CNC lathe

MAZAK QTN NEXUS 450IIM

Condition: good (used), Year of construction: 2014, Table size 3500 x 820 mm, Traverses XYZ 3000 x 820 x 720 mm, Table load 2500 kgs, Fjdpfx Agow Nwt Ej Tepd Spindle taper Din 40, Spindle speed 12000 rpm, spindle power 22Kw, 30 ATC, Mazatrol Matrix Nexus control, through spindle coolant, swarf conveyor

Condition: used, Technical details: operating hours: 2151 h milling spindle operating time: 2 h turning spindle switch on : 709 h swing diameter: 1000 mm turning diameter: 900 mm workpiece height max.: 800 mm control: Mazatrol Smoothg x-axis: 470 mm z-axis: 876 mm c-axis: 20 m/min tool holder / places: 12 revolution per minute: Revolver 4000 U/min workpiece weight: 3000 kg rapid power traverse in X-and Z direction: 24 m/min Fpedpfx Aeydvfcog Ted weight of the machine ca.: 14 t dimension machine xH: 3989 x 2375 x 3400 mm

Condition: used, Year of construction: 2016, The Mazak VTC 800 series is a line of powerful, large-format 5-axis turning centers for large workpieces, known for their high precision and rigidity, ideal for aerospace, energy and heavy machinery, with functions such as integrated spindles, fast tool change, and for efficient complete processing. Accessories/Options: Tool magazine for 30 tools Tool length measurement, tool breakage detection Factory-installed preparation for chip conveyor (left) Magazine (HSK) for 155 tools Air blower at the workpiece Signal light (end of machining: yellow) Additional: Work area lighting Coolant gun Air blower through the spindle 70 bar preparation, including interface for high-pressure system Automatic opening/closing of the operator door Mazak Monitoring System B RMP 60 (only/H/V) Collision monitoring by Brankamp 2 Renishaw TS27R tool presetting devices Fpsdpfxox Idwie Ag Ted NC rotary table Holding device for vertical use of the NC rotary table Table center partition for pendulum machining 3D model of the work area in STEP format 5-axis milling technology Knoll compact filter KF400/2300 (filtration capacity 400 l/min, tank volume 2300 l/min) 1) High-pressure cooling 70 bar, 7 pressure stages Chip conveyor, hinged belt design Additional M-codes: 1 set = 2 M-codes Preparation for dual extraction system (mechanical nozzle) 0.198 mm Transformer for the European market 1 set of manuals in electronic form on CD 1 set of adjustment tools Foundation set (anchor bolts + plates) MAZAK standard paint Work area lighting Additional items: AirFresh FMN V12 extraction system (installed on both sides and coupled with a door sensor) Holding device for vertical operation of the rotary table 2 x Renishaw TS27R integrated tool presetting devices Spare parts: Y-axis motor, tool magazine Linear axis shifter motor Rotary axis shifter motor Cylinder for swivel unit width: 3500 mm length: 820 mm X-axis travel range: 3000 mm Y-axis travel range: 800 mm Traversal range Z-axis: 720 mm min. distance spindle nose to table top: 140 mm max. distance from spindle nose to table top: 860 mm max. table load: 2500 kgf B-axis: ± 110 degrees Working spindle taper: HSK63 Max speed: 18,000 RPM Min. Drehzahl: 35 min-1 Rated power: ( 100 % continuous operation) 33,0 kW Emergency travel speed X-Y & Z axis: 50 m/min Working table width: 3500 mm Worktable length: 820 mm Width of T-slots: 18 mm Number of T-slots: 7 Distance of T-slots: 100 mm Table height from the floor: 870 mm Tool changer number of tool places (Standard): 30 Number of tool stations (optional): 48 Tool selection method: shortest path tool shank: Steep cone 40 With occupied side positions: 80 mm With available spaces: 130 mm max. tool weight: 8kgf Total weight of all magazine tools: 150 kgf max. tool length: 350 mm Tool change time: (Span-to-Span) 4.7 s Connected load: 400 V / 50/60 Hz Air pressure: 5 – 9 bar Air volume: 260 l/min Tank capacity: 500 l Dimensions (Height x Length x Width): 3376 x 5480 x 4051 mm Weight approx: 16300 kg colour: Gray / Black

Condition: ready for operation (used), Year of construction: 2012, controller manufacturer: SIEMENS, controller model: 840 D, number of axes: 4, This 4-axis Mazak VTC 800/30SR was manufactured in 2012. It features a high-pressure coolant system at 15 bar, a 48-tool magazine, and dual auto tool length measurement units. Equipped with Siemens software, a Visiport, and an RMP60 probe, it's ideal for precise vertical machining tasks. If you are looking to get high-quality milling capabilities, consider the Mazak VTC 800/30SR machine we have for sale. Contact us for more information. • High-pressure coolant (15 bar) • Auto tool length measurement x 2 units • Visiport • 19" screen • Siemens software P • Signal tower • Additional work light • RMP60 probe • Bracket for NCRT for vertical use • Table centre partition • 48-tool magazine Fjdjx D I A Sjpfx Ag Tspd Additional equipment • Consep 2000 (chip conveyor/coolant system) for 15 bar, left-hand discharge

Condition: excellent (used), Year of construction: 2022, Turning diameter 376mm, turning length 760mm, bar capacity 76mm, Y axis -/+ 52.5mm, C axis 0.001 degrees on both spindles, 12 station turret, 22KW Motor, Main spindle 4000rpm, sub-spindle 4500rpm, 3 jaw chucks, swarf conveyor, tool setter, Fpsdpfx Agoyll Txj Tsd

Condition: excellent (used), Year of construction: 2011, CNC lathe Mori Seiki SL403B/800, year of manufacture 2011, Japan 2 axes - X axis 345 mm - Z axis 995 mm max spindle speed 2000 rpm Fanuc mapps MSX 500-IV control 18" Kitagawa B-18 (450 mm) chuck turning diameter 620 mm Fsdpfsyffctex Ag Topd max turning length 958 mm 12-position turret tailstock chip conveyor Renishaw probing system.

Condition: excellent (used), Year of construction: 2015, Maximum turning diameter: approx. 380 mm Maximum swing over bed: approx. 675 mm Maximum turning length: approx. 500–540 mm Fpjdjyg It Depfx Ag Tsd Bar capacity (main spindle): approx. 76 mm (3″) MAIN SPINDLE Maximum spindle speed: 4,000 rpm Spindle motor power: 26 kW Spindle bore: approx. 77–88 mm Chuck: 8″ power chuck SUB SPINDLE Maximum spindle speed: 6,000 rpm Spindle motor power: approx. 11 kW Chuck: 6″ or 8″ power chuck Part transfer function AXES X-axis travel: approx. 230 mm Z-axis travel: approx. 575 mm C-axis on main spindle (full contouring and interpolation) TURRET / TOOLING Number of tool stations: 12 positions Live tooling capability (drilling and milling) Tool measurement system (Tool Eye) CNC control: Mazatrol Matrix Nexus EIA/ISO programming Conversational Mazatrol programming 19″ color LCD screen (touch screen) COOLING & CHIP HANDLING High pressure coolant through spindle: 15 bar External flood coolant via spindle nozzles Hinged belt chip conveyor with side discharge Complete coolant system with pumps and filters AUTOMATION Automatic bar feeder included Automatic chuck open/close Chuck status feedback via sensors Automatic part transfer between spindles OTHER FEATURES Pitch error compensation (X, Z) 3D tool compensation Helical interpolation Polar coordinate programming Thread cutting (G33) Workpiece coordinate rotation User macro functions Tool breakage detection MACHINE DIMENSIONS & WEIGHT (approx.) Machine weight: 5,000 – 5,500 kg Machine footprint: approx. 2,600 × 2,000 × 1,900 mm

Condition: ready for operation (used), Year of construction: 2023, number of axes: 9, This 9-axis NAKAMURA-TOME WY150 was manufactured in 2023, featuring a turn-mill centre with a comprehensive toolholder setup including 6 external, 4 internal, 3 radial rotating, and 12 axial rotating holders, plus a collet chuck and a 3-jaw chuck. Consider the opportunity to buy this NAKAMURA-TOME WY150 turn-mill centre. Contact us for more information. Fodpfxsyb Sako Ag Tjpd Additional equipment • 6 external toolholders • 4 internal toolholders • 3 radial rotating (driven) toolholders • 12 axial rotating (driven) toolholders • 1 collet chuck • 1 three-jaw chuck

Condition: used, Year of construction: 2005, operating hours: 60,683 h, functionality: fully functional, turning length: 1,524 mm, turning diameter: 820 mm, spindle speed (min.): 3,300 rpm, spindle bore: 104 mm, travel distance X-axis: 870 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 1,598 mm, rapid traverse X-axis: 40 m/min, rapid traverse Y-axis: 40 m/min, rapid traverse Z-axis: 40 m/min, Equipment: rotational speed infinitely variable, MAZAK CNC Turning Machine MODEL: INTEGREX e-500 HS /U1500 with Mazatrol 640M PRO Control for sale. The machine is in good condition and can be inspected under power on site. The machine maintenance can be documented. In 2025, the X and Y axes were replaced. The milling spindle and gearbox were replaced in 2024. Technical Data Fjdpex Syldjfx Ag Tspd - Max. swing diameter: 820 mm - Max. turning diameter: 820 mm - Max. turning length: 1524 mm Main spindle: - Speed range: 0-3300 rpm - Drive power: 30 kW / 22 kW - Max. torque: 588 Nm - Spindle nose: A2-11" - Spindle bore: 104 mm - Indexing: 0.0001 Sub spindle: - Speed: 0-3300 rpm - Drive power: 30 kW / 22 kW - Max. torque: 588 Nm - Spindle nose: A2-11" - Indexing: 0.0001 Milling spindle: - Drive power: 37 kW - Max. torque: 260 Nm - Speed range: 0-10,000 rpm - Tool holder: SK50 Tool magazine: - Number of tool pockets: 120 Travel: - X: 870 mm - Z: 1598 mm - Z2: 2458 mm - Y: 500 mm - B axis: -30 to 210°, 0.0001° Feed rate: - X/Y/Z: 40 mm/min Machine data: - Connected load: 104 kVA - Operating voltage: 400V / 50 Hz - Required footprint (L x W): 7 x 3.5 m Special accessories: - 120-position tool magazine - High-pressure coolant 70 bar - Renishaw - Laser measurement system for rotating tools - Interface set - Air/water through-spindle cooling - Overload monitoring system - Mayfran Consep 2000 chip conveyor - SMW quick-change chuck

Condition: used, Year of construction: 2020, Lathes Travel distance X: 293 mm Travel distance Y :130 mm Travel distance Z: 1350 mm turning length: 1285 mm Fsdpfx Ageyrfl Us Topd max. turning diameter: 850 mm max. circulation diameter: 420 mm spindle boring: 102 mm input Power: 26 kW max. turning moment: 1123 NM range of revolutions till: 2800 rpm Control: Fanuc I-series powered tools control Fanuc The machine offers a maximum turning length of 1,285 mm, a maximum turning diameter of 420 mm, and a maximum swing over bed of 850 mm. The main spindle provides a spindle bore of 102 mm and a speed range up to 2,800 rpm, delivering high torque and stable machining performance. Equipped with a 12-station turret, driven tools, and a FANUC i-Series control, the machine is well suited for complex turning and milling operations in modern production environments.
