Bed type milling machine
MTE BT3200

Year of construction

2014

Condition

Used

Location

Siegen

Basic data

Machine type:: Bed type milling machine

Manufacturer:: MTE

Model:: BT3200

Year of construction:: 2014

Condition:: used

Price & Location

Location:: Eisenhüttenstr. 27a, 57074 Siegen, Deutschland

Call

Technical details

Spindles

Spindle speed (max.):

6,000 rpm

Spindle speed (min.):

20 rpm

Axis specifications

Travel distance X-axis:

3,000 mm

Travel distance Y-axis:

1,200 mm

Travel distance Z-axis:

1,500 mm

Details about the offer

Listing ID:: A211-42912

Update:: 02.02.2026

Description

RepairFIT by Dornhöfer
The Difference.

Installation & Commissioning Included!

TECHNICAL MAIN DATA
Year of manufacture: 2014
Travel/Capacity:
Longitudinal (X): mm 3,000
Transverse (Y): mm 1,200
Vertical (Z): mm 1,500
Clamping table/Clamping surface:
Itodpfeygipajx Ag Asn
Length: mm 3,200
Width: mm 1,000
Number of T-slots on table surface: pcs. 7
T-slot size: mm 22H12
Reference slot: mm 22H7
Distance between slots: mm 140
Maximum transport load: kg 11,000
Paint: graphite grey RAL 7024 and agate grey RAL 7038
Tool holder: ISO 50, DIN 69871 AD
Pull stud: DIN 69872 Form A

Main drive:
Maximum drive power, from 198 rpm: kW 30
Spindle speed range:
Spindle speed: rpm 20-6,000
Maximum torque: Nm 935
Speed control: 3-stage (oil-cooled) with automatic changeover

Feed rates:
X, Y and Z axes mm/min: 2 – 15,000
Maximum rapid traverse speed: X, Y and Z axes mm/min: 25,000
Maximum feed force: X, Y and Z axes: N 22,000

Space requirements:
Length approx. BT3200: mm 8,100 (without cross conveyor +1,280 mm)
Height approx. (at Z = 1,500 mm): mm 3,800
Width approx. (at Y = 1,200 mm): mm 5,000 (with spacer 4,500 mm)
Weight: approx. kg 20,200
Connected load: approx. KVA 52

HEIDENHAIN iTNC 530 HSCI
Automatic MTE universal milling head Diagonal 2.5° x 2.5°
Automatic tool changer with 40 positions
2 chip conveyors + cross conveyor
Coolant system with 20 bar & through-spindle coolant

RepairFIT is our proven offer for a profitable entry into our product lines.

The machines available in this line are sourced through a strict selection process and undergo thorough inspection (Deep-Dive Check). After intensive cleaning, any identified obvious defects and faults are professionally repaired by our qualified service team.

The listing was translated automatically. Translation errors are possible.
