Machine vice 200mm jaw width

Condition: ready for operation (used), Year of construction: 2001, functionality: fully functional, turning length: 555 mm, travel distance X-axis: 195 mm, travel distance Y-axis: 82 mm, travel distance Z-axis: 600 mm, workpiece diameter (max.): 250 mm, TECHNICAL DETAILS Counter-spindle speed: 59–4,500 rpm Bar capacity main spindle: 65 mm Bar capacity counter-spindle: 51 mm Travel X1/X2 axis: 195 mm Travel Y axis: ± 41 mm Travel Z axis: 600 mm Max. workpiece diameter: 250 mm Max. turning length: 555 mm Number of tool stations upper turret: 12 Number of tool stations lower turret: 12 All tools driven Main spindle nose: A 2-6 Counter-spindle nose: A 2-5 Feed power X1/X2/Y axis: 1 kW Feed power Z1/Z2 axis: 2.1 kW Maximum loading length: 6,200 mm MACHINE DETAILS Control model: Fanuc 18 IT Main spindle power: 18.5 kW / 15 kW Counter-spindle power: 11 kW / 7.5 kW Bar feeder Max. bar length: 6 m 8 channels with diameters: 22 mm, 27 mm, 32 mm, 37 mm, 42 mm, 47 mm, 57 mm, 67 mm 8 pushers with pusher cone Ffedpfx Aajynhihemjw Intermediate sizes can also be loaded Unload magazine Max. bar length: 2 m EQUIPMENT Coolant tank Chip conveyor from 10/2021 Last overhaul of bar feeder 09/2020 (channel replacement, replacement of various bearings, replacement of push rods and spindle liners, including maintenance)

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, turning length: 1,240 mm, turning diameter: 380 mm, spindle speed (max.): 3,200 rpm, quill diameter: 100 mm, controller model: Fanuc 18i-TB, TECHNICAL DETAILS Maximum turning diameter: 380 mm Maximum turning length: 1,240 mm Swing diameter over bed: 600 mm Rapid traverse X/Z-axis: 20 m/min Main spindle Maximum torque: 1,030 Nm Maximum speed: 3,200 rpm Maximum chuck diameter: 254 mm Maximum bar capacity: 76 mm Turret Ffodeyngziopfx Aamsw Number of turret stations: 12 positions (6 driven) Driven tool speed: 3,000 rpm Tool system (type): BMT C-axis: 0.001° Tailstock Quill diameter: 100 mm Quill stroke: 120 mm Taper: 5 MT Bar loader Type: Samsys Multisam 2000 Maximum bar length: 1,550 mm MACHINE DETAILS Operating hours: 46,103 h Control model: Fanuc 18i-TB Main spindle power: 22 kW Turret drive power: 3.7 kW EQUIPMENT Chip conveyor 3 spindle reduction tubes Box guideways 3-jaw power chuck 250 mm (Type: Seoam ACE CAH-10) Full-featured C-axis Touchsetter Manuals

Condition: ready for operation (used), operating hours: 7,738 h, functionality: fully functional, turning length: 225 mm, turning diameter: 260 mm, spindle speed (max.): 6,000 rpm, travel distance X-axis: 170 mm, travel distance Z-axis: 335 mm, TECHNICAL DETAILS Max. turning diameter: 260 mm Max. turning length: 225 mm Chuck size: 6" Swing diameter over bed: 550 mm Travel X-axis: 170 mm Travel Z-axis: 335 mm Rapid traverse X/Z-axis: 36 m/min Main Spindle Spindle nose (ASA): A2-5 Max. spindle speed: 6,000 rpm Spindle bore diameter: 56 mm Max. bar capacity: 45 mm Turret Number of turret stations: 12 positions Turret indexing time: 0.15 s Tailstock Quill diameter: 60 mm Quill stroke: 80 mm Taper/Quill mount: MT 4 Fodpfx Ajyngptsamjfw Live Tooling Spindle Max. spindle speed: 5,000 rpm Bar Feeder Model: Fedek Machine Co. DH-65 Bar length min./max.: 280/1,200 mm Bar diameter: 5-65 mm MACHINE DETAILS CNC control model: Fanuc 0i-TD Control on-time: 30,811 h Cutting time: 7,738 h Spindle motor power: 15/7.5 kW Feed motor power X/Z-axis: 3.0/1.8 kW Live tooling spindle motor power: 3.7/2.2 kW Dimensions Dimensions (L x W x H): approx. 1,620 × 1,200 x 1,400 mm EQUIPMENT Side-mounted chip conveyor and chip cart Short bar loader magazine Interface for bar feeder Workpiece catcher (parts catcher) Chuck open/close confirmation switch C-axis indexing Driven tools Trailing (drag-along) tailstock Linear guides Manuals

Condition: ready for operation (used), functionality: fully functional, machine/vehicle number: 516231X00505, Year of construction: 2020, operating hours: 14,926 h, load capacity: 2,000 kg, lifting height: 5,600 mm, free lift: 1,900 mm, mast type: triplex, construction height: 2,250 mm, TECHNICAL DETAILS Fedpfx Aeynaddeamsfw Load capacity: 2,000 kg Lift height: 5,600 mm Free lift: 1,900 mm MACHINE DETAILS Mast type: Triplex with full free lift Overall height: 2,250 mm Battery: 48 V 750 Ah (very good performance measured at 51.3 V) Operating hours: 14,926 h EQUIPMENT 3rd + 4th valve Fork positioner with side shift All dimensions are approximate. No liability is accepted for typographical or measurement errors. COLLECTION CONDITIONS Side loading up to 5 t possible with a large forklift truck on site at your own risk. Collection ONLY with email payment confirmation! Collection WITHOUT prior appointment: Monday to Friday, 7:00 a.m. - 4:30 p.m. A mast that is too high for transport can be disassembled upon request. If collection is not made within the agreed period, a storage fee of €20 per machine per day will be charged (the balance must be paid before collection).

Condition: ready for operation (used), functionality: fully functional, machine/vehicle number: 516231X00501, Year of construction: 2020, operating hours: 13,640 h, load capacity: 2,000 kg, lifting height: 5,600 mm, free lift: 1,900 mm, mast type: triplex, fork length: 1,400 mm, TECHNICAL DETAILS Load capacity: 2,000 kg Lifting height: 5,600 mm Overall height: 2,250 mm Free lift: 1,900 mm Fork length: 1,400 mm MACHINE DETAILS Mast type: Triplex with full free lift Battery: 48 V 750 Ah, excellent performance measured at 51.2 V Operating hours: 13,640 h EQUIPMENT 3rd + 4th hydraulic valve Kaup 2,500 kg fork positioner with side shifter Comfort seat with lumbar support and seat heating Full cab with heater and windshield wiper Front LED work light Rear LED work light Fedsym U Saspfx Aamefw Road-legal StVZO lighting with indicators Rear safety light Front safety light White, non-marking tires (new available upon request) Facelift model with tilt angle display Service valid until: 02/2027 UVV inspection valid until: 02/2027 Battery inspection valid until: 07/2026 All dimensions are approximate. No liability is assumed for typographical or measurement errors. COLLECTION TERMS Loading from the side up to 5 t possible with large forklift on site at your own risk. Collection ONLY with payment confirmation by e-mail! Collection WITHOUT appointment Monday to Friday 7:00 am - 4:30 pm. If the mast is too high for transport, it can be dismantled upon request. A storage fee of €20 per machine per day applies for late collection (payment due before pick-up).

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, travel distance X-axis: 750 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 600 mm, controller model: Heidenhain iTC530, rotational speed (max.): 12,000 rpm, TECHNICAL DETAILS Travel X-axis: 2 x 750 mm Travel Y-axis: 500 mm Travel Z-axis: 600 mm Rapid traverse X / Y direction: 25 m/min Rapid traverse Z direction: 20 m/min Feed force: 9 kN Spindle speed range: 30-12,000 rpm Tool changer: 22-position Tool holder: SK40 Maximum tool length: 400 mm Maximum tool diameter: 85 mm (135 mm with adjacent stations empty) Tool change time: 4.0 s Clamping area: 2 x 1,350 mm x 500 mm Maximum table load per table: 550 kg Fjdpfeymz D Njx Aamsfw MACHINE DETAILS Control model: Heidenhain iTC530 Drive power: 30/20 kW Total power requirement: 55 kVA Dimensions & Weight Dimensions (L x W x H): 6.0 x 3.5 x 3.5 m Machine weight: 10,000 kg EQUIPMENT Internal cooling Coolant system with paper band filter Documentation

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, travel distance X-axis: 560 mm, travel distance Y-axis: 410 mm, travel distance Z-axis: 510 mm, controller model: Mazatrol 640 Nexus, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Travel X-axis: 560 mm Travel Y-axis: 410 mm Travel Z-axis: 510 mm Table dimensions: 900 mm x 410 mm Fjdpfx Aasymzmkomjfw Spindle speed: 12,000 rpm Tool holder: SK40 Number of stations in tool changer: 30 Internal coolant supply: 15 bar MACHINE DETAILS Control: Mazatrol 640 Nexus Machine weight: 5,010 kg EQUIPMENT Chip conveyor

Condition: ready for operation (used), Year of construction: 2018, functionality: fully functional, resolution (max.): 2,400 dpi, paper weight (min.): 60 g/m², paper weight (max.): 350 g/m², paper width (max.): 330 mm, paper height (max.): 487 mm, No reserve price – guaranteed sale to the highest bidder! Original purchase price of the printer was €486,000 (net)! TECHNICAL DETAILS Print resolution: 2,400 × 2,400 dpi Print speed: 100 images per minute Recommended monthly print volume: 100,000 – 450,000 pages Maximum monthly duty cycle: 1,500,000 pages Supported paper sizes (min.): 182 × 182 mm Supported paper sizes (max.): 330.2 × 487.7 mm Paper weight range: 60 g/m² up to 350 g/m² Ffodpfxoymwzde Aamsw Paper weight range (validated): up to 400 g/m² Duplex printing media weight: 350 g/m² MACHINE DETAILS Standard paper feed capacity: 1,000 sheets Total capacity expandable up to: 10,000 sheets Main unit dimensions C10000 (H x W x D): 145.5 cm x 258.6 cm x 115.3 cm FEATURES Offset-like quality Supports specialty and textured media In-line sensors for color management Automatic calibration

Condition: ready for operation (used), Year of construction: 2004, operating hours: 17,500 h, functionality: fully functional, travel distance X-axis: 830 mm, travel distance Y-axis: 630 mm, travel distance Z-axis: 630 mm, controller model: Heidenhain 530 (MC422), rotational speed (max.): 12,000 rpm, The machine is in very good condition, runs quietly, and operates with precision. TECHNICAL DETAILS Travel X-axis: 830 mm Travel Y-axis: 630 mm Fodpfx Aoymn Sasamefw Travel Z-axis: 630 mm Feed rates: 15,000 mm/min Rapid traverse: 30,000 m/min Motor spindle: 12,000 rpm Number of tool stations: 32 MACHINE DETAILS Control: Heidenhain 530 (MC422) Tool holder: SK 40 Weight: approx. 9,000 kg Spindle hours: approx. 17,500 EQUIPMENT Internal coolant supply (IKZ) Chip conveyor Electronic handwheel Blum laser Flushing unit Filtration system Note: The probing system is not included in the scope of delivery.

Condition: ready for operation (used), Year of construction: 2003, operating hours: 11,600 h, functionality: fully functional, spindle bore: 107 mm, spindle speed (max.): 4,000 rpm, overall weight: 10,000 kg, controller model: Siemens 810D, Equipment: chip conveyor, TECHNICAL DETAILS Ffsdpeymn Ibefx Aamew Maximum swing diameter: 680 mm Swing diameter over X-guide: 565 mm Longitudinal travel: 1,300 mm Cross travel: 315 mm Spindle head: h5 Spindle diameter at front bearing: 150 mm Spindle bore: 107 mm Maximum torque: 600 Nm Spindle speed: 4,000 rpm Chuck diameter: 315 mm Rapid traverse X-axis: 60 m/min Rapid traverse Z-axis: 45 m/min Tool turret for: 12 tools Driven tools: 12 Tool holder: VDI 40 Quill stroke: 120 mm Quill taper: MK 5 MACHINE DETAILS Control system: Siemens 810D Dimensions & Weight Machine dimensions with chip conveyor (L x W x H): 5,700 x 2,600 x 2,210 mm Machine weight: approx. 10,000 kg Operating Hours Power-on hours: 47,781 h Spindle hours: 11,600 h EQUIPMENT Hydraulic steady rest, clamping range 30-245 mm Chip conveyor KNCS-N 315-91 power chuck
