Monguzzi four-sided cutter

MONGUZZI

Condition: excellent (used), functionality: fully functional, Motor power 5.5 kW Cutting length 3000 mm Maximum height 60 mm Hydraulic knife movement Hodpfx Anezxp S Doysu Hydraulic clamping Photocell protection

Condition: used, Year of construction: 2006, - Veneer bundle length (fiber direction): 400 - 4000 mm - Veneer bundle widths (perpendicular to the fiber direction): 45 - 515 mm - Veneer bundle thickness: approx. 10 - 40 - Throughput speed: approx. 27 m/min. Double gluing machine for veneer Manufacturer: Monguzzi, Carugate Type: Gluemaster Year of manufacture: 2006 For reliable, uniform, and precise application of PVAc or UREA adhesive in a single pass on veneer bundles that are joined parallel on both sides. Fine adjustment of the adhesive quantity and the uniformly applied lateral and vertical pressure on the veneer bundle result in precise, spot-free, and perfectly glued veneers with minimal adhesive consumption. Technical data: Veneer bundle length (fiber direction): 400 - 4000 mm Veneer bundle widths (perpendicular to the fiber direction): 45 - 515 mm Veneer bundle thickness: approx. 10 - 40 Throughput speed: approx. 27 m/min. Special features: - The Gluemaster can be positioned directly next to a veneer gluing machine. - Quickly and easily accessible adhesive containers for fast and easy refilling or cleaning. - Tool-free removal of the adhesive containers and easy cleaning (no dead spots). - Continuous pressure rollers and large pressure plates for uniform pressure on the veneer bundle/edges during gluing. - Rigid 4-point upper roller guide with floating upper rollers to press the veneer bundle without damaging it. - Easily adjustable adhesive quantity. Hsdpfxozuzp To Anyju Adhesive pot cooling unit For a longer service life of the adhesive pot, especially recommended for the use of UREA adhesive. 1 motorized discharge roller conveyor To feed the glued veneer bundle out of the Gluemaster and transport it to the connected Fanningmaster. Length of the roller conveyor: 3600 mm Note: The technical data and descriptions are copies of the original order confirmation. The information is provided for informational purposes only and is not binding.

Condition: used, Year of construction: 2006, - Max. cutting length: 2600 mm - Cutting widths: 45 - 350 mm - Opening of the pressure bar: 100 mm - Width of the pressure bar: 350 mm - Parallel stop with digital display: 25 - 1000 mm - Cutting angle approx.: 45 Veneer shears Hjdpfxjzuzpms Anyeu Manufacturer: Monguzzi, Carugate Type: AFD-35/2600 Year of manufacture: 2006 For clean, perfectly parallel and right-angled joining of veneer bundles in a single operation. Thanks to its high productivity, gentle handling of the raw material (no manual turning) and its precisely parallel cut, this guillotine is the perfect machine for preparing veneer strips for splicing. Production Up to 3 bundles/min Technical data Max. cutting length: 2600 mm Cutting widths: 45 - 350 mm Opening of the pressure bar: 100 mm Width of the pressure bar: 350 mm Parallel stop with digital display: 25 - 1000 mm Cutting angle approx.: 45 Features - Solid, robust construction with generously sized pressure bar and cutting table to accommodate the high clamping and shearing forces - Unique system with a fixed, solid cutting table and a movable pressure bar - Laser lights for precise visual identification of the cutting lines - High-quality hydraulic system with a large oil tank - Electrically driven parallel stop with quick adjustment - Industrial computer based on Windows, widescreen monitor and keyboard - Various operating modes and storable program sequences - Extensive recording of production data - Central lubrication unit Movable laser lines For optimizing veneer yield. The manually operated laser line for the position of the front knife can be quickly adjusted. The veneer width is transmitted to the computer at the touch of a button. The cutting process then starts automatically. Note: The technical data and descriptions are a transcript of the order confirmation from that time. Data is for informational purposes only and is not binding.

Condition: good (used), Year of construction: 1985, functionality: fully functional, machine/vehicle number: 00359, cutting length (max.): 2,300 mm, cutting height (max.): 30 mm, Monguzzi 2300 TRC MP - Veneer scissors Defect - oil i leaking a little from the hydraulics. Fully functional. Hjdpfjumvvrox Anyeu

Condition: used, 3 m mechanical cutting machine Hjdpfx Ajzhnm Ssnyou

Condition: used, Year of construction: 2000, Used MONGUZZI model 3200 hydraulic veneer cutter Theoretical cutting width: 3200 mm 2 motors Hsdoy Th Rwjpfx Anyou Installed power: 10 HP Motorized rear guide with mechanical cutting width indicator REER safety barrier (new) for finger detection – safety level type 4 Machine length: 4400 mm Weight: 3800 kg Overhauled machine, in excellent condition Complies with CE standards Year of manufacture: 2000

Condition: excellent (used), functionality: fully functional, cutting length (max.): 2,600 mm, AUTOMATIC HYDRAULIC GUILLOTINE fo veneer model MONGUZZI TRA 2600 second hand machine volt. 380/50 working conditions : good technical details : max. useful cutting length mm. 2650 max. useful cutting heigth mm. 100 max. useful cutting width mm. 1000 min. useful cutting width mm. 40 hydraulic motor power Hp 5,5 net weigth kgs. 2600 CE mark : NO Hodjfftuwopfx Anyou
