CNC turn-mill center

MAS Multicut 500iT

Condition: good (used), Year of construction: 2018, functionality: fully functional, MITUTOYO Contracer CV-2100M4 contour measuring device Horizontal measuring range X = 100mm Vertical measuring range Z = 50mm Column travel range Z2 = 350mm Inclination +/- 45° Dimensions (W, D, H) 745mm x 450mm x 885mm Total weight approx. 150kg Incl. PC system, Incl. cross table 218-001 Incl. rotating vice 2028-003 Crodpfovun Tpjx Af Hek

Condition: used, Year of construction: 2015, TAKISAWA TS4000YS year 2015 CNC control FANUC 32i-MODEL B Max. turning diameter 315 [mm] Max. swing over bed 600 [mm] Crodpfx Ajwq Sf Tef Hek Max. Turning length 735 [mm] Stroke X axis 267 [mm] Stroke Z axis 840 [mm] Stroke Y axis -50 [mm] / +70 [mm] Stroke A axis 780 [mm] Rapid traverse rate X axis 30000 [mm/min] Rapid traverse rate Z axis 30000 [mm/min] Rapid traverse rate Y axis 10000 [mm/min] Rapid traverse rate A axis 30000 [mm/min] Spindle nose A2-8" Max. bar diameter 82 [mm] Spindle throughbore 94 [mm] Max. spindle speed 4200 [rpm] Spindle power 22 [kW] Counter spindle nose F140 Counter spindle throughbore 53 [mm] Max. counter spindle speed 6000 [rpm] Counter spindle power 11 [kW] Max. tool holder cross-section 25 [mm] Number of tool stations 15 Number of tool stations driven 15 Max. speed driven tools 6000 [rpm] Lubrication tank capacity 370 [l] Total power required 37 [kVA] Supply voltage 400 [V] Chip conveyor with machine 5 live tool holders Weight 6700 [Kg]

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, turning diameter: 500 mm, DMG CTX Beta 1250 TC 2009 Credpfxev N Hc Ss Af Hek

Condition: ready for operation (used), Year of construction: 2020, operating hours: 6,056 h, Control Unit Brand SIEMENS Model 840D General Data Measurements width 3150 Measurements depth 5564 mm Measurements height 2135 mm Machine weight 10000 kg Main Drive Spindle speed range 3600 Movement X-Axis Rapid Traverse 30 m/min Y-Axis Rapid Traverse 22.5 m/min Z-Axis Rapid Traverse 33 m/min Workpiece Workpiece drm over bed 800 mm Workpiece drm 600 mm Cedpfx Afswnkdco Hsrk Tools Slots in storage 12 This 3-axis horizontal turning machine manufactured in 2020 features a Siemens 840D control and a spindle speed up to 3,600 rpm. It offers a max turning diameter of 600 mm and a length of 2000 mm. Equipped with a chip conveyor, Siemens CELOS control system, and a fume extraction system, it's ideal for complex machining tasks. Consider the opportunity to buy this DMG MORI CTX 2000 horizontal turning machine. Contact us for more information about this machine. Application Types Turning

Condition: reconditioned (used), Year of construction: 2008, functionality: fully functional, turning length: 1,250 mm, turning diameter over cross slide: 500 mm, turning diameter: 390 mm, spindle speed (max.): 5,000 rpm, spindle bore: 65 mm, travel distance X-axis: 450 mm, travel distance Y-axis: 200 mm, travel distance Z-axis: 1,300 mm, bar passage: 65 mm, total height: 2,700 mm, total length: 7,000 mm, total width: 3,000 mm, overall weight: 12,000 kg, Equipment: documentation/manual, Manufacturer: DMGMORI Type: CTXbeta1250TC Year of manufacture: 2008 (retrofit in 2022) Control: Siemens 840D Solutionline Number of axes: 5 axes Equipment: - automatic tool changer - swivel head as B-axis - belt filter system with internal cooling and chip conveyor - differential pressure clamping main/counter spindle - workpiece collection device - preparation for bar loader (optionally available) Technical data: Max. turning diameter 500 mm X-axis 450 mm Y-axis 100 mm Z-axis 1300 mm B axis 220 ° Spindle bore 65 mm Speed 5000 rpm Spindle power 34 kW Counter spindle speed 6000 rpm Counter spindle passage 52 mm Counter spindle power 20 kW Tool changer 24 B-axis mount HSK 63 Credeubyv Ropfx Af Hsk B-axis spindle speed 12000 rpm B-axis power 22 kW Installation dimensions approx. L 7000 / W 2300 / H 2300 mm Weight approx. 8,000 kg Chip conveyor: Yes Coolant device: Yes Internal coolant supply: Yes Options: · Full cabin · NC swivel head as B-axis · Coolant device and chip conveyor · Documentation · Geometrically within the new machine tolerances Condition: - Machine fully functional - Geometry within the manufacturer's tolerance for new machines - All wear parts replaced Retrofit 2022: - Linear guides Z1 and Z2/3 replaced - Linear guide Y-axis replaced - Main and counter spindle overhauled - Milling spindle overhauled - B-axis (bearings and clamping) renewed - sliding plates overhauled - hoses and cables overhauled, drag chains revised - cabin doors repainted, viewing windows renewed - maintenance carried out according to manufacturer's specifications

Condition: excellent (used), Year of construction: 2002, functionality: fully functional, Turning length: 3,000 mm Swing diameter over cross slide: 520 mm X-axis travel: 600 mm Y-axis travel: 150 mm Z-axis travel: 3,150 mm Swing diameter: 520 mm Turning length: 3,000 mm Control: SIN 840 D Siemens Z-axis: 3,150 mm Z-axis feed rate: 1 – 40,000 mm/min Rapid traverse Z-axis: 40.00 m/min X-axis: 600 mm X-axis feed rate: 1 – 30,000 mm/min Rapid traverse X-axis: 30.00 m/min Main spindle S1 Spindle speed range: 1 – 3,300 rpm Drive power at 100% load: 29.00 kW Spindle nose DIN 55026 – size A11 Spindle diameter at front bearing: 160 mm Spindle bore: 115 mm C-axis: 360 x 0.001° Milling spindle S2 Tool holder: Capto C6 Infinitely variable speed range: 1 – 6,000 rpm Y-axis: -100 / +150 mm B-axis: -110 / +110° Crodpfxsxpfd Dj Af Hsk Tool magazine with 100 stations Total power requirement: 145 kW Machine weight approx.: 24 t

Condition: excellent (used), Year of construction: 2015, Technical Data: Capacity Max. Swing Diameter: Ø 600 mm Max. Turning Diameter and Length: Ø 370 x 750 mm Spindle Bore: Ø 82 mm Spindle Center Height from Floor: 1,140 mm Spindle Bearing/Bore Diameter: Ø 140 / Ø 90 mm Spindle Nose: A2-8 Spindle Speed: 4,200 rpm C-Axis Resolution: 0.001° Sub-Spindle Center Height from Floor: 1,140 mm Spindle Bearing/Bore Diameter: Ø 90 / Ø 53 mm Spindle Nose: F-140 Spindle Speed: 6,000 rpm C-Axis Resolution: 0.001° Travel and Rapid Traverse Travels X-Axis: 267 mm, Z-Axis: 840 mm Y-Axis: -50 to +70 mm, A-Axis: 780 mm Rapid Traverse X-Axis: 30 m/min, Z-Axis: 30 m/min Y-Axis: 10 m/min, A-Axis: 30 m/min Power Spindle Motor (30 min. / 100% duty cycle): AC 22 / 15 kW Credewp Uhhepfx Af Hjk Max. Torque: 618 Nm (S3 25%) Driven Tools Number of Turret Stations: 15 Max. Tool Speed: 6,000 rpm Drive Power (30 min. / 100% duty cycle): 7.5 / 3.7 kW Max. Torque: 48 Nm Tooling Live Tool Stations: 15 Tool Cross Section: 25 x 25 mm For Boring Operations: Ø 40 mm LNS Short Bar Loader Servo III Dimensions Height: 2,300 mm Depth (without chip conveyor): 2,140 mm Width (without chip conveyor): 3,000 mm Net Weight: 6,200 kg

Condition: good (used), Year of construction: 2011, CNC Milling and Turning Center Machine Type: DMG CTX beta 1250 TC Control: Siemens 840 D solutionsline + ShopTurn Year of Manufacture: 2011 Available from: February 2026 TECHNICAL SPECIFICATIONS: Maximum turning length: 1,250 mm Turning diameter: 390 mm Bar capacity: 75 mm Main Spindle Speed range: 0 - 5,000 rpm Drive power: 34 / 25 kW C-axis: 0.001° 3-jaw chuck: Röhm KFD-HS 250-91 mm Counter spindle: ISM 52 Speed range: 6,000 rpm Drive power: 27 / 20 kW C-axis: 0.001° 3-jaw chuck: Röhm KFD-HS 200-66 mm CNC spindle swiveling for milling and turning operations B-axis: +/- 110° Speed range: 15 - 12,000 rpm Drive power: 22 kW Torque: 100 Nm Tool holder: HSK 63 Crsdpfxoxvaqrj Af Hek Tool stations: 24 Y-axis: 100 +/- mm Machine weight: 8,000 kg Footprint (LxWxH): 5.67 x 2.72 x 2.1 m Features: Chip conveyor High-pressure pumps: 8/20/80 Paper band filter Coolant tank: 980 l Oil mist extraction Tool breakage control: Renishaw

Year of construction: 2018, condition: ready for operation (used), General Data Measurements width 2070 mm Measurements depth 5400 mm Measurements height 2600 mm Machine weight 7800 kg Cjdpfxew Ul D Nj Af Hork Control Unit Brand SIEMENS Model CELOS with Siemens 840D sl Operate Main Drive Spindle speed range up to 4000 rpm Spindle motor power 22 kW Number of axis 3 Additional Equipment Counter spindle turnMASTER 6 inch, ISM 36, Y-axis / C-axis and spindle brake (hydr.) / Reinforced coolant pump (5 - 20 bar) / Hinged belt chip conveyor / Tool measuring device in the work area (automatic, Ø 315 mm) / 12-station star turret, VDI 40 with quick-change system (TRIFIX) / Tool revolver completely replaced in December 2024 / Machine comes without chuck Turret: Number of tool stations: 12 / Number of driven tool stations: 12 / Max. speed: up to 6000 rpm /Max. power (100% ED): 10 kW Shank diameter according to DIN 69880: 40 mm Off-center turning and milling / Milling of gearing using the hobbing process / Alternating speed technology cycle / Polygon turning (machining of elliptical and polygonal shapes) / Program status control / Gear skiving (technology cycle for gears) / Multi-thread cycle 2.0 (position-oriented threads) / Easy Tool Monitor 2.0 (tool monitoring system) / Energy meter for Siemens 840D sl OP CELOS / Hydraulic hollow clamping device Ø77 mm This 3-axis DMG MORI CTX 2500/1250 Horizontal turning machine was manufactured in 2018. Ideal for complex machining tasks, it combines turning and milling capabilities in one machine. Consider the opportunity to buy this DMG MORI CTX 2500/1250 Horizontal turning machine. Contact us for more information. Application Types Turning

Condition: excellent (used), Various used, very well-preserved high-performance tool holders SANDVIK COROMANT CAPTO C3, turning tools, turning tool holders VDI 30, extensions C3, blind plugs VDI 30, various HM indexable inserts, spare parts, as per attached picture Make: SANDVIK COROMANT Credpsvu Rvgofx Af Hjk Model: CAPTO C3 New price: approx. EUR 20,000.00 net Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel
