CNC turn-mill center

MORI SEIKI MT 2000 SZ

Condition: good (used), Year of construction: 2001, turning length: 1,020 mm, turning diameter: 540 mm, spindle speed (max.): 4,500 rpm, travel distance X-axis: 565 mm, travel distance Y-axis: 160 mm, travel distance Z-axis: 1,077 mm, overall weight: 12,500 kg, 🛠️ Description For sale is a powerful CNC turning and milling center, MORI SEIKI MT 2000SZ, with a subspindle and Y-axis. ⚙️ Technical Data Control: MSX-501 Travel X / Y / Z: approx. 565 / 160 / 1,077 mm Max. turning diameter: approx. 540 mm Max. turning length: approx. 1,020 mm Main spindle: up to approx. 4,500 rpm Tool spindle: up to approx. 8,000 rpm Tool holder: Capto C6 Tool positions: depending on the configuration Axes: X, Y, Z + subspindle ⏱️ Operating Data Spindle: operating hours: approx. 33,600 h Machining time: approx. 14,200 h Subspindle: operating hours: approx. 18,100 h Machining time: approx. 11,500 h (further data see pictures) 📦 Equipment Subspindle (SZ version) Powered tools Y-axis Chip conveyor Coolant system Multitasking function (turning & milling) 📌 Condition The machine is in used, functional condition. Tool holders (turning tools and Capto) are included in the scope of delivery. Cutting inserts are not included. 🚛 Delivery & Conditions Sale is ex works / free loading Dismantling and loading can be arranged upon request Sale without warranty 📞 Contact Bjdpfxsy Sm U Ss Aldswn If you are interested or require further information, please do not hesitate to contact us.

Condition: ready for operation (used), Year of construction: 2006, spindle speed (max.): 5,000 rpm, travel distance X-axis: 580 mm, travel distance Y-axis: 80 mm, travel distance Z-axis: 935 mm, controller manufacturer: OKUMA, controller model: OSP-P200L, number of axes: 5, This 5-axis Okuma Multus B300-W was manufactured in 2006. It features a robust turn-mill center with a swing over bed of 630 mm and a maximum turning diameter of 450 mm. Equipped with a bar feeder, toolsetter, and a tool magazine holding 40 tools, it ensures efficient operation. The control system is an advanced Okuma OSP-P200L. If you are looking to get high-quality turning capabilities consider the Okuma Multus B300-W machine we have for sale. Contact us for more information. • ATC / tool magazine: 40 positions • Toolsetter Bwsdpfx Alex D Rvhoden • Maximum distance between chucks: 900 mm • Maximum turning diameter: 450 mm • Sub spindle: A2-6 nose; 38–5000 rpm • Indexing: C-axis 0.001°; B-axis 0.001° Additional equipment • Barfeeder IF • Approximately 60 HSK 63 tool holders • Half a pallet of soft and hardened chuck jaws • 3 spindle stops (various lengths) • Various collets

Condition: good (used), Year of construction: 2002, operating hours: 18,000 h, CNC MULTITASKING LATHE MORI SEI MOD. MT 2000 SZ Main Spindle Kw 22 6,000 RPM X/y/z/b Travels: 565 - +/- 80 - 1077 - +/- 120° Milling Head Capto C6 6,000 RPM Motorized Lower Turret 12 Stations Tool Magazine 40 Posts Bwjdpfx Alju Sg Auedjn Year 2002

Condition: like new (used), Year of construction: 2010, CNC controller: FANUC FS-31iA5 (MAPPS 4) Capacity X-axis travel mm: 685 Y-axis travel mm: 125 Z-axis travel mm: 1075 Turning length mm: 1045 Max. turning diameter mm: ø: 600 Bar work capacity mm: 65 Turn-mill spindle Full indexing specifications: YES B-axis degree: 120º FULL INDEXING SPECIFICATION Speed spindle rpm: 12000 Drive power kW: 18.5/11 Tool magazine Magazine places: 80 Tool holder: CAPTO C5 Tool length max. mm: 250 Tool diameter max. mm: 70/130 Tool weight max kg: 5 Lower turret Number of tool slots St .: 12 Drive power driven tools kW: 5.5/3.7 Main spindle Speed spindle rpm: 5000 Drive power spindle kW: 25/22 (100%/40%ED) Spindle bore mm: 73 Chuck type: HOLLOW CHUCK (8") Manufacturer: KITAGAWA Counter spindle Speed spindle rpm: 5000 Drive power spindle kW: 25/22 (100%/40%ED) Spindle bore mm: 73 Chuck type: HOLLOW CHUCK (8") Manufacturer: KITAGAWA Equipment Electronic Handwheel Chip conveyor Swivel head Signal lamp High pressure pump Mist collector Workarea light CE conformity Chuck foot switch (double) for main and counter spindle Coolant gun Toolholders are not included Bedpfx Alowwuaasdswn Precision NC rotary table, rapid traverse and feed rate 100 1/min incl. direct measuring system Oil skimmer Linear scales Gantry loader LG-10 AII RENISHAW MP700 Working time hours Under power: 76.510 Spindle 1: 11.521 Spindle 2: 9.271 Potencial nominal kVA: 102 Basic machine dimensions / weight Length mm: 8.000 Width mm: 4.000 Height mm: 3.000 Weight kg: 15.000

Condition: good (used), Year of construction: 2007, Brand: Mori Seiki Type: NT3200 Year of build: 2007 Serial number: NT320GA0030 Additional information: Run time: 7976H Maximum turning diameter (milling head): 600mm Maximum turning diameter (turret): 210mm Maximum turning length: 1045mm Spindel bore: 67mm Number of tool spaces: 40 Spindel: Kitagawa SS1666 Spindel speed: 5000 RPM Control system: Fanuc Series 31i Equipped with: tool presetter,Absolent AB oil mist filter, Enomoto chip conveyor, Ercoatius coolant filter, documentation Milling head Maximum speed: 12000 RPM Tool shaft size: C5 X-axis travel: 685mm Y-axis travel: ±125mm Z-axis travel: 1075mm B-axis travel: ±120° X/Z-axis rapid traverse: 50 m/min Y-axis rapid traverse: 30 m/min Turret Number of tool places: 12 Driven tool speed: 6000 RPM X-axis travel: 130mm Z-axis travel: 970mm X/Z-axis rapid traverse: 30 m/min Machine dimensions LxWxH: 5200x3100x3000mm Own weight: 14400 kg Including bar feder Brand: Iemca Type: VIP 80E II Year 2007 S/N: 020710QA07 Own weight: 605 KG Bar capacity: 6-80mm Bwedoxn Ddtspfx Aldjn

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, turning length: 900 mm, turning diameter over cross slide: 630 mm, turning diameter: 450 mm, spindle motor power: 22,000 W, spindle speed (min.): 38 rpm, spindle speed (max.): 3,800 rpm, spindle bore: 80 mm, travel distance X-axis: 580 mm, travel distance Y-axis: 160 mm, travel distance Z-axis: 945 mm, mount diameter: 130 mm, rapid traverse X-axis: 40,000 m/min, rapid traverse Y-axis: 26,000 m/min, rapid traverse Z-axis: 40,000 m/min, total height: 2,600 mm, total length: 3,750 mm, total width: 2,050 mm, spindle nose: JIS A2-6, travel distance W-axis: 1,000 mm, Equipment: documentation/manual, Turn-mill center OKUMA Multus B300-W TECHNICAL CHARACTERISTICS : CNC control : OSP-P200L Distance between centers : 900 [mm] Max. cutting diameter : 630 [mm] Height of centers over cariage: 630 [mm] Max. swing over bed: 630 [mm] Stroke X axis: 580 [mm] Stroke Y axis: -80 / +80 [mm] Stroke Z axis: 935 [mm] Stroke W axis: 1000 [mm] B axis indexing precision: 0.001 [°] Milling head max. speed: 10000 [rpm] Bwsdow Eip Sopfx Aldsn Milling head spindle attachment: HSK-A63 Max. milling spindle power :16 [kW] Tool magazine capacity: 60 Max. tool length :300 [mm] Max. tool diameter: 130 [mm] Max. weight of single tool: 8 [Kg] Rapid traverse rate X axis: 40000 [mm/min] Rapid traverse rate Z axis: 40000 [mm/min] Rapid traverse rate Y axis: 26000 [mm/min] Rapid traverse rate W axis: 20000 [mm/min] Spindle nose: JIS A2-6 Min. spindle speed :38 [rpm] Max. spindle speed: 5000 [rpm] Increment C-axis :0.001 [°] Spindle power: 22 [kW] Counter spindle nose: JIS A2-6 Min. counter spindle spindle speed: 38 [rpm] Max. counter spindle speed: 5000 [rpm] Counter spindle power :15 [kW] Total power required :39.3 [kVA] Rated current :56.7 [A] Supply voltage :400 [V] Machine dimensions: 4340 x 2050 x 2600 ADDITIONAL INFORMATION : x1 One-Touch IGF software option (CD-ROM also for PC programming) x1 remote electronic handwheel x1 2-colour status light x1 chip conveyor x1 coolant tank

Condition: good (used), Year of construction: 2004, functionality: limited functionality, travel distance X-axis: 560 mm, travel distance Y-axis: 610 mm, travel distance Z-axis: 625 mm, rapid traverse X-axis: 60 m/min, rapid traverse Y-axis: 60 m/min, rapid traverse Z-axis: 60 m/min, controller manufacturer: Okuma, controller model: OSP-E100M, workpiece length (max.): 600 mm, workpiece width (max.): 710 mm, workpiece weight (max.): 400 kg, total height: 2,760 mm, total length: 4,535 mm, total width: 2,415 mm, table width: 400 mm, table length: 400 mm, table load: 400 kg, overall weight: 10,000 kg, spindle speed (max.): 8,000 rpm, distance table center to spindle nose: 710 mm, spindle motor power: 15,000 W, spindle nose: BT40, number of spindles: 1, number of slots in tool magazine: 40, input voltage: 400 V, type of input current: three-phase, Equipment: chip conveyor, rotational speed infinitely variable, Okuma Space Center MA400HA Horizontal Machining Centre Machine Type: CNC Horizontal Machining Centre Year: 2004 Control: OSP-E100M Axes: 4 No. of Pallets: 2 Condition: Good - There is an issue with the pallet changer. Includes Cromar Swarf Conveyor Coolant Filtration System Bodpfxewcd Evj Aldjwn Technical Specifications Pallets: 2 Size of Pallets: 400 x 400mm X Axis Travel: 560mm Y Axis Travel: 610mm Z Axis Travel: 625mm B Axis Travel: 360 Deg Rapid Traverse: 60m/min Spindle Centre to Pallet Top: 50 - 660mm Spindle Nose to Pallet Centre: 85 - 710mm Max Pallet Load: 400kg Max Workpiece Dimensions: 600 x 710mm Tool Pockets: 40 Spindle Taper: BT40 Spindle Power: 15kW Spindle Speed: 8,000rpm Machine Dimensions: 4535 x 2415 x 2760mm Machine Weight: 10,000kg Notes: *Specifications are given in good faith but not guaranteed*

Condition: excellent (used), Year of construction: 2008, Nakamura Super Mill WY-250 CNC Lathe Capacity: Max. turning diameter: 215 mm Standard turning diameter: 150 mm Distance between centers: max. 870 mm / min. 250 mm Max. turning length: 580 mm Bar capacity left/right: L: 65 mm R: 51 mm Chuck size: left: 210 mm (8″) right: 165 mm (6″) Axis travel: Slide travel (X1 / X2): 160.5 mm / 160 mm Slide travel (Z1 / Z2): 580 / 580 mm Slide travel (Y1 / Y2): ±50 mm / -50 mm, +20 mm Slide travel (B2 axis): 620 mm Rapid traverse X1 / X2: 18 m/min Rapid traverse Z1 / Z2: 36 m/min Rapid traverse B2 axis: 36 m/min Rapid traverse Y1 / Y2: 10 m/min Bwedpfx Aoy Ipp Rjlden Main and sub spindle: Spindle speed: 4500 rpm / 5000 rpm Speed range: stepless / stepless Spindle nose: A2-6 / A2-5 Spindle bore: 80 mm / 63 mm Front bearing inner diameter: 110 mm / 90 mm Drawtube diameter: 66 mm / 52 mm C-axes: Minimum input unit: 0.001° Minimum command increment: 0.001° Max. indexing speed: 600 rpm Feed speed: 1–4800 mm/min C-axis lock: disc brake C-axis positioning time: 1.5 s Upper/lower turret: Turret type: 12-position drum turret Number of tool stations: 48 (2 x 24) Square tool size: 25 mm Round shank tool size: 32 mm Driven tools: Drive system: single drive Spindle speed: 6000 rpm / 3600 rpm Speed range: stepless Number of driven tool stations: 12 × 2 Collet size: ER32 Straight toolholder size: 2 mm – 20 mm Cross toolholder size: 2 mm – 20 mm Drive power and torque: Left spindle: 18.5 / 11 kW 225 / 185 Nm Right spindle: 15 / 11 kW 120 / 120 Nm Tool spindles: 7.5 / 3.7 kW 40 / 16 Nm General: Machine height: 2395 mm (without extraction) Footprint: 4436 mm × 2674 mm / 4905 mm × 3331 mm Machine weight: 14,000 kg Scope of supply as shown in photo gallery includes, among others: Nakamura lathe, toolholders (driven and non-driven), collets, complete operating documentation, portal loader and loading robot, Iemca Master 880 Verso bar feeder, peripheral devices (chip conveyor, transformer, oil mist separator, etc.) No guarantee is given for the correctness, completeness or currentness of the information provided.

Condition: good (used), Year of construction: 2008, functionality: fully functional, spindle speed (min.): 6,000 rpm, bar passage: 32 mm, overall weight: 3,800 kg, 32 mm-5 axis Swiss Cnc lathe with moving bushing - Iemca Boss 332E barfeed new in 2008 - Syntec Control Bwsdpetxq Emsfx Aldon
