Machining Center - Horizontal
MAKINO A 61

Name: MAKINO A 61
Brand: MAKINO
Availability: InStock

Year of construction

2005

Condition

Used

Location

Germany

Machining Center - Horizontal MAKINO A 61

Show map

Machine data

Machine type:: Machining Center - Horizontal

Manufacturer:: MAKINO

Model:: A 61

Year of construction:: 2005

Condition:: used

Price & Location

Location:: , Germany

Call

Details about the offer

Listing ID:: A191-74486

Reference number:: 1070-300297

Update:: 19.05.2025

Description

Technical details:
Godpewlgc Aefx Aa Ijil

x-travel: 730 mm
y-travel: 650 mm
z-travel: 730 mm
control: Professional 3 (Fanuc 18i)
turning speeds: 12000 1/min
spindle drive: 22 kW
Torque: 166 Nm
Number of tool station: 132 HSK-A 63
max. tool length: 360 mm
max. tool diameter: 70 mm
max. tool-dia with free toolbox: 140 mm
max. tool weight: 12 kg
tool changing time: 0,9 / 2,5 sec
numbers of pallets: 2
Pallet dimension: 500x500 mm
working diameter: 800 mm
table load: 0,7 t
distance spindle center to table: 80 - 730 mm
Distance spindle nose - pallet centre: 70 - 800 mm
rapid travel x/y/z: 50 m/min
Feed x/y/z: 50 m/min
total power requirement: 65 kVA
Dimensions (L/W/H): 7 x 2,5 x 3,4 mm
weight of the machine ca.: 9,5 t
Custom Macro, Number of Variables: 600
program memory: 500 kB = 1280 m

Accerories

Chip conveyor
Signal lamp 3 colors
Coolant through spindle 30 bar 30 l/min
Rotoclear window
Tool breakage control in magazine
High speed countour control
No. of tool offset pairs 99

This very solid Makino A 61 has a full B-axis, coolant through spindle 30 bar.

*

Seller

Registered since: 2005

17 listings online

Call

Send inquiry

Telephone & Fax

+49 7231 ... show

Fax:
