Bes Maschinenbau S-32-3

S-32-3 Vorführmaschine

Condition: used, Year of construction: 1980, grinding length 500 mm grinding width 200 mm workpiece height 290 mm Machine from the German Federal Institute of Physics and Metrology - geometrically revised - electrics tested, fully functional, relevant parts replaced - all wear parts replaced - colour light grey, colour condition good Equipment: - electro magnet 500x200mm - grinding spindle overhauled 2-axis display for Y and Z axes Automatic delivery for Y and Z axes Y-axis with zero shutdown Manual hand dresser Stepless speed for grinding wheel V-constant via disc wear Paper band filter system, used Max. height with 250 disc diameter 290mm max. grinding area 600x250mm max. load incl. magnet 100kg Hsdpfswb Hygex Adzsr Warranty: 1 year on geometry and electronics, Germany-wide Delivery: ex works Shipping time: immediately Payment: before pickup Acceptance at our premises Shipping according to your specifications

Condition: excellent (used), Year of construction: 1996, grinding length 600 mm grinding width 350 mm total power requirement 7,5 kW Q U O T A T I O N We are pleased to offer you ex our stock, subject to prior sale, and error in technical data : GEIBEL & HOTZ CNC horizontal surface & profile grinding machine model FS 635 - Z CNC year 1996 Grinding length max. (table movement 660 mm) 600 mm Grinding width max. (cross movement 360 mm) 350 mm Mounting height under new grinding wheel 375 mm Distance table – center of spindle min / max 140 – 525 mm Standard size of magnetic plate 600 x 350 mm Table size 820 x 350 mm Max. table load 400 kg Table speed 5 – 35.000 mm/min Cross movement, intermittently 3 – 40 mm Cross-/Vertical quick feed 5 m/min Grinding wheel measurements 300 x 50 x 76,2 mm Grinding spindle speeds, variable 1.000 – 3.000 rpm Grinding spindle-drive approx. 7,5 kW Total electrical load approx. 15 kW - 400 V - 50 Hz Weight approx. 2.600 kg Hsdox Haryjpfx Adzer Accessories / Special Features: • SIEMENS CNC control model 840 D with comprehensivel GEIBEL&HOTZ grinding software. User friendly interface, supported by dialog and graphics, simple programming also of complex grinding wheel profiling and easy linking of grinding cycles. • All standard grinding-programms and cycles as surface and multiple surfaces grinding with roughing-finishing-sparkout- return, plunge in grinding, automatic dressing cycle with compensation, etc. • electronic handwheel for 3 axis; cross feed (Z) and infeed (Y) effected by ball screw drive. • Table movement is actuated by belt drive (Z), which allows both very high and very low table speeds and is also ideal for profile grinding. • Hydraulically upwarding diamond dressing device mounted on the left side of the table (also for profile dressing); additional fixed dresser with automatic dressing cycle, including compensation. • Mounted sinus tilting magnetic plate 600 x 200 mm, fine pole division. • Separate paper band coolant filtration unit, separate switch cabinet, lamp for working area, various accessories, manuals, etc. Condition : very good, universal machine for all sorts of grinding tasks ! Please click here to view a video of the machine running : ! Delivery : immediately available, FCA Metzingen Payment : 100 % Net, after conclusion of contract, before loading We always have a large selection of surface grinders – CNC or conventional - available. Please let us know your requirements.

Condition: used, Year of construction: 1995, Surface grinding machine Manufacturer: Jung Type: JA 500 CNC-C Year of manufacture: 1995 Overhauled in: 2003 Grinding length: 500 mm Grinding width: 200 mm Maximum workpiece height: 250 mm Hsdpfx Aewp E Rgedzjr Table dimensions X/Y: 600 mm / 200 mm Grinding wheel diameter: 225 mm Grinding wheel width: 25 mm Grinding wheel bore: 51 mm Speed: 4,200 rpm Machine weight: approx. 2,500 kg 22726ä

Condition: good (used), Year of construction: 2012, Hasegawa PM150 Machining Center Manufacturer: Hasegawa Model: PM 150 Year of manufacture: 2012 Number of axes: 4 Travel X axis: 150 mm Travel Y axis: 225 mm Travel Z axis: 200 mm Swivel axis: YES Rapid traverse X, Y, Z: 30 m/min Table load capacity: 80 kg Table working surface: 300 × 260 mm T-slot table: 12H7 × 5 Spindle taper: HSK E32 Spindle speed: 100 to 30000 rpm Tool magazine: 10 tools Max. tool size: Ø50 mm Memory capacity: 5120 m 2048 kB Minimum input increment: 0.1 µm Interface: RS232C Number of programs: 63 Hodpox Hqv Nsfx Adzjr No guarantee is given for the accuracy, completeness, or timeliness of the information provided.

Condition: as good as new (ex-display), Year of construction: 2024, functionality: fully functional, travel distance X-axis: 450 mm, travel distance Y-axis: 270 mm, travel distance Z-axis: 310 mm, General: Spindle speed: 15,000 rpm Power: 7.3 kW Tool interface: HSK-A 40 Tool changer: 40 stations Control system: Siemens 840 DsL Working area Travel in X: 450 mm Travel in Y: 270 mm Travel in Z: 310 mm Rapid traverse (X/Y/Z): 75 m/min A-axis Swivel angle: +/- 120° System accuracy: +/- 5" Drive: Torque motor Spindle speed: 100 rpm C-axis Diameter of rotary table: 198 mm System accuracy: +/- 5" Drive: Torque motor Spindle speed: 200 rpm Equipment Hsdpfxozf Adme Adzer Rotary union: 6-pole, integrated in A and C axes Chip conveyor: Drag chain, discharge height 490 mm, rear
