Machining Center - Horizontal

MORI SEIKI NH 4000 DCG

Condition: ready for operation (used), Year of construction: 2015, CNC Control: F31iA X mm: 560 Y mm: 560 Z mm: 630 B mm: 360.000 Table load capacity kg: 400 Cutting feed rate mm/min X, Y, Z: 50,000 Maximum rapid traverse rate m/min X, Y, Z: 50 Spindle speed rpm: 14,000 Spindle power kW: 18.5 Hsdpfx Aozu Tryjb Tst Taper type: ISO-40 Torque Nm: 120 Tool changer type: Chain Number of positions in tool changer: 60 Maximum tool diameter: mm 70 Maximum tool diameter with adjacent positions empty: 140 Maximum tool length mm: 400 Maximum tool weight kg: 8 Coolant tank capacity l: 500 Through-spindle coolant: Yes

Condition: used, Year of construction: 1984, functionality: fully functional, travel distance X-axis: 1,800 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 2,000 mm, table load: 5,000 kg, spindle diameter: 110 mm, total height: 3,800 mm, total length: 5,000 mm, total width: 3,000 mm, table length: 1,520 mm, table width: 1,225 mm, feed length X-axis: 1,800 mm, feed length Y-axis: 1,500 mm, feed length Z-axis: 2,000 mm, Tool holder SK50, Heidenhain control, machine is ready for collection and immediately operational. Hjdpfsxga Tnox Ab Tet

Condition: ready for operation (used), Year of construction: 2010, travel distance X-axis: 560 mm, travel distance Y-axis: 560 mm, travel distance Z-axis: 630 mm, table load: 400 kg, spindle speed (max.): 14,000 rpm, number of slots in tool magazine: 60, number of axes: 4, This 4-axis MORI SEIKI NH 4000 DCG was manufactured in 2010. It features an X-axis travel of 560 mm, Y-axis travel of 560 mm, and Z-axis travel of 630 mm. The machine has a spindle speed of 14,000 rpm and a tool magazine capacity of 60 positions. If you are looking to get high-quality machining capabilities, consider the MORI SEIKI NH 4000 DCG horizontal machining centre we have for sale. Contact us for further details. Hsdpfx Asy Uw I Isb Tjt • B-axis: Continuous Additional equipment • Pallet cubes: 250 × 250 × 600 mm and 400 × 150 × 600 mm • Various tooling • D'Andrea boring head attachment • Full machine manuals • SEI filtration/extraction unit • KUBE mist collector system Technical Specification Taper Size BT 40

Condition: used, Year of construction: 2010, CNC M57-701 IV Specifications X-axis travel: 560 mm Y-axis travel: 560 mm Z-axis travel: 630 mm Continuous B axis Table load capacity: 400 kg Spindle speed: 14,000 rpm Tool holder: BT 40 Tool magazine: 60 positions Accessories Pallet cubes 250x250x600 Pallet cubes 400x150x600 Various tooling Attachment with D’Andrea facing head Machine supplied with manuals Hodpfjy Sh Aksx Ab Tot All technical data provided are indicative and subject to change without notice and should not be considered binding.

Condition: used, Year of construction: 2004, Technical details: x-travel: 1500 mm y-travel: 1000 mm z-travel: 1000 mm control for program: TNC 530 spindle hours: noch nicht bekannt h milling head speed: 1: 30 bis 930 und 2: 930 bis 4000 / steples U/min tool taper: horiz./vertical: SK 50 (DIN 69871/Din 69872 Form A) max. torque on the spindle: 1000 Nm spindle head swivable left - right: 90 ° feed: 1 - 6000 mm/min feed power: 30 kN kN rapid traverse: 15 m/min Number of tools: 1 St. table clamping surface LxW: 1600 x 800 mm table load: 40 kN kN voltage: 400 V / 50 HZ V total power requirement: 42 kW Weight approx.: 15,2 t compressed air: 6,3 bar dimension machine xH: 3,1 x 4,7 x 2,6 m dimensions: Kühlfilter: 1,9 x 1,6 x 1,4 mm space requirements approx. LxWxH: ca. 38,5 m² m² Applications: Milling, drilling; tapping, boring. with direct coded length measuring systems the guideways of the 3 axes are on flat guideways CTS and external cooling Milling head position controlled +/-90° milling spindle nominal drive power 22 kW with integrated hydraulic power unit up to 100bar operating pressure with coolant unit with filtration, with high pressure pump 60 bar (internal cooling), nominal delivery 20 l/min. and low pressure pump 4 bar (external cooling) as well as spray gun Hjdeu Nc Riopfx Ab Tst Hinged belt chip conveyor DGS, type SSF 600 P50 Accessories: Measuring probe SK40 Reference tool SK40 Milling head SEMPUCO *

Condition: ready for operation (used), Year of construction: 2009, operating hours: 17,691 h, functionality: fully functional, travel distance X-axis: 560 mm, travel distance Y-axis: 560 mm, travel distance Z-axis: 630 mm, workpiece diameter (max.): 630 mm, workpiece weight (max.): 400 kg, TECHNICAL DETAILS Travel Paths & Axes Travel path X-axis: 560 mm Travel path Y-axis: 560 mm Travel path Z-axis: 630 mm B-axis max. rotational speed: 44.4 rpm Rapid Traverse Rapid traverse X-axis: 50 m/min Rapid traverse Y-axis: 50 m/min Rapid traverse Z-axis: 50 m/min Workpiece Dimensions Max. workpiece height: 900 mm Max. workpiece diameter: 630 mm Max. workpiece weight: 400 kg Spindle & Tools Max. spindle speed: 14,000 rpm Distance spindle center to top of pallet: 80–640 mm Distance spindle nose to center of pallet: 100–730 mm Tool magazine: 60 positions Tool change time: 0.9 s Tool holder: BT 40 Pallets Pallet dimensions: 400 x 400 mm Number of pallets: 2 Pallet change time: 6 s Feed Feed rate X-axis: 50,000 mm/min Feed rate Y-axis: 50,000 mm/min Feed rate Z-axis: 50,000 mm/min Work Table Table width: 400 mm Table length: 400 mm Table load capacity: 400 kg MACHINE DETAILS Hjdsxvzt Ispfx Ab Tst Control model: MSX-701IV Power consumption: 32.8 kVA Dimensions & Weight Dimensions (L x W x H): 4,000 x 2,400 x 2,600 mm Total weight: 9,800 kg Operating Hours Power-on hours: 46,259 h Operating hours: 26,725 h Machining hours: 17,691 h

Condition: excellent (used), Year of construction: 2011, TECHNICAL DETAILS CNC control: MSX-501III X axis mm: 560 Y axis mm: 560 Z axis mm: 660 B axis deg.: 360.000 Hodpfxoxfka Ne Ab Tot Table load capacity kg: 400 Cutting feed rate mm/min X,Y,Z: 60,000 Max. rapid traverse m/min X,Y,Z: 50 Spindle speed rpm: 12,000 Spindle power kW: 15 Taper type: ISO-40 Torque Nm: 120 Tool changer type: Chain Tool changer positions: 60 Max. tool diameter mm: 70 Max. tool diameter with adjacent positions empty mm: 170 Max. tool length mm: 450 Max. tool weight kg: 8 Coolant tank capacity l: 500 Through-spindle coolant (high-pressure): Yes EQUIPMENT Double chip conveyor ISO-40 taper High-pressure through-spindle coolant with pump Tool breakage detection probe Part measuring probe RENISHAW MACHINE DIMENSIONS Length mm: 3,755 Width mm: 2,300 Height mm: 2,610 Weight kg: 7,600

Condition: good (used), Year of construction: 1983, Machine number: 316204/22 Type / Model: FSS 315/E Travel ranges x-y-z: 850 – 280 – 355 mm Table: 1,200 x 370 mm Clamping area: 1,060 x 260 mm Speed range: 28 to 1,400 rpm Spindle mount: SK 50 Quill stroke: 80 mm Feeds for x and y axes: 16 to 800 mm/min Feed for z axis: 5 to 250 mm/min Hedpfsfli Afjx Ab Tet Power: 8 kW Accessories/Equipment: Head swivels Condition: good Weight: 4 t Dimensions: 2,000 x 2,000 x 2,400 mm

Condition: ready for operation (used), Year of construction: 1988, functionality: fully functional, travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,600 mm, travel distance Z-axis: 1,250 mm, table load: 6,300 kg, spindle diameter: 120 mm, spindle speed (min.): 2,000 rpm, quill travel distance: 600 mm, quill stroke: 600 mm, quill diameter: 120 mm, Control: Wotan 1500 Dialog, SK50 DIN 69871, complete documentation available, table size 1600 x 1250, T-slot width 22 H7, Heidenhain linear scales/measurement systems, Siemens feed drive. Hsdpjyxwwwsfx Ab Tet

Condition: used, Year of construction: 2014, Technical details: Hedpfx Asxrwpdob Tjt x-travel: 760 mm y-travel: 760 mm z-travel: 760 mm total power requirement: 43 kW weight of the machine ca.: 11,5 t dimensions of the machine ca.: 2,7 x 4,73 x 2,87 m max. table loading capacity: 500 kg
