CNC LATHE

Miyano BNE-51SY

Condition: used, TECHNICAL DETAILS - Number of spindles : 9 - Bar capacity : 26 [mm] MAIN SPINDLES 1 TO 6 - Nominal torque : 18.5 [Nm] - Max. spindle speed : 7000 [rpm] - Stroke X : 70 [mm] - Stroke Z : 125 [mm] MAIN SPINDLES 8 AND 9 - Nominal torque : 15 [Nm] - Max. spindle speed : 10000 [rpm] - Stroke X : 110 [mm] - Travel Z : 125 [mm] COUNTER SPINDLE 7 - Nominal torque : 15 [Nm] - Max. spindle speed : 10000 [rpm] - Stroke Z : 300 [mm] POWER SUPPLY - Supply voltage : 400 [V] - Installed power : 109 [A] DIMENSIONS - Floor dimensions : 9.100 x 1.805 [mm] - Machine height : 2,800 [mm] - Machine weight : 18.500 [kg] MACHINE HOURS - operating hours : 82000 [h] EQUIPMENT - CNC Siemens Sinumerik 840D - Chips conveyor - Bar loader : SIR 36/33 F - Coolant tank : KNOLL VRF 450/2600 * with high pressure pump * with paper filtration Pgedpfjuhaq Isx Ai Tou * capacity : 2600 [l]

Condition: used, Year of construction: 1998, number of spindles 6 spindle passage 27 mm turning length 59 mm Pgodpovh Naqofx Ai Tou hexagon material 24 mm square material 18 mm cross slide travel 36 mm longitudinal slide travel 85 mm spindle turning speed range 366 - 5020 U/min max. torque 95 Nm control INDEX total power requirement 20 kW - 6 cross slides - 6 longitudinal slides - polygon device - thread cutting device - hydr. tapping device - workpiece removal belt - bar loading magazine PIETRO CUCCHI, model AN-BN Accessories: various tool holders, various collets, chip conveyor, coolant

Condition: good (used), functionality: fully functional, 2 Index MS 25 E machines in very good condition and fully functional – also available individually – for sale. Inspection while the machines are powered on is possible. Podpfx Aozicxlei Tegu

Condition: used, TECHNICAL DETAILS - Number of axes : 18 - Number of spindles : 6 - Max. part length : 120 [mm] SPINDLES - Max. bar diameter : 8 - 25.4 [mm] - Spindle speeds : 6000 [rpm] - Spindle power : 18 [kW] NUMERICAL AXES - 1 cross slide, position 1: x=50 [mm], Z1=80 [mm] - 1 cross slide, position 2: x=50 [mm], Z1=80 [mm] - 1 cross slide, position 3: x=50 [mm], Z1=80 [mm] - 1 cross slide, position 4: x=50 [mm], Z1=80 [mm] - 1 cross slide, position 5: x=50 [mm], Z1=80 [mm] - 1 cutting carriage 6: x=65 [mm] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 71 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 3.500 x 1.600 [mm] - Machine height : 1.950 [mm] - Machine weight : 8500 [kg] MACHINE HOURS - Number of hours under power : 65000 [h] EQUIPMENT - CNC : Fanuc 16i-TB - Hirth teeth - Counter spindle with counter-operation device - Goltenbolt turning tool holders in all positions - 5 fixed drills - 1 cutting tool holder - Chips conveyor - Coolant tank * with high-pressure pump - Bar loader : ROBOBAR MSF-522/6 - Oil mist extractor Podpfx Aijzhphke Tsgu
