CNC Turning- and Milling Center

Mazak Integrex e-500H II (1500)

Condition: good (used), Year of construction: 2020, 5-Axis CNC Machining Center - Universal - Manufacturer: MAZAK Machine Model: Variaxis J-500 Control Unit: Mazatrol SmoothG Year of Manufacture: 2020 Number of Controlled Axes: 5 Hsdpfxjyabu Io Afcji TECHNICAL DATA Travel - X-Axis (mm): 350 - Y-Axis (mm): 550 - Z-Axis (mm): 510 - Swivel Range A-Axis (degrees): -120 / +30 - C-Axis (rotary axis, rotary and tilt table): (degrees): 360 Feed Rate X/Y/Z (mm/min): 8,000 Rapid Traverse - X-Axis (mm/min): 30,000 - A-/C-Axis: 10,800 degrees/min. Spindle - Max. Spindle Speed (rpm): 12,000 - Drive Power (ED) 100 / 40 (kW): 7.5 / 11.0 Tool Magazine - Tool Holder: BT40/CAT40 - Pull Stud: Yamazaki ANSI Type - Number of Tool Positions: 30 - Tool Diameter (mm): 90 - Tool Length (mm): 300 Machine Table: Swivel rotary table Pallet System - Pallet Changer: 2-position - Clamping Table Dimensions (mm): 500 x 400 Swivel Rotary Table - Rotary Table Diameter (mm): 500 x 400 - Max. Workpiece Weight (kg): 200 FEATURES + Through-spindle coolant 70 bar + Hinged belt chip conveyor + Oil mist extractor + Tool length measurement and breakage control + Additional interior lighting + Signal tower (3-color) Subject to change and errors in technical details and specifications.

Condition: good (used), Year of construction: 2014, Table size 3500 x 820 mm, Traverses XYZ 3000 x 820 x 720 mm, Table load 2500 kgs, Spindle taper Din 40, Hjdjw Nwt Eopfx Afcoi Spindle speed 12000 rpm, spindle power 22Kw, 30 ATC, Mazatrol Matrix Nexus control, through spindle coolant, swarf conveyor

Condition: excellent (used), Year of construction: 2005, functionality: fully functional, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,100 mm, Rotary table 1,250 x 1,400 mm (interference circle 1,700 mm) Heidenhain 530 Diagonal milling head with 1° x 1° indexing Speed up to 5,000 rpm Tool holder SK50 Tool changer with 40 positions Internal coolant supply with 19 bar Chip conveyor in longitudinal direction Hsdex Iuccjpfx Afcei

Condition: used, Technical details: operating hours: 2151 h milling spindle operating time: 2 h turning spindle switch on : 709 h swing diameter: 1000 mm turning diameter: 900 mm workpiece height max.: 800 mm control: Mazatrol Smoothg x-axis: 470 mm z-axis: 876 mm Hedpfsydvfcjx Afcoi c-axis: 20 m/min tool holder / places: 12 revolution per minute: Revolver 4000 U/min workpiece weight: 3000 kg rapid power traverse in X-and Z direction: 24 m/min weight of the machine ca.: 14 t dimension machine xH: 3989 x 2375 x 3400 mm

Condition: used, Year of construction: 2016, The Mazak VTC 800 series is a line of powerful, large-format 5-axis turning centers for large workpieces, known for their high precision and rigidity, ideal for aerospace, energy and heavy machinery, with functions such as integrated spindles, fast tool change, and for efficient complete processing. Accessories/Options: Tool magazine for 30 tools Tool length measurement, tool breakage detection Factory-installed preparation for chip conveyor (left) Magazine (HSK) for 155 tools Air blower at the workpiece Signal light (end of machining: yellow) Additional: Work area lighting Coolant gun Air blower through the spindle 70 bar preparation, including interface for high-pressure system Automatic opening/closing of the operator door Mazak Monitoring System B RMP 60 (only/H/V) Collision monitoring by Brankamp 2 Renishaw TS27R tool presetting devices NC rotary table Holding device for vertical use of the NC rotary table Table center partition for pendulum machining 3D model of the work area in STEP format 5-axis milling technology Knoll compact filter KF400/2300 (filtration capacity 400 l/min, tank volume 2300 l/min) 1) High-pressure cooling 70 bar, 7 pressure stages Chip conveyor, hinged belt design Additional M-codes: 1 set = 2 M-codes Preparation for dual extraction system (mechanical nozzle) 0.198 mm Transformer for the European market 1 set of manuals in electronic form on CD Hodpfxsx Idwis Afcji 1 set of adjustment tools Foundation set (anchor bolts + plates) MAZAK standard paint Work area lighting Additional items: AirFresh FMN V12 extraction system (installed on both sides and coupled with a door sensor) Holding device for vertical operation of the rotary table 2 x Renishaw TS27R integrated tool presetting devices Spare parts: Y-axis motor, tool magazine Linear axis shifter motor Rotary axis shifter motor Cylinder for swivel unit width: 3500 mm length: 820 mm X-axis travel range: 3000 mm Y-axis travel range: 800 mm Traversal range Z-axis: 720 mm min. distance spindle nose to table top: 140 mm max. distance from spindle nose to table top: 860 mm max. table load: 2500 kgf B-axis: ± 110 degrees Working spindle taper: HSK63 Max speed: 18,000 RPM Min. Drehzahl: 35 min-1 Rated power: ( 100 % continuous operation) 33,0 kW Emergency travel speed X-Y & Z axis: 50 m/min Working table width: 3500 mm Worktable length: 820 mm Width of T-slots: 18 mm Number of T-slots: 7 Distance of T-slots: 100 mm Table height from the floor: 870 mm Tool changer number of tool places (Standard): 30 Number of tool stations (optional): 48 Tool selection method: shortest path tool shank: Steep cone 40 With occupied side positions: 80 mm With available spaces: 130 mm max. tool weight: 8kgf Total weight of all magazine tools: 150 kgf max. tool length: 350 mm Tool change time: (Span-to-Span) 4.7 s Connected load: 400 V / 50/60 Hz Air pressure: 5 – 9 bar Air volume: 260 l/min Tank capacity: 500 l Dimensions (Height x Length x Width): 3376 x 5480 x 4051 mm Weight approx: 16300 kg colour: Gray / Black

Condition: ready for operation (used), Year of construction: 2009, functionality: fully functional, CNC Turning and Milling Center - DMG GILDEMEISTER - CTX gamma 1250 TC YOM: 2009, until 2011 showroom machine, from 2012 operating The machine can be inspected by appointment in the factory under power. Condition: Good (high accuracy), ready for immediate use. Spindle hours (August 1st, 2025): 9.580 h The heart of the machine is the integrated traveling column with turning milling spindle and interpolating B-axis. Machine basic data: * Part hollow clamping device (hydraulic) * C-axis * Cross slide above with turning/milling spindle as motor spindle, with hydraulic clamping in turning, tool holder: Capto C6 * Y-axis: +/- 200 mm * B-axis: +/- 120° * Disc-type tool magazine * Absolute, direct measuring systems in X-, Y-, Z1-axis * USB-interface, Ethernet interface TECHNICAL SPECIFICATIONS: * Control: Heidenhain CNC Pilot 4290, 3-D path control TURN PLUS Working area: * Swing diameter over bed: 630 mm * Turning diameter: 630 mm * Spindle distance: 1.510 mm * Bar diameter max.: 65 mm Main drive I: * Drive power (100% / 40% ED): 24 / 34 kW * Speed range from - up to: - 5.000 rpm * Speed of the C-axis: - 5.000 rpm Turning/milling spindle: * Tool holder: Capto C6 * Spindle speed: - 12.000 rpm * Drive power (100% / 40% ED): 13.2 / 22 kW * Torque (100% / 40% ED): 60 / 100 Nm Tool magazine: * Number of tools: 36 * Dimensions of the machine approx. (Width/Depth/Height): 6.860 x 4.220 x 2.530 mm Hodew Hg Nlepfx Afcei * Total weight of the machine approx.: 18,5 tons EQUIPMENT: * Well equipped … * No steady rest available * Documentation complete available. Detailed technical data sheet and information on equipment available on request. There is no guarantee for correctness and completeness of the technical details and and accessories.

Condition: used, Year of construction: 2014, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,500 mm, spindle speed (max.): 6,000 rpm, spindle speed (min.): 20 rpm, RepairFIT by Dornhöfer The Difference. Installation & Commissioning Included! TECHNICAL MAIN DATA Year of manufacture: 2014 Travel/Capacity: Longitudinal (X): mm 3,000 Transverse (Y): mm 1,200 Vertical (Z): mm 1,500 Clamping table/Clamping surface: Length: mm 3,200 Width: mm 1,000 Number of T-slots on table surface: pcs. 7 T-slot size: mm 22H12 Reference slot: mm 22H7 Distance between slots: mm 140 Hedpfx Ajygipaefcei Maximum transport load: kg 11,000 Paint: graphite grey RAL 7024 and agate grey RAL 7038 Tool holder: ISO 50, DIN 69871 AD Pull stud: DIN 69872 Form A Main drive: Maximum drive power, from 198 rpm: kW 30 Spindle speed range: Spindle speed: rpm 20-6,000 Maximum torque: Nm 935 Speed control: 3-stage (oil-cooled) with automatic changeover Feed rates: X, Y and Z axes mm/min: 2 – 15,000 Maximum rapid traverse speed: X, Y and Z axes mm/min: 25,000 Maximum feed force: X, Y and Z axes: N 22,000 Space requirements: Length approx. BT3200: mm 8,100 (without cross conveyor +1,280 mm) Height approx. (at Z = 1,500 mm): mm 3,800 Width approx. (at Y = 1,200 mm): mm 5,000 (with spacer 4,500 mm) Weight: approx. kg 20,200 Connected load: approx. KVA 52 HEIDENHAIN iTNC 530 HSCI Automatic MTE universal milling head Diagonal 2.5° x 2.5° Automatic tool changer with 40 positions 2 chip conveyors + cross conveyor Coolant system with 20 bar & through-spindle coolant RepairFIT is our proven offer for a profitable entry into our product lines. The machines available in this line are sourced through a strict selection process and undergo thorough inspection (Deep-Dive Check). After intensive cleaning, any identified obvious defects and faults are professionally repaired by our qualified service team.

Condition: ready for operation (used), Year of construction: 2012, controller manufacturer: SIEMENS, controller model: 840 D, number of axes: 4, This 4-axis Mazak VTC 800/30SR was manufactured in 2012. It features a high-pressure coolant system at 15 bar, a 48-tool magazine, and dual auto tool length measurement units. Equipped with Siemens software, a Visiport, and an RMP60 probe, it's ideal for precise vertical machining tasks. If you are looking to get high-quality milling capabilities, consider the Mazak VTC 800/30SR machine we have for sale. Contact us for more information. • High-pressure coolant (15 bar) • Auto tool length measurement x 2 units • Visiport • 19" screen • Siemens software P • Signal tower Hedpfx Aox D I A Sjfcei • Additional work light • RMP60 probe • Bracket for NCRT for vertical use • Table centre partition • 48-tool magazine Additional equipment • Consep 2000 (chip conveyor/coolant system) for 15 bar, left-hand discharge

Condition: excellent (used), Year of construction: 2015, Maximum turning diameter: approx. 380 mm Maximum swing over bed: approx. 675 mm Maximum turning length: approx. 500–540 mm Hodpfjyg It Dox Afcei Bar capacity (main spindle): approx. 76 mm (3″) MAIN SPINDLE Maximum spindle speed: 4,000 rpm Spindle motor power: 26 kW Spindle bore: approx. 77–88 mm Chuck: 8″ power chuck SUB SPINDLE Maximum spindle speed: 6,000 rpm Spindle motor power: approx. 11 kW Chuck: 6″ or 8″ power chuck Part transfer function AXES X-axis travel: approx. 230 mm Z-axis travel: approx. 575 mm C-axis on main spindle (full contouring and interpolation) TURRET / TOOLING Number of tool stations: 12 positions Live tooling capability (drilling and milling) Tool measurement system (Tool Eye) CNC control: Mazatrol Matrix Nexus EIA/ISO programming Conversational Mazatrol programming 19″ color LCD screen (touch screen) COOLING & CHIP HANDLING High pressure coolant through spindle: 15 bar External flood coolant via spindle nozzles Hinged belt chip conveyor with side discharge Complete coolant system with pumps and filters AUTOMATION Automatic bar feeder included Automatic chuck open/close Chuck status feedback via sensors Automatic part transfer between spindles OTHER FEATURES Pitch error compensation (X, Z) 3D tool compensation Helical interpolation Polar coordinate programming Thread cutting (G33) Workpiece coordinate rotation User macro functions Tool breakage detection MACHINE DIMENSIONS & WEIGHT (approx.) Machine weight: 5,000 – 5,500 kg Machine footprint: approx. 2,600 × 2,000 × 1,900 mm

Condition: excellent (used), Year of construction: 2022, Turning diameter 376mm, turning length 760mm, bar capacity 76mm, Y axis -/+ 52.5mm, C axis 0.001 degrees on both spindles, 12 station turret, 22KW Motor, Main spindle 4000rpm, sub-spindle 4500rpm, Hedpfsyll Txex Afcoi 3 jaw chucks, swarf conveyor, tool setter,
