Orbital stretch winder

SPINNER 1800s + BN

Fully automatic orbital stretchfilmwraping machine with air bubble film unit

SPINNER 1800s + BN

Application:
Packaging, grouping and protection of long or bulky products like furniture, doors, timber boards, etc.

operator side:
- in throughput direction right

General machine features:
- Main motor power: 3kW
- Max. ring rotation speed: 50 rpm
- Min. ring rotation speed: 10 rpm
- Electronic control components: Siemens , Schneider, LS
- Total weight: 2600 kg

Standard Equipments;
- Driven conveyors belt (infeed and outfeed) for automatic product feeding
- Adjustable ring rotation speed
- Adjustable stretchfilm tension with mechanical brake device
- Automatic stretchfilm clamp and cutter system
- Pneumatic front and back top presses to hold the product while wrapping
- Photocell to start automatically the wrapping cycle
- Touch screen to adjust machine parameters to the product needs
- Operator safety systems

Optional Equipments;
- Different sized conveyors
- Infeed and outfeed rollers
- Air bubble film unit. (INCLUDED FOR THIS OFFER)

Technical features:
Product to Wrap Sizes
- Max. length: Unlimited
- Min. length (Wx Hx L): 600x 450x 1200 mm
Dedpofzrmfofx Af Hola

Conveyor belt’s features:
- Useful length: 2680mm
- Total length: 210mm
- Working height: 950mm
- Electric motor power: 0,55 kW
- Max. speed: 12m/min.
- Max. load capacity: 100 kg/m

Stretchfilm features:
- Max. width: 250mm
- Max. diameter: 230mm
- Reel core diameter: 76mm
- Recommended thickness: 23, 30, 35 micron

Air bubble film unit:
- Max. film width: 2000 mm
- Max. film reel diameter: 650mm
- Reel core diameter: 20~76mm
- Suitable film materials: PW film, PE air bubble film, PVC film, PE foam film
- Cutting & welding system operating temperature: 50°C~150°C
