder! For sale is a Canon varioPrint 115 printing system with extensive accessories. The system uses monochrome laser printing technology and supports the DIN A3 format. Psdpfx Adjzu Aliexegr TECHNICAL DETAILS Manufacturer/Model: Canon varioPrint 115 Equipment Class: Production printing system / printing line Serial Number: 698501644 Printing Technology: Monochrome laser printing Maximum Format: DIN A3 Page Counter: 3,889,839 pages Network: Yes WLAN: Yes Duplex Function: No MACHINE DETAILS The main unit is offered without a hard drive or SSD. The existing data storage medium has been destroyed and recycled. According to the technical report, the printer cartridge is almost empty. The technical condition of the main unit should be checked before commissioning. Hard Drive / SSD: Not available Existing Storage Medium: Destroyed and recycled Printer Cartridge: Almost empty Technical Condition of Main Unit: To be checked before commissioning Accessory Components: Not technically tested / untested EQUIPMENT Canon Paper Folding Unit-J1 (F281270) Serial Number: 75718 Oce 01051 Serial Number: 75721 Canon Staple Finisher-W1 (F710700) Serial Number: 75722 Please note the following: The height and weight of the asset must be taken into account when selecting the transport vehicle. A forklift is available for loading. If the item is not collected on time, a storage fee of €20.00 per lot and commenced day will be charged. The fee must be paid before collection. The sale is made excluding any warranty or guarantee. The information on the technical data comes from the original offer. No liability is accepted for typing or measurement errors. If in doubt, please compare the information with the photos provided or inspect the goods on site before the end of the auction.

Condition: ready for operation (used), Year of construction: 2018, operating hours: 13,072 h, functionality: fully functional, working width: 2,500 mm, No minimum price – guaranteed sale to the highest bidder! The machine is in very good overall condition, both visually and technically. No visible damage, corrosion, or significant wear and tear can be detected. Maintenance was carried out internally using SAP PM (electrical maintenance every 6 months, mechanical maintenance every 3 months). TECHNICAL DETAILS Material: Continuous corrugated cardboard Working width max.: 2,500 mm Minimum length: 200 mm Cardboard thickness: 2.57 mm Tool width: approx. 45 mm Longitudinal cutting accuracy: 0.2 mm Length tolerance: 1.5 mm/m Packaging size: 600 × 600 × 300 mm Performance: approx. 55 s/packaging unit Software and control (with 21" multi-touch panel and integrated control cabinet) PC: Beckhoff C6930 (Intel Core i5, 16 GB RAM, SSD) with Windows 10 IoT Enterprise Software: Beckhoff TwinCAT 3 Packaging design database: approx. 250 designs Production list control Dynamic tool management Multi-level waste optimization Bidirectional processing Remaining length monitoring Production data recording in CSV format Podpfszu Akrox Adxegr Plain text error messages MACHINE DETAILS Operating hours: 13,072 h (in single-shift operation) Machine construction: Welded construction Multi-function tools for longitudinal processing: 6 Transverse processing tools: 1 Rubberized rollers: 2 Overpressure: segment-controlled Weight (according to nameplate): approx. 2,110 kg EQUIPMENT Automatic cardboard changer Automatic selection of the optimal cardboard web width Two stations for cardboard webs Box designer programming software for customer-side workstations Creasing, scoring, perforating, and cutting according to the single-point principle Material-friendly creasing technology to prevent the cardboard from flaking Perforation using an oscillating knife with adjustable perforation level Cutting using a toothed knife on a rubberized roller Clean, fiber-free cut edges Servo-motor adjustable tools Packaging designs Bottom/lid construction Bottom with corner locks for upright fixing of rims Lid according to FEFCO 0331 Suitable for the production of precisely fitting individual packaging for aluminum and forged wheels
