Turn-mill center

MAZAK INTEGREX 100-IV ST

Condition: ready for operation (used), Year of construction: 2011, controller manufacturer: MAZATROL, controller model: Matrix, This 5-axis Mazak Integrex 100 IV ST was manufactured in 2011. It features a main spindle with a 6" hydraulic chuck, 4,000 rpm max speed, and 30 kW power. The second spindle matches these capabilities. Its milling spindle can reach up to 20,000 rpm. Includes a high-speed ATC with a 20-tool capacity, expandable to 120. Ideal for single-setup machining with its heavy-duty construction and MAZATROL MATRIX CNC control. Contact us for more information about this machine. Machine Benefits Qualitative Machine Benefits • There are 2 units available Technical Machine Benefits Dodpjyalpisfx Afpscf • Chuck type: 6" hydraulic chuck with bar capacity max /spindle speed: 4000 rpm max /power: 30 kw / 22 kw continuous/ max torque: 500 nm /spindle nose: a2-8/ acceleration time: 5. 1 seconds • Type: 6" hydraulic chuck max speed: 4000 rpm max power: 26 kw / 22 kw continuous /max torque: 724 nm /spindle nose: a2-8 /acceleration time: 2. 7 seconds • Max speed: up to 20000 rpm (optional) /max power: 18. 5 kw/ max torque: 119 nm/ taper type: km63, capto c6, bt40 • X-axis: 410 mm/ y-axis: ±70 mm (total 140 mm) /z-axis: 805 mm/ b-axis (milling head): 210° rotation/ c-axis (spindle): 0. 0001° resolution (full contouring) • Max turning diameter: approx. ø545 mm/ max turning length: approx. 600 mm • Tool capacity: 20 tools standard, expandable to 120 /changer type: high-speed cam-driven system • Heavy-duty construction with linear guides “done in one” multi-tasking concept for single-setup machining/ cnc control: mazatrol matrix with 3d simulation/ intelligent thermal shield for automatic thermal compensation

Year of construction: 2001, condition: excellent (used), Multispindle lathe Schütte AG20 Djdpfx Aohrihyefpecf

Condition: excellent (used), Year of construction: 2010, 412mm max. machining diameter, maximun turning length 753mm, 225 degree movement on B axis, 15HP spindle motor power, 6,000rpm spindle speed, 6,000 rpm sub spindle speed, 52mm bar capacity, milling speed 12,000rpm C axis & Milling, Dcedpswxw A Hefx Afpjf 9 station lower turret. Swarf conveyor, tool setter, Coolant, Interlocked guards, Swivelling Universal Head., C Axis (0.001deg), Mazatrol Matrix control

Condition: good (used), Year of construction: 1997, Also available CONQUEST T51 model Djdpsvtrc Sofx Afpocf The used HARDINGE CONQUEST T42L 3-axis motorized CNC lathe is a robust and precise medium-sized inclined bed numerical control lathe, turning length approximately 700mm, bar passage 42m, automatic turret with 12 positions with motorized tools, FANUC 18-T CNC with color LCD and RS232 serial interface for data transfer 5″ ASA spindle maximum revolutions: 4,200 rpm continuous C-axis 20HP spindle power X-axis travel: 172mm Z-axis travel: 575mm machine weight 4,000 Kg. Complete with 210mm AUTOBLOCK hydraulic chuck, tool presetting, programmable tailstock, 2 motorized tool holders (1 axial and 1 radial), chip evacuator, set of fixed and manual tool holders and backup disk; Year of construction 1997; machine compliant with “CE” standards, in excellent condition.

Condition: ready for operation (used), Year of construction: 1991, machine/vehicle number: MS 25E19111, Number of spindles: 6 Dedsv Raatopfx Afpscf Spindle bore: 27 mm Turning length: 59 mm Hexagonal material: 24 mm Square material: 18 mm Cross slide travel: 36 mm Longitudinal slide travel: 85 mm Spindle speeds: 366 - 5020 rpm Torque: 95 Nm Control: INDEX Total power requirement: 20 kW - 6 cross slides - 6 longitudinal slides - Multi-edge device - Thread cutting device - Hydraulic pick-up device - Workpiece conveyor belt - Bar loading magazine, IEMCA, type PRA 40/35/P

Condition: used, Cnc multispindle lathe TORNOS MULTIDECO 26/6 Dcjdpfsuhaqhex Afpsf

Condition: used, TECHNICAL DETAILS - Spindle number : 6 - Max. bar diameter : 20 [mm], 25 [mm] in option - Cross slides number : 4 - Max. supply length : 100 [mm] - Spindle rotation speed : 420 - 5000 [Rpm] - Indexing time : 0,7 [s] - Machining time : 1,4 - 60 [s] - Power : 11 [kW] - Dimensions : 5800 x 1500 [mm] - Weight : 6000 [kg] EQUIPMENT - 4 cross slides posts 1 2 4 5 - 1 chip conveyor - 5 drillers Dcjdsuharrspfx Afpjf - 1 IEMCA PRA41/31/P feeder DBMS-36 (1995)

Condition: used, TECHNICAL DETAILS - Number of spindles : 6 - Max. machining length : 60 [mm] - Number of cross slides : 6 - Max. production : 75 [parts/min] - Number of independent feeds available : 4 - Normal travel of independent feeds : 45 [mm] - Hirth teeth SPINDLES - Max. bar diameter : 16 [mm] - Spindle speeds : 800 - 8000 [rpm] - Spindle power : 7.5 [kW] - Number of spindle speeds : 16 POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 15 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 5049 x 1100 [mm] - Machine height : 1615 [mm] - Machine weight : 2700 [kg] Dcjdjuharljpfx Afpef EQUIPMENT - CNC : Fanuc - Parts catcher - Coolant tank - Electric transformer Spindle stop

Condition: repair required (used), Location: 49838 Langen Dedpfxsuqy Tps Afpocf

Condition: used, Year of construction: 2008, machine/vehicle number: 654/08, functionality: fully functional, Used automatic edge bander with pre-milling unit. Robust machine designed especially for solid wood edges and lippings. - Control via LCD touch panel - Heavy-duty chain feed conveyor - Automatic thin edge feeding from magazine - Solid edge magazine - Pre-milling of panels using 2 cutter heads (with insert knives) - Glue preheating in a separate tank Dcjdsu T Nhmspfx Afpef - Reinforced pressure zone with 5 pressure rollers - End trimming with 2 saw blades - Top and bottom trimming Technical data: - Min./Max. edge height: 14 / 104 mm - Min. edge thickness: 0.4 mm - Min./Max. panel thickness: 10 / 100 mm - Feed speed: 12 m/min - Min. working length/width: 200 / 85 mm - Milling tool speed: 12,000 rpm - Dimensions: 5250 x 1100 x 1650 mm - Weight: 2000 kg The machine has been used and tested. It is operational but requires maintenance, cleaning, adjustment, and sharpening of the tools. Sold in its current condition.
